Show Tec SpaceTracer 2000 CMY User manual

SpaceTracer 2000 CMY
ORDERCODE 40961

Congratulations!
You have bought a great, innovative product from Showtec.
The Showtec SpaceTracer 2000 CMY brings excitement to any venue. Whether you want simple plug-&-
play action or a sophisticated DMX show, this product provides the effect you need.
You can rely on Showtec, for more excellent lighting products.
We design and manufacture professional light equipment for the entertainment industry.
New products are being launched regularly. We work hard to keep you, our customer, satisfied.
For more information: [e-mail]
You can get some of the best quality, best priced products on the market from Showtec.
So next time, turn to Showtec for more great lighting equipment.
Always get the best -- with Showtec !
Thank you!

1
2
2
3
4
5
5
6
6
9
9
10
10
10
11
12
12
12
13
14
15
15
15
15
16
16
16
17
Showtec
Showtec SpaceTracer 2000 CMY™Product Guide
Warning.................................................................................…...……………..…………………………….………..…..
Safety-instructions…………………………………………………………………………………………………………
Operating Determinations.………………………………………………………………………………………………
Rigging.………………………………………………………………………………………………………………………
Description...............................................................................…...………………………………………….………..….
Features and Overview ………………………………...….……………….………….……….……….………………
Installation...............................................................................…...…………………………………………………...….
Installing the Lamp ........................................................………………………………………………………….......
Lamp Adjustment.….......................................................………………………………………..…….………………
Locking the Head and Base.............................................………………………………………..…….……………
Set Up and Operation.....................................................................……..………………………………………………
One SpaceTracer........................................................................………………………………………..…………..
Multiple SpaceTracers........................................................................…………………………….………………...
DMX Protocol………...................................................…………………………………………………………………
Control Panel….............……....................................…………………………………………………………………..
Control Mode........................................…………………………………………………………………………………
DMX addressing...................................………………………………………………….…………………………..….
Control panel functions...................................…………………………………………………………………………
Menu Functions Explained.............................…………………………………………………………………………
Addressing…………………………………………………………………………………………………………………..
Maintenance...................................................................................………..………….…….…………………………..
Changing the Lamp........................................................................…………………….…………………………..
Replacing the Fuse........................................................................…………………….…………………………….
Troubleshooting............................................................................………………….………………….………………...
No Light..………………………………………..........................................………………….……………………….....
No Response to DMX ....................................................................………………….……………………………….
Product Specifications.................................................................……………….…….………………………………...

2
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!
SAFETY INSTRUCTIONS
Every person involved with the installation, operation and maintenance of this device has to:
-be qualified
-follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-
observance of this manual or any unauthorized modification to the device.
Never let the power-cord come into contact with other cables! Handle the power-cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never run the device without lamp!
Never ignite the lamp if the objective-lens or any housing-cover is open, as discharge lamps may
expose and emit a high ultraviolet radiation, which may cause burns.
Never look directly into the light source.
Never leave any cables lying around.
Do not insert objects into air vents.
Do not connect this device to a dimmerpack.
Do not switch the device on and off in short intervals, as this would reduce the lamp’s life.
If the lamp has been turned OFF, let the lamp cool down for 15 minutes, before turning the lamp
ON again.
Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Do not shake the device. Avoid brute force when installing or operating the device.
Only use device indoor, avoid contact with water or other liquids.
Only operate the fixture after having checked that the housing is firmly closed and all screws are
tightly fastened.
Only operate the device after having familiarized with its functions.
Avoid flames and do not put close to flammable liquids or gases.
Always replace the lamp, when it is damaged or deformed due to the heat.
Always keep case closed while operating.
Always allow free air space of at least 50 cm around the unit for ventilation.
CAUTION!
Keep this device away from rain and moisture!
Unplug mains lead before opening the housing!
CAUTION! Be careful with your operations.
With a dangerous voltage you can suffer
a dangerous electric shock when touching the wires!

