Show Tec 42199 User manual

LED light bar 8 V2
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 42199
MANUAL
ENGLISH

1
Ordercode: 42199
LED Light Bar 8
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................4
Return Procedure..........................................................................................................................................................5
Claims..............................................................................................................................................................................5
Description of the device.................................................................................................................................................6
Optional accessories....................................................................................................................................................6
Overview ........................................................................................................................................................................7
Installation...........................................................................................................................................................................7
Set Up and Operation .......................................................................................................................................................7
Control Modes...............................................................................................................................................................7
One Light Bar (Manual control) .............................................................................................................................7
One Light Bar (Built-in programs,Macro colors) ..................................................................................................8
One Light Bar (Sound-control) ................................................................................................................................8
Multiple Light Bars (Master/Slave control).............................................................................................................8
Multiple Light Bars (DMX512 Mode) .......................................................................................................................9
Fixture Linking ...............................................................................................................................................................10
Data Cabling...............................................................................................................................................................10
Control Panel ...............................................................................................................................................................11
DMX Control Mode.....................................................................................................................................................11
DMX Addressing ..........................................................................................................................................................11
Menu overview ................................................................................................................................................................12
Main Menu Options ....................................................................................................................................................14
1. DMX Mode ...............................................................................................................................................................14
2. Master / slave addressing .....................................................................................................................................14
3. Sound control Mode ..............................................................................................................................................15
4. Static Color Mode ..................................................................................................................................................15
5. Built-in Programs......................................................................................................................................................15
6. Auto Run Program ..................................................................................................................................................18
DMX Channels .............................................................................................................................................................19
3 DMX Channels (d-P1)...........................................................................................................................................19
4 DMX Channels (d-P2)...........................................................................................................................................19
14 DMX Channels (d-P3).........................................................................................................................................19
26 DMX Channels (d-P4).........................................................................................................................................20
2 DMX Channels (d-P5)...........................................................................................................................................22
7 DMX Channels (d-P6)...........................................................................................................................................23
Maintenance....................................................................................................................................................................24
Replacing a Fuse ........................................................................................................................................................24
Troubleshooting ...............................................................................................................................................................25
No Light.........................................................................................................................................................................25
No Response to DMX..................................................................................................................................................25
Product Specifications....................................................................................................................................................27
Dimensions........................................................................................................................................................................28
Notes ..................................................................................................................................................................................29

2
Ordercode: 42199
LED Light Bar 8
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear to be damaged from shipping or the carton
itself shows signs of mishandling. Save the carton and all packing materials. In the event that the fixture
must be returned to the factory, it is important that the fixture be returned in the original factory box and
packing.
Your shipment includes:
Showtec LED Light Bar 8
•2 brackets and screws
•Volex IEC powercable 1,5m
•User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
●be qualified
●follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty. This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

3
Ordercode: 42199
LED Light Bar 8
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never place any material over the lens.
Never look directly into the light source.
Never leave any cables lying around.
Do not insert objects into air vents.
Do not connect this device to a dimmerpack.
Do not switch the device on and off in short intervals, as this would reduce the device’s lifespan.
Do not touch the device’s housing bare-handed during its operation. Allow the fixture to cool for at
least 5 minutes before handling.
Do not shake the device. Avoid brute force when installing or operating the device.
Only use device indoor, avoid contact with water or other liquids.
Only operate the fixture after having checked that the housing is firmly closed and all screws are
tightly fastened.
Only operate the device after having familiarized with its functions.
Avoid flames and do not put close to flammable liquids or gases.
Always keep case closed while operating.
Always allow free air space of at least 50 cm around the unit for ventilation.
Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord by the plug. Never pull out the plug by tugging the power cord.
Make sure that the device is not exposed to extreme heat, moisture or dust.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
If the lens is obviously damaged, it has to be replaced to prevent its functions from being impaired,
due to cracks or deep scratches.
If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
For adult use only. Device must be installed out of reach of children. Never leave the unit running
unattended.
Never attempt to bypass the thermostatic switch or fuses.
For replacement, use fuses of same type and rating only.
The user is responsible for correct positioning and operating of the Light Bar 8.
The manufacturer will not accept liability for damages caused by the misuse or incorrect installation
of this device.
This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
Repairs, servicing and electrical connection must be carried out by a qualified technician.
WARRANTY: Till one year after date of purchase.

