Show Tec City Painter 9000 LED User manual

City Painter 9000 LED V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 40910
MANUAL
ENGLISH

1
Ordercode: 40910
City Painter 9000 LED
Table of contents
Warning ...............................................................................................................................................................................3
Safety Instructions .........................................................................................................................................................3
Operating Determinations ..........................................................................................................................................5
Rigging ............................................................................................................................................................................5
Connection with the mains.........................................................................................................................................6
Return Procedure..........................................................................................................................................................7
Claims..............................................................................................................................................................................7
Description of the device.................................................................................................................................................8
Optional accessories....................................................................................................................................................8
Overview ........................................................................................................................................................................9
Installation...........................................................................................................................................................................9
Set Up and Operation .......................................................................................................................................................9
Control Modes...............................................................................................................................................................9
One City Painter 9000 LED (Static colors and Auto Mode) .............................................................................10
Multiple City Painters 9000 LED (Master/Slave control) ....................................................................................10
Multiple City Painters 9000 LED (DMX Control)...................................................................................................11
Fixture Linking...............................................................................................................................................................12
Data Cabling...............................................................................................................................................................12
Control Panel ...............................................................................................................................................................13
Control Mode ..............................................................................................................................................................13
DMX Addressing ..........................................................................................................................................................13
Menu Overview...........................................................................................................................................................14
Main Menu Options....................................................................................................................................................16
1. Static Colors..........................................................................................................................................................16
2. Built-in and custom programs ...........................................................................................................................17
3. DMX-address ........................................................................................................................................................17
4. Master/Slave Mode.............................................................................................................................................17
5. DMX configuration ..............................................................................................................................................17
6. Settings...................................................................................................................................................................18
6.1 Upload .................................................................................................................................................................18
6.2 Reset ....................................................................................................................................................................18
6.3 Dimmer ................................................................................................................................................................18
6.4 Color.....................................................................................................................................................................19
7. Edit Mode..............................................................................................................................................................19
7.1. How to make your own custom program ...................................................................................................20
8. Calibration menu 1 .............................................................................................................................................20
9. Calibration menu 2 .............................................................................................................................................20
10. Optional Wireless DMX mode .........................................................................................................................20
11. Keylock mode ....................................................................................................................................................20
DMX Channels .............................................................................................................................................................21
11 channels TOUR ....................................................................................................................................................21
3 channels ARC.1.....................................................................................................................................................22
4 channels AR1.D.....................................................................................................................................................23
5 channels ARC.3.....................................................................................................................................................23
6 channels AR3.D.....................................................................................................................................................23
7 channels AR3.S......................................................................................................................................................24
3 channels (HSV) ......................................................................................................................................................24
Maintenance....................................................................................................................................................................25
Troubleshooting ...............................................................................................................................................................25
No Light.........................................................................................................................................................................25
No Response to DMX..................................................................................................................................................25

2
Ordercode: 40910
City Painter 9000 LED
Product Specifications....................................................................................................................................................27
Dimensions........................................................................................................................................................................28
Notes ..................................................................................................................................................................................29

3
Ordercode: 40910
City Painter 9000 LED
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual
Your shipment includes:
Showtec City Painter 9000
LED
2 Quicklock mounting
brackets
1x Schuko to 3-pins (IP-67 )
Power cable 1,5m
1x special 3-pin to DMX IN
(3 pin) 0,17m
1x special 3-pin to DMX
OUT (3 pin) 0,17m
1x Safety cable
Flightcase
User manual

4
Ordercode: 40910
City Painter 9000 LED
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged. Always
hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. The fixture must be installed beyond the reach of children. Never leave the unit
running unattended.

