Show Tec Phantom 75 MKII Led Spot v1 User manual

Phantom 75 MKII LED Spot V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 40207
MANUAL
ENGLISH

1
Ordercode: 40207
Phantom 75 MKII LED Spot
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Features ..........................................................................................................................................................................7
Frontside..........................................................................................................................................................................7
Backside .........................................................................................................................................................................8
Installation...........................................................................................................................................................................8
Set Up and Operation .......................................................................................................................................................8
Control Modes...............................................................................................................................................................9
One Phantom (Auto) ................................................................................................................................................9
One Phantom (Sound-controlled) .........................................................................................................................9
Multiple Phantoms (Master/Slave control) ...........................................................................................................9
Multiple Phantoms (DMX Control) ........................................................................................................................10
Fixture Linking...............................................................................................................................................................11
Data Cabling...............................................................................................................................................................11
Control Panel ...............................................................................................................................................................12
Control Mode ..............................................................................................................................................................12
DMX Addressing ..........................................................................................................................................................12
Menu Overview...........................................................................................................................................................13
Main Menu Options....................................................................................................................................................14
1. DMX Addressing...................................................................................................................................................14
2. Control Modes .....................................................................................................................................................14
2.1. DMX-512 Mode .................................................................................................................................................15
2.2. Master/Slave Mode .........................................................................................................................................15
2.3. Auto Mode ........................................................................................................................................................15
2.4. Sound-controlled Mode..................................................................................................................................16
3. Setup ......................................................................................................................................................................16
3.1. Pan Reverse.......................................................................................................................................................16
3.2. Tilt Reverse..........................................................................................................................................................16
3.3. Screen Reverse .................................................................................................................................................17
3.4. Pan Angle ..........................................................................................................................................................17
3.5. Tilt Angle .............................................................................................................................................................17
3.6. Sound Sensitivity................................................................................................................................................17
4. System Information..............................................................................................................................................17
DMX Channels .............................................................................................................................................................18
8 Channels ................................................................................................................................................................18
14 Channels ..............................................................................................................................................................19
Maintenance....................................................................................................................................................................22
Replacing the Fuse.....................................................................................................................................................22
Replacing a Gobo From the Rotating Gobo Wheel ...........................................................................................23
Replacing a Gobo From the Rotating Gobo Wheel ...........................................................................................24
Rotating Gobo Wheel + Color Wheel.....................................................................................................................24
Troubleshooting ...............................................................................................................................................................25
No Light.........................................................................................................................................................................25
No Response to DMX..................................................................................................................................................25
Product Specifications....................................................................................................................................................27
Dimensions........................................................................................................................................................................28
Notes ..................................................................................................................................................................................29

2
Ordercode: 40207
Phantom 75 MKII LED Spot
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec Phantom 75 MKII LED Spot
IEC power cable (1,5 m)
1 bracket and 2 screws for truss mounting
Safety eye
User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual

3
Ordercode: 40207
Phantom 75 MKII LED Spot
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged. Always
hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Never loosen the screws of the rotating gobo otherwise you risk opening of the ball bearing.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced. So that its functions are not impaired, due to
cracks or deep scratches.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. Moving head must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.

4
Ordercode: 40207
Phantom 75 MKII LED Spot
•The user is responsible for correct positioning and operating of the Phantom. The manufacturer will
not accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the fixture is lowered from the ceiling or high joists, professional trussing systems have to be used.
•Use a clamp to mount the projector, with the mounting bracket, to the trussing system.
•The fixture must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the projector, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.

5
Ordercode: 40207
Phantom 75 MKII LED Spot
The Phantom can be placed on a flat stage floor or mounted to any kind of truss with a clamp.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE
GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!

