OCEM LIRE Series Instruction manual

Document UT-MT-0779_EN Page 1 of 37
Via della Solidarietà, 2/1
40056 Valsamoggia Loc. Crespellano
BOLOGNA ITALY
Edition 23/04/2019 Supersedes edition 06/03/2019
a division of Energy Technology srl
Via della Solidarietà 2/1, 40056 Valsamoggia (Bologna) - Italy
THIS COPY IS NOT SIGNED SINCE IT IS FILED AND DELIVERED BY MEANS OF THE AUTOMATIC KNOWLEDGE MANAGEMENT SYSTEM (IT CAN BE SIGNED ON REQUEST). THIS DOCUMENT AND THE DATA CONTAINED HERE IN, IS
PROPRIETARY PROPERTY AND SHALL NOT BE DUPLICATED, USED OR DISCLOSED –IN WHOLE OR IN PART –FOR ANY PURPOSE WITHOUT WRITTEN CONSENT OF OCEM.
LED INSET RUNWAY EDGE LIGHT
LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION
AND MAINTENANCE
Compiled by: Emidio Rauli
Approved by: Matteo Mazzotti
N° Attachments:
Copy n°:

Document UT-MT-0779_EN Page 2 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
LIMITED PRODUCT WARRANTY
THE FOLLOWING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, WHETHER EXPRESS,
IMPLIED OR STATUTORY, INCLUDING, BUT NOT BY WAY OF LIMITATION, ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE.
OCEM - ENERGY TECHNOLOGY warrants to each original Buyer of Products manufactured by the Company
that such Products are at the time of delivery to the Buyer, free of material and workmanship defects,
provided that no warranty is made with respect to:
(a) any Product, which has been repaired or altered in such a way, in Company’s judgement, as to affect
the Product adversely;
(b) any Product which has, in Company’s judgement, been subject to negligence, accident or improper
storage;
(c) any Product which has not been operated and maintained in accordance with normal practice and in
conformity with recommendations and published specification of Company;
(d) the breaking of the warranty seals, if present, determines the immediate termination of the warranty;
and,
OCEM - ENERGY TECHNOLOGY’s obligation under this warranty is limited to use reasonable efforts to
repair or, at its option, replace, during normal working hours at the facility of the Company, any Product
which in its judgement proved not to be as warranted within the applicable warranty period. All costs of
transportation of Products claimed not to be warranted and of those repaired or replaced, to or from the
facility of the Company shall be borne by Purchaser. Company may require the return of any Product
claimed not to be as warranted to its facility, transportation prepaid by Purchaser, to establish a claim
under this warranty. The cost of labour for the installation of a repaired or replaced Product shall be
borne by Purchaser. Replacement parts provided under the terms of this warranty are warranted for the
remainder of the warranty period of the Products upon which they are installed to the same extent as if
such parts were original components thereof. Warranty services provided under the Agreement do not
assure uninterrupted operations of Products; Company does not assume any liability for damages caused
by any delays involving warranty service.
IMPORTANT: READ THIS DOCUMENT
Before proceeding to the operations of installation, commissioning, operation, maintenance or disposal,
carefully read the entire document.
SAFETY INFORMATION
Extreme caution should be exercised when working with this equipment; it is normally used or connected
to circuits that operate at dangerous voltages and can be fatal.
The following section contains important safety information that you must follow when installing and
using the apparatus.
Misuse of the equipment or lack of care in applying safety procedures and prescriptions specified in this
document, may result in a hazard.
Avoid contact with voltage or current sources.
For no reason the protections and the safety devices must be removed.