3
Always disconnect power from the mains, when device is not used, before cleaning or when
replacing lamp! Only handle the power-cord by the plug. Never pull out the plug by tugging the
power-cord.
Make sure that the device is not exposed to extreme heat, moisture or dust.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power-cord is never crimped or damaged. Check the device and the power-
cord from time to time.
If the lens is obviously damaged, it has to be replaced. So that its functions are not impaired, due
to cracks or deep scratches.
If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do
not switch it on immediately. The arising condensation water might damage your device. Leave
the device switched off until it has reached room temperature.
If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
For adult use only. Sky Spot must be installed out of the reach of children. Never leave the unit
running unattended.
For replacement use lamps and fuses of same type and rating only.
Allow time to cool down, before replacing lamp.
The user is responsible for correct positioning and operating of the Sky Spot. The manufacturer will
not accept liability for damages caused by the misuse or incorrect installation of this device.
This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
During the initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective.
Repairs, servicing and electric connection must be carried out by a qualified technician.
WARRANTY: Till one year after date of purchase.
OPERATING DETERMINATIONS
This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
The minimum distance between light-output and the illuminated surface must be more than 2 meters.
The maximum ambient temperature ta= 40°C must never be exceeded.
The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
If this device is operated in any other way, than the one described in this manual, the product may suffer
damages and the warranty becomes void.
Any other operation may lead to dangers like short-circuit, burns, electric shock, lamp explosion, crash
etc.
You endanger your own safety and the safety of others!
Improper installation can cause serious damage to people and property !
CAUTION ! EYEDAMAGES !.
Avoid looking directly into the light source.
(meant especially for epileptics) !

4
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all other
safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
If the projector is lowered from the ceiling or high joists, professional trussing systems have to be
used.
Use a clamp to mount the projector, with the mounting-bracket, to the trussing system.
The projector must never be fixed swinging freely in the room.
The installation must always be secured with a safety attachment, e.g. an appropriate safety net
or safety-cable.
When rigging, derigging or servicing the projector, always make sure, that the area below the
installation place is blocked and staying in the area is forbidden.
The SpaceTracer can be placed on a flat stage floor or mounted to any kind of truss by a clamp.
Improper installation can cause serious damage to people and property !
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
FASE
N
BLUE
BLACK
SILVER
NUL
YELLOW/GREEN
GREEN
GREEN
EARTH
Make sure that the device is always connected properly to the earth!

5
Description of the device
Features
The Showtec SpaceTracer 2000 CMY is an immensely powerful SpaceTracer.
• Power consumption: 2300 Watt
•Master-slave
• DMX-512
• DMX connector: 3 pole XLR male, female
• Channels: 14
• CMY colour changer frame
• Automatic mechanic dimmer
• Electronic shutter
• Automatic Frost filter
• Electronic beam adjustment 30%- 100%
• Pan/ Tilt auto correction
• Beam angle: 0,8 - 60°
• Lamp Timer
• Lamp and Flightcase included
• IP-33
• Lamp Xenon 2000W Xenon included (ordercode 82640)
• Move the SpaceTracer, horizontally 360º (Pan) and vertically (Tilt) 220º.
Note: If the lamp has been turned OFF, let the lamp cool down for 15 minutes, before turning the lamp
ON again.
Overview
Fig. 1
1) Fuse
2) Powerswitch ON / OFF

6
Installation
Installing the Lamp
The Showtec SpaceTracer 2000 CMY uses the XOB 2000W Xenon (ordercode 82640) bulb as
manufactured by all popular manufacturers. Use only the appropriate lamp for your unit.
Note that, product versions that use other lamps, may be offered in the future. Check your product
specification label for information.
Always disconnect from electric mains power supply before changing lamps.
The lamp has to be replaced when it is damaged or deformed due to the heat.
Do not install lamps with a higher wattage! Lamps with a higher wattage generate temperatures the
device was not designed for.
Damages caused by non-observance are not subject to warranty.
XBO lamps are at high internal pressure when cold (up to 35 bar or approximately 525 psi) and at
operating temperature (up to 80 bar or approximately 1200 psi at bulb wall temperatures of 600°C to
800°C).
Therefore, XBO lamps may unexpectedly rupture resulting in the discharge of hot fragments of quartz
and/or glass and metal. In the event of such a rupture, there is a risk of personal injury, burns and fire.
Only handle lamps with their protective covers in place.
OSRAM XBO: These lamps use standard quartz glass and will also emit UV radiation that produces ozone.
These lamps, like the W/4 types, must always be externally ventilated. With these types of lamps, health
risks must always be minimized by suitably extracting the air from the lamp housing and externally venting
it.
Procedure :
• Always read the safety instructions that are included with the lamp.
• Oil on hands shortens the lamp life. (If you touch the bulb glass, wipe off the glass with a clean,
lint-free towel and rubbing alcohol.).
• Always read all the safety warnings at the beginning of this manual, before replacing the lamp !!!
1. Remove the 14 screws. 2. Remove the 10 screws. The screws pointed out
with the yellow arrows have already been
removed in step1.

