Powerport 3
Product code: 50275
Preface
Thank you for purchasing this Showgear product.
The purpose of this user manual is to provide instructions for the correct and safe use of this product.
Keep the user manual for future reference as it is an integral part of the product. The user manual shall be
stored at an easily accessible location.
This user manual contains information concerning:
●Safety instructions
●Installation and operation of the device
●Intended and non-intended use of the device
●Maintenance procedures
●Troubleshooting
●Transport, storage and disposal of the device
Non-observance of the instructions in this user manual may result in serious injuries and damage of
property.
©2022 Showgear. All rights reserved.
No part of this document may be copied, published or otherwise reproduced without the prior written
consent of Highlite International.
Design and product specifications are subject to change without prior notice.
For the latest version of this document or other language versions, please visit our website
www.highlite.com or contact us at [e-mail].
Highlite International and its authorized service providers are not liable for any injury, damage, direct or
indirect loss, consequential or economic loss or any other loss arising from the use of, or inability to use or
reliance on the information contained in this document.

2
Powerport 3
Product code: 50275
Table of contents
1. Introduction..........................................................................................................................................................3
Before Using the Product ..................................................................................................................................3
Intended Use .......................................................................................................................................................3
Text Conventions ................................................................................................................................................3
Symbols and Signal Words................................................................................................................................4
Symbols on the Information Label ..................................................................................................................4
2. Safety ....................................................................................................................................................................5
Warnings and Safety Instructions ....................................................................................................................5
Requirements for the User.................................................................................................................................7
3. Description of the Device ...................................................................................................................................7
Overview..............................................................................................................................................................7
Product Specifications ......................................................................................................................................8
Dimensions...........................................................................................................................................................8
4. Setup and Operation ..........................................................................................................................................9
Safety Instructions for Installation ....................................................................................................................9
Installation Site Requirements ..........................................................................................................................9
Connecting to Power Supply.........................................................................................................................10
Power Linking of Multiple Devices.................................................................................................................10
5. Troubleshooting .................................................................................................................................................11
6. Maintenance .....................................................................................................................................................11
Safety Instructions for Maintenance.............................................................................................................11
Preventive Maintenance................................................................................................................................11
Basic Cleaning Instructions ...................................................................................................................12
Corrective Maintenance................................................................................................................................12
7. Deinstallation, Transportation and Storage ....................................................................................................12
8. Disposal ..............................................................................................................................................................12
9. Approval.............................................................................................................................................................12

3
Powerport 3
Product code: 50275
1. Introduction
Before Using the Product
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your
Highlite International dealer.
Your shipment includes:
Showgear Powerport 3
User manual
Fig. 01
Intended Use
This device is intended for professional use as a power distribution unit. It is suitable only for indoor use. This
device is not suitable for households.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
Text Conventions
Throughout the user manual the following text conventions are used:
Buttons: All buttons are in bold lettering, for example “Press the UP/DOWN buttons”
References: References to chapters and parts of the device are in bold lettering, for example:
“Refer to 2. Safety”, “turn the adjustment screw (02)”
0–255: Defines a range of values
Notes: Note: (in bold lettering) is followed by useful information or tips

4
Powerport 3
Product code: 50275
Symbols and Signal Words
Safety notes and warnings are indicated throughout the user manual by safety signs.
Always follow the instructions provided in this user manual.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
Attention
Indicates important information for the correct operation and use of the
product.
Important
Read and observe the instructions in this document.
Electrical hazard
Provides important information about the disposal of this product.
Symbols on the Information Label
This product is provided with an information label. The information label is located on the backside of the
device.
The information label contains the following symbols:
This device is designed for indoor use.
This device falls under IEC protection class I.
This device shall not be treated as household waste.
Read and follow the instructions in the user manual before installing, operating or
servicing the device.

5
Powerport 3
Product code: 50275
2. Safety
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
Warnings and Safety Instructions
DANGER
Danger for children
For adult use only. The device must be installed beyond the reach of children.
Do not leave various parts of the packaging (plastic bags, polystyrene foam, nails, etc.) within
children’s reach. Packaging material is a potential source of danger for children.
DANGER
Electric shock caused by dangerous voltage inside
There are areas within the device where dangerous touch voltage may be present.
●Do not open the device or remove any covers.
Disconnect the device from electrical power supply before service and maintenance, and when the
device is not in use.
DANGER
Electric shock caused by short-circuit
This device falls under IEC protection class I.
Make sure that the device is electrically connected to ground (earth). Connect the device only to a
socket-outlet with ground (earth) connection.
Do not cover the ground (earth) connection.
●Do not immerse the device in water or other liquids. Do not install the device in a location where
flooding may occur.
Do not use the device during thunderstorms. Disconnect the device from the electrical power supply
immediately.

