Show Tec Aircone Q6 WDMX User manual

Aircone Q6 WDMX V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 40314
MANUAL
ENGLISH

1
Ordercode: 40314
Aircone Q6 WDMX
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Features ..........................................................................................................................................................................7
Overview ........................................................................................................................................................................7
Installation...........................................................................................................................................................................8
Set Up and Operation .......................................................................................................................................................8
Cone Installation ...........................................................................................................................................................8
Wireless DMX Control ...................................................................................................................................................9
Transmitter/Receiver Mode Selection ...................................................................................................................9
Transmitter Mode .......................................................................................................................................................9
Receiver Mode...........................................................................................................................................................9
Control Modes.............................................................................................................................................................10
One Aircone (Auto, Built-in programs and Manual).........................................................................................10
One Aircone (Sound-controlled)..........................................................................................................................10
Multiple Aircones (Master/Slave control)............................................................................................................10
Multiple Aircones (DMX Control) ..........................................................................................................................11
Fixture Linking...............................................................................................................................................................12
Data Cabling...............................................................................................................................................................12
Control Panel ...............................................................................................................................................................13
Control Mode ..............................................................................................................................................................13
DMX Addressing ..........................................................................................................................................................13
Menu Overview...........................................................................................................................................................14
Main Menu Options....................................................................................................................................................15
1. Auto........................................................................................................................................................................15
2. Built-in programs ..................................................................................................................................................15
3. Manual (Static Colors) ........................................................................................................................................16
4. Sound-controlled .................................................................................................................................................16
5. DMX-512 ................................................................................................................................................................16
6. Master/Slave.........................................................................................................................................................16
7. Settings...................................................................................................................................................................16
7.1. Dimming Curves................................................................................................................................................17
7.2. Fan Speed..........................................................................................................................................................17
7.3. DMX Failure ........................................................................................................................................................17
7.4. Reset Settings ....................................................................................................................................................17
DMX Channels .............................................................................................................................................................18
3 channels (3.b) .......................................................................................................................................................18
6 channels (6.A) .......................................................................................................................................................18
6 channels (6.C).......................................................................................................................................................20
12 channels (12.F)....................................................................................................................................................20
Maintenance....................................................................................................................................................................22
Replacing the Fuse.....................................................................................................................................................22
Troubleshooting ...............................................................................................................................................................23
No Light.........................................................................................................................................................................23
No Response to DMX..................................................................................................................................................23
Product Specifications....................................................................................................................................................25
Dimensions........................................................................................................................................................................26

2
Ordercode: 40314
Aircone Q6 WDMX
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec Aircone Q6 WDMX
1 x cone with Velcro
PowerCON power cable (1,5 m)
2 x quick-lock brackets for truss mounting
User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual

3
Ordercode: 40314
Aircone Q6 WDMX
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged. Always
hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Do not insert objects into air vents.
•Do not connect this device to a dimmer pack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. The device must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.
•The user is responsible for correct positioning and operating of the Aircone. The manufacturer will not
accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.

4
Ordercode: 40314
Aircone Q6 WDMX
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•To eliminate wear and improve lifespan, during periods of non-use, completely disconnect from
power via breaker or by unplugging.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the Aircone is lowered from the ceiling or high joists, professional trussing systems have to be used.
•Use a clamp to mount the Aircone, with the mounting bracket, to the trussing system.
•The Aircone must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the Aircone, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.

5
Ordercode: 40314
Aircone Q6 WDMX
The Aircone can be placed on a flat stage floor or mounted to any kind of truss with a clamp.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!

