Show Tec Pixel Square 16 COB User manual

Pixel Square 16 COB V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 41267
MANUAL
ENGLISH

1
Ordercode: 41267
Pixel Square 16 COB
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Frontside..........................................................................................................................................................................7
Backside .........................................................................................................................................................................8
Installation...........................................................................................................................................................................8
Set Up and Operation .......................................................................................................................................................8
Control Modes...............................................................................................................................................................9
One Pixel Square (Auto mode, Built-in programs and Manual mode) ..........................................................9
One Pixel Square (Sound-controlled)....................................................................................................................9
Multiple Pixel Squares (Master/Slave Mode)........................................................................................................9
Multiple Pixel Squares (DMX Control) ..................................................................................................................10
Fixture Linking...............................................................................................................................................................11
Data Cabling...............................................................................................................................................................11
Control Panel ...............................................................................................................................................................12
Control Mode ..............................................................................................................................................................12
DMX Addressing ..........................................................................................................................................................12
Main Menu Options....................................................................................................................................................13
1. Static colors ..........................................................................................................................................................13
2. Built-in programs ..................................................................................................................................................13
3. Auto mode ...........................................................................................................................................................13
4. Sound-controlled mode ....................................................................................................................................14
5. DMX-512 mode....................................................................................................................................................14
6. Master/Slave mode ............................................................................................................................................14
DMX Channels .............................................................................................................................................................14
2 channels ................................................................................................................................................................14
3 channels ................................................................................................................................................................15
5 channels ................................................................................................................................................................15
12 channels ..............................................................................................................................................................16
24 channels ..............................................................................................................................................................18
48 channels ..............................................................................................................................................................19
Maintenance....................................................................................................................................................................21
Replacing the Fuse.....................................................................................................................................................21
Troubleshooting ...............................................................................................................................................................21
No Light.........................................................................................................................................................................21
No Response to DMX..................................................................................................................................................21
Product Specifications....................................................................................................................................................23
Dimensions........................................................................................................................................................................24
Notes ..................................................................................................................................................................................25

2
Ordercode: 41267
Pixel Square 16 COB
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec Pixel Square 16 COB
1 mounting bracket
2 adjustment screws
IEC power cable 1,5 m
User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
•be qualified
•follow the instructions of this manual
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.

3
Ordercode: 41267
Pixel Square 16 COB
This device contains no user-serviceable parts. Refer to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged.
Always hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device.
Leave the device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. The device must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.
•The user is responsible for correct positioning and operating of the Pixel. The manufacturer will not
accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.

4
Ordercode: 41267
Pixel Square 16 COB
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer!
Procedure:
•If the projector is lowered from the ceiling or high joists, professional trussing systems have to be used.
•Use a clamp to mount the projector, with the mounting bracket, to the trussing system.
•The projector must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, de-rigging or servicing the projector, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.

5
Ordercode: 41267
Pixel Square 16 COB
The Pixel Square can be placed on a flat stage floor or mounted to any kind of truss with a clamp, or
attached to each other by means of the retractable, built-in hooks.
Improper installation can cause serious injuries to people and/or damage of property !
Connection with the mains
Connect the device to the mains with the power plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries to people and/or damage of property!

6
Ordercode: 41267
Pixel Square 16 COB
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

7
Ordercode: 41267
Pixel Square 16 COB
Description of the device
Features
The Showtec Pixel Square 16 COB is a LED fixture with high output and great effects.
Input voltage: 100-240V, 60/50 Hz
Power consumption: 170W
Light source: 16 x 9W COB RGB LED
Beam Angle: 55°
LCD display for easy setup
Control protocol: DMX-512
DMX channels: 2, 3, 5, 12, 24, 48 channels
Color mixing: RGB
Color range: 16,7 million additive colors
Control modes: Static Colors, Built-in programs, Auto, Sound-controlled, DMX-512, Master/Slave
Metal & Flame-retardant plastic housing
Dimmer: 0-100%
Strobe: 0-20Hz
IEC power connector IN/OUT & 3-pin XLR IN/OUT
Fuse: F1,5A/250V
Dimensions: 340 x 105 x 400 mm (LxWxH)
Weight: 6,7 kg
Frontside
Fig. 01
01) Mounting bracket with inclination screw
02) 16 x 9W COB RGB LED
03) Adjustment screw

8
Ordercode: 41267
Pixel Square 16 COB
Backside
04) Safety eye
05) 3-pin DMX signal connector OUT
06) 3-pin DMX signal connector IN
07) Ground/earth connection
08) IEC power connector 100-240V IN + Fuse F1,5A/250V
09) IEC power connector 100-240V OUT
10) LCD display + menu buttons
Installation
Remove all packing materials from the Pixel Square 16 COB . Check that all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Fig. 02