6
Powerport 3
Product code: 50275
Attention
Power supply
●Before connecting the device to the power supply, make sure that the current, voltage and
frequency match the input voltage, current and frequency specified on the information label on the
device.
●Make sure that the cross-sectional area of the extension cords and power cables is sufficient for the
required power consumption of the device.
Attention
General safety
●Do not shake the device. Avoid brute force when installing or operating the device.
●If the device is dropped or struck, disconnect the device from the electrical power supply
immediately.
If the device is exposed to extreme temperature variations (e.g. after transportation), do not switch it
on immediately. Let the device reach room temperature before switching it on, otherwise it may be
damaged by the formed condensation.
If the device fails to work properly, discontinue the use immediately.
Attention
For professional use only
This device shall be used only for the purposes it is designed for.
This device is designed to be used as a power distribution unit. Any incorrect use may lead to hazardous
situations and result in injuries and material damage.
●This device is not suitable for households.
●This device is not designed for permanent operation.
This device does not contain user-serviceable parts. Unauthorized modifications to the device will
render the warranty void. Such modifications may result in injuries and material damage.
Attention
Before each use, examine the device visually for any defects.
Make sure that:
All screws used for installing the device or parts of the device are tightly fastened and are not
corroded.
There are no deformations on housings, fixations and installation points.
The power cables are not damaged and do not show any material fatigue.

7
Powerport 3
Product code: 50275
Attention
Do not expose the device to conditions that exceed the rated IP class conditions.
This device is IP20 rated. IP (Ingress Protection) 20 class provides protection against solid objects greater
than 12 mm, such as fingers, and no protection against harmful ingress of water.
Requirements for the User
This product may be used only by instructed or skilled persons. Installation and maintenance can be
carried out by instructed or skilled persons. Service shall be carried out only by skilled persons. Contact
your Highlite International dealer for more information.
Instructed persons have been instructed and trained by a skilled person, or are supervised by a skilled
person, for specific tasks and work activities associated with the installation, service and maintenance of
this product, so that they can identify risks and take precautions to avoid them.
Skilled persons have training or experience, which enables them to recognize risks and to avoid hazards
associated with the installation, service and maintenance of this product.
Ordinary persons are all persons other than instructed persons and skilled persons. Ordinary persons
include not only users of the product but also any other persons that may have access to the device or
who may be in the vicinity of the device.
3. Description of the Device
The Powerport 3 is a compact power distribution unit. The device is equipped with a Neutrik powerCON
input and 3 Neutrik powerCON outputs. The maximum allowed current load is 16 A, divided over 3
outputs.
Overview
Fig. 02
Neutrik powerCON connector IN (Blue)
2 x mounting openings (M13)
Neutrik powerCON connector OUT (Gray)
Neutrik powerCON connector OUT (Gray)
Neutrik powerCON connector OUT (Gray)

8
Powerport 3
Product code: 50275
Product Specifications
Model:
Powerport 3
Electrical:
Input voltage
240 V AC, 50 Hz, max. 16 A
Rated current:
16 A (divided over 3 outputs)
Conductors:
3
Pins:
3
Connections:
Power connector IN:
Neutrik powerCON connector IN (Blue)
Power connector OUT:
3 x Neutrik powerCON connector OUT (Gray)
Power cable min. wire size:
1,5 mm2/16 AWG
Physical:
Dimensions:
140 x 75 x 55 mm (LxWxH)
Weight:
0,65 kg
Construction:
Housing:
Metal
Color:
Gray
IP rating:
IP20
Thermal:
Ambient temperature ta:
From -10 °C to 45 °C
Dimensions
Fig. 03

9
Powerport 3
Product code: 50275
4. Setup and Operation
Safety Instructions for Installation
WARNING
Incorrect installation can cause serious injuries and damage of property.
Installation must be carried out only by instructed or skilled persons.
Follow all applicable European, national and local safety regulations concerning electrical installations.
Installation Site Requirements
●The device must be installed only indoors.
●The device can be positioned on a flat surface or be mounted on a structure.
●The maximum ambient temperature ta= 45 °C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 45 °C.
Attention
Power supply
Before connecting the device to the power supply, make sure that the current, voltage and frequency
match the input voltage, current and frequency specified on the information label on the device.
To connect the device:
Insert 2 screws into the 2 x mounting openings (02) and tighten them to mount the device on a
structure. See Fig. 04.
Fig. 04
Connect the power supply to the Neutrik powerCON connector IN (01). See 4.3. Connecting to
Power Supply on page 10 for more information.
Connect external devices to the 3 x Neutrik powerCON connectors OUT (03/04/05). See 4.4. Power
Linking of Multiple Devices on page 10 for more information.
Switch on the external devices.