6
Ordercode: 40314
Aircone Q6 WDMX
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

7
Ordercode: 40314
Aircone Q6 WDMX
Description of the device
Features
The Aircone Q6 WDMX is equipped with 6x 8W Q6 RGBWA-UV LEDs and can be controlled by means of
wireless DMX (WDMX Sweden protocol). It is possible to adjust the fan speed. The Aircone Q6 WDMX is the
ultimate decorative light effect, suitable for a wide range of venues, such as: festivals, stages, weddings,
corporate events and theme parks.
Input voltage: 100-240V AC, 50/60Hz
Power consumption: 160W
Light source: 6 x 8W RGBWA-UV LEDs
DMX channels: 3, 6, 6, 12 channels
4-digit LED display
Control modes: Auto, Built-in programs, Static Colors, Sound, Slave, DMX
Control protocol: DMX-512, WDMX
Dimmer: 0-100%
Strobe: 0-20Hz
Connections: 3-pin XLR data connectors IN/OUT, PowerCON power connector IN/OUT
IP rating: IP-20
Housing: Aluminum
Color: Black
Cone length: 2500 mm
Fuse: T2AL/250V
Dimensions: 470 x 150 mm (WxH)
Weight: 11 kg
Optional accessories
40315 –Separate cone for the Aircone Q6 WDMX
40316 –Separate pyramid cone for the Aircone Q6 WDMX
Overview
Fig. 01
01) 100-240V PowerCON power connector Blue IN
02) 100-240V PowerCON power connector Grey OUT
03) Fuse T2AL/250V
04) 3-pin DMX signal connector OUT
05) 3-pin DMX signal connector IN
06) LED display + control buttons
07) Function button
08) Built-in microphone
09) Wireless DMX LED indicator
10) Power switch ON/OFF
11) Velcro strip
12) Wireless DMX antenna
13) 6 x 8W RGBWA-UV LEDs
14) Air exhaust

8
Ordercode: 40314
Aircone Q6 WDMX
Installation
Remove all packing materials from the Aircone Q6 WDMX. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.
Cone Installation
Fig. 02
Attach the Velcro strip on the cone to the Velcro strip on the edge of the Aircone.

9
Ordercode: 40314
Aircone Q6 WDMX
Wireless DMX Control
Transmitter/Receiver Mode Selection
01) Press the Function button (07) once. The display will show the currently selected wireless DMX
operation mode:
Transmitter mode
Receiver mode
02) Press and hold down the Function button (07) for 5 seconds in order to switch between the 2
operation modes (Transmitter mode and Receiver mode).
03) The display will count up from 0 to 5, to indicate how long the Function button (07) remains pressed.
04) When the display shows “5,” release the Function button (07). The operation mode has been
changed.
05) Press the Function button (07) once, to see the currently selected operation mode.
06) Repeat steps 2-5 to switch to the other operation mode.
Transmitter Mode
In this mode, the Aircone sends DMX signals to the paired receivers.
01) Press and hold down the Function button (07), until the display shows . The Aircone will now
attempt to connect to the available wireless DMX receivers. The LED indicator (09) will be blinking
fast. Once the connection has been established, the LED indicator (09) remains on.
02) Press one of the control buttons (06) to enter main menu and choose the desired operation mode.
This step is necessary for the Aircone to send a DMX signal to wireless DMX receivers. When a DMX
signal is being sent, the LED indicator (09) will be blinking slowly.
03) Press and hold down the Function button (07), until the display shows . The Aircone will now
terminate the connection with all paired wireless DMX receivers.
Receiver Mode
In this mode, the Aircone receives DMX signals sent by a transmitter.
01) When the Aircone does not receive any signal, the LED indicator (09) is off.
02) Try to pair your transmitter with the Aircone. The LED indicator (09) will be blinking fast. Once the
connection has been established, the LED indicator (09) will be blinking slowly.
03) When the Aircone receives a signal from the transmitter, the LED indicator (09) is on.
04) Press and hold down the Function button (07), until the display shows . The Aircone will now
terminate the connection with the transmitter.

10
Ordercode: 40314
Aircone Q6 WDMX
Control Modes
There are 6 modes:
•Stand-alone (Auto)
•Built-in programs
•Manual
•Sound-controlled
•Master/Slave
•DMX-512 (3CH, 6CH, 6CH, 12CH)
One Aircone (Auto, Built-in programs and Manual)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the Aircone is not connected with a DMX cable, it functions as a stand-alone device.
Please see page 15 for more information about Auto, Built-in programs and Manual mode.
One Aircone (Sound-controlled)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) Turn on the music. If the device is set to sound-control, then the Aircone will react to the beat of the
music. Please see page 16 for more information about the sound-control options.
Multiple Aircones (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Use a 3-pin XLR cable to connect the Aircone.
The pins:
01) Earth
02) Signal -
03) Signal +
03) Link the units as shown in fig. 03. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX signal cable. Repeat this process to link the second, third, and fourth units.
You can use the same functions on the master device as described on pages 15-16 (Auto, Built-in
programs, Manual or Sound-controlled mode). This means that you can set your desired operation
mode on the master device and all slave devices will react the same as the master device.
Multiple Aircones (Master/Slave control)
Fig. 03

