Show Tec Pixel Bubble 80 MKII User manual

Pixel Bubble 80 MKII V1
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands
Ordercode: 41094
MANUAL
ENGLISH

Ordercode: 41094
Pixel Bubble 80 MKII
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions.........................................................................................................................................................2
Operating Determinations..........................................................................................................................................4
Rigging............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................5
Claims..............................................................................................................................................................................5
Description of the device.................................................................................................................................................6
Frontside..........................................................................................................................................................................6
Backside..........................................................................................................................................................................7
Installation...........................................................................................................................................................................8
Set Up and Operation.......................................................................................................................................................8
Installation of multiple LED strings...............................................................................................................................8
Control Modes...............................................................................................................................................................9
One Pixel Bubble (Auto Mode)...............................................................................................................................9
Multiple Pixel Bubbles (Master/Slave control)......................................................................................................9
Multiple Pixel Bubbles (DMX Control)...................................................................................................................10
Multiple Pixel Bubbles (ArtNet/KlingNet Control)...............................................................................................11
Fixture Linking...............................................................................................................................................................12
Data Cabling...............................................................................................................................................................12
Control Panel...............................................................................................................................................................13
Control Mode..............................................................................................................................................................13
DMX Addressing..........................................................................................................................................................13
Menu Overview...........................................................................................................................................................14
Main Menu Options....................................................................................................................................................15
DMX channel mode settings.................................................................................................................................15
1. Auto Mode............................................................................................................................................................15
2. DMX channel mode settings.............................................................................................................................16
3. DMX Address.........................................................................................................................................................17
4. Software Information...........................................................................................................................................17
5. Strip length settings..............................................................................................................................................17
6. Network Settings ..................................................................................................................................................18
7. Master/Slave Mode.............................................................................................................................................18
DMX Channels.............................................................................................................................................................19
8 channels.................................................................................................................................................................19
150 channels.............................................................................................................................................................21
225 channels.............................................................................................................................................................22
300 channels.............................................................................................................................................................23
375 channels.............................................................................................................................................................24
450 channels.............................................................................................................................................................25
Connecting to a Network ..............................................................................................................................................26
KlingNet settings..........................................................................................................................................................26
ArtNet settings..............................................................................................................................................................26
How to make a data cable......................................................................................................................................27
Software for controlling..............................................................................................................................................27
Maintenance....................................................................................................................................................................28
Troubleshooting................................................................................................................................................................28
No Light.........................................................................................................................................................................28
No Response to DMX..................................................................................................................................................29
Product Specifications....................................................................................................................................................30
Dimensions........................................................................................................................................................................31
Notes..................................................................................................................................................................................32
1

Ordercode: 41094
Pixel Bubble 80 MKII
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
•Showtec Pixel Bubble 80 MKII
•Powercon power cable (1,5 m)
•User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
•be qualified
•follow the instructions of this manual
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
2

Ordercode: 41094
Pixel Bubble 80 MKII
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never leave any cables lying around.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always hold the fixture by the transport handles.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. The fixture must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•The user is responsible for correct positioning and operating of the Pixel Bubble. The manufacturer will
not accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
3

Ordercode: 41094
Pixel Bubble 80 MKII
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the fixture is lowered from the ceiling or high joists, professional trussing systems have to be used.
•Use a clamp to mount the fixture, with the mounting bracket, to the trussing system.
•The fixture must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the projector, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.
4

Ordercode: 41094
Pixel Bubble 80 MKII
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.
5

Ordercode: 41094
Pixel Bubble 80 MKII
Description of the device
Features
The Pixel Bubble 80 MKII is a LED visual effect with high output and great effects.
The set includes 15 x 1-meter long LED strings but it is possible to connect a maximum of 30 LED strings to
the Pixel Bubble. The Pixel Bubble 80 MKII supports the most popular protocols, such as: DMX, ArtNet and
KlingNet.
•Power Supply: 100-240 VAC, 60/50Hz
•Power Consumption: 90W
•Light source: min. 50 – max. 150 x 5050 SMD RGB LEDs
•Control Protocol: DMX-512, ArtNet, KlingNet
•DMX channels: 8, 150, 225, 300, 375, 450 channels
•Onboard: LCD display for easy setup
•String length: 1 m (5 LEDs per string); maximum setup length: 6 m
•Connectors: Powercon power connector, 3-pin XLR IN/OUT, RJ45 IN/OUT
•Cooling: Convection
•Dimmer: 0-100%
•Strobe: 0-20Hz
•Refresh rate: 444Hz
•Beam angle: 360°
•Housing: Die-cast aluminum
•Dimensions: 1000 x 65 x 73 mm (LxWxH)
•Weight: 5,2 kg
Optional accessories:
41095 – 1m string for Pixel Bubble 80 MKII
41096 – Extension cable for Pixel Bubble 80 MKII (43 cm)
41097 – Extension cable for Pixel Bubble 80 MKII (100 cm)
You can connect from 2 up to 6 LED strings per output (30 strings in total)
Frontside
Fig. 01
01) Safety eye
02) 5050 SMD RGB LEDs
03) LCD display + menu buttons
6

