Clevertronics LP CSBLED Series Installation and operating instructions

1943075 V2.6 March 2019
Testing:
Once connected to the 240V mains supply, the unit must be allowed to charge the battery for at least 24
hours. Conduct the following tests:
•For the first test, the emergency lamp must remain illuminated for at least 2 (4 for the -4HR) hours
after disconnection from the mains supply.
•Subsequent tests require the unit to illuminate for at least 90 minutes (4 hours for -4HR). The results
of all tests are required to be recorded in a service logbook, which is to be kept on-site at all times.
If the unit fails to remain illuminated for the requisite time, remedial action must be taken to repair
the situation and once completed, the unit must pass a subsequent test. For more specific
information, please refer to the current edition of the AS 2293.3 Standard.
Swingblade Maintenance:
Battery/Lamp Replacement:
•Prise off the plastic end caps from ends
using a terminal screwdriver
•Disconnect the lamp lead from the PCB
and slide out the LED light bar.
•Reinsert new LED light bar, reconnect the
lamp lead and replace the plastic end cap..
•Remove the central screw connecting the
two earth leads to the earth bar. This screw
holds the equipment tray in place.
•Slide the gear tray out from the test
switch/light bar end, unplugging the AC
connector once it is revealed.
•Unplug the battery lead then bend back the
metal tabs securing the battery pack.
Remove the battery and replace with the
changeover battery pack.
•Re-assemble the fitting reversing the above
procedure. It is important that the screw
securing the two earth leads is re-installed
and tightened correctly.
Trouble Shooting:
Below are a list of common problems and their
possible causes.
Fault: The Green LED Test Switch
indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected
Test Switch for damage.
Fault: Lamp does not illuminate in
emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency
mode, but only stays on for a short
period.
Check: Battery has been allowed to charge for
at least 24 hours.
Battery for damage.
Rated Emergency Lumen Output in accordance with AS2293.1 (refer
to spacing tables for installation positions):
Refer to tech label for classification details (Not applicable to TH version).
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or “cycled”. The battery in this fitting has been selected to give excellent long life performance
in a controlledAS2293 testing environment. Excessive battery cyclingwill reduce through-life performance
and may lead to premature battery failure. Battery warranty claims, as a result of such abuse, are
specifically EXCLUDED from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
LP™ Swingblade LED
Installation & Maintenance Instruction Leaflet
Designed in Australia to comply with the
requirements of AS2293.3: 2005 and AS/NZS
CISPR15: 2011.
NOTE: Standard product codes with this symbol are
enabled with Clevertest Plus capability. Please refer
to the operation guide supplied with the product for
details.
Victoria (Head Office & Manufacturing)
195 Chesterville Rd Moorabbin VIC 3189
Phone: [phone]
Fax: [phone]
News South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Models:
CSBLED-yy-xx-ss-zz
CCSBLED-yy-xx-ss-zz (Classic blade option)
Testing:
Options:
Special Legend
ss = SP
Manual Test
xx = Blank
4 Hour runtime
zz = 4HR
Zoneworks
xx = ZW
Fire Panel Sound Control
zz = SND-24V
Zoneworks DATA
xx = DATA
Zoneworks Sound Control
zz = SND
DALI Compatible
xx = DALI
Theatre
yy = TH
Clevertest
xx = CT (NOTE: Products supplied with the Clevertest Plus Symbol are
activated with Clevertest PLUS capability. Please refer to the operation guide
supplied with the product for details).
Spare Parts:
1550070
BATT: LP 3.2V 3200mAh 200mm lead, sp.BRKT
1550235
BATT: LP -4HR 3.2V 6400mAh.200mm lead.Brkt
8002355
PCA: Swingblade LED Driver
8002354
PCA:LBSLED-TH #CT10164-L4 6C20 (for use with -TH options)
8002185
PCA: Swingblade Duris LED Strip
Important:
It is illegalfor anyone, except for a licensed electrician toinstall ormaintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.