11
Ordercode: 40314
Aircone Q6 WDMX
Multiple Aircones (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the Aircones and other devices.
04) Link the units as shown in fig. 04. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's PowerCON socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Aircones DMX Set Up
Fig. 04
Note : Link all cables before connecting electric power

12
Ordercode: 40314
Aircone Q6 WDMX
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Maximum recommended number of devices on a power link @120V: 3 fixtures
Maximum recommended number of devices on a power link @230V: 7 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).

13
Ordercode: 40314
Aircone Q6 WDMX
The Aircone Q6 WDMX can be operated with a controller in control mode or without the controller in
stand-alone mode.
Control Panel
A) LED display
B) MODE button
C) SETUP button
D) UP button
E) DOWN button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the Aircone will respond to the controller.
Please note, when you use the controller, the unit has 12 channels.
When using multiple Aircones, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Aircone should be 1(001); the DMX address of the second Aircone
should be 1+12=13 (013); the DMX address of the third Aircone should be 13+12=25 (025), etc.
Please, be sure that you do not have any overlapping channels in order to control each Aircone
correctly. If two or more Aircones are addressed similarly, they will work similarly.
Controlling:
After having addressed all Aircone fixtures, you may now start operating these via your lighting controller.
Note: After switching on, the Aircone will automatically detect whether DMX 512 data is received or not.
If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Aircone Q6 WDMX.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 60 seconds
When no button is pressed for 60 seconds, the display will turn off.
To light up the display, you have to press the MODE, SETUP, UP or DOWN button.
Once you have pressed the button, the display will light up.

14
Ordercode: 40314
Aircone Q6 WDMX
Menu Overview

15
Ordercode: 40314
Aircone Q6 WDMX
Main Menu Options
1. Auto
2. Built-in programs
3. Manual (Static Colors)
4. Sound-controlled
5. DMX-512
6. Master/Slave
7. Settings
The Aircone will show its software version upon start-up: .
1. Auto
01) While in main menu, press the MODE button until the display shows .
02) The device will now run the built-in programs in a sequence.
2. Built-in programs
01) While in main menu, press the MODE button until the display shows .
02) Press the SETUP button to enter.
03) Press the UP/DOWN buttons to choose the desired built-in program.
The adjustment range is between and .
04) If you have chosen , press the SETUP button to open the menu.
05) Press the UP/DOWN buttons to choose the desired color macro. The adjustment range is between
.
06) Press the SETUP button to proceed to strobe settings.
07) Press the UP/DOWN buttons to set the strobe frequency. The adjustment range is between
, from OFF to high frequency.
08) In step 3, if you have chosen one of the programs , press the SETUP button to
open the menu.
09) Press the UP/DOWN buttons to set the program speed. The adjustment range is between
, from slow to fast and full speed.
10) Press the SETUP button to proceed to strobe settings.
11) Press the UP/DOWN buttons to set the strobe frequency. The adjustment range is between
, from OFF to high frequency.

16
Ordercode: 40314
Aircone Q6 WDMX
3. Manual (Static Colors)
01) While in main menu, press the MODE button until the display shows .
02) Press the SETUP button to enter.
03) Repeatedly press the SETUP button to toggle through the following static colors RED, GREEN, BLUE,
WHITE, AMBER, UV.
04) Press the UP/DOWN buttons to set the LED brightness.
Red
0-255
Green
0-255
Blue
0-255
White
0-255
Amber
0-255
UV
0-255
05) The adjustment range for each color is between 0-255.
06) Use the Up / Down buttons to change the strobe speed from .
07) You can combine RED, GREEN, BLUE, WHITE, AMBER and UV to create an infinite range of colors (0-
255).
4. Sound-controlled
01) While in main menu, press the MODE button until the display shows .
02) Press the SETUP button to enter.
03) Press the UP/DOWN buttons to set the sound sensitivity. The adjustment range is between
, from OFF to high sound sensitivity.
5. DMX-512
01) While in main menu, press the MODE button until the display shows .
02) Press the SETUP button to enter.
03) Press the UP/DOWN buttons to choose the desired DMX address.
The adjustment range is between .
6. Master/Slave
01) While in main menu, press the MODE button until the display shows .
02) The device is now operating in Slave mode and will react the same as its master device.
7. Settings
01) While in main menu, press the MODE buttons until the display shows .
02) Press the SETUP button to enter.
03) Repeatedly press the UP/DOWN buttons to toggle through the following submenus:
Dimming curves
Fan speed
DMX failure
Reset settings
04) Press the SETUP button to open the desired menu.

