Show Tec compact par 7 MKII User manual

Compact Par 7 MKII V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 42595
MANUAL
ENGLISH

1
Ordercode: 42595
Compact Par 7 MKII
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................5
Claims..............................................................................................................................................................................5
Description of the device.................................................................................................................................................6
Frontside..........................................................................................................................................................................7
Backside .........................................................................................................................................................................8
Installation...........................................................................................................................................................................8
Set Up and Operation .......................................................................................................................................................9
Control Modes...............................................................................................................................................................9
One Compact Par 7 MKII (Manual Control)............................................................................................................9
Multiple Compact Pars (Master/Slave control) ......................................................................................................9
Multiple Compact Pars (DMX Control)...................................................................................................................10
Fixture Linking...............................................................................................................................................................11
Data Cabling...............................................................................................................................................................11
Control Panel ...............................................................................................................................................................12
Control Mode ..............................................................................................................................................................12
DMX Addressing ..........................................................................................................................................................12
Menu Overview...........................................................................................................................................................13
Main Menu Options....................................................................................................................................................14
1.DMX Addressing....................................................................................................................................................14
2.Slave Mode............................................................................................................................................................14
3.Auto Run Mode.....................................................................................................................................................14
4.Built-in Programs....................................................................................................................................................15
5.Manual Color control...........................................................................................................................................15
6.Sound control Mode ............................................................................................................................................16
DMX Channels .............................................................................................................................................................16
3 Channels ................................................................................................................................................................16
6 Channels ................................................................................................................................................................16
7 Channels ................................................................................................................................................................17
Maintenance....................................................................................................................................................................18
Replacing a Fuse ........................................................................................................................................................18
Troubleshooting ...............................................................................................................................................................19
No Light.........................................................................................................................................................................19
No Response to DMX..................................................................................................................................................19
Restore Factory Settings ............................................................................................................................................19
Product Specification .....................................................................................................................................................21
Dimensions........................................................................................................................................................................22

2
Ordercode: 42595
Compact Par 7 MKII
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
●Showtec Compact Par 7 MKII
●Schuko to IEC powercable 1,5m
●User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving your lifespan expectancy is of a higher priority, place care in providing
for lower operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
●be qualified
●follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

3
Ordercode: 42595
Compact Par 7 MKII
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
Never let the power-cord come into contact with other cables! Handle the power-cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never place any material over the lens.
Never look directly into the light source.
Never leave any cables lying around.
Do not insert objects into air vents.
Do not connect this device to a dimmerpack.
Do not switch the device on and off in short intervals, as this would reduce the device’s life.
Do not touch the device’s housing bare-handed during its operation. Allow the fixture to cool for at
least 5 minutes before handling.
Do not shake the device. Avoid brute force when installing or operating the device.
Only use device indoor, avoid contact with water or other liquids.
Only operate the fixture after having checked that the housing is firmly closed and all screws are
tightly fastened.
Only operate the device after having familiarized with its functions.
Avoid flames and do not put close to flammable liquids or gases.
Always keep case closed while operating.
Always allow free air space of at least 50 cm around the unit for ventilation.
Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power-cord by the plug. Never pull out the plug by tugging the power-cord.
Make sure that the device is not exposed to extreme heat, moisture or dust.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power-cord is never crimped or damaged. Check the device and the power-
cord from time to time.
If the lens is obviously damaged, it has to be replaced. So that its functions are not impaired, due to
cracks or deep scratches.
If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
For adult use only. Device must be installed out of the reach of children. Never leave the unit running
unattended.
Never attempt to bypass the thermostatic switch or fuses.
For replacement use fuses of same type and rating only.
The user is responsible for correct positioning and operating of the Compact Par 7 MKII. The
manufacturer will not accept liability for damages caused by the misuse or incorrect installation of
this device.
This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
During the initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective.
Repairs, servicing and electric connection must be carried out by a qualified technician.
WARRANTY: Till one year after date of purchase.

4
Ordercode: 42595
Compact Par 7 MKII
Operating Determinations
●This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
●The minimum distance between light-output and the illuminated surface must be more than 1 meter.
●The maximum ambient temperature ta = 45°C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
●If this device is operated in any other way, than the one described in this manual, the product may
suffer damages and the warranty becomes void.
●Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
●If the Compact Par 7 MKII is lowered from the ceiling or high joists, professional trussing systems have
to be used.
●Use a clamp to mount the Compact Par 7 MKII, with the mounting-bracket, to the trussing system.
●The Compact Par 7 MKII must never be fixed swinging freely in the room.
●The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety-cable.
●When rigging, derigging or servicing the Compact Par 7 MKII, always make sure, that the area below
the installation place is blocked and staying in the area is forbidden.
The Compact Par 7 MKII can be placed to any kind of truss with a clamp.
Improper installation can cause serious damage to people and property !