Document UT-MT-0779_EN Page 3 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
OPERATION ON THE EQUIPMENT - SKILLS
Operation on the equipment and access to its internal parts shall be done by experienced personnel,
adequately trained and aware of the risks related to electricity and high voltages.
Safety rules shall be adopted when operating on the equipment, or on cables and other apparatus
connected to the it
DO NOT OPERATE ON ENERGIZED CIRCUITS
Do not carry out any operation on the converter or on apparatus connected to it when the circuits are
energized.
WHEN HANDLING AND SERVICING THIS EQUIPMENT, OBSERVE PRECAUTIONS FOR HIGH VOLTAGE
EQUIPMENT.
Before any access, inspection or intervention, be sure to have switched-off the unit, opened the main
circuit breaker and removed the supply to the unit (by opening the circuit breaker/switch on the
distribution board at the beginning of the supply line).
Then wait discharge time (at least 5 minutes), ground carefully the system, and check for voltage
presence before accessing..
REANIMATION
The maintenance staff must be aware of the risks related to electricity, criteria to prevent the risk of
electric shock and resuscitation techniques
CE MARK
This equipment complies with the requirements of European regulations for the CE mark.The
user has to respect all prescriptions reported in this document.
This equipment complies with the requirements of the EEC directives 2004/108/EEC and
2006/95/EEC with regard to “Electromagnetic Compatibility” and “Low Voltage Electrical
Apparatus” respectively.
OUT OF SERVICE
In case of dismantling, decommissioning, destruction, disposal, the user shall follow all the required
precautions for component and material elimination, according to local rules and applicable law.

Document UT-MT-0779_EN Page 4 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
EDITIONS
Date
07/24/2013
First issue
02/03/2014
Deleted § “List of the recommended spare parts” and added relevant
attachment
03/11/2014
New address of the Company
Updated the P/N identification
04/05/2018
Added ground wire specifications
REVISIONS
Index
Date
Description
Edited by
Approved by
01
11/07/2018
Added spare parts.
New power supply cable lead.
Image update. New lower cover image.
Screws replacement.
EBER
MMAZ
02
06/03/2019
Updated the P/N identification
Added CASA conformity
EBER
MMAZ
03
23/04/2019
Updated the P/N identification
EBER
MMAZ

Document UT-MT-0779_EN Page 5 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
INDEX
1GENERAL......................................................................................................................... 7
2MAIN FEATURES .............................................................................................................7
2.1 REMOVABLE LIGHT UNIT................................................................................................ 7
2.1.1 Dome..................................................................................................................... 7
2.1.2 Optical Assembly................................................................................................... 8
2.1.3 Power Supply/Control Board ................................................................................ 8
2.1.4 Lower Cover .......................................................................................................... 9
2.2 SHALLOW BASE ............................................................................................................ 14
2.3 ELECTRONIC SECTION................................................................................................... 15
2.3.1 Current / current conversion circuit (patented)................................................. 15
2.3.2 LED command circuit .......................................................................................... 15
2.3.3 Control circuit ..................................................................................................... 15
2.4 ARCTIC KIT .................................................................................................................... 16
3INSTALLATION .............................................................................................................. 17
3.1 PAVEMENT BORING AND SAWCUTTING...................................................................... 17
3.1.1 Scheme of Light Configurations.......................................................................... 18
3.2 INSTALLING THE SHALLOW BASE ................................................................................. 18
3.3 INSTALLING THE LIGHT UNIT ON L-868 BASE, SIZE B ................................................... 23
3.4 SECONDARY WIRING .................................................................................................... 23
4MAINTENANCE ............................................................................................................. 24
4.1 MAINTENANCE PROGRAM........................................................................................... 24
4.1.1 Periodical Checks ................................................................................................ 24
4.1.2 Snowplow Operations......................................................................................... 25
4.2 REMOVING AND OPENING THE LIGHT UNIT FROM THE BASE .................................... 25
4.2.1 Removing the fixture .......................................................................................... 25
4.2.2 Opening the fixture............................................................................................. 25
4.2.3 Closing the fixture............................................................................................... 26
4.2.4 Leakage test ........................................................................................................ 26
4.2.5 Reinstalling the fixture........................................................................................ 27
4.3 PRIMS CLEANING.......................................................................................................... 27
4.3.1 Prism outside cleaning........................................................................................ 27
4.3.2 Prism inside cleaning .......................................................................................... 27
4.4 PRISM REPLACEMENT .................................................................................................. 28
4.4.1 Removing the Prism ............................................................................................ 28
4.4.2 Installing the New Prism ..................................................................................... 28
4.5 LED MODULE REPLACEMENT ....................................................................................... 29
4.6 ELECTRONICS REPLACEMENT....................................................................................... 30
4.7 ARCTIC KIT REPLACEMENT ........................................................................................... 30
4.7.1 Thermostat.......................................................................................................... 30

