Show Tec GALACTIC BEAM G40 V1 User manual

Galactic Beam G40 V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 51315
MANUAL
ENGLISH

1
Ordercode: 51315
Galactic Beam G40
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................3
Operating Determinations ..........................................................................................................................................4
Laser safety for a Class 3B Laser Product .................................................................................................................5
Rigging ............................................................................................................................................................................6
Connection with the mains.........................................................................................................................................7
Return Procedure..........................................................................................................................................................7
Claims..............................................................................................................................................................................7
Description of the device.................................................................................................................................................8
Overview ........................................................................................................................................................................8
Backside .........................................................................................................................................................................9
Installation.........................................................................................................................................................................10
Set Up and Operation .....................................................................................................................................................11
Control Modes.............................................................................................................................................................12
One Galactic Auto run (visual effects) ...............................................................................................................12
One Galactic Sound-controlled...........................................................................................................................12
Multiple Galactics (Master/Slave control) ..........................................................................................................12
Multiple Galactics (DMX Control).........................................................................................................................13
Fixture Linking...............................................................................................................................................................14
Data Cabling...............................................................................................................................................................14
Control Panel ...............................................................................................................................................................15
Control Mode ..............................................................................................................................................................15
DMX Addressing ..........................................................................................................................................................15
Menu Overview...........................................................................................................................................................16
Main Menu Options.................................................................................................................................................17
1. Automatic / Sound-active Show ......................................................................................................................17
2. Automatic / Sound-active Patterns .................................................................................................................17
3. Sound-active to Beam ON ................................................................................................................................17
4. Sound-active to Beam OFF ...............................................................................................................................18
5. Sensitivity Mode ...................................................................................................................................................18
6. DMX Mode ............................................................................................................................................................18
7. Slave Mode...........................................................................................................................................................18
8. Reverse Setting.....................................................................................................................................................18
9. Factory default setting .......................................................................................................................................18
DMX Channels .............................................................................................................................................................19
8 Channels ................................................................................................................................................................19
Patterns ..............................................................................................................................................................................20
Maintenance....................................................................................................................................................................21
Replacing a Fuse ........................................................................................................................................................21
Troubleshooting ...............................................................................................................................................................22
No Light.........................................................................................................................................................................22
No Response to DMX..................................................................................................................................................22
Product Specification .....................................................................................................................................................24
Dimensions........................................................................................................................................................................25

2
Ordercode: 51315
Galactic Beam G40
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
●Showtec Galactic Beam G40 with IEC powercable 1,75m
●Remote plug and 2 key
●User manual

3
Ordercode: 51315
Galactic Beam G40
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
●be qualified
●follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
Never let the power-cord come into contact with other cables! Handle the power-cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never place any material over the lens.
Never look directly into the light source.
Never leave any cables lying around.
Never aim the laser beam at people or animals!
Never use the device during thunderstorms, unplug the device immediately.
Never point a laser at aircraft, this is a federal offense.
Never point un-terminated laser beams into the sky.
Never open the laser housing. The high laser power levels inside of the protective housing can start
fires, burn skin and will cause instant eye injury.
Do not insert objects into air vents.
Do not connect this device to a dimmerpack.
Do not open the device and do not modify the device.
Do not point lasers at highly reflective surfaces such as windows, mirrors and shiny metal. Even laser
reflections can be hazardous.
Do not expose the output optic (aperture) to cleaning chemicals
Do not use laser if the laser appears to be emitting only one or two beams
Do not use laser if housing is damaged or open, or if optics appear damaged in any way.
Do not operate laser without first reading and understanding all safety and technical data in this
manual. Never look into the laser aperture or laser beams
Do not switch the device on and off in short intervals, as this would reduce the device’s life.
Do not shake the device. Avoid brute force when installing or operating the device.
After set up and prior to public use, test laser to ensure proper function. Do not use the laser if any
defect is detected. Do not use, if the laser emits only one or two laser beams rather than
dozens/hundreds, as this could indicate damage to the diffraction grating optic, and could allow
emission of higher laser levels.
Only use device indoor, avoid contact with water or other liquids.
Only operate the fixture after having checked that the housing is firmly closed and all screws are
tightly fastened.
Only operate the device after having familiarized with its functions.
Avoid flames and do not put close to flammable liquids or gases.
Always check the regulations when using a class IIIB laser product.