5
Ordercode: 40910
City Painter 9000 LED
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.
•The user is responsible for correct positioning and operating of the City Painter 9000 LED. The
manufacturer will not accept liability for damages caused by the misuse or incorrect installation of
this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the City Painter 9000 LED is lowered from the ceiling or high joists, professional trussing systems have
to be used.
•Use a clamp to mount the City Painter 9000 LED, with the mounting bracket, to the trussing system.
•The City Painter 9000 LED must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the City Painter 9000 LED, always make sure, that the area
below the installation site is secured and that there are not any unauthorized people around.

6
Ordercode: 40910
City Painter 9000 LED
The City Painter 9000 LED can be placed on a flat surface or mounted to any kind of truss with a clamp.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!

7
Ordercode: 40910
City Painter 9000 LED
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

8
Ordercode: 40910
City Painter 9000 LED
Description of the device
Features
The Showtec City Painter 9000 LED is an extremely bright LED based fixture, powerful enough to illuminate
large architectrural facades or entire stage areas.
High Lightoutput
RGBWA colormixing
Including flightcase
Quicklock adaptors for easy truss mounting
Low power consumption
Roadproof design
Input voltage: 100-240V, 50/60Hz
Power consumption: 300W max (full output)
DMX linking: 30 pcs
DMX channels: 3, 4, 5, 6, 7 or 11 channels
4-digit LED display for easy setup
Light source: 22 x 3W Red LEDs, 22 x 3W Green LEDs, 22 x 3W Blue LEDs, 12 x 3 W White (6000K) LEDs
and 12 x 3W Amber LEDs
Lumens: 9000+
Lux (@2m): 29000+
Efficiency: 33 lm/W
Driver current: 700/1000mA
Control modes: Static colors, Auto run, DMX, Master/Slave
Control protocol: DMX-512
Dimmer: 0-100%
Strobe: 0-20Hz
Protection rate: IP-67 (with display cover installed)
Beam Angle: 30°
Max. projection distance: 150m
Connections: Dedicated IP67 Power & Data connectors
Cooling: Convection
Dimensions: 784 x 252 x 310 mm (LxWxH)
Weight: 24,0 kg
Note: Knowledge of DMX is required to fully utilize this unit.
Optional accessories
43600 IP65 Power extensioncable for Spectral Series 1,5m
43601 IP65 Power extensioncable for Spectral Series 5,0m
43602 IP65 Power extensioncable for Spectral Series 10,0m
43610 IP65 Data extensioncable for Spectral Series 1,5m
43611 IP65 Data extensioncable for Spectral Series 5,0m
43612 IP65 Data extensioncable for Spectral Series 10,0m
A9920301 Artecta Connection device 3 poles IP68
A9920303 Artecta Connection device 3 poles

9
Ordercode: 40910
City Painter 9000 LED
Overview
Fig. 01
01) 22 x 3W Red LEDs, 22 x 3W Green LEDs, 22 x 3W Blue LEDs, 12 x 3 W White (6000K) LEDs and 12 x 3W
Amber LEDs
02) Special 3-pin power cable IN IP-67
03) Special 3-pin DMX signal cable IN/OUT IP-67
04) 4-digit LED display + menu buttons
Installation
Remove all packing materials from the City Painter 9000 LED. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.
Control Modes
There are 4 modes:
•Static Colors
•Auto Mode
•Master/Slave
•DMX-512 (3CH, 4CH, 5CH, 6CH, 7CH, 11CH)

10
Ordercode: 40910
City Painter 9000 LED
One City Painter 9000 LED (Static colors and Auto Mode)
01) Place the effect light on a flat surface. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the City Painter is not connected with a DMX cable, it functions as a stand-alone device.
Please see pages 15-16 for more information about the Static colors and Auto Mode.
Multiple City Painters 9000 LED (Master/Slave control)
01) Place the effect light on a flat surface. Leave at least 0,5 meter on all sides for air circulation.
02) Use a 3-pin XLR cable to connect the City Painters and other devices.
The pins:
01) Earth
02) Signal -
03) Signal +
03) Link the units as shown in Fig. 02. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
You can use the same functions on the master device as described on pages 15-16 (Static colors or
Auto Mode). This means that you can set your desired operation mode on the master device and
all slave devices will react the same as the master device.
Multiple City Painters 9000 LED (Master/Slave control)
Fig. 02

