Show Tec Club Par 18 User manual

Club Par 18-1 RGB V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 42652
MANUAL
ENGLISH

1
Ordercode: 42652
Club Par 18-1 RGB
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Frontside..........................................................................................................................................................................7
Backside .........................................................................................................................................................................8
Installation...........................................................................................................................................................................8
Set Up and Operation .......................................................................................................................................................8
Control Modes...............................................................................................................................................................9
One Club Par (Built-in programs, Static Color Mode and Manual Mode).....................................................9
One Club Par (Sound-controlled)...........................................................................................................................9
Multiple Club Pars (DMX Control) ...........................................................................................................................9
Fixture Linking...............................................................................................................................................................10
Data Cabling...............................................................................................................................................................10
Control Panel ...............................................................................................................................................................11
Control Mode ..............................................................................................................................................................11
DMX Addressing ..........................................................................................................................................................11
Menu Overview...........................................................................................................................................................12
Main Menu Options....................................................................................................................................................13
1. DMX-512 Mode ....................................................................................................................................................13
2. Channel Mode.....................................................................................................................................................13
3. Speed.....................................................................................................................................................................14
4. Built-in programs ..................................................................................................................................................14
5. Sound-controlled .................................................................................................................................................14
6. Static Colors..........................................................................................................................................................14
7. Strobe.....................................................................................................................................................................14
8. Red .........................................................................................................................................................................14
9. Green.....................................................................................................................................................................14
10. Blue.......................................................................................................................................................................14
11. Node ....................................................................................................................................................................15
12. LED Display..........................................................................................................................................................15
13. Temperature .......................................................................................................................................................15
14. Version .................................................................................................................................................................15
15. Reset ....................................................................................................................................................................15
DMX Channels .............................................................................................................................................................16
3 channels .................................................................................................................................................................16
8 channels .................................................................................................................................................................16
Maintenance....................................................................................................................................................................17
Replacing the Fuse.....................................................................................................................................................17
Troubleshooting ...............................................................................................................................................................17
No Light.........................................................................................................................................................................17
No Response to DMX..................................................................................................................................................18
Product Specifications....................................................................................................................................................19
Dimensions........................................................................................................................................................................20
Notes ..................................................................................................................................................................................21

2
Ordercode: 42652
Club Par 18-1 RGB
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec Club Par 18-1 RGB
IEC power cable (1,5 m)
User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual

3
Ordercode: 42652
Club Par 18-1 RGB
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged. Always
hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Never loosen the screws of the rotating gobo otherwise you risk opening of the ball bearing.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. The fixture must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.

4
Ordercode: 42652
Club Par 18-1 RGB
•The user is responsible for correct positioning and operating of the Club Par 18-1 RGB. The
manufacturer will not accept liability for damages caused by the misuse or incorrect installation of
this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•During the initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the projector is lowered from the ceiling or high joists, professional trussing systems have to be used.
•Use a clamp to mount the projector, with the mounting bracket, to the trussing system.
•The projector must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the projector, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.

5
Ordercode: 42652
Club Par 18-1 RGB
The Club Par 18-1 RGB can be placed on a flat stage floor or mounted to any kind of truss with a clamp.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!

6
Ordercode: 42652
Club Par 18-1 RGB
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

7
Ordercode: 42652
Club Par 18-1 RGB
Description of the device
Features
The Club Par 18-1 RGB is an compact light effect with high output and great effects.
Ideal solution for small clubs and mobile DJs
Compact size
Sound Control
Input voltage: 100-240V, 60/50Hz
Drive Current: 270mA
Refresh rate: 1200Hz
Power consumption: 20W
DMX channels: 3 or 8 channels
4-digit LED display for easy setup
Light source: 6xRed, 6xGreen, 6x Blue 1W LEDs
Lumens: 460
Lux @2m: 2330
Control modes: Built-in programs, Static Colors, DMX, Sound-controlled, Manual color control
Control protocol: DMX-512
Dimmer: 0-100%
Strobe: 0-20Hz
Beam Angle: 15°
Protection rate: IP-20
Housing: Metal & Flame retardant plastic
Cooling: Fan
Connections: IEC & 3-pin XLR IN & OUT
Fuse: F0,5AL/250V
Dimensions: 290 x 270 x 73 mm (LxWxH)
Weight: 1,48 kg
Frontside
Fig. 01
01) Mounting bracket with inclination screw
02) Adjustment screw
03) 6xRed, 6xGreen, 6x Blue 1W LEDs

8
Ordercode: 42652
Club Par 18-1 RGB
Backside
Fig. 02
04) Built-in Microphone
05) Audio Sensitivity
06) 4-digit LED display + menu buttons
07) 3-pin DMX signal connector IN
08) 3-pin DMX signal connector
09) IEC power connector 100-240V + Fuse F0,5AL/250V
Installation
Remove all packing materials from the Club Par 18-1 RGB. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.

