Show Tec Spectral D5000 User manual

Spectral D5000 RGB IP65
ORDERCODE 43509
Highlite International B.V.
Vestastraat 2
6468 EX Kerkrade
The Netherlands
Phone: [phone]

Congratulations!
You have bought a great, innovative product from Showtec.
The Showtec Spectral D5000 brings excitement to any venue. Whether you want simple plug-&-play
action or a sophisticated DMX show, this product provides the effect you need.
You can rely on Showtec, for more excellent lighting products.
We design and manufacture professional light equipment for the entertainment industry.
New products are being launched regularly. We work hard to keep you, our customer, satisfied.
For more information: [e-mail]
You can get some of the best quality, best priced products on the market from Showtec.
So next time, turn to Showtec for more great lighting equipment.
Always get the best -- with Showtec !
Thank you!

1
Showtec
Showtec Spectral D5000™Product Guide
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Return Procedure..........................................................................................................................................................5
Claims..............................................................................................................................................................................5
Description of the device ................................................................................................................................................6
DMX Channel Summary ..............................................................................................................................................7
Overview ........................................................................................................................................................................7
Backside .........................................................................................................................................................................8
Installation ...........................................................................................................................................................................9
Set Up and Operation ......................................................................................................................................................9
Control Modes...............................................................................................................................................................9
One Spectral (Static Colors) ..................................................................................................................................9
One Spectral (7-color Jump) .................................................................................................................................9
One Spectral (Built-in Programs) ...........................................................................................................................9
Multiple Spectrals (Master/Slave control)..........................................................................................................10
Multiple Spectrals (DMX Control) ........................................................................................................................10
Fixture Linking...............................................................................................................................................................12
Data Cabling...............................................................................................................................................................12
Control Panel ...............................................................................................................................................................13
DMX Control Mode.....................................................................................................................................................13
DMX Addressing ..........................................................................................................................................................13
Menu Overview...........................................................................................................................................................14
Main Menu Options ...............................................................................................................................................15
1. Personality............................................................................................................................................................15
2. Master/Slave Mode ...........................................................................................................................................15
3. DMX 512 Address................................................................................................................................................16
4. Node (dimming curve) .....................................................................................................................................16
5. Blue .......................................................................................................................................................................16
6. Green ...................................................................................................................................................................16
7. Red........................................................................................................................................................................16
8. Flash/Strobe.........................................................................................................................................................16
9. Fade Speed.........................................................................................................................................................17
10. Seven Color Jump ...........................................................................................................................................17
11. Built-in Programs ...............................................................................................................................................17
12. Speed of the Built-in Programs ......................................................................................................................17
DMX Channels .............................................................................................................................................................18
3 DMX Channels .....................................................................................................................................................18
6 DMX Channels .....................................................................................................................................................18
7 DMX Channels .....................................................................................................................................................19
Beam Angle and illuminance .......................................................................................................................................20
Connection Cables ........................................................................................................................................................21
Maintenance ...................................................................................................................................................................21
Troubleshooting ...............................................................................................................................................................22
No Light.........................................................................................................................................................................22
No Response to DMX..................................................................................................................................................22
Product Specification.....................................................................................................................................................24

2
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
• Spectral D5000 IP54
• 1X Special Powercable 1,5m.
• 1X special 3-pin to DMX IN (3-pin)
• 1X special 3-pin to DMX OUT (3-pin)
• 1X special mounting plate
• 2X Endcap
• User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. It is estimated that a viable lifespan of 40,000 to 50,000 hours will be achieved
under normal operational conditions. If improving on this lifespan expectancy is of a higher priority, place
care in providing for lower operational temperatures. This may include climatic-environmental and the
reduction of overall projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
-be qualified
-follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
CAUTION! Be careful with your operations.
With a dangerous voltage you can suffer
a dangerous electric shock when touching the wires!
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!