Document UT-MT-0779_EN Page 6 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
4.7.2 Heater.................................................................................................................. 31
4.8 GASKETS........................................................................................................................ 32
4.8.1 Gasket examination ............................................................................................ 32
4.8.2 O-Ring replacement ............................................................................................ 33
4.9 CABLE LEAD WITH PLUG............................................................................................... 33
4.9.1 Removing the cable lead with plug..................................................................... 33
4.9.2 Installing the new cable lead with plug .............................................................. 33
4.10 PRESSURE VALVE .......................................................................................................... 34
4.11 CLEANING ..................................................................................................................... 34
4.12 MONITORING ............................................................................................................... 34
5TROUBLESHOOTING ..................................................................................................... 36
6SPARE PARTS................................................................................................................ 37
INDEX OF FIGURES
Figure 1 –8” Dome outside view ...................................................................................................... 8
Figure 2 –Lower Cover Outside View ............................................................................................. 10
Figure 3 –Lower Cover Inside View ................................................................................................ 10
Figure 4 –Wiring Diagram............................................................................................................... 11
Figure 5 –Exploded View ................................................................................................................ 11
Figure 6 –Part List........................................................................................................................... 12
Figure 7 - Complete P/N identification............................................................................................ 13
Figure 8 –Standard 12” shallow base ............................................................................................. 14
Figure 9 –Pavement Boring, Sawcutting and Joint Intersection Details ........................................ 17
Figure 10 –Example of Light Unit Configuration ............................................................................ 18
Figure 11 –Gaskets for 12” shallow base ....................................................................................... 21
Figure 12 –12” shallow base for side or bottom ducts (method “B”)............................................ 21
Figure 13 –Shallow base installation details .................................................................................. 22
Figure 14 –Optical device (refer to the manual UT-MT-0485 for further information) ................ 22
Figure 15 –Gaskets for L-868 base ................................................................................................. 23
Figure 16 - Lower Cover Fixing Screws ............................................................................................ 26
Figure 17 - Lower Cover with Pressure Valve.................................................................................. 27
Figure 18 –Fixture Gaskets ............................................................................................................. 27
Figure 19 - Prism Cleaning............................................................................................................... 28
Figure 20 - Prism Replacement ....................................................................................................... 29
Figure 21 –LED Module Replacement ............................................................................................ 30
Figure 22 –Wiring diagrams for the heaters .................................................................................. 31
Figure 23–Fixture Gaskets .............................................................................................................. 32
Figure 24 –Prism Gasket................................................................................................................. 32
Figure 25 - Cable Lead With Plug..................................................................................................... 33
Figure 26 - Lower Cover with Pressure Valve.................................................................................. 34
Figure 27 - Restoring the Monitoring Device .................................................................................. 35