9
Ordercode: 42652
Club Par 18-1 RGB
Control Modes
There are 5 modes:
•Built-in programs
•Manual Mode
•Static Color
•Sound-controlled
•DMX-512 (3CH or 8CH)
One Club Par (Built-in programs, Static Color Mode and Manual Mode)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the Club Par is not connected with a DMX cable, it functions as a stand-alone device.
Please see pages 14 for more information about the Built-in programs, Auto Mode and Manual
Mode.
One Club Par (Sound-controlled)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) Turn on the music. If the device is set to sound-control, then the Club Par will react to the beat of the
music. Please see page 14 for more information about the sound-control options.
Multiple Club Pars (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the Club Pars and other devices.
04) Link the units as shown in fig. 03. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.

10
Ordercode: 42652
Club Par 18-1 RGB
Multiple Club Pars DMX Set Up
Fig. 03
Note : Link all cables before connecting electric power
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).

11
Ordercode: 42652
Club Par 18-1 RGB
The Club Par 18-1 RGB can be operated with a controller in control mode or without the controller in
stand-alone mode.
Control Panel
A) LED display
B) MODE button
C) SETUP button
D) UP button
E) DOWN button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the Club Par will respond to the controller.
Please note, when you use the controller, the unit has 8channels.
When using multiple Club Pars, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Club Par should be 1(001); the DMX address of the second Club
Par should be 1+8=9 (009); the DMX address of the third Club Par should be 9+8=17 (017), etc. Please, be
sure that you do not have any overlapping channels in order to control each Club Par correctly.
If two or more Club Pars are addressed similarly, they will work similarly.
Controlling:
After having addressed all Club Par fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the Club Par will automatically detect whether DMX 512 data is received or not.
If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Club Par 18-1 RGB.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 30 seconds
When no button is pressed for 10 seconds, the display will turn off.
To light up the display, you have to press the MODE, SETUP, UP or DOWN button.
Once you have pressed the button, the display will light up.

12
Ordercode: 42652
Club Par 18-1 RGB
Menu Overview

13
Ordercode: 42652
Club Par 18-1 RGB
Main Menu Options
DMX-512 Mode
Channel Mode
Program Speed
Built-in programs
Sound-controlled Mode
Static Color Mode
Strobe
Red
Green
Blue
Mode
Led On/Off
Temperature
Version
Reset
1. DMX-512 Mode
With this menu, you can set the DMX address and select the desired channel mode.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the submenu, the display will show .
03) Press the UP/DOWN buttons to choose the desired DMX address. There are 512 DMX addresses
available.
2. Channel Mode
With this menu, you can set the desired channel mode.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the submenu, then press the UP/DOWN buttons to choose one of the
2 channel modes:
3-channel mode
8-channel mode

14
Ordercode: 42652
Club Par 18-1 RGB
3. Speed
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the submenu, then press the UP/DOWN buttons to adjust the run
speed of the built-in programs. The adjustment range is between , 00-99 (from
fast to slow).
4. Built-in programs
With this menu, you can set the built-in programs.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the submenu, then press the UP/DOWN buttons to toggle between
one of the 13 built-in programs: .
03) The device will now run the desired built-in program.
5. Sound-controlled
With this menu, you can set the audio sensitivity.
01) Press the MODE button until the display shows .
02) Press the SETUP button until the display shows . Use the control on the back to adjust the
sensitivity.
6. Static Colors
With this menu, you can set the static colors.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the submenu, then press the UP/DOWN buttons to toggle between
one of the 63 built-in colors: .
03) The device will now run the desired static color.
7. Strobe
With this menu, you can set the Strobe speed.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the submenu, then press the UP/DOWN buttons to set the strobe
speed: .
03) The device will now run at the desired strobe speed.
8. Red
With this menu, you can manually adjust the intensity of the red LEDs.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the submenu, then press the UP/DOWN buttons to adjust the intensity
of the red LEDs. Adjustment range is between 0-255, from low to high intensity.
9. Green
With this menu, you can manually adjust the intensity of the green LEDs.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the submenu, then press the UP/DOWN buttons to adjust the intensity
of the green LEDs. Adjustment range is between 0-255, from low to high intensity.
10. Blue
With this menu, you can manually adjust the intensity of the blue LEDs.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the submenu, then press the UP/DOWN buttons to adjust the intensity
of the blue LEDs. Adjustment range is between 0-255, from low to high intensity.