11
Ordercode: 40910
City Painter 9000 LED
Multiple City Painters 9000 LED (DMX Control)
01) Place the effect light on a flat surface. Leave at least 0,5 meter on all sides for air circulation.
02) Use a 3-pin XLR cable to connect the City Painters and other devices.
03) Link the units as shown in Fig. 03. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
04) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple City Painters 9000 LED DMX Set Up
Fig. 03
Note : Link all cables before connecting electric power

12
Ordercode: 40910
City Painter 9000 LED
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin. Ordercode
FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
•DAP Audio DMX adapter: 3-pin/5-pin. Ordercode FLA30.
Note: You cannot plug a standard DMX cable directly into the connector. Be sure to use
the special extension cables (43610, 43611 or 43612) or the included special 3-pin to DMX
IN / 3-pin to DMX OUT cables to connect with regular DMX data cables.
The City Painter 9000 LED can be operated with a controller in control mode or without the controller in
stand-alone mode.

13
Ordercode: 40910
City Painter 9000 LED
Control Panel
A) LED display
B) MENU button
C) SET button
D) UP button
E) DOWN button
Fig. 04
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the base of the device allows you to assign DMX fixture addresses, which is the first
channel with which the City Painter will respond to the controller.
Please note, when you use the controller, the unit has 11 channels.
When using multiple City Painters, make sure you set the DMX addresses right.
Therefore, the DMX address of the first City Painter should be 1(001); the DMX address of the second City
Painter should be 1+11=12 (012); the DMX address of the third City Painter should be 12+11=23 (023), etc.
Please, be sure that you do not have any overlapping channels in order to control each City Painter
correctly. If two or more City Painters are addressed similarly, they will work similarly.
Controlling:
After having addressed all City Painter fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the City Painter will automatically detect whether DMX 512 data is received or
not. If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the City Painter.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.

14
Ordercode: 40910
City Painter 9000 LED
Menu Overview

15
Ordercode: 40910
City Painter 9000 LED

16
Ordercode: 40910
City Painter 9000 LED
Main Menu Options
Manual Mode (Static Color Mode)
Built-in and custom programs Mode
DMX address
Master/ slave mode
DMX configuration
Settings
Edit mode
Calibration menu 1
Calibration menu 2
Optional Wireless DMX mode
Keylock mode
1. Static Colors
With this menu you can set the static colors.
01) Press the MODE button until the display shows .
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to toggle between the static colors (Red, Green, Blue, White and
Amber) and strobe.
04) Once you have chosen the desired color with the UP/DOWN buttons , press the SET button to adjust
the color intensity. The adjustment range is between 0-255, from dark to brightest. You can set this
with the UP/DOWN buttons.
05) When the display shows , press the UP/DOWN buttons to increase/decrease
the strobe frequency. The adjustment range is between 0-20, from OFF to high strobe frequency.
06) You can combine RED, GREEN, BLUE, WHITE and AMBER to create an infinite range of colors (0-255).

17
Ordercode: 40910
City Painter 9000 LED
2. Built-in and custom programs
With this menu you can set the built-in programs or choose your edited custom programs.
01) Press the MENU button on the device until the display shows .
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to choose one of the 10 uneditable built-in programs (AT01-AT10) and
10 editable presets (PR.C1-PR.10) which can be edited in Edit mode (see page 19).
04) The device will now run the desired built-in program or edited custom program.
3. DMX-address
With this menu you can set the desired DMX address.
01) Press the MENU button until the display shows .
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to choose the desired DMX address. There are 512 available DMX
addresses to choose from .
4. Master/Slave Mode
With this menu, you can set the device as a slave.
01) Press the MENU button until the display shows .
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to toggle between the 2 following options:
DMX/Master Mode
Slave Mode
04) When the display shows , the device is operating in DMX/Master Mode.
05) When the display shows , the device is operating in Slave Mode. It means that it will react the
same as the master device.
5. DMX configuration
With this menu you can set the desired DMX channel mode (personality).