9
Ordercode: 41267
Pixel Square 16 COB
Control Modes
There are 6 modes:
Auto mode
Built-in programs
Static colors
Sound-controlled
Master/Slave
DMX-512 (2CH, 3CH, 5CH, 12CH, 24CH, 48CH)
One Pixel Square (Auto mode, Built-in programs and Static colors)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Pixel Square is not connected with a DMX cable, it functions as a stand-alone device.
05) Please see page 13 for more information about Auto mode, Built-in programs and Static colors.
One Pixel Square (Sound-controlled)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Pixel Square is not connected with a DMX cable, it functions as a stand-alone device.
05) Please see page 14 for more information about the Sound-controlled mode.
Multiple Pixel Squares (Master/Slave Mode)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-pin XLR cable to connect the Pixel Squares.
The pins:
01) Earth
02) Signal (-)
03) Signal (+)
05) Link the units as shown in Fig. 03, connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units. You can
use the same functions on the master device as described on pages 13-14 (Auto, Built-in programs,
Static colors or Sound-controlled). This means that you can set your desired operation mode on the
master device and all slave devices will react the same as the master device.
Multiple Pixel Squares Master/Slave Set Up
Fig. 03

10
Ordercode: 41267
Pixel Square 16 COB
Multiple Pixel Squares (DMX Control)
01) Fasten the effect light onto firm trussing. Leave at least 1 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-pin XLR cable to connect the Pixel Square and other devices.
05) Link the units as shown in Fig. 04, Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
06) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple Pixel Squares DMX Set Up
Fig. 04

11
Ordercode: 41267
Pixel Square 16 COB
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).

12
Ordercode: 41267
Pixel Square 16 COB
Control Panel
A) LCD display
B) MODE button
C) SETUP button
D) UP button
E) DOWN button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address the next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign the DMX fixture address, which is the
first channel from which the Pixel Square will respond to the controller.
Please note when you use the controller, the unit has 48 channels.
When using multiple Pixel Square, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Pixel Square should be 1(001); the DMX address of the second Pixel
Square should be 1+48=49 (049); the DMX address of the third Pixel Square should be 49+48=97 (097), etc.
Please, make sure that you do not have any overlapping channels in order to control each Pixel Square
correctly. If two or more Pixel Squares are addressed similarly, they will work similarly.
Controlling:
After having addressed all Pixel Square fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the Pixel Square will automatically detect whether DMX-512 data is received or
not. If there is no data received at the DMX-input, the “LED“ on the control panel will not flash.
The problem may be:
•The XLR cable from the controller is not connected with the input of the Pixel Square.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 20 seconds
When no button is pressed for 20 seconds, the display will turn off.
To light up the display, you have to press the MODE, SETUP, UP or DOWN button.
Once you have pressed the button, the display will light up.

13
Ordercode: 41267
Pixel Square 16 COB
Main Menu Options
Static colors
Built-in programs
Auto mode
Sound-controlled mode
DMX-512 mode
Master/Slave mode
1. Static colors
With this menu you can set the device’s static colors.
01) While in the main menu, press the MODE button until the display shows .
02) Repeatedly press the SETUP button to switch between the colors (RED, GREEN, BLUE). Observe the
selection bar change its location.
03) Once you have chosen the desired color, press the UP/DOWN buttons to increase/decrease the
color brightness. The adjustment range is between 0-255, from OFF to full ON.
04) You can combine RED, GREEN and BLUE to create an infinite range of colors (0-255).
2. Built-in programs
With this menu, you can set the device’s built-in programs.
01) While in the main menu, press the MODE button until the display shows .
02) Repeatedly press the SETUP button to switch between 3 options. Observe the selection bar change
its location:
Built-in program number (RUN PROGRAM): 25 programs
Program speed (SP): 1-100, from slow to fast
Strobe frequency (FS): 0-100, from OFF to highest frequency
03) Press the UP/DOWN buttons to increase/decrease the values.
3. Auto mode
With this menu, you can set the device’s Auto mode. The device will play all the built-in programs in a
sequence, for the desired amount of times.
01) While in the main menu, press the MODE button until the display shows .
02) Repeatedly press the SETUP button to switch between 3 options. Observe the selection bar change
its location:
Auto mode repetition number (AUTO times): up to 100 repetitions
Auto mode speed (SP): 1-100, from slow to fast
Strobe frequency (FS): 0-100, from OFF to highest frequency
03) Press the UP/DOWN buttons to increase/decrease the values