17
Ordercode: 40314
Aircone Q6 WDMX
7.1. Dimming Curves
01) While in this menu, press the UP/DOWN buttons to set one of the 4 dimming curves:
7.2. Fan Speed
01) While in this menu, press the UP/DOWN buttons to set the fan speed. The adjustment range is
between , from slow to fast.
7.3. DMX Failure
01) While in this menu, press the UP/DOWN buttons to choose OFF or HOLD.
02) If you have chosen , in case of a DMX failure, the Aircone will cut off its light output.
03) If you have chosen , in case of a DMX failure, the Aircone will use the last working DMX
signal, ensuring undisrupted performance.
7.4. Reset Settings
01) While in this menu, press the UP/DOWN buttons to choose between NO and YES.
02) If you have chosen , press the SETUP button. The device will return to main menu.
03) If you have chosen , press the SETUP button. The device’s settings will be reset.

18
Ordercode: 40314
Aircone Q6 WDMX
DMX Channels
3 channels (3.b)
Channel 1 –Dimmer
0-255
Dimmer intensity, from dark to brightest
Channel 2 –Strobe CH1 must be open
0-255
Strobe ON, from low to high frequency
Channel 3 –Color presets CH1 must be open
0-6
OFF
7-13
Color 1: R(255)G(0)B(0)W(100)A(0)P(0)
14-20
Color 2: R(255)G(0)B(0)W(200)A(0)P(0)
21-27
Color 3: R(255)G(50)B(0)W(0)A(0)P(0)
28-34
Color 4: R(255)G(150)B(0)W(0)A(255)P(0)
35-41
Color 5: R(255)G(255)B(0)W(0)A(120)P(0)
42-48
Color 6: R(255)G(255)B(0)W(75)A(0)P(0)
49-55
Color 7: R(0)G(255)B(0)W(255)A(0)P(0)
56-62
Color 8: R(0)G(255)B(0)W(150)A(0)P(0)
63-69
Color 9: R(0)G(255)B(0)W(50)A(0)P(0)
70-76
Color 10: R(0)G(255)B(0)W(0)A(0)P(0)
77-83
Color 11: R(0)G(255)B(50)W(0)A(0)P(50)
84-90
Color 12: R(0)G(255)B(150)W(0)A(0)P(150)
91-97
Color 13: R(0)G(255)B(255)W(0)A(0)P(255)
98-104
Color 14: R(0)G(255)B(255)W(75)A(0)P(255)
105-111
Color 15: R(0)G(255)B(255)W(150)A(0)P(255)
112-118
Color 16: R(0)G(100)B(255)W(255)A(0)P(255)
119-125
Color 17: R(0)G(0)B(255)W(100)A(0)P(255)
126-132
Color 18: R(0)G(0)B(255)W(50)A(0)P(255)
133-139
Color 19: R(0)G(0)B(255)W(0)A(0)P(0)
140-146
Color 20: R(75)G(0)B(255)W(0)A(0)P(255)
147-153
Color 21: R(160)G(0)B(255)W(0)A(0)P(255)
154-160
Color 22: R(255)G(0)B(255)W(0)A(0)P(255)
161-167
Color 23: R(255)G(0)B(175)W(0)A(0)P(175)
168-174
Color 24: R(255)G(0)B(100)W(0)A(0)P(100)
175-181
Color 25: R(255)G(0)B(100)W(50)A(0)P(100)
182-188
Color 26: R(255)G(0)B(25)W(50)A(0)P(25)
189-195
Color 27: R(255)G(0)B(25)W(25)A(0)P(25)
196-202
Color 28: R(255)G(0)B(25)W(0)A(0)P(25)
203-209
Color 29: R(0)G(0)B(0)W(255)A(0)P(0)
210-216
Color 30: R(75)G(75)B(0)W(255)A(0)P(0)
217-223
Color 31: R(0)G(0)B(100)W(255)A(0)P(100)
224-230
Color 32: R(255)G(150)B(0)W(70)A(255)P(0)
231-237
Color 33: R(255)G(255)B(255)W(255)A(40)P(255)
238-255
Color 34: R(255)G(255)B(255)W(255)A(255)P(255)
6 channels (6.A)
Channel 1 –Dimmer
0-255
Dimmer intensity, from dark to brightest
Channel 2 –Strobe CH1 must be open
0-255
Strobe ON, from low to high frequency

