PowerBOX 4PG
Product code: 90662
Preface
Thank you for purchasing this Showgear product.
The purpose of this user manual is to provide instructions for the correct and safe use of this product.
Keep the user manual for future reference as it is an integral part of the product. The user manual shall be
stored at an easily accessible location.
This user manual contains information concerning:
●Safety instructions
●Installation and operation of the device
●Intended and non-intended use of the device
●Maintenance procedures
●Troubleshooting
●Transport, storage and disposal of the device
Non-observance of the instructions in this user manual may result in serious injuries and damage of
property.
©2021 Showgear. All rights reserved.
No part of this document may be copied, published or otherwise reproduced without the prior written
consent of Highlite International.
Design and product specifications are subject to change without prior notice.
For the latest version of this document, please visit our website www.highlite.com or contact us at
[e-mail].
Highlite International and its authorized service providers are not liable for any injury, damage, direct or
indirect loss, consequential or economic loss or any other loss arising from the use of, or inability to use or
reliance on the information contained in this document.

2
PowerBOX 4PG
Product code: 90662
Table of contents
1. Introduction..........................................................................................................................................................3
Before Using the Product ..................................................................................................................................3
Intended Use .......................................................................................................................................................3
Product Lifespan.................................................................................................................................................3
Text Conventions ................................................................................................................................................3
Symbols and Signal Words................................................................................................................................4
Symbols on the Information Label ..................................................................................................................4
2. Safety ....................................................................................................................................................................5
Warnings and Safety Instructions ....................................................................................................................5
Requirements for the User.................................................................................................................................7
3. Description of the Device ...................................................................................................................................8
Front View ............................................................................................................................................................8
Product Specifications ......................................................................................................................................8
Optional Accessories.........................................................................................................................................9
Dimensions...........................................................................................................................................................9
4. Installation ............................................................................................................................................................9
Safety Instructions for Installation ....................................................................................................................9
Personal Protective Equipment .......................................................................................................................9
Installation Site Requirements ..........................................................................................................................9
Rigging ...............................................................................................................................................................10
Connecting to Power Supply.........................................................................................................................11
5. Setup ...................................................................................................................................................................11
Warnings and Precautions .............................................................................................................................11
6. Operation ...........................................................................................................................................................11
Safety Instructions for Operation...................................................................................................................11
Start-up...............................................................................................................................................................12
7. Troubleshooting .................................................................................................................................................12
8. Maintenance .....................................................................................................................................................12
Safety Instructions for Maintenance.............................................................................................................12
Preventive Maintenance................................................................................................................................12
Basic Cleaning Instructions ...................................................................................................................12
Corrective Maintenance................................................................................................................................13
9. Deinstallation, Transportation and Storage ....................................................................................................13
10. Disposal ..............................................................................................................................................................13
11. Approval.............................................................................................................................................................13

3
PowerBOX 4PG
Product code: 90662
1. Introduction
Before Using the Product
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your
Highlite International dealer.
Your shipment includes:
Showgear PowerBOX 4PG
User manual
Fig. 01
Intended Use
This device is intended for professional use as a socket box. It is suitable only for indoor installation. This
device is not suitable for households.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
Product Lifespan
This device is not designed for permanent operation. Disconnect the device from the electrical power
supply when the device is not in operation. This will reduce the wear and will improve the device’s
lifespan.
Text Conventions
Throughout the user manual the following text conventions are used:
Buttons: All buttons are in bold lettering, for example “Press the UP/DOWN buttons”
References: References to chapters and parts of the device are in bold lettering, for example:
“Refer to 2. Safety”, “turn the adjustment screw (02)”
0–255: Defines a range of values
Notes: Note: (in bold lettering) is followed by useful information or tips

4
PowerBOX 4PG
Product code: 90662
Symbols and Signal Words
Safety notes and warnings are indicated throughout the user manual by safety signs.
Always follow the instructions provided in this user manual.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
Attention
Indicates important information for the correct operation and use of the
product.
Important
Read and observe the instructions in this document.
Electrical hazard
Provides important information about the disposal of this product.
Symbols on the Information Label
This product is provided with an information label. The information label is located on the backside of the
device.
The information label contains the following symbols:
This device shall not be treated as household waste.
This device is designed for indoor use.