4
Ordercode: 42199
LED Light Bar 8
Operating Determinations
●This device is not designed for permanent operation. Regular operation breaks will ensure that the
device will serve you for a long time without defects.
●The minimum distance between light-output and the illuminated surface must be bigger than 1
meter.
●The maximum ambient temperature ta = 40°C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
●If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
●Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself!
Always let the installation be carried out by an authorized dealer!
Procedure:
If the projector is lowered from the ceiling or high joists, professional trussing systems have to be
used.
Use a clamp to mount the projector, with the mounting-bracket, to the trussing system.
The projector must never be fixed swinging freely in the room.
The installation must always be secured with a safety attachment, e.g. an appropriate safety net
or safety-cable.
When rigging, derigging or servicing the projector, always make sure, that the area below the
installation place is blocked and staying in the area is forbidden.
The Light Bar 8 can be placed on a flat stage floor or mounted to any kind of truss by a clamp.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!

5
Ordercode: 42199
LED Light Bar 8
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause of the
return. Be sure to properly pack fixture as any shipping damage resulting from inadequate packaging is
the customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name.
02) Your address.
03) Your phone number.
04) A brief description of the symptoms.
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that the fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period, complaints will not be handled anymore.
Complaints will only be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

6
Ordercode: 42199
LED Light Bar 8
Description of the device
Features
The LED Light Bar 8 is a LED fixture from Showtec.
•LEDs: 240 RGB high intensity 10mm LEDs (Red 96, Green 72, Blue 72)
•Beam angle: 30 º
•Inexpensive batten effect
•8 sections
•Compact size
•Output: 800Lumen
•Lux @2m: 613,3
•Max. Distance: 15m
•Efficacy (lm/W) 36W
•Drive Current: 25mA
•Refresh rate: 400Hz
•Color Range: RGB
•Power Supply: 100-240V AC
•Control Mode: DMX512
•Dimmer: 0-100%
•Strobe: 0-20Hz
•Peak Power 130 Watt
•Continuous Power 60 Watt
•3 pin female XLR socket and 3 pin male XLR socket
•IEC Power In and IEC power Out (Max. 10A)
•Linkable via 3-pin XLR cable
•Built-in microphone
•Black aluminum material
•LED Digital display
•Fuse: 1A / 250V
•Built-in programs mode, Auto running mode, DMX mode, slave mode, sound-activated mode.
•DMX controlled
•Selectable 2, 3, 4, 7, 14 and 26 DMX channel operation
•Dimensions: 1070 x 65 x 88 mm (LXWXH)
•Weight: 1,74 kg
Note: Knowledge of DMX is required to fully utilize this unit.
Optional accessories
D7012 Flightcase for LED Light Bar 8
D7595 Flightcase for LED Light Bar 8
70109B Heavy Duty Pipe Clamp, SWL=35 kg
70359B 50 mm Quick coupler
70365B 50 mm Compact Half Coupler

7
Ordercode: 42199
LED Light Bar 8
Overview
Fig. 01
01) Adjustment screw + mounting bracket for Truss mounting
02) IEC Power In
03) Ground
04) Fuse 1A / 250V
05) Total LED Light Bar 240 LEDs
06) Menu Buttons + LED display
07) DMX signal connector (IN) 3-pin
08) DMX signal connector (OUT) 3-pin
09) IEC Power Out (Max. 10A)
Installation
Remove all packing materials from the LED Light Bar 8.
Check that all foam and plastic padding is removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.
Control Modes
There are 6 modes:
Manual control (Static)
Built-in Programs
Macro Colors (Auto Run)
Sound-controlled
Master/Slave
DMX512
One Light Bar (Manual control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) When the Light Bar is not connected by a DMX-cable, it functions as a stand-alone device.
03) If device is set to , then the fixture can be manually controlled.
04) Please see page 15 for more information about manual control Mode.