5
Ordercode: 42595
Compact Par 7 MKII
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

6
Ordercode: 42595
Compact Par 7 MKII
Description of the device
Features
The Showtec Compact Par 7 MKII is a compact and powerful parcan for indoor use.
LED Quantity: 7 x 3-in-1 LED
3 DMX Modes: 3, 6 or 7 Channels
Colormixing: RGB
Colour range: 16,7 million additive colors
Lightoutput: High Power
IP Rating: IP20
Housing: Specially designed housing ensures an optimum heat dissipation during operation
Mounting: Multiple mounting possibilities
Input Voltage: 100-240 VAC, 50/60Hz
Drive current: 0,68A/110V, 0,32A/240V
Power consumption: 28W max @FO (full output)
Power linking: 20pcs@110V, 38pcs@240V
DMX-control: Via standard DMX-controller
On Board: Display for easy Set Up
Control: DMX-512, Built-in Programs, Auto, Manual color, Master/Slave, Sound controlled
Beam Angle: 35°
Dimmer: 0-100%
Strobe: 0-20Hz
Housing: Die Cast Aluminium Powder Coat Finish
Connections: Dedicated IEC Power & Data connector
Cooling: Convection (no fans) which eliminates the use of fans and noise
Design: Stylish
Lens Plate: Tempered Glass
Lux (@ 2 meter): RGB 2010
Fuse: T1AL/250V
Dimensions: 200 x 95 x 220 mm (LxWxH)
Weight: 1,56 kg
Included: Schuko to IEC powercable

7
Ordercode: 42595
Compact Par 7 MKII
Frontside
Fig.01
01) Frontside Mounting bracket with Screw
02) Lens

8
Ordercode: 42595
Compact Par 7 MKII
Backside
Fig.02
03) Mode Button
04) Setup Button
05) Up Button
06) Down Button
07) LCD Display
08) DMX signal connector (IN)
09) IEC powercable IN, IEC powercable OUT for linking and Fuse T1AL/250V
10) DMX signal connector (OUT)
NOTE: Knowledge of DMX is required to fully utilize this unit.
Installation
Remove all packing materials from the Compact Par 7 MKII. Check that all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.

9
Ordercode: 42595
Compact Par 7 MKII
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Control Modes
There are 6 modes:
Stand-alone (Built-in Programs, Auto run, Static Colors, Sound control)
Master/Slave
DMX512 (3CH, 6CH or 7CH)
One Compact Par 7 MKII (Manual Control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Compact Par 7 MKII is not connected by a DMX-cable, it functions as a stand-alone
device.
05) Please see page 14 and 15 for more information about the manual control functions.
Multiple Compact Pars (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-p XLR cable to connect the Compact Pars.
The pins:
1. Earth
2. Signal (-)
3. Signal (+)
05) Link the units as shown in (Fig. 03), Connect a DMX signal cable from the first unit's DMX "out" socket
to the second unit's "in" socket. Repeat this process to link the second, third, and fourth units. You can
use the same functions on the master device as described on page 14, 15 and 16 (Manual Control
or Music control). This means on the master device you can set your desired operation Mode and all
slave devices will react the same as the master device.
Multiple Compact Pars (Master/Slave control)
Fig. 03

10
Ordercode: 42595
Compact Par 7 MKII
Multiple Compact Pars (DMX Control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-p XLR cable to connect the Compact Par 7 MKII and other devices.
05) Link the units as shown in (figure 04), Connect a DMX signal cable from the first unit's DMX "out" socket
to the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
06) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple Compact Pars DMX Set Up
Fig. 04
Note : Link all cables before connecting electric power

11
Ordercode: 42595
Compact Par 7 MKII
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows on two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy chained in one single line. To comply with the
EIA-485 standard no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of Compact Pars on a DMX data link: 30 fixtures
Maximum recommended number of Compact Pars on a Power link: 20 fixtures @110V
Maximum recommended number of Compact Pars on a Power link: 38 fixtures @240V
Data Cabling
To link fixtures together you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio Certified DMX Data Cables
●DAP Audio cable for all-round use. bal. XLR/M 3 p. > XLR/F 3 p.
Ordercode FL01150 (1,5m.), FL013 (3m.), FL016 (6m.), FL0110 (10m.), FL0115 (15m.), FL0120 (20m.).
●DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5m.), FL713 (3m.), FL716 (6m.), FL7110 (10m.).
The Compact Par 7 MKII can be operated with a controller in control mode or without the controller in
stand-alone mode.