Ordercode: 41094
Pixel Bubble 80 MKII
Backside
Fig. 02
04) Powercon power connector 100-240V OUT
05) 3-pin DMX signal connector IN
06) RJ45 ArtNet/KlingNet connector IN
07) RJ45 ArtNet/KlingNet connector OUT
08) 3-pin DMX signal connector OUT
09) Power switch ON/OFF
10) Powercon power connector 100-240V IN
11) Ground/earth connection
7

Ordercode: 41094
Pixel Bubble 80 MKII
Installation
Remove all packing materials from the Pixel Bubble 80 MKII. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.
Installation of multiple LED strings
01) It is possible to connect multiple LED strings (41095) to the Pixel Bubble 80 MKII.
02) You can connect up to 6 strings per output (30 in total).
03) The number of strings is determined by the Length settings in the main menu.
04) See page 17: Strip length settings, for more information.
Fig. 03
8

Ordercode: 41094
Pixel Bubble 80 MKII
Control Modes
There are 3 modes:
•Auto Mode
•Master/Slave
•DMX-512 (8CH, 150CH, 225CH, 300CH, 375CH, 450CH)/ArtNet/KlingNet
One Pixel Bubble (Auto Mode)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the Pixel Bubble is not connected with a DMX cable, it functions as a stand-alone device.
Please see page 15 for more information about Auto Mode.
Multiple Pixel Bubbles (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Use a 3-pin XLR cable to connect the Pixel Bubbles.
The pins:
01) Earth
02) Signal -
03) Signal +
03) Link the units as shown in fig. 04. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
04) You can use the same functions on the master device as described on page 15 (Auto Mode).
This means that you can set your desired operation mode on the master device and all slave
devices will react the same as the master device.
Multiple Pixel Bubbles (Master/Slave control)
Fig. 04
9

Ordercode: 41094
Pixel Bubble 80 MKII
Multiple Pixel Bubbles (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the Pixel Bubbles and other devices.
04) Link the units as shown in fig. 05. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's Powercon socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Pixel Bubbles DMX Set Up
Fig. 05
Note : Link all cables before connecting electric power
10

Ordercode: 41094
Pixel Bubble 80 MKII
Multiple Pixel Bubbles (ArtNet/KlingNet Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a CAT-5/CAT-6 cable to connect the Pixel Bubble’s "in" socket to your software/light controller’s
output.
04) Use a CAT-5/CAT-6 cable to connect the Pixel Bubble and other KlingNet devices.
04) Link the units as shown in fig. 06. Connect the first Pixel Bubble's RJ45 "out" socket with the second
unit's "in" socket, using a CAT-5/CAT-6 signal cable. Repeat this process to link the second, third, and
fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's Powercon socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Pixel Bubbles ArtNet/KlingNet Set Up
Fig. 06
Note : Link all cables before connecting electric power
11

Ordercode: 41094
Pixel Bubble 80 MKII
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
DAP Audio PC Interface Cables
•CAT-5 cable 7,6 mm Matte blue PVC. Ordercode FL55150 (1,5 m), FL553 (3 m), FL556 (6 m),
FL5510 (10 m), FL5515 (15 m), FL5520 (20 m).
•CAT-6 cable (recommended for best data transfer). Ordercode FL563 (3 m), FL566 (6 m),
FL5610 (10 m), FL5615 (15 m), FL5640 (40 m).
12

Ordercode: 41094
Pixel Bubble 80 MKII
The Pixel Bubble 80 MKII can be operated with a light controller in control mode or without the controller
in stand-alone mode.
Control Panel
A) LCD display
B) MENU button
C) UP button
D) DOWN button
E) ENTER button
Fig. 07
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the Pixel Bubble will respond to the controller.
Please note, when you use the controller, the unit has 8channels.
When using multiple Pixel Bubbles, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Pixel Bubble should be 1(001); the DMX address of the second Pixel
Bubble should be 1+8=9 (009); the DMX address of the third Pixel Bubble should be 9+8=17 (017), etc.
Please, be sure that you do not have any overlapping channels in order to control each Pixel Bubble
correctly. If two or more Pixel Bubbles are addressed similarly, they will work similarly.
Note: When in 300-channel mode, 375-channel mode and 450-channel mode it is possible to connect
multiple devices only by means of ArtNet or KlingNet. See page 26 for more information.
Controlling:
After having addressed all Pixel Bubble fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the Pixel Bubble will automatically detect whether DMX 512 data is received or
not.
If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Pixel Bubble 80 MKII.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 20 seconds
When no button is pressed for 20 seconds, the display will turn off.
To light up the display, you have to press the MENU, ENTER, UP or DOWN button.
Once you have pressed the button, the display will light up.
13