5
PowerBOX 4PG
Product code: 90662
2. Safety
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
Warnings and Safety Instructions
DANGER
Danger for children
For adult use only. The device must be installed beyond the reach of children.
Do not leave various parts of the packaging (plastic bags, polystyrene foam, nails, etc.) within
children’s reach. Packaging material is a potential source of danger for children.
DANGER
Electric shock caused by dangerous voltage inside
There are areas within the device where dangerous touch voltage may be present.
●Do not open the device or remove any covers.
●Do not operate the device if the covers or the housing are open. Before operation, check if the
housing is firmly closed and all screws are tightly fastened.
Disconnect the device from electrical power supply before service and maintenance, and when the
device is not in use.
DANGER
Electric shock caused by short-circuit
This device falls under IEC protection class I.
Make sure that the device is electrically connected to ground (earth). Connect the device only to a
socket-outlet with ground (earth) connection.
Do not cover the ground (earth) connection.
Do not bypass the thermostatic switch or fuses.
●Do not let the power cable come into contact with other cables. Handle the power cable and all
connections with the mains with caution.
●Do not modify, bend, mechanically strain, put pressure on, pull or heat up the power cable.
●Make sure that the power cable is not crimped or damaged. Examine the power cable periodically
for any defects.
●Do not immerse the device in water or other liquids. Do not install the device in a location where
flooding may occur.
Do not use the device during thunderstorms. Disconnect the device from the electrical power supply
immediately.

6
PowerBOX 4PG
Product code: 90662
Attention
Power supply
Before connecting the device to the power supply, make sure that the current, voltage and
frequency match the input voltage, current and frequency specified on the information label on the
device.
Make sure that the cross-sectional area of the extension cords and power cables is sufficient for the
required power consumption of the device.
Attention
General safety
●Do not connect the device to a dimmer pack.
●Do not switch the device on and off in short intervals. This decreases the device’s life.
●Do not shake the device. Avoid brute force when installing or operating the device.
●If the device is dropped or struck, disconnect the device from the electrical power supply
immediately.
If the device is exposed to extreme temperature variations (e.g. after transportation), do not switch it
on immediately. Let the device reach room temperature before switching it on, otherwise it may be
damaged by the formed condensation.
If the device fails to work properly, discontinue the use immediately.
Attention
For professional use only
This device shall be used only for the purposes it is designed for.
This device is designed to be used as a socket box. Any incorrect use may lead to hazardous situations
and result in injuries and material damage.
●This device is not suitable for households.
●This device is not designed for permanent operation.
This device does not contain user-serviceable parts. Unauthorized modifications to the device will
render the warranty void. Such modifications may result in injuries and material damage.
Attention
Before each use, examine the device visually for any defects.
Make sure that:
All screws used for installing the device or parts of the device are tightly fastened and are not
corroded.
The safety devices are not damaged.
There are no deformations on housings, fixations and installation points.
The power cables are not damaged and do not show any material fatigue.

7
PowerBOX 4PG
Product code: 90662
Attention
Do not expose the device to conditions that exceed the rated IP class conditions.
This device is IP20 rated. IP (Ingress Protection) 20 class provides protection against solid objects greater
than 12 mm, such as fingers, and no protection against harmful ingress of water.
Requirements for the User
This product may be used by ordinary persons. Maintenance may be carried by ordinary persons.
Installation and service shall be carried out only by instructed or skilled persons. Contact your Highlite
dealer for more information.
Instructed persons have been instructed and trained by a skilled person, or are supervised by a skilled
person, for specific tasks and work activities associated with the installation, service and maintenance of
this product, so that they can identify risks and take precautions to avoid them.
Skilled persons have training or experience, which enables them to recognize risks and to avoid hazards
associated with the installation, service and maintenance of this product.
Ordinary persons are all persons other than instructed persons and skilled persons. Ordinary persons
include not only users of the product but also any other persons that may have access to the device or
who may be in the vicinity of the device.

8
PowerBOX 4PG
Product code: 90662
3. Description of the Device
The Showtec PSA-63A4C is a socket box for lighting or back-line equipment. The device is suitable for self-
made power cables.
Front View
Fig. 02
Cable gland for the power cable
LED power indicator
4 x Schuko power connector OUT
Product Specifications
Model:
PowerBOX 4PG
Electrical:
Input voltage:
220–240 V AC, 50 Hz
Rated current:
10 A
Power connector IN:
Open end
Power connector OUT:
4 x Schuko, 10 A RMS/16 A peak
Pins:
3
Maximum wire size:
2,5 mm2/14 AWG
Physical:
Tunnel width:
30 mm
Dimensions:
355 x 90 x 75 mm (LxWxH)
Weight:
0,7 kg
Operation and control:
LED indicators:
Power
Construction:
Housing:
ABS
Color:
Black
IP rating:
IP20
Thermal:
Ambient temperature ta:
From -10 °C to 40 °C

9
PowerBOX 4PG
Product code: 90662
Optional Accessories
You can additionally purchase the following accessories:
Product code: 90659 (PowerBOX clamp)
Product code: D9575B (Snap Fastener 22)
Dimensions
Fig. 03
4. Installation
Safety Instructions for Installation
WARNING
Incorrect installation can cause serious injuries and damage of property.
If trussing systems are used, installation must be carried out only by instructed or skilled persons.
Follow all applicable European, national and local safety regulations concerning rigging and trussing.
Personal Protective Equipment
During installation and rigging wear personal protective equipment in compliance with the national and
site-specific regulations.
Installation Site Requirements
●The device must be installed only indoors.
●The device can be placed on a flat surface or be mounted to a truss or other rigging structure in any
orientation.
●The maximum ambient temperature ta= 40 °C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 40 °C.