15
Ordercode: 42652
Club Par 18-1 RGB
11. Node
With this menu, you can set the dimmer curve of your Club Par.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the submenu, then press the UP/DOWN buttons to toggle between
one of the 5 dimmer curves from fast to slow: .
03) is linear, is from (1 sec- 4 sec. dimming curve).
modes always override Channel 8
12. LED Display
With this menu you can set the LED Display On or Off.
01) Press the MODE button until the display shows .
02) Press Setup to enter the LED Display Menu. You can choose 2 different settings.
03) Use the Up / Down buttons to select:
: The LED display will light all the time.
: The LED display will turn off after 30 seconds.
13. Temperature
With this menu, you can see what the current temperature of the LEDs is.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the submenu, you will see the current temperature .
14. Version
With this menu, you can see what version software your Club Par has.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the submenu, you will see the current version .
15. Reset
With this menu, you can see reset your Club Par.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the submenu, then press the UP/DOWN buttons to select
.
03) Press the SETUP button to confirm your choice.

16
Ordercode: 42652
Club Par 18-1 RGB
DMX Channels
3 channels
Channel 1 –Red
0-255
Gradual adjustment Red, from 0-100%
Channel 2 –Green
0-255
Gradual adjustment Green, from 0-100%
Channel 3 –Blue
0-255
Gradual adjustment Blue, from 0-100%
8 channels
Channel 1 –Dimmer intensity
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 2 –Red Dimmer must be open
0-255
Gradual adjustment Red, from 0-100%
Channel 3 –Green Dimmer must be open
0-255
Gradual adjustment Green, from 0-100%
Channel 4 –Blue Dimmer must be open
0-255
Gradual adjustment Blue, from 0-100%
Channel 5 –Strobe
0-12
Closed
13-255
Strobe flash frequency, from slow to fast
Channel 6 –Built-in Programs
0-9
Not functional
10-19
Program 1
20-29
Program 2
30-39
Program 3
40-49
Program 4
50-59
Program 5
60-69
Program 6
70-79
Program 7
80-89
Program 8
90-99
Program 9
100-109
Program 10
110-119
Program 11
120-129
Program 12
130-139
Program 13
140-255
Sound-controlled
Channel 7 –Speed CH6 must be set between 10-255
0-255
Gradual speed adjustment, from slow to fast
Channel 8 –Fade Time Mode must be set to
0-255
Gradual speed adjustment, from color jump to color fade

17
Ordercode: 42652
Club Par 18-1 RGB
Maintenance
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by an expert after every year in the course of an acceptance test.
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by a skilled person once a year.
The following points have to be considered during the inspection:
01) All screws used for installing the device or parts of the device have to be tightly connected and
must not be corroded.
02) There may not be any deformations on housings, fixations and installation spots.
03) Mechanically moving parts like axles, eyes and others may not show any traces of wearing.
04) The electric power supply cables must not show any damages or material fatigue.
The Club Par 18-1 RGB requires almost no maintenance. However, you should keep the unit clean.
Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply, and
then wipe the cover with a damp cloth. Do not immerse in liquid. Wipe lens clean with glass cleaner and
a soft cloth. Do not use alcohol or solvents.
The front lens will require weekly cleaning, as smoke-fluid tends to build up residues, reducing the light-
output very quickly.
Keep connections clean. Disconnect electric power, and then wipe the DMX and audio connections
with a damp cloth. Make sure connections are thoroughly dry before linking equipment or supplying
electric power.
Replacing the Fuse
Power surges, short-circuit or inappropriate electrical power supply may cause a fuse to burn out.
If the fuse burns out, the product will not function whatsoever. If this happens, follow the directions below:
01) Unplug the unit from electric power source.
02) Insert a flat-headed screwdriver into a slot in the fuse cover. Gently pry up the fuse cover. The fuse
will come out.
03) Remove the used fuse. If brown or unclear, it is burned out.
04) Insert the replacement fuse into the holder. Reinsert the fuse cover. Be sure to use a fuse of the
same type and specification. See the product specification label for details.
Troubleshooting
This troubleshooting guide is meant to help solve simple problems.
If a problem occurs, carry out the steps below in sequence until a solution is found. Once the unit
operates properly, do not carry out following steps.
No Light
If the light effect does not operate properly, refer servicing to a technician.
Suspect three potential problem areas as: the power supply, the LEDs, the fuse.
01) Power supply. Check that the unit is plugged into an appropriate power supply.
02) The LEDs. Return the Club Par to your Showtec dealer.
03) The fuse. Replace the fuse. See page 18 for replacing the fuse.
04) If all of the above appears to be O.K., plug the unit in again.
05) If you are unable to determine the cause of the problem, do not open the Club Par, as this may
damage the unit and the warranty will become void.
06) Return the device to your Showtec dealer.