4
Ordercode: 51315
Galactic Beam G40
Always check and position the laser before anybody enters the room, when the laser is facing an
area with people
Always keep case closed while operating.
Always allow free air space of at least 50 cm around the unit for ventilation.
Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power-cord by the plug. Never pull out the plug by tugging the power-cord.
Make sure that the device is not exposed to extreme heat, moisture or dust.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power-cord is never crimped or damaged. Check the device and the power-
cord from time to time.
If the external cable is damaged, it has to be replaced by a qualified technician.
If the lens is obviously damaged, it has to be replaced. So that its functions are not impaired, due to
cracks or deep scratches.
If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
For adult use only. Device must be installed out of the reach of children. Never leave the unit running
unattended.
Never attempt to bypass the thermostatic switch or fuses.
For replacement use fuses of same type and rating only.
The operation of a class 3B laser show laser is only allowed if the show is controlled by a skilled and
well-trained operator familiar with the data included in this manual.
The user is responsible for correct positioning and operating of the Galactic Beam G40. The
manufacturer will not accept liability for damages caused by the misuse or incorrect installation of
this device.
This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
The laser will only work between 15-35ºC.
After 3 hours working, you must shut off the laser and let the laser diode cool off for 30 minutes,
otherwise the laser could be damaged and the warranty becomes void.
Repairs, servicing and electric connection must be carried out by a qualified technician.
WARRANTY: Till one year after date of purchase.
Operating Determinations
●This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
●The minimum distance between light-output and the illuminated surface must be more than 1 meter.
●The maximum ambient temperature ta = 35°C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 30° C.
●If this device is operated in any other way, than the one described in this manual, the product may
suffer damages and the warranty becomes void.
●Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!

5
Ordercode: 51315
Galactic Beam G40
Laser safety for a Class 3B Laser Product
CAUTION: AVOID EXPOSURE TO BEAM: Avoid direct eye contact with laser
light. Never intentionally expose your eyes or others to direct laser radiation.
Compliance Statement
Your Galactic Laser has been designed to comply with FDA and IEC Standards for it classification.
The Galactic is a Class IIIB laser product.
Laser Safety and Compliance Information
The Galactic is manufactured to comply with the IEC 60825-1 and in accordance with U.S. Food and
Drug Administration (FDA) Standards Listed under FDA Document 21 CFR 1040 and subsequent laser
notices.
Product Classification and Manufacturing Label Identification
Laser Classification
Class IIIB
Cooling
TE Cooling
Laser medium
wavelength 532 nm / Green (DPSS Nd:YV04)
Output
>40mW Green
Beam Diameter
<18mm at aperture
Pulse Data All pulses
< 4Hz (>0.25sec)
Divergence (each beam)
<2 mrad
Divergence (total light)
<160 degrees
The legal requirements for using laser entertainment products vary from country to country. The user is
responsible for the legal requirements at the location/country of use.
Further guidelines and safety programs for safe use of lasers can be found in the ANSI Z136.1 Standard
“For Safe Use of Lasers”, available from www.laserinstitute.org. Many local governments, corporations,
agencies, military and others, require all lasers to be used under the guidelines of ANSI Z136.1. Laser
Display guidance can be obtained via the International Laser Display Association, www.laserist.org.
CAUTION: The use of corrective eye wear or optics for viewing at distances such as telescopes or
binoculars within a distance of 100mm may pose an eye hazard.
This laser product is a Class IIIB laser and has an Interlocked
housing.
There are no user serviceable parts inside. Tampering or
removing warranty seals will void your products limited
warranty.
Combo label with the Product Model Number, Serial Number,
Date of Manufacturing, Laser Light Warning Label, Warranty
Void Label and Interlocked Housing Label