3
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-
observance of this manual or any unauthorized modification to the device.
Never let the power-cord come into contact with other cables! Handle the power-cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never look directly into the light source.
Never leave any cables lying around.
Never use the device during thunderstorms, unplug the device immediately.
Never leave various parts of the packaging (plastic bags, polystyrene foam, nails, etc.) within
children’s reach, as they are potential sources of danger.
Do not insert objects into air vents.
Do not open the device and do not modify the device.
Do not connect this device to a dimmerpack.
Do not shake the device. Avoid brute force when installing or operating the device.
Do not switch the device on and off in short intervals, as this would reduce the system’s life.
Only use device indoor, avoid contact with water or other liquids.
Only operate the device after having familiarized with its functions.
Avoid flames and do not put close to flammable liquids or gases.
Always allow free air space of at least 50 cm around the unit for ventilation.
Always disconnect power from the mains, when device is not used or before cleaning! Only
handle the power-cord by the plug. Never pull out the plug by tugging the power-cord.
Make sure that the device is not exposed to extreme heat, moisture or dust.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power-cord is never crimped or damaged. Check the device and the power-
cord from time to time.
Make sure that no side forces can impact on the truss system.
The cable insert or the female part in the device must never be strained. There must always be
sufficient cable to the device. Otherwise, the cable may be damaged which may lead to deadly
electrical shocks.
If the external cable is damaged, it has to be replaced by a qualified technician.
If the lens is obviously damaged, it has to be replaced. So that its functions are not impaired, due
to cracks or deep scratches.
If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do
not switch it on immediately. The arising condensation water might damage your device. Leave
the device switched off until it has reached room temperature.
If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
For adult use only. The device must be installed out of the reach of children. Never leave the unit
running unattended.
For replacement use fuses of same type and rating only.
The user is responsible for correct positioning and operating of the Spectral D5000. The
manufacturer will not accept liability for damages caused by the misuse or incorrect installation
of this device.
This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
Repairs, servicing and electric connection must be carried out by a qualified technician.
WARRANTY: Till one year after date of purchase.
CAUTION ! EYEDAMAGES !.
Avoid looking directly into the light source.
(meant especially for epileptics) !

4
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light-output and the illuminated surface must be more than 0.5 meter.
•The maximum ambient temperature ta= 45°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 45° C.
•If this device is operated in any other way, than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!
Improper installation can cause serious damage to people and property !
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all other
safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
If the Spectral D5000 is lowered from the ceiling or high joists, professional trussing systems have to
be used.
Use a clamp to mount the Spectral D5000, with the mounting-bracket, to the trussing system.
The Spectral D5000 must never be fixed swinging freely in the room.
The installation must always be secured with a safety attachment, e.g. an appropriate safety net
or safety-cable.
When rigging, derigging or servicing the Spectral D5000, always make sure, that the area below
the installation place is blocked and staying in the area is forbidden.
The Spectral D5000 can be mounted in a hanging position (Fig. Above) or Upright (Fig. Below), using the
support brackets. Mounting the Spectral D5000 with a clamp or any other mounting bracket is
recommended, depending on the requirements of your application.
The Spectral D5000 can be placed on a flat stage floor or mounted to any kind of truss by a clamp.
Improper installation can cause serious damage to people and property !

5
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
FASE
N
BLUE
BLACK
SILVER
NUL
YELLOW/GREEN
GREEN
GREEN
EARTH
Make sure that the device is always connected properly to the earth!
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
1) Your name
2) Your address
3) Your phone number
4) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

6
Description of the device
Features
The Spectral D5000 is a compact indoor/outdoor LED fixture from Showtec with 60 high power LEDs
•Spectral D5000 is the latest and most powerful addition in the popular Spectral Range
•High Power Lightoutput
•RGB Colormixing
•IP54 Rating
•Input-voltage: 240V
•60x 3W 3-in-1 RGB LEDs
•The LEDs have a 25 degree optical lens ensuring high lightoutput and even colormixing
•Drive current: 350mA
•Peak Power 390 Watt
•Continuous Power 230 Watt
•Control protocol: DMX 512
•3, 6 or 7 DMX channels
•5 different DMX Operating modes
•RGB colour mixing with or without DMX controller
•Display: LED display for auto and custom control
•Control: DMX-512, Auto, Master/Slave
•Dimmer: 0-100%
•Strobe: 0-20Hz
•Beam Angle: 25° degrees
•Refreshrate: 400 Hz
•Housing: Die Cast Aluminium Powder Coat Finish
•Colour: Black
•Lens Plate: Tempered Glass
•Double-bracket yoke doubles as floor stand
•DMX Connection Dedicated IP54 connector
•Cooling: Convection (no fans)
•Dedicated IP54 Powerconnector
•Colour range: 16,7 million additive colors
•Lumen: 5019+
•Lux (@ 2 meter) 4930+
•Max distance: 40 meter
•Dimensions: 340x310x220mm
•Weight: 11,70 kg
NOTE: Knowledge of DMX is required to fully utilize this unit.