7
3. Open up all glass frost lenses. 4. Open up all color filters.
5. Remove the small spring. 6. Now go to the bottom of the head.
7. Remove the small socket screw bolt on the 8. Pull the lamp out of the socket.
bottom of the lamp.
9. The screw on the backside of the lamp can 10. Pull the cable out of the small hole and unscrew
the now be removed and you can take out the screw. You can now take out the entire lamp.
the lamp partially.

8
The broken lamp must be placed in a safe spot, so it cannot fall or break, because of
danger of explosion. The lamp is chemical waste and may not be thrown away. Bring this
lamp to a designated collect point for chemical waste.
When installing the new lamp, pay attention to the polarity of the lamp. The lamp has a positive and a
negative side. This is written on the lamp: -or +.
- Side + Side
Bottom of the lamp base is - side Top of the lamp base is + side

9
Lamp Adjustment
You can adjust the lamp’s position by turning the screw on the backside of the Sky Spot.
The lamp position is set in the factory. As the lamps, which can be used, differ from manufacturer to
manufacturer, it can be necessary to readjust the position. The lamp must be readjusted e.g., if the light
does not seem to be evenly distributed within the ray of light.
First you have to loosen the 4 screws on the back of the device.
Ignite the lamp and focus the ray of light on an even surface (wall). If the Hot Spot appears too bright,
you can weaken its intensity, by moving the lamp closer to the reflector. If the light at the outside edge of
the ray of light appears brighter as in the center, the lamp is too close to the reflector. In this case move
the lamp away from the reflector, until the light is evenly distributed and the ray of light appears bright
enough.
1. Loosen the 4 screws. 2. Turn the screws to focus the lamp.
Locking the Head and Base
After opening the packaging, unlock the TILT of the head, as shown below.
LOCK locks the TILT movement of the head; UNLOCK unlocks the TILT movement of the head
When transporting the device, the head must always be locked twice.
Lock
Unlock
Lock
Unlock
Fig. 2

10
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
One SpaceTracer
1. Fasten the moving head onto firm trussing (Use a proper clamp fastened onto the SpaceTracer).
Leave at least 1 meter on all sides for air circulation.
2. Use a 3-p XLR cable to connect the SpaceTracers and other devices.
The pins:
1. Earth
2. Signal -
3. Signal +
3. Always use a safety cable (ordercode 70140 / 70141).
Multiple SpaceTracers
1. Fasten the effect light onto firm trussing (Use a clamp (Use a proper clamp fastened onto the
SpaceTracer). Leave at least 1 meter on all sides for air circulation.
2. Use a 3-p XLR cable to connect the SpaceTracers and other devices.
The pins:
1. Earth
2. Signal -
3. Signal +
3. Always use a safety cable (ordercode 70140 / 70141).
4. Link the units as shown in (figure 3), Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
5. Supply electric power: Plug electric mains power cords into proper electric power supply sockets,
starting with the first unit. Do not supply power before the whole system is set up and connected
properly.
Multiple SpaceTracers Set Up
DMX-Set up
Fig. 3
Note : Link all cables before connecting electric power