14
Ordercode: 41267
Pixel Square 16 COB
4. Sound-controlled mode
With this menu, you can set the device’s sound-controlled mode. The device will react to the beat of the
background music.
01) While in the main menu, press the MODE button until the display shows .
02) Press the UP/DOWN buttons to increase/decrease the device’s sound sensitivity. The adjustment
range is between 0-31, from OFF to highest sound sensitivity.
5. DMX-512 mode
With this menu, you can adjust the device’s DMX settings.
01) While in the main menu, press the MODE button until the display shows .
02) Repeatedly press the SETUP button to switch between 2 options. Observe the selection bar change
its location:
DMX starting address: 001-512
Current channel mode: 2, 3, 5, 12, 24, 48 channels
03) Press the UP/DOWN buttons to increase/decrease the values.
6. Master/Slave mode
With this menu, you can set the device as a slave.
04) While in the main menu, press the MODE button until the display shows .
05) The device is now operating in slave mode and it will react the same as the master device.
DMX Channels
2 channels
Channel 1 –Control modes
0
Not functional
1-7
Red
8-15
Red+Green
16-23
Green
24-31
Green+Blue
32-39
Blue
40-47
Red+Blue
48-55
Red+Green+Blue
56-63
Program 1
64-71
Program 2
72-79
Program 3
80-87
Program 4
88-95
Program 5
96-103
Program 6
104-111
Program 7
112-119
Program 8
120-127
Program 9
128-135
Program 10
136-143
Program 11
144-151
Program 12
152-159
Program 13
160-167
Program 14
168-175
Program 15
176-183
Program 16
184-191
Program 17
192-199
Program 18
200-207
Program 19
208-215
Program 20

15
Ordercode: 41267
Pixel Square 16 COB
216-223
Program 21
224-231
Program 22
232-239
Program 23
240-247
Program 24
248-255
Sound-controlled mode
Channel 2 –Program speed CH1 must be set between 56-247
0-255
Program speed adjustment, from slow to fast
Channel 2 –Sound sensitivity CH1 must be set between 248-255
0-255
Sound sensitivity, from OFF to highest sensitivity
3 channels
Channel 1 –Red
0-255
Gradual adjustment Red, from dark to brightest
Channel 2 –Green
0-255
Gradual adjustment Green, from dark to brightest
Channel 3 –Blue
0-255
Gradual adjustment Blue, from dark to brightest
5 channels
Channel 1 –Red Dimmer must be open
0-255
Gradual adjustment Red, from dark to brightest
Channel 2 –Green Dimmer must be open
0-255
Gradual adjustment Green, from dark to brightest
Channel 3 –Blue Dimmer must be open
0-255
Gradual adjustment Blue, from dark to brightest
Channel 4 –Dimmer
0-255
Dimmer intensity, from OFF to full ON

16
Ordercode: 41267
Pixel Square 16 COB
Channel 5 –Strobe Dimmer must be open
0-255
Strobe frequency, from OFF to highest frequency
12 channels
Channel 1 –Red 1
0-255
Gradual adjustment Red, from dark to brightest
Channel 2 –Green 1
0-255
Gradual adjustment Green, from dark to brightest
Channel 3 –Blue 1
0-255
Gradual adjustment Blue, from dark to brightest
Channel 4 –Red 2
0-255
Gradual adjustment Red, from dark to brightest
Channel 5 –Green 2
0-255
Gradual adjustment Green, from dark to brightest
Channel 6 –Blue 2
0-255
Gradual adjustment Blue, from dark to brightest

17
Ordercode: 41267
Pixel Square 16 COB
Channel 7 –Red 3
0-255
Gradual adjustment Red, from dark to brightest
Channel 8 –Green 3
0-255
Gradual adjustment Green, from dark to brightest
Channel 9 –Blue 3
0-255
Gradual adjustment Blue, from dark to brightest
Channel 10 –Red 4
0-255
Gradual adjustment Red, from dark to brightest
Channel 11 –Green 4
0-255
Gradual adjustment Green, from dark to brightest
Channel 12 –Blue 4
0-255
Gradual adjustment Blue, from dark to brightest

18
Ordercode: 41267
Pixel Square 16 COB
24 channels
Channel 1 –Red 1
0-255
Gradual adjustment Red, from dark to brightest
Channel 2 –Green 1
0-255
Gradual adjustment Green, from dark to brightest
Channel 3 –Blue 1
0-255
Gradual adjustment Blue, from dark to brightest
Channel 4 –Red 2
0-255
Gradual adjustment Red, from dark to brightest
Channel 5 –Green 2
0-255
Gradual adjustment Green, from dark to brightest
Channel 6 –Blue 2
0-255
Gradual adjustment Blue, from dark to brightest

19
Ordercode: 41267
Pixel Square 16 COB
Channel 22 –Red 8
0-255
Gradual adjustment Red, from dark to brightest
Channel 23 –Green 8
0-255
Gradual adjustment Green, from dark to brightest
Channel 24 –Blue 8
0-255
Gradual adjustment Blue, from dark to brightest
48 channels
Channel 1 –Red 1
0-255
Gradual adjustment Red, from dark to brightest
Channel 2 –Green 1
0-255
Gradual adjustment Green, from dark to brightest
Channel 3 –Blue 1
0-255
Gradual adjustment Blue, from dark to brightest
Channel 4 –Red 2
0-255
Gradual adjustment Red, from dark to brightest