12
Ordercode: 42595
Compact Par 7 MKII
Control Panel
A)
B)
C)
D)
E)
LCD Display
Mode button
Setup Button
Up Button
Down Button
Fig.05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address the next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign the DMX fixture address, which is the
first channel from which the Compact Par 7 MKII will respond to the controller.
Please note when you use the controller, the unit has 7channels.
When using multiple Compact Pars, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Compact Pars should be 1(d001); the DMX address of the second
Compact Par 7 MKII should be 1+7=8 (d008); the DMX address of the third Compact Par 7 MKII should be
8+7=15 (d015), etc.
Please, be sure that you don’t have any overlapping channels in order to control each Compact Par 7
MKII correctly.
If two or more Compact Pars are addressed similarly, they will work similarly.
Controlling:
After having addressed all Compact Par 7 MKII fixtures, you may now start operating these via your
lighting controller.
Note: After switching on, the Compact Par 7 MKII will automatically detect whether DMX 512 data is
received or not. If there is no data received at the DMX-input, the “LED“ on the control panel will not
flash.
The problem may be:
•The XLR cable from the controller is not connected with the input of the Compact Par 7 MKII.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It’s necessary to insert a XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 10 seconds
When no button is pressed for 10 seconds, the display will turn off.
To light up the display, you have to press the MODE, SETUP, UP or DOWN button.
Once you have pressed the button, the display will light up.

13
Ordercode: 42595
Compact Par 7 MKII
Menu Overview

14
Ordercode: 42595
Compact Par 7 MKII
Main Menu Options
DMX address
Master-Slave
Auto run
Built-in Programs
Manual Color
Sound
1.DMX Addressing
With this menu you can set the DMX address.
01) Press the MODE button and then the Up / Down buttons, until the display shows .
02) Press the SETUP button to open this menu. You can choose 512 different DMX addresses.
03) Use the Up / Down buttons to select the required address from .
Once you have set the desired DMX address, you can also choose the desired DMX Mode.
04) Press the SETUP button to set 3 different DMX Modes. Use the Up / Down buttons to choose between
3, 6 or 7 Channels.
2.Slave Mode
With this menu you can set the Master or Slave.
01) Press the MODE button and then the Up / Down buttons, until the display shows .
If the device has not been set to slave, it is automatically classified as a master device. All slave
devices will follow the master movement.
If the device has been set to slave, it will react the same as its master device.
3.Auto Run Mode
With this menu you can set Auto Run mode of the Compact Par 7 MKII.
01) Press the MODE button and then the Up / Down buttons, until the display shows .

15
Ordercode: 42595
Compact Par 7 MKII
4.Built-in Programs
With this menu you can you can set the built-in programs.
01) Press the MODE button and then the Up / Down buttons, until the display shows .
02) Press the SETUP button to open this menu.
03) You can use the SETUP button to scroll through the 12 built-in programs.
When you select menu , you can use a wide variety of manual color settings.
04) Press the SETUP button to open menu . You can now set the Flash frequency.
05) Press the SETUP button to open menu . In menu , you can
switch between the Flash frequency and the Program Running Speed by pressing the SETUP button.
06) Use the UP/DOWN buttons to change the values.
Speed from 01-99 and FL.
Flash Frequency from 00-99
5.Manual Color control
With this menu you can you can manually set a desired color.
01) Press the MODE button and then the Up / Down buttons, until the display shows .
02) Press the SETUP button to open this menu.
03) You can use the SETUP button to scroll through the 3 color options and adjust the flash frequency.
04) Use the UP/DOWN buttons to change the values.
Set the value of the red LEDs (0-255)
Set the value of the green LEDs (0-255)
Set the value of the blue LEDs (0-255)
Set the value of the flash frequency (0-99)
You can combine Red, Green and Blue to create an infinite range of colors (0-255).

16
Ordercode: 42595
Compact Par 7 MKII
6.Sound control Mode
01) Press the MODE button on the device, until the display shows .
02) Press the SETUP button to open this menu.
03) Use the UP/DOWN buttons to change the values.
04) Set the value of the sound control mode (0-31) .
DMX Channels
3 Channels
Channel 1 –Red Dimmer intensity
0-255
Red from 0 –100%
Channel 2 –Green Dimmer intensity
0-255
Green from 0 –100%
Channel 3 –Blue Dimmer intensity
0-255
Blue from 0 –100%
6 Channels
Channel 1 –Dimmer (Colors RGB must be open )
0-255
From black to brightest
Channel 2 –Red Dimmer intensity (CH1 must be set between 0-255 )
0-255
Red from 0 –100%
Channel 3 –Green Dimmer intensity (CH1 must be set between 0-255 )
0-255
Green from 0 –100%
Channel 4 –Blue Dimmer intensity (CH1 must be set between 0-255 )
0-255
Blue from 0 –100%
Channel 5 –Sound active (Use in combination with CH6 )
0-10
No use
11-255
Sound active
Channel 6 –Shutter / Strobe (CH1, CH2, CH3 or CH4 must be set between 1-255 )
0-10
No function
11-255
Strobe (color strobe selected by 1CH-4CH)
Channel 6 –Sound sensitivity (CH5 must be set between 11-255 )
0-255
Sound sensitivity