11
DMX Protocol
Channel 1 –Reset - Dimmer intensity
Channel 2 –Shutter, strobe
Channel 3 –Zoom
Channel 4 –Frost
Channel 5 –Cyan *
0-255
Change the color brightness. (CH 8 must be set to 100%)
Channel 6 –Magenta *
0-255
Change the color brightness. (CH 8 must be set to 100%)
Channel 7 –Yellow *
0-255
Change the color brightness. (CH 8 must be set to 100%)
Channel 8 –Speed Colour CMY
Channel 9 –Auto Colour
The device randomly changes its colors. Be sure to also use channel 8 to control the changing speed of
the colors. Without channel 8 the colors don’t change.
Channel 10 –Y (Tilt) Mirror
The device moves its head in the opposite direction.
Channel 11 - Horizontal movement (Pan)
Push the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 360° and stopped at any position you wish.
Channel 12 - Vertical movement (Tilt)
Push the slider, up in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 220° and stopped at any position you wish.
Channel 13 - Pan fine 16 bit
Channel 14 - Tilt fine 16 bit
* NOTE: Channel 5, 6 and 7 work together with CH8.
CH8 controls the speed of CH5, CH6, CH7. When CH8 is at 100%, the movement speed is at its
maximum.
0-3
Reset after 5 seconds
4-255
Gradual adjustment dimmer intensity from 0-100%
0-4
Shutter open
5-253
Strobe effect from slow to fast
254-255
Shutter open
0-255
Continuous adjustment from small to big
0-255
Lambency Effect
0-255
Gradual adjustment from color (CMY) changing speed

12
Control Panel
When the indicator light is on, means the SpaceTracer is working.
Fig. 4
A. Display D. Down Button
B. LED E. Up Button
C. [EXIT] Button F. [M/ENTER] Button
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address the next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign the DMX fixture address, which is the
first channel from which the SpaceTracer will respond to the controller.
Please note when you use the controller, the unit has 14 channels.
When using multiple SpaceTracers, make sure you set the DMX addresses right.
Therefore, the DMX address of the first SpaceTracer should be 1(A001); the DMX address of the second
SpaceTracer should be 1+14=15 (A015); the DMX address of the third SpaceTracer should be 15+14=29
(A029), etc.
Please, be sure that you don’t have any overlapping channels in order to control each SpaceTracer
correctly.
If two or more SpaceTracers are addressed similarly, they will work similarly.
For address settings, please refer to the instructions under ”Addressing’ (menu )
Controlling:
After having addressed all SpaceTracer fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the SpaceTracer will automatically detect whether DMX 512 data is received or
not. If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
The problem may be:
- The XLR cable from the controller is not connected with the input of the SpaceTracer.
- The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It’s necessary to insert a XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.

13
Overview Control Panel Functions
Press Exit to return to the main menu

14
Menu Functions Explained
DMX Address selection
Reset unit, the display will show for 30 seconds
Working Speed selection 80% of the working speed
Maximum working speed
Channel selection 16-bit available for Pan (X) and Tilt (Y)
16-bit not available for Pan (X) and Tilt (Y)
Channel Test selection. First select the channel, then press enter to test the desired
channel
Time Menu LED lifetime, hold enter for 5 seconds to reset time to 0
Unit working hours
Display open
Display main Menu
Display close after 10 seconds
Display inverse
Display normal
Tilt (Y) direction selection Tilt in positive direction
Tilt in negative direction
Pan (Y) direction selection Pan in positive direction
Pan in negative direction