6
Ordercode: 40207
Phantom 75 MKII LED Spot
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

7
Ordercode: 40207
Phantom 75 MKII LED Spot
Description of the device
Features
The Phantom 75 MKII LED Spot is a moving head with high output and great effects.
Input voltage: 100-240V AC, 50/60Hz
Power consumption: 230W
Light source: 1 x 75W White LED
Light output: 24500 Lux @ 1m (at 17°)
Beam angle: 17-20°
User-selectable Pan & Tilt ranges: 540°/360°/180°
Reverse Pan/Tilt movement
Special: Pan/Tilt movement blackout
Pan 0º-540º, Tilt 0º-270º
Pan/Tilt resolution: 16 bit
Channel modes: 8, 14 channels
Control: DMX-512, Auto, Master/Slave, Sound-controlled
16 built-in programs selectable with DMX
Color wheel with 8 dichroic colors and open
Color functions: Split colors, Rainbow-flow effect
Rotating gobo wheel with 2 glass gobos, 5 metal gobos and open with Gobo Shake Function
Prism: 3-facet prism
Gobo functions: Gobo-flow effect, Gobo shake
Dimmer: 0-100%
Strobe: 0-20Hz
Focus: Motorized focus
Housing: Black metal & flame-retardant plastic
Connectors: 3-pin XLR IN/OUTpin), IEC power connector 100-240V AC
Fuse: F4A/250V
Dimensions: 330 x 245 x 445 mm (LxWxH)
Weight: 11,4 kg
Frontside
Fig. 01
01) 1 x 75W White LED
02) LCD display + menu buttons

8
Ordercode: 40207
Phantom 75 MKII LED Spot
Backside
Fig. 02
03) IEC 100-240V power connector IN
04) IEC 100-240V power connector OUT
05) Fuse F4A/250V
06) 3-pin DMX signal connector IN
07) 3-pin DMX signal connector OUT
Installation
Remove all packing materials from the Phantom 75 MKII LED Spot. Check if all foam and plastic padding
is removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.

9
Ordercode: 40207
Phantom 75 MKII LED Spot
Control Modes
There are 4 modes:
• Stand-alone (Auto)
• Sound-controlled
• Master/Slave
• DMX-512 (8CH, 14CH)
One Phantom (Auto)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Phantom is not connected with a DMX cable, it functions as a stand-alone device.
Please see page 15 for more information about Auto mode.
One Phantom (Sound-controlled)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Turn on the music. If the device is set to sound-control, then the Phantom will react to the beat of
the music. Please see page 16 for more information about the sound-control options.
Multiple Phantoms (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Use a 3-pin XLR cable to connect the Phantom.
The pins:
01) Earth
02) Signal -
03) Signal +
03) Link the units as shown in fig. 03. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
You can use the same functions on the master device as described on page 15-16 (Auto Mode or
Sound-controlled Mode). This means that you can set your desired operation mode on the master
device and all slave devices will react the same as the master device.
Multiple Phantoms (Master/Slave control)
Fig. 03

10
Ordercode: 40207
Phantom 75 MKII LED Spot
Multiple Phantoms (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the Phantoms and other devices.
04) Link the units as shown in fig. 04. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple Phantoms DMX Set Up
Fig. 04
Note : Link all cables before connecting electric power

11
Ordercode: 40207
Phantom 75 MKII LED Spot
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX
optically isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m), FL09150 (1,5
m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).

12
Ordercode: 40207
Phantom 75 MKII LED Spot
The Phantom 75 MKII LED Spot can be operated with a controller in control mode or without the controller
in stand-alone mode.
Control Panel
A) LCD display
B) MODE button
C) UP button
D) DOWN button
E) ENTER button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the Phantom will respond to the controller.
Please note, when you use the controller, the unit has 14 channels.
When using multiple Phantoms, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Phantom should be 1(001); the DMX address of the second
Phantom should be 1+14=15 (015); the DMX address of the third Phantom should be 15+14=29 (029), etc.
Please, be sure that you do not have any overlapping channels in order to control each Phantom
correctly. If two or more Phantoms are addressed similarly, they will work similarly.
Controlling:
After having addressed all Phantom fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the Phantom will automatically detect whether DMX 512 data is received or
not.
If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Phantom 75 MKII LED Spot.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.