6
Ordercode: 51315
Galactic Beam G40
Proper Usage Safety and Compliance Information
According to FDA Regulations you
should operate this product as stated on
the left.
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
●If the Galactic is lowered from the ceiling or high joists, professional trussing systems have to be used.
●Use a clamp to mount the Galactic, with the mounting-bracket, to the trussing system.
●The Galactic must never be fixed swinging freely in the room.
●The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety-cable.
●When rigging, derigging or servicing the Galactic, always make sure, that the area below the
installation place is blocked and staying in the area is forbidden.
The Galactic can be placed on a flat stage floor or mounted to any kind of truss by a clamp.
Improper installation can cause serious damage to people and property !

7
Ordercode: 51315
Galactic Beam G40
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
FASE
N
BLUE
BLACK
SILVER
NULL
YELLOW/GREEN
GREEN
GREEN
EARTH
Make sure that the device is always connected properly to the earth!
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail aftersal[email protected] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

8
Ordercode: 51315
Galactic Beam G40
Description of the device
Features
The Showtec Galactic Beam G40 is a laser effect with high output and great effects.
●40mW Green Fatbeam Laser
●Strong solid beam
●By using fat-beam technology we are able to use 40mW laser and still be compliance to IEC-60825
●When using multiple units together, you can make a great and cost effective beam-show
●Power Input: AC 100-240V, 50/60Hz
●Power Consumption: 12 Watt
●Beam Diameter <18mm at aperture
●Laser Class: 3B
●Laser Modulation: TTL
●Laser Safety: EN/IEC 60825-1 Ed 2, 2007-03
●Laser Color: Green
●Laser Power: >40mW 532nm Green
●Scan Angle: +/-80°
●Control Modes: Auto, Sound, Master/Slave, DMX
●Divergence (each beam) <2 mrad; Divergence (total light) <160 degrees
●3-pin DMX In and 3-pin DMX Out
●Clear LCD display for all settings
●Compact strong metal housing
●Music-controlled via built-in microphone
●8 DMX Channels
●Safety Features: Key switch, Interlock
●Fuse 1L / 250V
●Dimensions: 300 x 88 x 222 mm (LxWxH)
●Weight: 2,3 Kg
●Accessories: 2 Keys, Interlock test connector
Overview
Fig. 01

9
Ordercode: 51315
Galactic Beam G40
Backside
Fig. 02
01) ON/OFF
02) Fuse 1 A/250V
03) IEC Powerconnector
04) Lock On/Off
05) 3-pin DMX signal connector (OUT)
06) 3-pin DMX signal connector (IN)
07) Remote Control
08) LCD Display + Menu Buttons
09) Cooling Fan
10) Built-in Microphone
NOTE: Knowledge of DMX is required to fully utilize this unit.

10
Ordercode: 51315
Galactic Beam G40
Installation
Remove all packing materials from the Galactic. Check that all foam and plastic padding is removed.
Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
By using the screw hole(s) on the side and/or top of the fixture, the laser(s) can be installed in any desired
position. Check below for some examples.

11
Ordercode: 51315
Galactic Beam G40
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply. The device can be music-controlled by its built-in
microphone.
The Interlock plug/remote plug and safety keys are included in the box.
The interlock is the “included-in-the-box” successor for the optional remote interlock (51316)
They should be kept with the Galactic laser !!!
The following safety precautions should be followed:
●The interlock plug should be placed on the backside (7) of your
Galactic laser.
●The keys should be put into the lock (4) of your Galactic laser.
Warning
Exclusion of liability
Be aware that in some countries, there are additional regulations, regarding the use of laser devices.
Therefore, we strongly advise you to verify your national laws with your authorities: We don’t take any
responsibility for eventual discrepancies, changes or adaptions regarding lawful use of laser devices.