15
Addressing
With this menu you can set the DMX address.
- DMX addressing
1) Press:
Hold for 3 sec Push to select address
2) The first device should be set to ADDR A001.
Maintenance
The operator has to make sure that safety-relating and machine-technical installations are to be
inspected by an expert after every four years in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are to be
inspected by a skilled person once a year.
The following points have to be considered during the inspection:
1. All screws used for installing the device or parts of the device have to be tightly connected and must
not be corroded.
2. There may not be any deformations on housings, fixations and installation spots.
3. Mechanically moving parts like axles, eyes and others may not show any traces of wearing.
4. The electric power supply cables must not show any damages or material fatigue.
The Showtec SpaceTracer 2000 CMY requires almost no maintenance. However, to keep luminous flux
rate at a high level, you must clean the lamp with a soft cloth or cotton stick to wipe the mirrors.
Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply, and
then wipe the cover with a damp cloth. Do not immerse in liquid. Wipe lens clean with glass cleaner and
a soft cloth. Do not use alcohol or solvents.
Clean all optics (lens and reflector) regularly to increase the Sky effect.
The cooling-fans and the lens should be cleaned monthly with a soft brush.
Please clean reflector once every 2 months with a soft cloth or a cotton stick dipped in alcohol.
Keep connections clean. Disconnect electric power, and then wipe the DMX and audio connections
with a damp cloth. Make sure connections are thoroughly dry before linking equipment or supplying
electric power.
Changing the Lamp
1. Disconnect the Sky Spot from the power and let the device cool down for 15 minutes.
2. Follow directions for installing a new lamp, page 6.
Replacing a Fuse
Power surges, short-circuit or inappropriate electrical power supply may cause a fuse to burn out. If the
fuse burns out, the product will not function whatsoever. If this happens, follow the directions below to do
so.
1. Unplug the unit from electric power source.
2. Insert a screwdriver into the slot in the fuse cover. Turn the screwdriver to the left, at the same time
Gently push a bit (Turn and Push). The fuse will come out.
3. Remove the used fuse. If brown or unclear, it is burned out.
4. Insert the replacement fuse into the holder where the old fuse was. Reinsert the fuse cover. Be sure to
use a fuse of the same type and specification. See the product specification label for details.

16
Troubleshooting
No Light
This troubleshooting guide is meant to help solve simple problems. If a problem occurs, carry out the steps
below in sequence until a solution is found. Once the unit operates properly, do not carry out following
steps.
If the light effect does not operate properly, refer servicing to a technician.
Response: Suspect three potential problem areas: the power supply, the lamp, the fuse.
1. Power supply. Check that the unit is plugged into an appropriate power supply.
2. The lamp. Replace the old lamp with a new one with the same specifications. See page 6 for
replacing lamps.
3. The fuse. Replace the fuse. See page 10 for replacing the fuse.
No Response to DMX
Response: Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card
malfunction.
1. Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power.
Try your DMX control again.
2. Determine whether the controller or light effect is at fault. Does the controller operate properly with
other DMX products ? If not, take the controller in for repair. If so, take the DMX cable and the light
effect to a qualified technician.
Problem
Probable cause(s)
Remedy
Fixtures is
completely dead.
No power to the fixture
· Check that power is switched on
and cables are plugged in.
Primary fuse blown.
· Replace fuse.
No light
The power supply settings do not
match local AC voltage and
frequency.
· Disconnect fixture. Check settings
and correct if necessary.
Lamp missing or blown
· Disconnect fixture and replace lamp.
Lamp cuts out
intermittently.
Fixture is too hot.
· Allow fixture to cool.
· Clean fan.
· Make sure air vents at control panel
and front lens are not blocked.
· Turn up the air conditioning.

17
Product Specification
Model: Showtec SpaceTracer 2000 CMY
Voltage: 240V-50Hz (CE)
Power consumption: 2300 Watt
Master-slave, standalone control
DMX-512
DMX connector: 3 pole XLR male, female
Channels: 14
CMY colour changer frame
Automatic mechanic dimmer
Electronic shutter
Automatic Frost filter
Electronic beam adjustment 30%- 100%
Pan: 360°
Tilt: 220°
Pan/ Tilt auto correction
Beam angle: 0,8 - 60°
Lamp Timer
Lamp and Flightcase included
Dimensions: 540 x 310 x 640 mm (LxWxH)
Flightcase Dimensions incl wheels : 600 x 430 x 900 mm (LxWxH)
Weight: 33 kg excl. flightcase; Weight including flightcase 57 kg
IP-Rate: IP-33
For indoor use only!
Lamp
Allowed lamp models*:
Osram XOB 2000W Xenon (1000 hr; 155000 Lumen) (ordercode 82640)
Minimum distance:
Minimum distance from flammable surfaces: 0.5m
Minimum distance to lighted object: 2m
*: Versions for other lamps may be produced. Please check the specification label on your product.
Design and product specifications are subject to change without prior notice.
Website: www.Highlite.nl
Email: [e-mail]