Document UT-MT-0779_EN Page 7 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
1GENERAL
LIRE inset LED runway edge light is high intensity, bidirectional or unidirectional, 12”
steady burning type.
These fixtures are intended for use as runway edge, in order to provide a visual aid to
the moving aircraft.
LIRE lights are in compliance with ICAO Annex 14 Vol.1, EASA CS-ADR DSN, FAA AC
150/5345-46 (Style 3), IEC TS 61827 (Style 4), CASA Manual of Standard part 139 and
NATO-STANAG 3316.
The fixtures described in this manual are designed to be connected to series circuit,
replacing those equipped with incandescent lamps, fed through standard isolation
transformers connected to CCR with variable current from 2.8 A to 6.6 A.
Location of these fittings shall be in compliance with ICAO - Annex 14, STANAG 3316
and FAA 150/5340-30.
2MAIN FEATURES
Each light assembly consists of a removable fixture and a shallow base receptacle.
The fixture is waterproof and designed to withstand aircraft impact and roll-over
loads without damage.
The fixture can be bidirectional type (bidirectional dome equipped with four LED
modules, operating at the same time or independently) or unidirectional type
(unidirectional dome equipped with only two LED module).
It is also possible to obtain an unidirectional light from a bidirectional dome choosing
the “S – Screened” option; this configuration includes a bidirectional dome mounting
only two LED module.
Power consumption for bidirectional fixture is 65 VA (1 plug) and 62 VA (2 plugs),
unidirectional fixture is 31 VA (1 plug).
2.1 REMOVABLE LIGHT UNIT
The removable fixture mainly consists of a dome, an optical assembly, a power
supply/control board, and a lower cover.
2.1.1 Dome
The dome is made of treated drop-forged aluminium and includes four windows to
seat the prisms, complete with gaskets, kept in the proper position by means of a
mounting plate fixed with HSCS M5x12 screws. In correspondence of the windows,
the dome is outside provided with identification letters “A” and “B”.
The dome is provided with six through holes for fastening the light unit to the base.

Document UT-MT-0779_EN Page 8 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
It is also provided with two suitable slots, in opposite position, to make easy the
fixture removal by using two suitable lifting tools (available on request, P/N 332.4140
or 332.4230). As alternative, two screwdrivers can be used.
A silicone O-Ring (separately supplied) has to be mounted outside around the dome,
to avoid dirt deposits between dome and shallow base.
1. Dome
2. Slot for dome removal
3. Letter “A” to identify the
beam
4. Through hole for light unit
fastening
Figure 1 –12” Dome outside view
2.1.2 Optical Assembly
The optical assembly consists of four prisms (Figure 5 - n°13) with relevant gaskets
(Figure 5 - n°12) kept into the proper position by mounting plate (Figure 5 - n°15) and
four LED modules (Figure 5 - n°7) with reflector (Figure 5 - n°6). Unidirectional
fixtures mount only two prisms and two LED modules.
Each LED module consists of six LEDs mounted on a metal core PCB, coupled with the
support through thermo conductive material; the reflector is fixed to the support
assembly.
All the optical assembly parts are factory assembled; they may be field-replaced if
necessary.
2.1.3 Power Supply/Control Board
The power supply/control board is encapsulated into waterproof and heat
conductive silicon resin.

Document UT-MT-0779_EN Page 9 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
The PCB powers and controls the LEDs so that the light output provided at every
current step from 2.8 A to 6.6 A is comparable to a traditional halogen lamp,
according to the requirements of FAA “Engineering Brief N°67” document.
2.1.4 Lower Cover
The lower cover consists of a treated aluminium casting; it is fastened to the dome
by means of six screws flat CSS TORX M5x10. Two O-Ring are provided between
dome and lower cover. The dome is equipped with a reference pin for its proper
positioning.
The cover is provided with one or two threaded holes for cable entry and external
grounding screw with XHHW, 600V, AWG12 cable, 0.5 m long, with male faston
terminal or ground clamp for AWG6, XHHW, 600V cable. A suitable valve is outside
mounted for the leakage test.
Watertightness between fixture and shallow base is ensured by means of an O-Ring
(separately supplied) to be placed on the relevant shallow base groove.
The fixture is supplied with one or two cable lead with L-823 plug Style 1; external
length 0.46 m. The plug is in compliance with FAA AC 150/5345-26 for very quick
coupling with the receptacle mounted on the shallow base.
If the light unit is equipped with one cable lead with plug, both the power
supply/control board sections will work simultaneously; if it is necessary to operate
independently the two power supply/control board sections, then two cable leads
with plug are necessary.
The fixture is 304 mm in diameter and 107 mm (+ 18.5 mm for plugs) high; the
protrusion above the ground is less than 6.35 mm.
An identification data label is externally applied over the lower cover (
Figure 2 –n°2). Moreover, to identify quickly the beam colour, the letters “A” and “B”
of the dome in front of the windows are painted in the same colour of the light beam.