18
Ordercode: 42652
Club Par 18-1 RGB
No Response to DMX
Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card malfunction.
01) Check the DMX setting. Make sure that DMX addresses are correct.
02) Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power.
Try your DMX control again.
03) Determine whether the controller or light effect is at fault. Does the controller operate properly with
other DMX products? If not, take the controller in for repair. If so, take the DMX cable and the light
effect to a qualified technician.
Problem
Probable cause(s)
Solution
One or more
fixtures do not
function at all
No power to the fixture
•Check if power is switched on and
cables are plugged in
Primary fuse blown
•Replace fuse
Fixtures reset
correctly, but all
respond
erratically or not
at all to the
controller
The controller is not connected.
•Connect controller.
3-pin XLR Out of the controller
does not match XLR Out of the first
fixture on the link (i.e. signal is
reversed)
•Install a phase reversing cable
between the controller and the
first fixture on the link
Fixtures reset
correctly, but
some respond
erratically or not
at all to the
controller
Poor data quality
•Check data quality. If much lower
than 100 percent, the problem
may be a bad data link
connection, poor quality or
broken cables, missing termination
plug, or a defective fixture
disturbing the link
Bad data link connection
•Inspect connections and cables.
Correct poor connections. Repair
or replace damaged cables
Data link not terminated with 120
Ohm termination plug
•Insert termination plug in output
jack of the last fixture on the link
Incorrect addressing of the fixtures
•Check address setting
One of the fixtures is defective and
disturbs data transmission on the
link
•Bypass one fixture at a time until
normal operation is restored:
unplug both connectors and
connect them directly together.
•Have the defective fixture
serviced by a qualified technician
3-pin XLR Out on the fixtures does
not match (pins 2 and 3 reversed)
•Install a phase-reversing cable
between the fixtures or swap pin 2
and 3 in the fixture that behaves
erratically
No light or lamp
cuts out
intermittently
Fixture is too hot
•Allow the fixture to cool down
•Clean the fan
•Make sure air vents in control
panel and the front lens are not
blocked
•Turn up the air conditioning
LEDs damaged
•Disconnect the fixture and return it
to your dealer
The power supply settings do not
match local AC voltage and
frequency
•Disconnect fixture. Check settings
and correct if necessary

19
Ordercode: 42652
Club Par 18-1 RGB
Product Specifications
Model:
Showtec Club Par 18-1 RGB
Input Voltage:
100-240 VAC, 60/50Hz
Power consumption:
20W (full output)
Drive Current:
270mA
Refresh rate
1200Hz
DMX linking:
30pcs
Protection rate:
IP-20
Fuse:
F0,5AL/250V
Dimensions:
290 x 270 x 73 mm (LxWxH)
Weight:
1,48 kg
Operating and Programming:
Signal pin OUT:
Pin 1 (earth), pin 2 (-), pin 3 (+)
DMX Mode:
3 or 8 channels
Signal input:
3-pin DMX IN
Signal output:
3-pin DMX OUT
Electro-mechanical effects:
LED Quantity:
6xRed, 6xGreen, 6x Blue 1W LEDs
Light output:
Lumens: 460
Lux @2m:
2330
Color mixing:
RGB
Beam angle:
15°
Dimmer:
0-100%
Strobe:
0-20Hz
Housing:
Metal & Flame retardant plastic
DMX-control:
via standard DMX-controller
On Board:
4-digit LED display for easy setup
Control:
Built-in programs, Static Colors, DMX, Sound-controlled,
Manual Color control
Connections:
Dedicated IEC & 3-pin XLR IN & OUT
Cooling:
Internal fan
Max. ambient temperature ta:
40°C
Max. housing temperature tB:
80°C
Minimum distance:
Minimum distance from flammable surfaces:
0,5 m
Minimum distance to lighted object:
1 m
Design and product specifications are subject to change without prior notice.
Website: www.Showtec.info
Email: [email protected]