8
Ordercode: 42199
LED Light Bar 8
One Light Bar (Built-in programs,Macro colors)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) When the Light Bar is not connected by a DMX-cable, it functions as a stand-alone device.
03) If device is set to or , then the fixture will play one of its built-in programs or show
one of its macro colors. Please see pages 15-18 for more information about the built-in programs or
macro colors.
One Light Bar (Sound-control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) When the Light Bar is not connected by a DMX-cable, it functions as a stand-alone device.
03) Turn on the music. If device is set to (Audio) and you have pressed enter, then the fixture
will react to the beat of the music. Please see page 15 for more information about the Sound-
controlled mode.
Multiple Light Bars (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) Use a 3-p XLR cable to connect the Light Bar and other devices.
The pins:
1. Earth
2. Signal (-)
3. Signal (+)
04) Link the units as shown in (Fig. 02), connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, and third units. You can use the
same functions on the master device as described on page 14-17 (Built-in Programs). This means you
can set your desired operation mode on the master device and all slave devices will react the same
as the master device.
Multiple Light Bars (Master/Slave control)
Fig. 02

9
Ordercode: 42199
LED Light Bar 8
Multiple Light Bars (DMX512 Mode)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) Use a 3-p XLR cable to connect the Light Bar and other devices.
04) Link the units as shown in (Fig. 03), Connect a DMX signal cable from the first unit's DMX "out" socket
to the second unit's "in" socket. Repeat this process to link the second and third units.
05) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple Light Bars DMX Set Up
Fig. 03
Note: Link all cables before connecting electric power!

10
Ordercode: 42199
LED Light Bar 8
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows on two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
The LED Light Bar 8 uses up to 26 channels.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin. Ordercode
FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
•DAP Audio DMX adapter: 3-pin/5-pin. Ordercode FLA30.

11
Ordercode: 42199
LED Light Bar 8
Control Panel
A. LED Display
B. Mode button
C. Setup Button
D. Up Button
E. Down Button
Fig. 04
DMX Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address the next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign the DMX fixture address, which is the
first channel from which the Light Bar will respond to the controller. Please note when you use the
controller, the unit has up to 26 channels. When using multiple Light Bars, make sure you set the DMX
addresses right. Therefore, the DMX address of the first Light Bar should be 1(A001); the DMX address of
the second Light Bar should be 1+26=27(A027); the DMX address of the third Light Bar should be 27+26=53
(A053), etc. Please, be sure that you do not have any overlapping channels in order to control each
Light Bar correctly. If two or more Light Bars are addressed similarly, they will work similarly.
Controlling:
After having addressed all Light Bars, you may now start operating these via your lighting controller.
Note: After switching on, the Light bar will automatically detect whether DMX 512 data is received or not.
The problem may be:
•The XLR cable from the controller is not connected with the input of the Light Bar.
•The controller is switched off or defective, the cable or connector is defective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert a XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.

12
Ordercode: 42199
LED Light Bar 8
Menu overview

13
Ordercode: 42199
LED Light Bar 8

14
Ordercode: 42199
LED Light Bar 8
Main Menu Options
DMX address
Slave
Sound controlled
Color
Built-in Programs
Auto
1. DMX Mode
With this menu you can set the DMX address.
01) Press the MODE button, until the display shows .
02) You can choose 512 different DMX addresses.
03) Use the Up and Down buttons to select the required address between .
04) You can also press the SETUP button to set a different DMX Mode .
3 Channels
4 Channels
14 Channels
26 Channels
2 Channels
7 Channels
2. Master / slave addressing
Master
01) The default setting for this device is master.
02) Only one fixture can be the master.
Note:
•Disconnect the fixture from the DMX controller before master/slave operating, otherwise data
collisions may occur and the fixtures will not work properly!
•In master/slave mode, the master fixture can execute the built-in programs, all the slave fixtures will
work the same.
•When operating the master/slave chain, you can identify the master fixture from the slave fixtures
easily. The master doesn’t have any cable plugged into the DMX input connector.