7
DMX Channel Summary
3 CH
Channel
Description
1
Red
2
Green
3
Blue
6 CH
Channel
Description
1
Master Dimmer
2
Red
3
Green
4
Blue
5
Strobe
6
Built-in Programs
7 CH
Channel
Description
1
Master Dimmer
2
Red
3
Green
4
Blue
5
Strobe
6
Built-in Programs
7
Preset Colors
Overview
1
2
Fig. 1
1) Mountingbracket for Truss mounting
2) 60x 3W 3-in-1 RGB LEDs

8
Backside
3
Fig. 2
4 5 6 7 8
3) LCD Display+menu Buttons
4) Power IN
5) DMX signal connector (IN)
6) Safety Eye
7) Power OUT
8) ) DMX signal connector (OUT)
4 5 6 8
Note: You cannot plug a standard DMX cable directly into the connector
Be sure to use the included special cable for DMX connection.
Female 3 pin DMX to special 3-pin Male Male 3 pin DMX to special 3-pin Female
Powercable to special 3-pin Female

9
Installation
Remove all packing materials from the Spectral D5000. Check that all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Control Modes
FUNCTIONS:
There are 5 modes: • Static Colors (manual)
• 7-color jump Speed controlled
• Built-in programs (Auto) Speed controlled
• Master/Slave
• DMX512 (3, 6 or 7 Channels)
One Spectral (Static Colors)
1) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
2) When the Spectral is not connected by a DMX-cable, it functions as a stand-alone device. Please
see page 16 for more information about the static colors.
One Spectral (7-color Jump)
1. Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
2. When the Spectral is not connected by a DMX-cable, it functions as a stand-alone device. Please
see page 17 for more information about the 7-color jump.
One Spectral (Built-in Programs)
3. Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
4. When the Spectral is not connected by a DMX-cable, it functions as a stand-alone device. Please
see page 17 for more information about the built-in programs.

10
Multiple Spectrals (Master/Slave control)
1. Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
2. Use a 3-p XLR cable to connect the Spectral.
The pins: 1. Earth
2. Signal -
3. Signal +
3. Link the units as shown in (Fig. 3), Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units. You can
use the same functions on the master device as described on page 16+17 (Static Colors or Built-in
Programs). This means on the master device you can set your desired operation Mode and all slave
devices will react the same as the master device.
Multiple Spectrals (Master/Slave control)
Fig. 3
Multiple Spectrals (DMX Control)
1. Plug the end of the electric mains power cord into a proper electric power supply socket.
2. Use a 3-p XLR cable to connect the Spectrals.
3. Link the units as shown in (figure 4), Connect a DMX signal cable from the first unit's DMX "out" socket
to the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
4. Supply electric power: Plug the end of the mains power cord into proper electric power supply
sockets. Do so for all units and the controller. Do not supply power before the whole system is set up
and connected properly.

11
Multiple Spectrals Pro Set Up
Max. 30 Spectrals
Fig. 4
Note : Link all DMX cables before connecting electric power
5. Do not supply power before the whole system is set up and connected properly. Design your show
according to your DMX controller functions. See page 16 and 17 for more about DMX programming.

12
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows on two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
The Spectral D5000 uses a maximum of 7 channels.
Important: Fixtures on a serial data link must be daisy chained in one single line. To comply with the
EIA-485 standard no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of Spectrals on a DMX data link: 30 fixtures
@ 220V: 8 units may be connected in series
Data Cabling
To link fixtures together you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio Certified DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3 p. > XLR/F 3 p.
Ordercode FL01150 (1,5m.), FL013 (3m.), FL016 (6m.), FL0110 (10m.), FL0115 (15m.), FL0120 (20m.).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5m.), FL713 (3m.), FL716 (6m.), FL7110 (10m.).

13
The Spectral D5000 has a total of 3 DMX channel configurations, referred to as Personalities.
The 3 personalities are [3CH, 6CH, 7 CH].
Each of the different personalities can be accessed from the control panel.
Control Panel
Fig. 5
A. Display D. Down Button
B. MENU Button E. ENTER Button
C. Up Button
DMX Control Mode
The fixtures are individually addressed on a data-link and connected to
the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address the next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign the DMX fixture address, which is the
first channel from which the Spectral will respond to the controller.
Please note when you use the controller, the unit has max. 7channels.
When using multiple Spectrals, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Spectral should be 1(A001); the DMX address of the second
Spectral should be 1+7=8; the DMX address of the third Spectral should be 8+7=15, etc.
Please, be sure that you don’t have any overlapping channels in order to control each Spectral
correctly. If two or more Spectrals are addressed similarly, they will work similarly.
For address settings, please refer to the instructions under ”Addressing’.
Controlling:
After having addressed all Spectrals, you may now start operating these via your lighting controller.
Note: After switching on, the Spectral will automatically detect whether DMX 512 data is received or not.
The problem may be:
•The XLR cable from the controller is not connected with the input of the Spectral.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It’s necessary to insert a XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.

