Show Tec Powersplit 32 True 1 User manual

Powersplit 32 True1 V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Product code: 91136
MANUAL
ENGLISH

1
Product code: 91136
Powersplit 32 True1
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................3
Connection with the Three Phase Power Network ................................................................................................4
Return Procedure..........................................................................................................................................................4
Claims..............................................................................................................................................................................4
Description of the device.................................................................................................................................................5
Overview ........................................................................................................................................................................5
Side ..................................................................................................................................................................................6
Installation...........................................................................................................................................................................6
Setup and Operation ........................................................................................................................................................7
MCB Trip Curves ............................................................................................................................................................7
Maintenance......................................................................................................................................................................7
Troubleshooting .................................................................................................................................................................7
Product Specifications......................................................................................................................................................8
Notes ....................................................................................................................................................................................9

2
Product code: 91136
Powersplit 32 True1
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a device must be
returned to the factory, it is important that the device be returned in the original factory box and
packing.
Your shipment includes:
●Showtec Powersplit 32 True1
●User manual
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
●be qualified
●follow the instructions of this manual
Before the initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

3
Product code: 91136
Powersplit 32 True1
IMPORTANT!
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
●Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
●Never remove warning or informative labels from the device.
●Do not open the device and do not modify the device.
●Never use anything to cover the ground contact.
●Never leave any cables lying around.
●Never use the device during thunderstorms, unplug the device immediately.
●Do not connect this device to a dimmer pack.
●Do not switch the device on and off in short intervals, as this would reduce the device’s life.
●Do not shake the device. Avoid brute force when installing or operating the device.
●Only use device indoors, avoid contact with water or other liquids.
●Only operate the device after having checked if the housing is firmly closed and all screws are tightly
fastened.
●Only operate the device after having familiarized with its functions.
●Avoid flames and do not put close to flammable liquids or gases.
●Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord by the plug. Never pull out the plug by tugging the power cord.
●Make sure that the device is not exposed to extreme heat, moisture or dust.
●Make sure that the available voltage is not higher than stated on the rear panel.
●Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
●If the device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
●If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
●If your Showtec device fails to work properly, discontinue use immediately. Pack the device securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
●For adult use only. Device must be installed out of the reach of children. Never leave the device
running unattended.
●The user is responsible for correct positioning and operating of the Powersplit. The manufacturer will
not accept liability for damages caused by the misuse or incorrect installation of this device.
●This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
●Repairs, servicing and electric connection must be carried out by a qualified technician.
●WARRANTY: Till one year after date of purchase.
Operating Determinations
●This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
●The maximum ambient temperature ta= 60 °C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 60 °C.
●In order to eliminate wear and improve the device’s lifespan, during periods of non-use, completely
disconnect from power source via breaker or by unplugging.
●If this device is operated in any other way, than the one described in this manual, the product may
suffer damages and the warranty becomes void.
●Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!

4
Product code: 91136
Powersplit 32 True1
Connection with the Three Phase Power Network
Connect the device to the 3-phase Power Socket with a CEE-form power-plug.
Always make sure that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L1
BROWN
RED
BLACK
PHASE 1
L2
BLACK
YELLOW
RED
PHASE 2
L3
GREY
BLUE
BLUE
PHASE 3
N
BLUE
BLACK
WHITE
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious injuries to people and/or damage of property !
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the
device. Be prepared to provide the model number, serial number and a brief description of the cause for
the return. Be sure to properly pack device, any shipping damage resulting from inadequate packaging
is the customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a device is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

5
Product code: 91136
Powersplit 32 True1
Description of the device
Features
The Showtec Powersplit 32 True1 is a professional power splitter.
●MCB pins: 2
●MCB class: B
●MCB rated current: 16 A
●Rated current: 32 A
●Power connector IN/OUT: 5-pin 32 A CEE
●Power connector OUT: 6 x Pro power True1
●Housing: Metal
●IP rating: IP20
●Color: Gray
●Dimensions: 465 x 162 x 125 mm (LxWxH)
●Weight: 4,3 kg
Overview
Fig. 01
01) L1–3 power indicators
02) CH1–6 Main Circuit Breakers (MCB)
The circuit breakers will cut off the power supply if the load current per output exceeds 16 A.
03) L1–3 Pro power True1 OUT
6 x pro power True1 sockets. Maximum load is 1 x 16 A per output.