18
Ordercode: 40910
City Painter 9000 LED
01) Press the MENU button until the display shows .
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to toggle between the following DMX channel modes:
TOUR:
11 channels
AR3.S:
7 channels
ARC.1:
3 channels
HSV:
3 channels
AR1.D:
4 channels
ARC.3:
5 channels
AR3.D:
6 channels
6. Settings
With this menu you can set the device’s settings.
01) Press the MENU button until the display shows .
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to toggle between the menus described below.
6.1 Upload
With this menu you can export current programs from the master device to the connected slave devices.
01) Press the UP/DOWN buttons until the display shows .
02) Press the SET button to open the menu.
03) Insert the password: UP>DOWN>UP>DOWN and press the SET button to confirm.
04) The display will show .
05) While exporting, the devices will light up yellow.
06) If there are any problems with exporting, the master and the slave devices will light up red.
07) If the operation is completed successfully, the master and the slave devices will light up green.
6.2 Reset
With this menu you can reset the custom programs.
01) Press the UP/DOWN buttons until the display shows .
02) Press the SET button to open the menu.
03) Insert the password: UP>DOWN>UP>DOWN and press the SET button to confirm.
04) The display will show END and the custom programs will have been reset.
6.3 Dimmer
With this menu you can adjust the dimmer.
01) Press the UP/DOWN buttons until the display shows .
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to choose one of the 4 dimmer speed options (DIM1-DIM4, from fast to
slow) and OFF.
04) If you choose OFF, then RGBW and the master dimmer are linear.
05) The dimmer settings do not have any influence on the device’s performance in DMX TOUR mode.
The DMX settings override the dimmer settings.

19
Ordercode: 40910
City Painter 9000 LED
6.4 Color
With this menu you can adjust the color calibration functions.
01) Press the UP/DOWN buttons until the display shows .
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to toggle between the following 3 options:
Off
RGB to White
Adjusted output
04) When the display shows , the RGB settings are: 255, 255, 255. The RGB values are not adjusted
and the output is the most powerful.
05) When the display shows , RGB to White is active. This means RGB = 255, 255, 255. The color
displayed is the specific color which you have calibrated in CAL 2 RGB.W menu.
06) When the display shows , the RGB output is adjusted to a standard preset universal color. In
this way, different City Painter versions are color-balanced in order to match each other.
7. Edit Mode
With this menu you can create your own custom shows.
01) Press the MENU button until the display shows .
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to choose the desired custom program: PR.01 –PR.10.
04) Press the ENTER button to proceed to the scene choice. Each custom program has 30 scenes, which
can be edited.
05) Once you have chosen the desired scene, press the SET button to enter the settings.
06) Press the UP/DOWN buttons to toggle between RED, GREEN, BLUE, WHITE, AMBER, STROBE, STEP TIME
and FADE options.
07) When the display shows RED, GREEN, BLUE, WHITE and AMBER, press the SET button to open the
menu and press the UP/DOWN buttons to increase/decrease the LED brightness. The adjustment
range is between 0-255, from OFF to FULL ON.
08) When the display shows STROBE, press the SET button to open the menu and press the UP/DOWN
buttons to set the strobe frequency. The adjustment range is between 0-20, from OFF to high
frequency.
09) When the display shows TIME, press the SET button to open the menu and press the UP/DOWN
buttons to set the duration of a scene. The adjustment range is between 0-255, from 0 to 255
seconds.
10) When the display shows FADE, press the SET button to open the menu and press the UP/DOWN
buttons to set the fade time between particular scenes. The adjustment range is between 0-255,
from 0 to 255 seconds.