19
Ordercode: 40314
Aircone Q6 WDMX
Channel 3 –Color presets CH1 must be open, CH4 must be set between 0-41
0-6
OFF
7-13
Color 1: R(255)G(0)B(0)W(100)A(0)P(0)
14-20
Color 2: R(255)G(0)B(0)W(200)A(0)P(0)
21-27
Color 3: R(255)G(50)B(0)W(0)A(0)P(0)
28-34
Color 4: R(255)G(150)B(0)W(0)A(255)P(0)
35-41
Color 5: R(255)G(255)B(0)W(0)A(120)P(0)
42-48
Color 6: R(255)G(255)B(0)W(75)A(0)P(0)
49-55
Color 7: R(0)G(255)B(0)W(255)A(0)P(0)
56-62
Color 8: R(0)G(255)B(0)W(150)A(0)P(0)
63-69
Color 9: R(0)G(255)B(0)W(50)A(0)P(0)
70-76
Color 10: R(0)G(255)B(0)W(0)A(0)P(0)
77-83
Color 11: R(0)G(255)B(50)W(0)A(0)P(50)
84-90
Color 12: R(0)G(255)B(150)W(0)A(0)P(150)
91-97
Color 13: R(0)G(255)B(255)W(0)A(0)P(255)
98-104
Color 14: R(0)G(255)B(255)W(75)A(0)P(255)
105-111
Color 15: R(0)G(255)B(255)W(150)A(0)P(255)
112-118
Color 16: R(0)G(100)B(255)W(255)A(0)P(255)
119-125
Color 17: R(0)G(0)B(255)W(100)A(0)P(255)
126-132
Color 18: R(0)G(0)B(255)W(50)A(0)P(255)
133-139
Color 19: R(0)G(0)B(255)W(0)A(0)P(0)
140-146
Color 20: R(75)G(0)B(255)W(0)A(0)P(255)
147-153
Color 21: R(160)G(0)B(255)W(0)A(0)P(255)
154-160
Color 22: R(255)G(0)B(255)W(0)A(0)P(255)
161-167
Color 23: R(255)G(0)B(175)W(0)A(0)P(175)
168-174
Color 24: R(255)G(0)B(100)W(0)A(0)P(100)
175-181
Color 25: R(255)G(0)B(100)W(50)A(0)P(100)
182-188
Color 26: R(255)G(0)B(25)W(50)A(0)P(25)
189-195
Color 27: R(255)G(0)B(25)W(25)A(0)P(25)
196-202
Color 28: R(255)G(0)B(25)W(0)A(0)P(25)
203-209
Color 29: R(0)G(0)B(0)W(255)A(0)P(0)
210-216
Color 30: R(75)G(75)B(0)W(255)A(0)P(0)
217-223
Color 31: R(0)G(0)B(100)W(255)A(0)P(100)
224-230
Color 32: R(255)G(150)B(0)W(70)A(255)P(0)
231-237
Color 33: R(255)G(255)B(255)W(255)A(40)P(255)
238-255
Color 34: R(255)G(255)B(255)W(255)A(255)P(255)
Channel 4 –Functions
0-41
Built-in program (dimfade1)
42-83
Built-in program (dimfade2)
84-125
Built-in program (dimfade3)
126-167
Built-in program (colorswitch1)
168-209
Built-in program (colorswitch2)
210-251
Built-in program (colorswitch3)
252-255
Sound-controlled mode
Channel 5 –Program speed CH4 must be set between 42-251
0-255
Program speed adjustment, from slow to fast
Channel 5 –Sound sensitivity CH4 must be set between 252-255
0-255
Sound sensitivity, from low to high sensitivity
Channel 6 –Fan speed
0-255
Fan speed adjustment, from fast to slow