10
Powerport 3
Product code: 50275
Connecting to Power Supply
DANGER
Electric shock caused by short-circuit
The device accepts AC mains power at 240 V and 50 Hz. Do not supply power at any other voltage or
frequency to the device.
This device falls under IEC protection class I. Make sure that the device is always electrically connected
to the ground (earth).
Before connecting the device to the socket-outlet:
●Make sure that the power supply matches the input voltage specified on the information label on
the device.
●Make sure that the socket-outlet has ground (earth) connection.
Connect the device to the socket-outlet with a power plug. The power plug is not delivered with the
device and should be purchased separately. Contact your Highlite International dealer for more
information.
●Do not use the power plug as an on/off switch.
●Do not use the power plugs connected to the outputs as on/off switches to switch on the external
devices connected to the outputs. Switch on the external devices only with their own power
switches.
Power Linking of Multiple Devices
This device supports power linking. Power can be relayed to another device via one of the 3 power OUT
connectors. Note that the input and the output connectors have different designs: one type cannot be
connected to the other.
Power linking of multiple devices must be carried out only by instructed or skilled persons.
WARNING
Incorrect power linking may lead to overload of the electrical circuit and result in serious
injuries and damage of property.
To prevent overload of the electrical circuit, when power linking multiple devices:
Use cables with sufficient current-carrying capacity.
Make sure that the total current draw of the device and all connected devices does not exceed the
rated capacity of the power cables and the circuit breaker of the power supply.
Do not link more devices on one power link than the maximum recommended number.
The maximum recommended number of devices depends on the total load of all linked Powerport
devices and the devices connected to the 3 x Neutrik powerCON connectors OUT (03/04/05). The total
load of all linked devices shall not exceed 16 A.

11
Powerport 3
Product code: 50275
5. Troubleshooting
This troubleshooting guide contains solutions to problems which can be carried out by an ordinary
person. The device does not contain user-serviceable parts.
Unauthorized modifications to the device will render the warranty void. Such modifications may result in
injuries and material damage.
Refer servicing to instructed or skilled persons. Contact your Highlite International dealer in case the
solution is not described in the table.
Problem
Probable cause(s)
Solution
The device does not
function at all
No power to the device
●Check if power is switched on and
cables are plugged in
The residual-current device or the
main circuit breakers of the power
supply are in OFF position
●Check the total current load of the
connected devices.
●Check if the external devices
connected to the outputs are not
damaged
●Move the residual-current device and
the main circuit breakers of the power
supply to ON position.
6. Maintenance
Safety Instructions for Maintenance
DANGER
Electric shock caused by dangerous voltage inside
Disconnect power supply before servicing or cleaning.
Preventive Maintenance
Attention
Before use, examine the device visually for any defects.
Make sure that:
●All screws used for installing the device or parts of the device are tightly fastened and are not
corroded.
●There are no deformations on housings, fixations and installation points.
●The power cables are not damaged and do not show any material fatigue.

12
Powerport 3
Product code: 50275
Basic Cleaning Instructions
To clean the device, follow the steps below:
Disconnect the device from the electrical power supply.
Allow the device to cool down for 5 minutes.
03) Clean the device with a soft, lint-free cloth.
Attention
●Do not immerse the device in liquid.
●Do not use alcohol or solvents.
Corrective Maintenance
The device does not contain user-serviceable parts. Do not open the device and do not modify the
device.
Refer repairs and servicing to instructed or skilled persons. Contact your Highlite International dealer for
more information.
7. Deinstallation, Transportation and Storage
●Disconnect power supply before deinstallation.
●Use the original packaging to transport the device, if possible.
●Clean the device before storing. Follow the cleaning instructions in chapter 6.2.1. Basic Cleaning
Instructions on page 12.
●Store the device in the original packaging, if possible.
8. Disposal
Correct disposal of this product
Waste Electrical and Electronic Equipment
This symbol on the product, its packaging or documents indicates that the product
shall not be treated as household waste. Dispose of this product by handing it to the
respective collection point for recycling of electrical and electronic equipment. This
is to avoid environmental damage or personal injury due to uncontrolled waste
disposal. For more detailed information about recycling of this product contact the
local authorities or the authorized dealer.
9. Approval
Check the respective product page on the website of Highlite International (www.highlite.com) for an
available declaration of conformity.

13
Powerport 3
Product code: 50275

14
Powerport 3
Product code: 50275

©2022 Showgear