Ordercode: 41094
Pixel Bubble 80 MKII
Menu Overview
14

Ordercode: 41094
Pixel Bubble 80 MKII
Main Menu Options
Auto Mode
DMX channel mode settings
DMX-512 Mode
Software information
Strip length/quantity settings
Network settings
Master/Slave Mode
1. Auto Mode
With this menu, you can set the built-in programs.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle between the following 2 options:
Program speed
Program choice
04) When the display shows , press the ENTER button to open the menu.
05) Press the UP/DOWN buttons to increase/decrease the program speed. The adjustment range is
between , from slow to fast.
06) Press the ENTER button to save changes.
07) When the display shows , press the ENTER button to open the menu.
08) Press the UP/DOWN buttons to toggle between the available programs:
. You can choose between 29
programs and Mix (all the built-in programs will be displayed in a sequence).
09) Press the ENTER button to save changes.
15

Ordercode: 41094
Pixel Bubble 80 MKII
2. DMX channel mode settings
With this menu, you can choose the desired DMX channel mode.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle between the following 6 DMX channel modes:
8-channel mode (default)
150-channel mode. Available when Length is set to 2 m.
225-channel mode. Available when Length is set to 3 m.
300-channel mode. Available when Length is set to 4 m.
375-channel mode. Available when Length is set to 5 m.
450-channel mode. Available when Length is set to 6 m.
04) The DMX channel mode choice depends on the strip length settings. Different strip lengths
correspond with different DMX channel modes (see page 17: Strip length settings).
05) Press the ENTER button to confirm your choice.
16

Ordercode: 41094
Pixel Bubble 80 MKII
3. DMX Address
With this menu, you can set the desired DMX address.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to choose the desired DMX address. The DMX address range depends on
the choice of DMX channel mode. The adjustment ranges are:
8-channel mode
150-channel mode
225-channel mode
300-channel mode
375-channel mode
450-channel mode
04) Press the ENTER button to save changes.
4. Software Information
With this menu, you can check the currently installed software version.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) The display shows the current software version: .
5. Strip length settings
With this menu, you can set the setup length. This will determine the number of LED strings, which you can
connect, and the number of DMX channels which you can control the Pixel Bubble with.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle between the following 5 options:
2 meters. You can connect 2 LED strings (41095) per output.
3 meters. You can connect 3 LED strings (41095) per output.
4 meters. You can connect 4 LED strings (41095) per output.
5 meters. You can connect 5 LED strings (41095) per output.
6 meters. You can connect 6 LED strings (41095) per output.
04) Press the ENTER button to confirm your choice.
17

Ordercode: 41094
Pixel Bubble 80 MKII
6. Network Settings
With this menu, you can adjust the device’s properties, such as the IP address, subnet mask and the
universes.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle between the following 3 options:
IP address
Subnet mask
Universe
04) Once you have chosen one of the options listed above, press the ENTER button to proceed to
edition mode.
05) Press the UP/DOWN buttons to choose the piece of the IP address/Subnet mask/Universe, which
needs to be adjusted and which is indicated by the [bracket.
06) Press the ENTER button to confirm your choice.
07) Press the UP/DOWN buttons to adjust the desired setting.
08) Press the ENTER button to save changes.
7. Master/Slave Mode
With this menu, you can set the device as a slave.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to choose between “Yes” or “No”.
04) Press the ENTER button to confirm your choice.
18

Ordercode: 41094
Pixel Bubble 80 MKII
DMX Channels
8 channels
Channel 1 – Dimmer intensity
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 2 – Strobe
0-255
Strobe frequency, from low to high frequency
Channel 3 – Red Dimmer must be open
0-255
Gradual adjustment Red, from 0-100%
Channel 4 – Green Dimmer must be open
0-255
Gradual adjustment Green, from 0-100%
Channel 5 – Blue Dimmer must be open
0-255
Gradual adjustment Blue, from 0-100%
Channel 6 – Built-in programs 1-15 CH1 and CH2 must be set to 0
0-15
Not functional
16-31
Program 1
32-47
Program 2
48-63
Program 3
64-79
Program 4
80-95
Program 5
96-111
Program 6
112-127
Program 7
128-143
Program 8
144-159
Program 9
160-175
Program 10
176-191
Program 11
192-207
Program 12
208-223
Program 13
224-239
Program 14
240-255
Program 15
Channel 7 – Built-in programs 16-30 CH1 and CH2 must be set to 0
0-15
Not functional
16-31
Program 16
32-47
Program 17
48-63
Program 18
64-79
Program 19
80-95
Program 20
96-111
Program 21
112-127
Program 22
128-143
Program 23
144-159
Program 24
160-175
Program 25
176-191
Program 26
192-207
Program 27
208-223
Program 28
224-239
Program 29
240-255
Program Mix
Channel 8 – Program speed
0-255
Speed adjustment, from slow to fast
19