1943075 V2.6 March 2019
Installation:
The LP Swingblade LED Exit (CSBLED) is a surface mount (wall or ceiling) fitting. The CSBLED can be
attached directly to any solid surface, or to a ceiling tile using the integrated mounting bracket. Please
follow the steps below to install the CSBLED Exit:
•Remove the mounting bracket from the fitting.
•Using the bracket as a guide, mark 2 holes for mounting screws. Then install the bracket.
•Connect the 240VAC supply.
•Insert the CSBLED body into the bracket and slide to lock into position.
•If the CTP capabilities are activated please affix the CTP status Label to a visible surface.
NOTE: If product is suspended below the ceiling or mounted on a metal surface the Swingblade
bracket cover plate accessory (S/N:2740100) is required to cover the mains terminals.
Networking:
When installing the product on a monitored network, (ZONEWORKS, DATA, DALI) simply insert the
relevant Smart Node PCA.
Changing Diffuser Decals: (Not applicable to CCSBLED and –TH
options)
The Swingblade Exit uses Clevertronics patented “Tamper proof” Exit legend cover and comes complete
with spare legend inserts to enable straight on, left or right arrow as well as SS/DS combinations.
The tamper proof cover is held in place by 3 locking tabs recessed in the top edge of the diffuser. Use a
tool to disengage and push the locking tabs through to release the cover and remove the insert, replacing
it with the desired one.
To re-install the clear cover, first engage the three small lugs on the bottom of the cover into the respective
recesses in the diffuser. Once you are sure the lugs are located, carefully push the 3 locking tabs back in
to complete the process.
Clevertronics Clevertest and Clevertest Plus
Refer to the supplementary operation guide supplied with the Product.
After Power ON, the Status LED on a Clevertest Plus enabled fitting will display a rapid Green or Red
flashing for a period up to 2 minutes.
Zoneworks and DATA Monitored Options
Swingblades with part numbers CSBLED-ZW, CSBLED-DATA are fitted with Zoneworks communications
modules (nodes).These fittings are monitored using either Powerline Carrier Technology that utilises the
power cable to provide data communication or a dedicated data cable to/from data routers installed on a
dedicated data trunk connected to a central Server (can also be connected via Ethernet/Internet/Fibre).
Zoneworks software on the server is used to monitor, coordinate testing and collate test data from each
Swingblade and can be commissioned by a single push of the test switch, or scanning of the supplied
barcode. The LED Test Switch indicator provides a multifunction indication of the status of the Swingblade
during testing and normal operation:
State
LED Operation
Commissioned
LED on Solid (Green)
Un-commissioned
LED flashes at 0.5Hz (0.5s Green, 0.5s Yellow)
Emergency Light Test In Progress
LED flashes at 3s On (Yellow) & 0.5s Off
In the case of the DATA version a 2-way “figure 8” cable and terminal block facilitates the connection to
the DATA network via a multi-drop bus (daisy chain connection). For further information of installation of
a Zoneworks LW system, please refer to the Zoneworks Users Guide and Commissioning Guide (incl.
DATA version)
DALI EM Option
Swingblades with part numbers CSBLED-DALI are fitted with DALI modules (nodes) that facilitate
connection and integration to 3rd Party Lighting Control Systems. Before installing the CSBLED-DALI
please confirmthat the Lighting Control System has the capability tomonitor DALI Emergency Luminaires.
The CSBLED-DALI will be addressed and configured into the control system by the Lighting Control
System Commissioning Technicians and not Clevertronics.
State
LED Operation
Commissioned/ Un-commissioned
LED on Solid (Green)
Emergency Light Test in progress
LED flashes at 1s On (Yellow) & 1s Off
“IDENTIFY COMMAND”
Fitting goes into emergency mode for 10 seconds
A 2-way “figure 8” cable and terminal block facilitates the connection to the DALI network. DALI
connections are marked as Da Da.
Press locking tab and slide to remove from bracket
Mounting Bracket
Locking Tab
Locking Tabs