12
Ordercode: 51315
Galactic Beam G40
Control Modes
There are 4 modes:
Auto run (visual effects)
Sound-controlled
Master/Slave
DMX512
One Galactic Auto run (visual effects)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Galactic is not connected by a DMX-cable, it functions as a stand-alone device.
05) Please see page 17 for more information about the Auto run visual effects.
One Galactic Sound-controlled
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Galactic is not connected by a DMX-cable, it functions as a stand-alone device.
05) Please see page 17+18 for more information about the about the sound-control options.
Multiple Galactics (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-p XLR cable to connect the Galactic.
The pins:
1. Earth
2. Signal (-)
3. Signal (+)
05) Link the units as shown in (Fig. 03), Connect a DMX signal cable from the first unit's DMX "out" socket
to the second unit's "in" socket. Repeat this process to link the second, third, and fourth units. You can
use the same functions on the master device as described on page 17+18 (Autorun or Music
control). This means on the master device you can set your desired operation Mode and all slave
devices will react the same as the master device.
Multiple Galactics (Master/Slave control)
Fig. 03

13
Ordercode: 51315
Galactic Beam G40
Multiple Galactics (DMX Control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-p XLR cable to connect the Galactics and other devices.
05) Link the units as shown in (figure 04), Connect a DMX signal cable from the first unit's DMX "out" socket
to the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
06) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly. Design your
show according to your DMX controller functions.
Multiple Galactics DMX Set Up
Max. 30 Galactics
Fig. 04
Note : Link all cables before connecting electric power

14
Ordercode: 51315
Galactic Beam G40
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows on two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy chained in one single line. To comply with the
EIA-485 standard no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of Galactics on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
The Galactic can be operated with a controller in control mode or without the controller in stand-alone
mode.

15
Ordercode: 51315
Galactic Beam G40
Control Panel
A)
B)
C)
D)
E)
LED Display
Func button
Up Button
Down Button
Enter Button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address the next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign the DMX fixture address, which is the
first channel from which the Galactic will respond to the controller.
Please note when you use the controller, the unit has 8channels.
When using multiple Galactics, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Galactics should be 1(001); the DMX address of the second
Galactic should be 1+8=9 (009); the DMX address of the third Galactic should be 9+8=17 (017), etc.
Please, be sure that you don’t have any overlapping channels in order to control each Galactic
correctly.
If two or more Galactics are addressed similarly, they will work similarly.
Controlling:
After having addressed all Galactic fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the Galactic will automatically detect whether DMX 512 data is received or not.
If there is no data received at the DMX-input, the “LED“ on the control panel will not flash.
The problem may be:
•The XLR cable from the controller is not connected with the input of the Galactic.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It’s necessary to insert a XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 30 seconds
When no button is pressed for 30 seconds, the display will turn off.
To light up the display, you have to press the FUNC button.
Once you have pressed the button, the display will light up.

16
Ordercode: 51315
Galactic Beam G40
Menu Overview

17
Ordercode: 51315
Galactic Beam G40
Main Menu Options
Automatic Show with Patterns and Solid Beams
Automatic / Sound-active Moving Beams
Fixed Beam Sound-active to Block
Fixed Beam Sound-active to Beam
Sensitivity Mode
DMX address
Master/Slave Mode
Pattern Mirror Reverse
Default Setting
You can only change a certain setting when the display is blinking.
If you can’t change a certain value, please press the Function-button once and then change the value.
1. Automatic / Sound-active Show
01) Press the FUNC button, until the display shows .
02) Use the Up / Down buttons to scroll through the entire menu.
Automatic Show with Patterns and Solid Beams
Sound Activated Show with Patterns and Solid Beams
03) Use the ENTER button to store your setting.
2. Automatic / Sound-active Patterns
01) Press the FUNC button, until the display shows .
02) Use the Up / Down buttons to scroll through the entire menu.
Automatic Show with moving Solid Beams (Fast)
Automatic Show with moving Solid Beams (Slow)
Sound Activated Show with random moving Solid Beams
03) Use the ENTER button to store your setting.
3. Sound-active to Beam ON
01) Press the FUNC button, until the display shows .
02) The Galactic Beam is now sound activated to Beam ON.