13
Ordercode: 40207
Phantom 75 MKII LED Spot
Menu Overview

14
Ordercode: 40207
Phantom 75 MKII LED Spot
Main Menu Options
DMX Address
DMX-512 mode / Master-Slave mode / Auto / Sound-controlled mode
Audio Sensitivity / Pan + Tilt/Reverse Pan + Tilt / Display/Reverse Display/ Pan + Tilt
Angle
System Info
1. DMX Addressing
With this menu, you can set the DMX address of your Phantom 75 MKII LED Spot.
01) Press the MODE button, until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to choose the desired DMX address. The adjustment range is between
001-512.
04) Press the ENTER button to confirm the address.
2. Control Modes
With this menu, you can select the desired control mode.
01) Press the MODE button, until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to select one of the following 4 control modes:

15
Ordercode: 40207
Phantom 75 MKII LED Spot
2.1. DMX-512 Mode
01) Press the UP/DOWN buttons until the display shows:
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to choose one of the 2 channel modes: 8-channel mode or 14-channel
mode.
04) Press the ENTER button to confirm your choice.
2.2. Master/Slave Mode
01) Press the UP/DOWN buttons until the display shows:
02) Press the UP/DOWN buttons until the display shows .
03) Press the ENTER button to open the menu.
04) Press the UP/DOWN buttons to choose between Slave1-Slave4.
05) Press the ENTER button to confirm your choice.
06) The device is now operating in the slave mode. It means that it will react the same as the master
device.
2.3. Auto Mode
01) Press the UP/DOWN buttons until the display shows:
02) Press the ENTER button to activate the mode.
03) The device will now run the automatic built-in program.

16
Ordercode: 40207
Phantom 75 MKII LED Spot
2.4. Sound-controlled Mode
01) Press the UP/DOWN buttons until the display shows:
02) Press the ENTER button to activate the mode.
03) The device will now react to the beat of the background music.
3. Setup
With this menu, you can adjust the settings of your Phantom 75 MKII LED Spot.
01) Press the MODE button, until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle between the following options:
04) Press the ENTER button to open the desired menu and press the UP/DOWN buttons to adjust the
settings.
05) Press the ENTER button to save changes.
3.1. Pan Reverse
01) Press the UP/DOWN buttons to choose Pan Reserve.
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to choose ON/OFF and press the ENTER button to confirm your choice.
04) If you choose ON, the pan function will be reversed.
3.2. Tilt Reverse
01) Press the UP/DOWN buttons to choose Tilt Reserve.
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to choose ON/OFF and press the ENTER button to confirm your choice.
04) If you choose ON, the tilt function will be reversed.

17
Ordercode: 40207
Phantom 75 MKII LED Spot
3.3. Screen Reverse
01) Press the UP/DOWN buttons to choose Screen Reverse.
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to choose ON/OFF and press the ENTER button to confirm your choice.
04) If you choose ON, the display will be reversed.
3.4. Pan Angle
01) Press the UP/DOWN buttons to choose Pan Angle.
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to choose between 3 options: 540°, 360° or 180°.
04) Press the ENTER button to confirm your choice.
3.5. Tilt Angle
01) Press the UP/DOWN buttons to choose Tilt Angle.
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to choose between 3 options: 270°, 180° or 90°.
04) Press the ENTER button to confirm your choice.
3.6. Sound Sensitivity
01) Press the UP/DOWN buttons to choose Sensitivity.
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to set the sound sensitivity. The adjustment range is between 001-100,
from low to high sensitivity.
04) Press the ENTER button to save changes.
3.7. Reset
01) Press the UP/DOWN buttons to choose Reset.
02) Press the ENTER button to perform a full software reset. The fixture will switch off and on.
3.8. Factory Settings
01) Press the UP/DOWN buttons to choose Factory Set.
02) Press the ENTER button to perform a full software reset and restore the factory settings.
4. System Information
With this menu, you view the current parameters of your Phantom 75 MKII LED Spot.
01) Press the MODE button, until the display shows .
02) Press the ENTER button to open the menu. The display will show:
03) Now, it is possible to view the following pieces of information about the Phantom 75 MKII LED Spot:
Current software version
Current active mode
Current DMX address
Current device temperature