Document UT-MT-0779_EN Page 10 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
1. Lower cover
2. Identification label
3. Grounding cable hole
4. Letter “A” and “B” for
cable lead identification
5. Cable lead entry
Figure 2 –Lower Cover Outside View
The same colour painting is provided outside on the lower cover.
See “Complete P/N identification” figure for P/N information.
All hardware is made of stainless steel A2-70.
1. Cable lead with plug
2. Leak test valve
3. Letter “A” and “B” for
cable lead identification
Figure 3 –Lower Cover Inside View

Document UT-MT-0779_EN Page 11 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
LEDLED
POWER
SUPPLY
POWER
SUPPLY
LEDLED
LEDLED
POWER
SUPPLY POWER SUPPLY
LEDLED
LEDLED
1 In 1 Out
1 In 2 Out
2 In 2 Out
Figure 4 –Wiring Diagram
Figure 5 –Exploded View
No. Description Qty

Document UT-MT-0779_EN Page 12 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
1 Dome....................................................................................................................1
2 O-Ring for dome (external)..................................................................................1
3 O-Ring for dome (internal)...................................................................................1
4 O-Ring for lower cover.........................................................................................1
5 Arctic kit heater................................................................................................ 1-2
6 Reflector with hardware ......................................................................................4
7 LED module with accessories...............................................................................4
8 Lower cover..........................................................................................................1
9 Valve for watertightness test...............................................................................1
10 FAA L-823 plug ................................................................................................. 1-2
11 Arctic kit thermostat ........................................................................................ 1-2
12 Prism gasket.........................................................................................................4
13 Prism ....................................................................................................................4
14 Prism holder gasket .............................................................................................4
15 Mounting plate ....................................................................................................4
Figure 6 –Part List

Document UT-MT-0779_EN Page 13 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
LIRE - F - WY - 2P - M - A
Basic P/N:
Compliance:
I = ICAO 60 m
S = ICAO 45 m
F = FAA
Colour(Side L)/(Side R):
W = White
Y = Yellow
G = Green (FAA)
R = Red
M = Blank (unidirectional dome)*
Cables and connectors:
1P = One Plug
2P = Two Plugs
Monitoring:
0 = Without Monitoring
M = With Monitoring
Arctic Kit:
0 = Without Arctic Kit
A = With Arctic Kit
* The aperture not finished "M" will be always on side "B"
** The beams aiming is not field adjustable
Figure 7 - Complete P/N identification

Document UT-MT-0779_EN Page 14 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
2.2 SHALLOW BASE
The shallow base (Figure 8) consists of a treated aluminium casting containing an
electrical feed-thru system to connect the power cables, consisting of one or two
cable leads with receptacle incoming inside the base through one or two cable
glands. The cable lead with receptacle consists of two single-pole leads, size 2.5 mm2,
1.00 m long, with FAA L-823 receptacle.
The letters "A" and “B” are printed inside the base for cable leads identification.
The base is equipped with an internal grounding screw with XHHW, 600V, AWG12
cable lead, 0.250 m long, with female faston terminal for quick connection to the
corresponding of the fixture. An additional external grounding screw is provided
close to the cable entry.
The shallow base is designed for cementing in place by means of epoxy-resin in a hole
drilled in the pavement.
The fixture has to be fastened to the base by means of six hex cap screws, complete
with external silicon-coated lock-washer.
A gasket (separately supplied) must be placed between base and fixture for
watertightness (Figure 8 - n°9) placed in the relevant shallow base groove.
The 12” shallow base is 320 mm in diameter and 150 mm high.
On request, special bases without cable leads can be supplied, provided with holes
suitable for conduit connections.
Inside the base two suitable holders (Figure 8 - n°7) are provided to properly sustain
the secondary power cable, in case of this cable is inside incoming through a conduit.
1. Cable gland for cable entry
2. External grounding screw
3. Cable leads with socket
4. Internal grounding screw
5. Grounding cable with female
faston terminal
6. Letters “A” for cable lead
identification
7. Power cable holders
8. Threaded holes for fixture
fastening by bolts
9. O-Ring between fixture and base
Figure 8 –Standard 12” shallow base