18
Ordercode: 51315
Galactic Beam G40
4. Sound-active to Beam OFF
01) Press the FUNC button, until the display shows .
02) The Galactic Beam is now sound activated to Beam OFF.
5. Sensitivity Mode
01) Press the FUNC button, until the display shows .
02) You can choose 10 different Audio Sensitivity levels.
03) Use the Up / Down buttons to select the required address from .
No audio activation
Audio sensitivity, from low to highly sensitive.
04) Use the ENTER button to store your setting.
6. DMX Mode
01) Press the FUNC button, until the display shows .
02) You can choose 505 different DMX addresses.
03) Use the Up / Down buttons to select the required address from .
04) Use the ENTER button to store your setting.
7. Slave Mode
01) Press the FUNC button, until the display shows .
02) You can use the same functions on the master device as described on page 12.
This means, you can set your desired operation Mode on the master device and all slave devices will
react the same as the master device.
03) Use the ENTER button to store your setting.
8. Reverse Setting
01) Press the FUNC button, until the display shows .
02) Use the Up / Down buttons to select:
Vertical Reverse Setting (x-axis reverse)
Horizontal Reverse Setting (y-axis reverse)
03) Use the ENTER button to store your setting.
9. Factory default setting
01) Press the FUNC button, until the display shows .
02) Use the Up / Down buttons to select:
Default Horizontal Setting
Default Vertical Setting
03) Switch between both settings, by pressing the Up / Down buttons.
04) Use the ENTER button to store your setting.

19
Ordercode: 51315
Galactic Beam G40
DMX Channels
8 Channels
Channel 1 –Built-in Programs
0-31
Laser OFF
32-63
AdS (Auto show with slow solid beam effect)
64-95
AdF (Auto show with fast solid beam effect)
96-127
Sdr (Sound activated random solid beam)
128-159
AUT (Automatic Show with Patterns and Solid Beams)
160-191
SOU (Sound activated Show with Patterns and Solid Beams)
192-223
DMX (Solid Beam Mode)
224-255
DMX (Pattern Beam Mode)
Only when CH1 is set between 221-255, CH2-CH8 will function.
Channel 2 –32 Patterns
1-255
32 Individual patterns
Channel 3 –Zoom
0-127
Zoom from 100% –5%
128-169
Zoom In from 100% –5% (slow to fast)
170-209
Zoom Out from 5% - 100% (slow to fast)
210-255
Zoom In and Out from slow to fast
Channel 4 –Y-axis Rolling
0-127
0-359 degree fixed Y Axis rolling
128-191
Clockwise rolling from slow to fast
192-255
Counterclockwise rolling from slow to fast
Channel 5 –X-axis Rolling
0-127
0-359 degree fixed X Axis rolling
128-191
Clockwise rolling from slow to fast
192-255
Counterclockwise rolling from slow to fast
Channel 6 –Z-axis Rolling
0-127
0-359 degree fixed Z Axis rolling
128-191
Clockwise rolling from slow to fast
192-255
Counterclockwise rolling from slow to fast
Channel 7 –X-axis Moving
0-127
0-359 degree fixed Z Axis rolling
128-191
Clockwise rolling from slow to fast
192-255
Counterclockwise rolling from slow to fast
Channel 8 –Y-axis Moving
0-127
0-359 degree fixed Z Axis rolling
128-191
Clockwise rolling from slow to fast
192-255
Counterclockwise rolling from slow to fast