10
PowerBOX 4PG
Product code: 90662
Rigging
The device can be positioned on a flat surface or mounted to a truss or other rigging structure in any
orientation. Make sure that all loads are within the pre-determined limits of the supporting structure.
CAUTION
Restrict the access under the work area during rigging and/or derigging.
The mounting options are as follows:
Option 1: installation with the Snap Fastener 22
Use the Snap Fastener 22 to attach the device to the supporting structure, as shown in Fig. 04. Put the
snap fastener through the slot.
Note:
The Snap Fastener (product code: D9575B) is not included in the delivery. You can purchase it with any
Highlite International dealer.
Fig. 04
Option 2: installation with the PowerBOX clamp
Use the PowerBOX clamp to attach the device to the supporting structure, as shown in Fig. 05.
Note:
The PowerBOX clamp (product code: 90659) is not included in the delivery. You can purchase it with any
Highlite International dealer.
Fig. 05

11
PowerBOX 4PG
Product code: 90662
Connecting to Power Supply
DANGER
Electric shock caused by short-circuit
The device accepts AC mains power at 220–240 V and 50 Hz. Do not supply power at any other voltage
or frequency to the device.
This device falls under IEC protection class I. Make sure that the device is always electrically connected
to the ground (earth).
Before connecting the device to the socket-outlet:
Make sure that the power supply matches the input voltage specified on the information label on
the device.
Make sure that the socket-outlet has ground (earth) connection.
Connect the device to the socket-outlet with a self-made power cable.
5. Setup
Warnings and Precautions
Attention
Connect all cables before supplying power.
Disconnect power supply before connecting or disconnecting cables.
6. Operation
Safety Instructions for Operation
Attention
This device must be used only for the purposes it is designed for.
This device is intended for use as a socket box. It is suitable only for indoor installation. It is not suitable for
households.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
Attention
Power supply
Before connecting the device to the power supply, make sure that the current, voltage and frequency
match the input voltage, current and frequency specified on the information label on the device.

12
PowerBOX 4PG
Product code: 90662
Start-up
Connect one end of your self-made power cable to the cable gland (01).
Connect the other end to the appropriate 220–240 V AC power supply.
Connect other devices to the Schuko outputs (03).
7. Troubleshooting
This troubleshooting guide contains solutions to problems which can be carried out by an ordinary
person. The device does not contain user-serviceable parts.
Unauthorized modifications to the device will render the warranty void. Such modifications may result in
injuries and material damage.
Refer servicing to instructed or skilled persons. Contact your Highlite International dealer in case the
solution is not described in the table.
Problem
Probable cause(s)
Solution
The device does not
function at all
No power to the device
●Check if power is switched on and
cables are plugged in
●Check the total load of the connected
devices.
8. Maintenance
Safety Instructions for Maintenance
DANGER
Electric shock caused by dangerous voltage inside
Disconnect power supply before servicing or cleaning.
Preventive Maintenance
Attention
Before use, examine the device visually for any defects.
Make sure that:
●All screws used for installing the device or parts of the device are tightly fastened and are not
corroded.
●There are no deformations on housings, fixations and installation points.
●The power cables are not damaged and do not show any material fatigue.
Basic Cleaning Instructions
To clean the device, follow the steps below:
Disconnect the device from the electrical power supply.
Allow the device to cool down for 5 minutes.
03) Clean the device with a soft, lint-free cloth.

13
PowerBOX 4PG
Product code: 90662
Attention
●Do not immerse the device in liquid.
●Do not use alcohol or solvents.
Corrective Maintenance
The device does not contain user-serviceable parts. Do not open the device and do not modify the
device.
Refer repairs and servicing to instructed or skilled persons. Contact your Highlite International dealer for
more information.
9. Deinstallation, Transportation and Storage
●Disconnect power supply before deinstallation.
●Use the original packaging to transport the device, if possible.
●Clean the device before storing. Follow the cleaning instructions in chapter 8.2.1. Basic Cleaning
Instructions on page 12.
●Store the device in the original packaging, if possible.
10. Disposal
Correct disposal of this product
Waste Electrical and Electronic Equipment
This symbol on the product, its packaging or documents indicates that the product
shall not be treated as household waste. Dispose of this product by handing it to the
respective collection point for recycling of electrical and electronic equipment. This
is to avoid environmental damage or personal injury due to uncontrolled waste
disposal. For more detailed information about recycling of this product contact the
local authorities or the authorized dealer.
11. Approval
Check the respective product page on the website of Highlite International (www.highlite.com) for an
available declaration of conformity.

14
PowerBOX 4PG
Product code: 90662

©2021 Showgear
