Show Tec LED Pixel Track V2 User manual

LED Pixel Track V2
ORDERCODE 42200

Congratulations!
You have bought a great, innovative product from Showtec.
The Showtec LED Pixel Track brings excitement to any venue. Whether you want simple plug-&-play
action or a sophisticated DMX show, this product provides the effect you need.
You can rely on Showtec, for more excellent lighting products.
We design and manufacture professional light equipment for the entertainment industry.
New products are being launched regularly. We work hard to keep you, our customer, satisfied.
For more information: [e-mail]
You can get some of the best quality, best priced products on the market from Showtec.
So next time, turn to Showtec for more great lighting equipment.
Always get the best -- with Showtec !
Thank you!

1
2
2
3
4
5
5
6
6
6
7
7
7
7
7
8
8
9
10
11
11
11
11
12
Showtec
Showtec LED Pixel Track™Product Guide
Warning.................................................................................…...……………..…………………………….…………
Safety-instructions………………………………………………………………………………………………………
Operating Determinations.…………………………………………………………………………………………...
Rigging.…………………………………………………………………………………………………………………..
Return Procedure…………………………………………………………………………….....................................
Claims……………………………………………………………………………........................................................
Description...............................................................................…...………………………………………….………..
Features and Overview ………………………………...….……………….………….……….……….……………
Backside…………………………………………………………………………………………………………………..
Installation...............................................................................…...…………………………………………………..…
Set Up and Operation............................................................................................................................................
Panel Functions……..……………………………………………………………………………….………………...…
- Mode…...............................................………….........................……………………....………………..…..
- F / S…..............................................................................….....………….........…………….………………..
Stand-Alone…………………………..…………………………………………………………….………………...…..
Sound-Active……..…………………..…………………………………………………………….………………...…..
DMX Operation…………..…………..…………………………………………………………….………………...…..
- DMX Modes..…...............................………….........................……………………....……………………….
Maintenance...................................................................................………..………….…….……………………..…
Replacing the Fuse........................................................................…………………….………………………….
Troubleshooting............................................................................………………….………………….………………
No Light……………………………………............................................………………….………………………….
Product Specifications.................................................................……………….…….………………………………

2
WARNING
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
• Showtec LED Pixel Track with IEC powercable 1,5m
• User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. It is estimated that a viable lifespan of 40,000 to 50,000 hours will be achieved
under normal operational conditions. If improving on this lifespan expectancy is of a higher priority, place
care in providing for lower operational temperatures. This may include climatic-environmental and the
reduction of overall projection intensity.
SAFETY INSTRUCTIONS
Every person involved with the installation, operation and maintenance of this device has to:
-be qualified
-follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-
observance of this manual or any unauthorized modification to the device.
CAUTION!
Keep this device away from rain and moisture!
Unplug mains lead before opening the housing!
CAUTION! Be careful with your operations.
With a dangerous voltage you can suffer
a dangerous electric shock when touching the wires!
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!

3
Never let the power-cord come into contact with other cables! Handle the power-cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never leave any cables lying around.
Never cover the air vents, otherwise the device will get to hot.
Do not insert objects into air vents.
Do not open the device and do not modify the device.
Do not connect this device to a dimmerpack.
Do not shake the device. Avoid brute force when installing or operating the device.
Do not switch the device on and off in short intervals, as this would reduce the system’s life.
Only use device indoor, avoid contact with water or other liquids.
Only operate the device after having familiarized with its functions.
Avoid flames and do not put close to flammable liquids or gases.
Always allow free air space of at least 50 cm around the unit for ventilation.
Always disconnect power from the mains, when device is not used or before cleaning! Only
handle the power-cord by the plug. Never pull out the plug by tugging the power-cord.
Make sure that the device is not exposed to extreme heat, moisture or dust.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power-cord is never crimped or damaged. Check the device and the power-
cord from time to time.
If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do
not switch it on immediately. The arising condensation water might damage your device. Leave
the device switched off until it has reached room temperature.
If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
For adult use only. The device must be installed out of the reach of children. Never leave the unit
running unattended.
For replacement use fuses of same type and rating only.
Repairs, servicing and electric connection must be carried out by a qualified technician.
WARRANTY: Till one year after date of purchase.
OPERATING DETERMINATIONS
This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
The minimum distance between light-output and the illuminated surface must be more than 0,5 meters.
The maximum ambient temperature ta= 45°C must never be exceeded.
The relative humidity must not exceed 50 % with an ambient temperature of 45° C.
If this device is operated in any other way, than the one described in this manual, the product may suffer
damages and the warranty becomes void.
Any other operation may lead to dangers like short-circuit, burns, electric shock, lamp explosion, crash
etc.
You endanger your own safety and the safety of others!

4
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all other
safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
If the LED Pixel Track is lowered from the ceiling or high joists, professional trussing systems have to
be used.
Use a clamp to mount the LED Pixel Track, with the mounting-bracket, to the trussing system.
The LED Pixel Track must never be fixed swinging freely in the room.
The installation must always be secured with a safety attachment, e.g. an appropriate safety net
or safety-cable.
When rigging, derigging or servicing the LED Pixel Track, always make sure, that the area below
the installation place is blocked and staying in the area is forbidden.
The LED Pixel Track can be placed on a flat stage floor or mounted to any kind of truss by a clamp.
Improper installation can cause serious damage to people and property !
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
FASE
N
BLUE
BLACK
SILVER
NUL
YELLOW/GREEN
GREEN
GREEN
EARTH
Make sure that the device is always connected properly to the earth!