18
Ordercode: 40207
Phantom 75 MKII LED Spot
DMX Channels
8 Channels
Channel 1 –Horizontal movement (Pan)
Move the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 540° and stopped at any position you wish.
Channel 2 –Vertical movement (Tilt)
Move the slider up, in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 270° and stopped at any position you wish.
Channel 3 –Color Wheel
Linear color change following the movement of the slider. Between 128 - 255, the color wheel rotates
continuously (so-called “Rainbow” effect).
0-6
Open / White
7-13
Yellow
14-20
Pink
21-27
Green
28-34
Red
35-41
Light Blue
42-48
Light Green
49-55
Orange
56-63
Dark Blue
64-70
Split Color White / Yellow
71-77
Split Color Yellow / Pink
78-84
Split Color Pink / Green
85-92
Split Color Green / Red
93-98
Split Color Red / Light Blue
99-105
Split Color Light Blue / Light Green
106-112
Split Color Light Green / Orange
113-119
Split Color Orange / Dark Blue
120-127
Split Color Dark Blue / White
128-191
Clockwise rotation (CW) rainbow effect from slow to fast
192-255
Counterclockwise rotation (CCW) rainbow effect from slow to fast
Channel 4 –Shutter / Strobe ( Dimmer must be open )
0-3
Close
4-7
Shutter open
8-76
Strobe effect, from slow to fast (0-10 flashes/sec.)
77-145
Pulse strobe effect from slow to fast
146-215
Random strobe effect, from slow to fast (0-10 flashes/sec.)
216-255
Shutter open
Channel 5 –Rotating Gobo-wheel + Gobo Shake
0-7
Open / White
8-15
Gobo 1 (Glass)
16-23
Gobo 2 (Glass)
24-31
Gobo 3 (Metal)
32-39
Gobo 4 (Metal)
40-47
Gobo 5 (Metal)
48-55
Gobo 6 (Metal)
56-63
Gobo 7 (Metal)
64-71
Gobo Shake 7 from slow to fast
72-79
Gobo Shake 6 from slow to fast
80-87
Gobo Shake 5 from slow to fast

19
Ordercode: 40207
Phantom 75 MKII LED Spot
88-95
Gobo Shake 4 from slow to fast
96-103
Gobo Shake 3 from slow to fast
104-111
Gobo Shake 2 from slow to fast
112-119
Gobo Shake 1 from slow to fast
120-127
Open / White
128-191
Clockwise rotation (CW) rainbow effect from slow to fast
192-255
Counterclockwise rotation (CCW) rainbow effect from slow to fast
Channel 6 –Gobo Rotation
0-1
Stop
2-63
Gobo indexing
64-147
Clockwise rotation (CW) from slow to fast
148-231
Counterclockwise rotation (CCW) from slow to fast
232-255
Gobo bouncing
Channel 7 –Prism
0-7
Open
8-12
3-facet Prism Effect, no rotation
13-130
Clockwise rotation (CW) prism effect from slow to fast
131-247
Counterclockwise rotation (CCW) prism effect from slow to fast
248-255
3-facet Prism Effect, no rotation
Channel 8 –Focus
0-255
Continuous adjustment from far to near
14 Channels
Channel 1 –Horizontal movement (Pan)
Move the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 540° and stopped at any position you wish.
Channel 2 –Vertical movement (Tilt)
Move the slider up, in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 270° and stopped at any position you wish.
Channel 3 –Pan fine 16 bit
Channel 4 –Tilt fine 16 bit
Channel 5 –PAN/TILT Speed
0-255
From Max Speed (0) to Min. Speed (255)
Channel 6 –Color Wheel
Linear color change following the movement of the slider. Between 128 - 255, the color wheel rotates
continuously (so-called “Rainbow” effect).
0-6
Open / White
7-13
Yellow
14-20
Pink
21-27
Green
28-34
Red
35-41
Light Blue
42-48
Light Green
49-55
Orange
56-63
Dark Blue
64-70
Split Color White / Yellow