14
Menu Overview

15
Main Menu Options
Press the MENU button to scroll through 12 options of the menu:
1. DMX Personalities 3CH, 6CH or 7CH
2. Master/Slave
3. DMX Address
4. Node (dimming curve)
5. Blue
6. Green
7. Red
8. Flash/Strobe (speed adjustable)
9. Fade (speed adjustable)
10. Seven Color Jump (speed adjustable)
11. Built-in Programs (speed adjustable)
12. Speed of the built-in programs and 7-color jump
1. Personality
Enter the PERSONALITY mode to select a DMX mode: CH3, CH6 or CH7.
2. Master/Slave Mode
1) When you press ENTER in menu SLAV, you can set the Spectral to Slave Mode.
2) An extra dot will appear behind SL, indicating your in slave mode.

16
3. DMX 512 Address
1) When you press ENTER in menu DMX, you can set the DMX address of your Spectral.
2) You can set your DMX address between 001-512.
4. Node (dimming curve)
Smooth dimming curve
Smoother dimming curve
Smoothest dimming curve
1) When you press ENTER in menu Node, you can set the dimming curve of your Spectral.
2) You can choose 3 different dimming curves, 0 being smooth and 2 being the smoothest.
Creating a static color
5. Blue
1) When you press ENTER in menu bL--, you can set the intensity of the blue LEDs.
2) You can set the value of the blue LEDs (0-255).
6. Green
1) When you press ENTER in menu GL--, you can set the intensity of the green LEDs.
2) You can set the value of the green LEDs (0-255).
7. Red
1) When you press ENTER in menu rL--, you can set the intensity of the red LEDs.
2) You can set the value of the red LEDs (0-255).
8. Flash/Strobe
1) When you press ENTER in menu Flash, you can set the strobe intensity of your Spectral.
2) You can choose/set the value of the strobe (0-15) from fast to slow.

17
9. Fade Speed
1) When you press ENTER in menu Fade, you can set the fade speed of your Spectral.
2) You can set the value of the fade speed (0-15) from fast to slow.
10. Seven Color Jump
1) When you press ENTER in menu CE--, you can choose a variety of color jump programs.
2) You can choose one of the 16 built-in color jump programs (0-16).
11. Built-in Programs
1) When you press ENTER in menu Pr--, you can choose a variety of built-in programs.
2) You can choose one of the 16 built-in programs (0-16).
Pr00 Red
Pr01 Green
Pr02 Blue
Pr03 Yellow
Pr04 Cyan
Pr05 Purple
Pr06 White
Pr07 Red strobe
Pr08 Green strobe
Pr09 Blue strobe
Pr10 Yellow strobe
Pr11 Cyan strobe
Pr12 Purple strobe
Pr13 White strobe
Pr14 3-color (RGB) color jump
Pr15 7-color jump
3) You can adjust the speed of Pr07 - Pr15 by using the Speed menu (SP).
12. Speed of the Built-in Programs
1) When you press ENTER in menu SP--, you can choose the speed of the built-in programs.
2) You can choose 16 different speeds (0-16) from fast to slow.

18
DMX Channels
3 DMX Channels
Channel 1 –Red
0-255
Gradual adjustment Red from 0 –100%
Channel 2 –Green
0-255
Gradual adjustment Green from 0 –100%
Channel 3 –Blue
0-255
Gradual adjustment Blue from 0 –100%
6 DMX Channels
Channel 1 –Dimmer intensity
0-255
Gradual adjustment From black to brightest
Channel 2 –Red
0-255
Gradual adjustment Red from 0 –100%
Channel 3 –Green
0-255
Gradual adjustment Green from 0 –100%
Channel 4 –Blue
0-255
Gradual adjustment Blue from 0 –100%
Channel 5 –Shutter / Strobe (Dimmer must be open )
0-14
No Function
15-255
Strobe effect, from slow to fast (0-20 flashes/sec.)
Channel 5 –Program Speed (when CH6 is set between 32-255 )
0-14
No Function
15-255
Strobe effect, from slow to fast (0-20 flashes/sec.)
Channel 6 –Built-in Programs (CH1, CH 2, CH 3 and CH4 must also be used, when CH6=32-127)
0-31
No Function
32-63
Dim- Bright
64-95
Bright -Dim
96-127
Dim- Bright -Dim
128-159
RGB gradual Color Change
160-223
3-color jump
224-255
7-color jump