5
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
1) Your name
2) Your address
3) Your phone number
4) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

6
Description of the device
Features
The LED Pixel Track is a LED system from Showtec.
• Sound-controlled via built-in microphone
• 3 Modes: Stand-alone, DMX-controlled or Sound-controlled
NOTE: Knowledge of DMX is required to fully utilize this unit.
Overview
Fig. 1
1) Safety Eye for Truss mounting
2) Total LED Pixel Track 648 LEDS
3) Mountingbracket for Truss mounting
4) Adjustment Screw
Backside
Fig. 2
5) Audio Level (sensitivity)
6) Mic
7) DMX signal connector (IN)
8) DMX signal connector (OUT)
9) Power On / Off
10) AC powercord

7
Installation
Remove all packing materials from the LED Pixel Track. Check that all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Panel Functions

8
Stand-alone Operation
Refer to the four buttons on the front panel of the LED Pixel Track: Mode
F / S
Up
Down
Press the MODE button to view the Chase menu:
Select Chases 1-9 using the UP and DOWN buttons.
Chases 1-8 run according to the Fade and Speed values.
Chase 9 is sound-active.
Press the F/S button to set the Fade and Speed values:
Adjust Chase Fade Time from 0-100%.
Adjust Chase Speed from 1-500 steps per minute.
Press the MODE button to view the Manual Color Mixing menu:
Press F/S to select the color you want to adjust.
Use UP and DOWN to mix the RGB colors and change their values.
Indicates Red with value from Dark (0) to Bright (255).
Indicates Green with value from Dark (0) to Bright (255).
Indicates Blue with value from Dark (0) to Bright (255).
Sound-active Operation
In Stand-alone mode, select Chase 9 and adjust the audio input level using the sensitivity control dial on
the side panel of the LED Pixel Track.
In DMX mode, use Channel 6 to select Sound-active operation and to adjust the audio sensitivity.

9
DMX Operation
Press the MODE button to view the DMX address setting rnenu:
Select the DMX starting address for the Pixel Drive 8 using the
UP and DOWN buttons.
The DMX Channel functions are:
Channel 1: Rainbow
Channel 2: Red (0-255)
Channel 3: Green (0-255)
Channel 4: Blue (0-255)
Channel 5: Strobe (1-20HZ)
Channel 6: Sound-active/ Audio sensitivity
There are 8 modes of self-running programs (1-240) and 1 sound-active program (241-255) in Channel 6.
Chase 1: 1-30
Chase 2: 31-60
Chase 3: 61-90
Chase 4: 91-120
Chase 5: 121-150
Chase 6: 151-180
Chase 7: 181-210
Chase 8: 211-240
Sound-Active: 241-255
The LED Pixel Track’s built-in controller will automatically detect the presence of a DMX signal.
IF a DMX signal is present, the front panel LED display will blink.
In order to receive a DMX signal, the built-in controller must be attached to a DMX controller by a 3-pin
DMX cable and the DMX controller must be turned on.
To mix RGB color using DMX, Channel 1 (Rainbow) must be off (0).
When programming your own DMX sequences, note that Channel 6 must be off (0) to avoid activating
Sound-active mode during playback.
The LED Pixel Track system can operate as a 48-, 24-, 12- or 6- channel DMX fixture. Select DMX Mode 1,
2, 3 or 4 as described on the next page.

10
DMX Modes
Press the MODE button to view the DMX mode selection menu. Use the UP and DOWN buttons to select
the DMX mode.
DMX Mode 1 : 48-channel operation (Control each LED Pixel Track LED cluster
separately)
DMX Mode 2 : 24-channel operation (Control 4 sets of 2 LED Pixel Track LED
clusters)
DMX Mode 4 : 12-channel operation (Control 2 sets of 4 LED Pixel Track LED
clusters)
DMX Mode 8 : 6-channel operation (Control 8 LED Pixel Track LED clusters in
unison)

11
Maintenance
The LED Pixel Track requires almost no maintenance. However, you should keep the unit clean.
Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in
liquid.
Keep connections clean. Disconnect electric power, and then wipe the audio connections with a damp
cloth. Make sure connections are thoroughly dry before linking equipment or supplying electric power.
Replacing a Fuse
Power surges, short-circuit or inappropriate electrical power supply may cause a fuse to burn out. If the
fuse burns out, the product will not function whatsoever. If this happens, follow the directions below to do
so.
1. Unplug the unit from electric power source.
2. Insert a screwdriver into the slot in the fuse cover. Turn the screwdriver to the left, at the same time
gently push a bit (Turn and Push). The fuse will come out. (Fig. 3)
3. Remove the broken fuse. If brown or unclear, it is burned out.
4. Insert the replacement fuse into the holder where the old fuse was. Reinsert the fuse cover.
Be sure to use a fuse of the same type and specification. See the product specification label for
details.
Fig. 3
Troubleshooting
Showtec LED Pixel Track
This troubleshooting guide is meant to help solve simple problems.
If a problem occurs, carry out the steps below in sequence until a solution is found. Once the unit
operates properly, do not carry out following steps.
1. If the device does not operate properly, unplug the device.
2. Check the fuse, power from the wall, all cables etc.
3. If all of the above appears to be O.K., plug the unit in again.
4. If you are unable to determine the cause of the problem, do not open the LED Pixel Track, as this may
damage the unit and the warranty will become void.
5. Return the device to your Showtec dealer.

12
Product Specification
Model: Showtec LED Pixel Track
Voltage : AC 230V-50Hz (CE)
Power: 115W
Fuse: 250V / T1,5A
Audio trigger: Built-in Mic
DMX Input : 3-pin XLR Male connector
DMX Output : 3-pin XLR Female connector
Dimensions : 811 x 173 x 160 mm (LxWxH)
Weight : 8,2 kg
Design and product specifications are subject to change without prior notice.
Website: www.Showtec.info
Email: [e-mail]