Document UT-MT-0779_EN Page 15 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
2.3 ELECTRONIC SECTION
The electronic section consists of the following circuits:
Current / current conversion circuit
LED command circuit
Control circuit
2.3.1 Current / current conversion circuit (patented)
This electronic section provide a conversion from the input current value (within
range from 2.8 A to 6.6 A) to the specified LED current value.
This conversion, performed in one transformation only, allows to achieve several
benefits:
minimize the power losses
significant increase of efficiency
high input power factor
independent form the CCR topology: the CCR may have any output current
waveform
no percentage of load dependent: the CCR can feed without any problem also
few lights in the series circuit
isolation transformers of smaller size can be used, respect to those used with the
equivalent fixtures equipped with halogen lamps
The input circuit is protected against over-voltage, tested in accordance with the
requirements in FAA “Engineering Brief N°67” document.
2.3.2 LED command circuit
A PWM technique is used to command the LEDs. As known LEDs need to be supplied
with a constant current; therefore in order to vary the luminous emission with a
proper linearity is necessary the supply current will be applied at impulses. In other
words, the LED luminous output depends on the time of application (duty-cycle) of
constant current impulses.
2.3.3 Control circuit
The main task of the control circuit is to assure the correct LED light emission
according to the series circuit current.
To perform this features, the circuit is provided with a current sensor that generate a
signal proportional to the series circuit current.
This signal is analyzed by a DSP which perform a RMS conversion of the input current.

Document UT-MT-0779_EN Page 16 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
The RMS conversion give a good accuracy with any input current waveform.
Other functions:
diagnostic, auxiliary voltage control and LED status control. In case of any LED
failure or relative power supply circuit failure, the electronic control circuit
commands the intervention of the monitoring device so that the secondary side
of the isolation transformer becomes open, like in the case of an incandescent
lamp failure. This features is essential when the monitoring option is required
events recording (not-volatile memory) for diagnostic purposes
PC operator interface through serial connection: this features allows to calibrate
the brightness depending on the current, to modify the emission curve, to read
the events occurred during the operating time
2.4 ARCTIC KIT
The optional arctic kit is in compliance with FAA “Engineering Brief N°67” document
and it prevents from the ice over the prisms area.
The arctic kit is connected in series to the PCB and it is consists of a thermostat (two
in case of fixture with double cable lead) and one or two heaters. It starts when the
dome temperature is less than about -1°C and turns-off when the dome temperature
reaches about 10°C.
Arctic kit consumption is less than 40 VA per plug.

Document UT-MT-0779_EN Page 17 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
3INSTALLATION
3.1 PAVEMENT BORING AND SAWCUTTING
Drill each recess in pavement following the instruction in Figure 9.
Figure 9 –Pavement Boring, Sawcutting and Joint Intersection Details
Make sure the recess size and depth are maintained within the specified limits. All
surfaces of the recess must be clean and dry. If any of these surfaces is damp, it is
desirable that it be dried and blown clean with a compressed air blast. The recess
side walls must be perpendicular to the pavement surface. The bottom surface must
be flat or slightly concave to assure that the shallow base rest securely and in true
position. The recess can best be drilled using a diamond-faced core drill in a sturdy,
stable drill rig.
Mark on the pavement surface the aiming direction of the light by chalk, nails or
other devices.