17
Ordercode: 42595
Compact Par 7 MKII
7 Channels
Channel 1 –Dimmer (Colors RGB must be open )
0-255
From black to brightest
Channel 2 –Red Dimmer intensity (CH1 must be set between 0-255 )
0-255
Red from 0 –100%
Channel 3 –Green Dimmer intensity (CH1 must be set between 0-255 )
0-255
Green from 0 –100%
Channel 4 –Blue Dimmer intensity (CH1 must be set between 0-255 )
0-255
Blue from 0 –100%
Channel 5 –Built-in Programs
0-24
No function
25-49
Built-in Program 01
50-74
Built-in Program 02
75-99
Built-in Program 03
100-124
Built-in Program 04
125-149
Built-in Program 05
150-174
Built-in Program 06
175-199
Built-in Program 07
200-255
Sound active mode
Channel 6 –Sound active mode (CH5 must be set between 200-255 )
0-255
Sound sensitivity
Channel 7 –Shutter / Strobe (Dimmer and Colors RGB must be open )
0-255
Strobe effect, from slow to fast (0-20 flashes/sec.)

18
Ordercode: 42595
Compact Par 7 MKII
Maintenance
The Showtec Compact Par 7 MKII requires almost no maintenance. However, you should keep the unit
clean. Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power
supply and then wipe the cover with a damp cloth. Wipe the front glass panel clean with glass cleaner
and a soft cloth. Do not use alcohol or solvents. The front glass panel will require weekly cleaning, as
smoke-fluid tends to build up residues, reducing the light-output very quickly. Do not immerse in liquid.
Keep connections clean. Disconnect electric power, and then wipe the DMX and audio connections
with a damp cloth. Make sure connections are thoroughly dry before linking equipment or supplying
electric power.
The operator has to make sure that safety-relating and machine-technical installations are to be
inspected by an expert after every year in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are to be
inspected by a skilled person once a year.
The following points have to be considered during the inspection:
01) All screws used for installing the device or parts of the device have to be tightly connected and must
not be corroded.
02) There may not be any deformations on housings, fixations and installation spots.
03) Mechanically moving parts like axles, eyes and others may not show any traces of wearing.
04) The electric power supply cables must not show any damages or material fatigue.
Replacing a Fuse
Power surges, short-circuit or inappropriate electrical power supply may cause a fuse to burn out. If the
fuse burns out, the product will not function whatsoever. If this happens, follow the directions below to do
so.
01) Unplug the unit from electric power source.
02) Insert a flat-head screwdriver into a slot in the fuse over. Gently pry up the fuse cover. The fuse will
come out. The fuse will come out.
03) Remove the used fuse. If brown or unclear, it is burned out.
04) Insert the replacement fuse into the holder where the old fuse was. Reinsert the fuse cover. Be sure to
use a fuse of the same type and specification. See the product specification label for details

19
Ordercode: 42595
Compact Par 7 MKII
Troubleshooting
No Light
This troubleshooting guide is meant to help solve simple problems.
If a problem occurs, carry out the steps below in sequence until a solution is found. Once the unit
operates properly, do not carry out following steps.
If the light effect does not operate properly, refer servicing to a technician.
Response: Suspect three potential problem areas as: the power supply, the LED, the fuse.
01) Power supply. Check that the unit is plugged into an appropriate power supply.
02) The LEDs. Return the Compact Par 7 MKII to your Showtec dealer.
03) The fuse. Replace the fuse. See page 18 for replacing the fuse
04) If all of the above appears to be O.K., plug the unit in again.
05) If you are unable to determine the cause of the problem, do not open the Compact Par 7 MKII, as
this may damage the unit and the warranty will become void.
06) Return the device to your Showtec dealer.
No Response to DMX
Response: Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card
malfunction.
01) Check the DMX setting. Make sure that DMX addresses are correct.
02) Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power.
Try your DMX control again.
03) Determine whether the controller or light effect is at fault. Does the controller operate properly with
other DMX products ? If not, take the controller in for repair. If so, take the DMX cable and the light
effect to a qualified technician.
Restore Factory Settings
You can remove all data from the Compact Par 7 MKII by resetting it to its factory settings.
01) Switch off the main power.
02) Press the MODE and SETUP buttons at the same time.
03) Switch on the main power while holding the MODE and SETUP buttons.
04) Release the MODE and SETUP buttons.
See next page for more problem solving.