6
Product code: 91136
Powersplit 32 True1
Side
Fig. 02
04) 32 A CEE power IN
Connect to the three phase mains. Make sure that the total load connected to the Powersplit does
not exceed 32 A per phase. The CEE input should be connected to the power source which is
equipped with its own RCCB protection.
05) Ground/earth connection
06) Mounting hole (M10)
07) 32 A CEE power OUT
Connect to the three phase mains. Make sure that the total load connected to the Powersplit does
not exceed 32 A per phase. The CEE input should be connected to the power source which is
equipped with its own RCCB protection.
Installation
Remove all packing materials from the Powersplit 32 True1. Check if all foam and plastic padding is
removed. Connect all cables.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Fig. 03
The device can be placed on a flat and dry stage floor or be mounted to any kind of truss with a clamp.
The True1 output connectors are IP65 but the metal housing is only IP20. It means that the device is not
water-resistant.

7
Product code: 91136
Powersplit 32 True1
Setup and Operation
●Always check the mains voltage before connecting the device.
●Do not use the main MCBs to switch power. Toggle the devices only when the system is in idle state.
●Switch MCBs to ON position only when all the devices have been connected to the outputs.
Before switching the device on, make sure that the power source is equipped with
its own RCCB protection system.
MCB Trip Curves
This device is equipped with a B-class MCB. This type of MCB is suitable for cable protection.
The B-class MCB trips when the current that flows through it reaches 3–5 times the rated current value.
The Powersplit (with its MCB rated current of 16 A) can safely receive current of up to 80 A (as 5 x 16 A =
80 A).
Maintenance
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by an expert after every year in the course of an acceptance test.
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by a skilled person once a year.
We strongly advise you to let a qualified technician give the device a maintenance check twice a year.
The following points have to be considered during the inspection:
01) All screws used for installing the device or parts of the device have to be tightly connected and
must not be corroded.
02) There may not be any deformations on housings, fixations and installation spots.
03) The electric power supply cables must not show any damages or material fatigue.
The Powersplit 32 True1 requires almost no maintenance. However, you should keep the device clean.
01) Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in
liquid. Do not use alcohol or solvents.
02) Please clean internal components twice a year with a light brush and vacuum cleaner.
03) Keep connections clean. Disconnect electric power, and then wipe the connections with a damp
cloth. Make sure connections are thoroughly dry before linking equipment or supplying electric
power.
04) Check and tighten all screws, especially the screw terminals.
05) The electric power supply cables must not show any damages or material fatigue.
Troubleshooting
This troubleshooting guide is meant to help solve simple problems. If a problem occurs, carry out the steps
below in sequence until a solution is found. Once the device operates properly, do not carry out the
following steps.
01) If the device does not operate properly, unplug the device.
02) Check power from the wall and all cables.
03) Plug the device in again.
04) If nothing happens after 30 seconds, unplug the device.
05) Return the device to your Showtec dealer.

8
Product code: 91136
Powersplit 32 True1
Product Specifications
Model:
Showtec Powersplit 32 True1
Dimensions:
465 x 162 x 125 mm (LxWxH)
Weight:
4,3 kg
Operation
Input:
5-pin 32 A CEE
Output:
5-pin 32 A CEE, 6 x Pro power True1
MCB pins:
2
MCB class:
B
MCB rated current:
16 A
Rated current:
32 A
Electro-mechanical effects
IP rating:
IP20
Housing:
Metal
Color:
Gray
Max. ambient temperature ta:
From -20 °C to 60 °C
Minimum distance:
Minimum distance from flammable surfaces:
0,5 m
Design and product specifications are subject to change without prior notice.
Website: www.Showtec.info
Email: [e-mail]

9
Product code: 91136
Powersplit 32 True1
Notes

10
Product code: 91136
Powersplit 32 True1

©2021 Showtec