Document UT-MT-0779_EN Page 18 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
3.1.1 Scheme of Light Configurations
Figure 10 –Example of Light Unit Configuration
3.2 INSTALLING THE SHALLOW BASE
Two different installations are possible:
Method “A” – cable leads to be laid in wireways
Method “B” – cable leads to be laid in cable ducts (Figure 12)

Document UT-MT-0779_EN Page 19 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
Proceed as follow to realize a proper installation.
STEP
A
B
ACTIVITY DESCRIPTION
1


Take the base from the shipping box.
2


To assure an adequate bond between base and hole all external surfaces of
the base should be sandblasted and must be cleaned with solvent. TAKE CARE
NOT TO DAMAGE THE ELECTRICAL SYSTEM.
3

/
Connect an insulated G/Y grounding wire of suitable length to the grounding
screw externally provided on the wall of the base.
4

/
Splice the light base leads to the power cables using solderless squeeze
connectors, as shown in the figure, crimped with the proper tool. Connect also
the grounding wire to the main grounding network by using a suitable
clamping lug.
ATTENTION: Insulate each splice carefully using either heat shrinkable
insulating tubing properly applied or at least three layers of plastic electrical
insulating tape applied with half overlap.
5


Mount the positioning jig (P/N 332.4301) on the base as shown in Figure 13.
An optical device for proper fixture orientation is available (P/N 332.4351 Figure
14).
6

/
Properly arrange the leads in the wireways using small pieces of insulating
tape if necessary.
7


Completely cover the bottom of the base with sealer material, apply a thin
coat of sealer to the bottom of the drilled hole to assure a bond between the
bottom of the light base and the drilled hole. It may be necessary to place
temporary plugs so as to block the wireways entrances into the drilled hole
(METHOD “A”) or the cable ducts entrance (METHOD “B”). The plugs will retain
the sealer while it begins to dry up.
ATTENTION: avoid starting the installation when the ambient temperature is
below 10°C (86°F), unless the sealer used is designed to dry up at a lower
temperature.

Document UT-MT-0779_EN Page 20 of 37
Edition 23/04/2019 Supersedes edition 06/03/2019
LED INSET RUNWAY EDGE LIGHT LIRE
INSTRUCTION MANUAL FOR USE, INSTALLATION AND MAINTENANCE
STEP
A
B
ACTIVITY DESCRIPTION
8


Push the base into the recess until its upper side is at the level of the
pavement surface; take care no sealer flowing inside the base. Align the notch
of the base with the markings on the pavement surface.
9

/
Observing the circular level fixed on the jig, level the jig by operating the three
leveling lobe knobs (Figure 13). If necessary, a weight may be placed on the jig
to hold the light base in position.
The remainder of the space between the sides of the shallow base and the
drilled hole should be filled with sealer up to approx 25 mm from the
pavement, according to the local needs.
Fill the remaining 25 mm with a suitable joint sealing filler.
10
/

Observing the circular level fixed on the jig, level the jig by operating the three
leveling lobe knobs (Figure 13). If necessary, a weight may be placed on the jig
to hold the light base in position.
When the shallow base is in its final position, the conduit(s) must be properly
jointed to the hole(s) provided on the shallow base. This(these) hole(s) can be
provided either on the wall either on the bottom, the number and the
dimensions according to customer requirements (Figure 12).
The remainder of the space between the sides of the shallow base and the
drilled hole should be filled with sealer up to approx 25 mm from the
pavement, according to the local needs.
Fill the remaining 25 mm with a suitable joint sealing filler.
11
/

Lay the secondary power cable, equipped with a suitable two-pole receptacle
kit, and the grounding wire inside the cable duct.
12


To install the fixture place the O-Ring around the dome (Figure 11- n°1) and
between fixture and base (Figure 11- n°3).
Connect the plug and the grounding wire of the fixture with the receptacle and
the grounding wire of the base; press the fixture by hand onto the base and
secure it using the six locking screws complete with washer, one drop of screw
paste (e.g. Dow Corning Molycote 1000) should be applied to the screws
before installation.
Tightening torque is 35 Nm.
ATTENTION: The fixture is subject to mechanical damage and/or optical
misalignment if not properly seated on the base flange.