15
Ordercode: 42199
LED Light Bar 8
Slave control
This function allows you to control the slaves from the master’s control panel in a master/slave operation.
01) Only 1 fixture can be the master, the others have to be Slaves. The Default setting for a device is
Master. So on the first device you don’t have to change anything.
On the slave devices you must press the MODE button until the display shows .
02) All slave devices must have address .
3. Sound control Mode
Press the MODE button on the device, until the display shows . Turn on the music and the LED
Light Bar will react to the beat of the music.
You can set the sensitivity from low-sensitivity to high-sensitivity
between SU.00 - SU.31 with the Up and Down buttons.
4. Static Color Mode
With this menu you can set the static color.
01) Press the MODE button, until the display shows .
02) With this menu you can set 3 Static colors of the LED Light Bar.
You can choose Red, Green or Blue by pressing the Setup button.
Use the Up / Down buttons to select the values of each individual color from 000-255.
5. Built-in Programs
01) Press the MODE button on the device, until the display shows .
02) With this menu you can set the Built-in Program Mode of the LED Light Bar. You can choose 22 built-in
programs , by using the Up and Down buttons.
03) Press Setup to enter the built-in programs Menu. You can choose 3 different sub menus:
See the next page to view the complete menu.

16
Ordercode: 42199
LED Light Bar 8
Red Flash from 00-99
Red-Green Flash from 00-99
Green Flash from 00-99
Green-Blue Flash from 00-99
Blue Flash from 00-99
Red-Blue Flash from 00-99
Red-Green-Blue Flash from 00-99
Off
Speed from 01-99, Full
Flash Frequency 00-99
Fade Time from 00-99
Speed from 01-99, Full
Flash Frequency 00-99
Fade Time from 00-99
The specialty about menu 21 and 22 is, that you can combine both menus!!!!

17
Ordercode: 42199
LED Light Bar 8
Examples
Menu 21
Menu 22

18
Ordercode: 42199
LED Light Bar 8
6. Auto Run Program
01) Press the MODE button on the device, until the display shows .
02) With this menu you can set the Auto Mode of the LED Light Bar.
03) Press Setup to enter the AUTO Menu. You can choose 4 different sub menus.
Number of Loops from 01-100
Speed from 01-99 and FL
Fade Time from 00-99
Flash Frequency from 00-99
Use the SETUP button to scroll through the menu.

19
Ordercode: 42199
LED Light Bar 8
DMX Channels
3 DMX Channels (d-P1)
Channel 1 –Red
0-255
Gradual adjustment Red from 0 –100%
Channel 2 –Green
0-255
Gradual adjustment Green from 0 –100%
Channel 3 –Blue
0-255
Gradual adjustment Blue from 0 –100%
4 DMX Channels (d-P2).
Channel 1 –Red (Dimmer must be open )
0-255
Gradual adjustment Red from 0 –100%
Channel 2 –Green (Dimmer must be open )
0-255
Gradual adjustment Green from 0 –100%
Channel 3 –Blue (Dimmer must be open )
0-255
Gradual adjustment Blue from 0 –100%
Channel 4 –Master Dimmer
0-255
Dimmer, from closed to open (0-100%)
14 DMX Channels (d-P3)
Channel 1 –Red Section 1
0-255
Gradual adjustment Red from 0 –100%
Channel 2 –Green Section 1
0-255
Gradual adjustment Green from 0 –100%
Channel 3 –Blue Section 1
0-255
Gradual adjustment Blue from 0 –100%
Channel 4 –Red Section 2
0-255
Gradual adjustment Red from 0 –100%
Channel 5 –Green Section 2
0-255
Gradual adjustment Green from 0 –100%
Channel 6 –Blue Section 2
0-255
Gradual adjustment Blue from 0 –100%
