Quick Cuff
User Manual
www.sitech.se

www.sitech.se
Quick Cuff -User manual
We want to congratulate you on your purchase of a Modular Quick Change
Solution developed and manufactured by SI TECH in Sweden. Our products
enhance your capacities through increased comfort and safety. All of our pro-
ducts are made in Sweden and used worldwide by the full spectrum of divers.
Quick Cuff turns your drysuit into a modular platform able of carrying a variety of
different seals as well as the possibility of changing a torn or broken seal in minutes
without tools or glue. It is also fully compatible with the Quick Glove System and the
Glove Lock QCP system. Note that the Wrist Ring has to be glued onto the suit.
1. Mounting seals
2. Attach to Wrist Ring
This manual does not address the topic of gluing/attaching the Wrist Ring of the
Quick Cuff to your drysuit. Please visit: www.sitech.se for information.
1.1 Carry the seal through the Stiff Ring and
invert the rear section of the seal to the outside
of the Stiff Ring. Position the rear end of the
seal as the illustration shows.
Seal position: The red, dotted line indicates
the final position of latex seals. The blue, dotted
line indicates the final position of silicone seals.
NOTE: The seal must be placed evenly around the
Stiff Ring – no bumps or gaps.
Seal Stiff
Ring
A tips for mounting of latex seals:
The latex seal can be secured with flexible tape
before insertion into the Wrist Ring, to prevent
the seal from sliding. Make sure the seal covers
the locking groove.
Cut out section of assembly shows
how the the components shall
be aligned when assembled correct.
A. Wrist Ring
B. Stiff Ring
C. Final position of latex
seal (if used)
D. Safety flange of
silicone seal (if used)
SEAL MUST BE USED
AT ALL TIMES
• Turns your drysuit into a modular platform
capable of carrying a variety of different seals
and Dry Glove systems.
• Provides the opportunity of changing a torn
or broken seal in minutes without tools or glue.
Benefits
The system itself consists of
three components per arm:
• Wrist Rings
• Stiff Rings
• Wrist Seals (silicone or latex)
Components
Wrist Ring Stiff Ring

www.sitech.se
3. Detaching the Quick Cuff assembly
Use together with Dry Gloves
The Quick Cuff is adapted for use as an attachment platform for the Dry Glove systems;
Quick Glove and Glove Lock QCP made by SI TECH. Both of these systems provides the user
a variety of dry gloves to be used.
3.1 If for some reason you need to remove the Stiff Ring and/or change seal; simply press the Wrist
Ring as hereby explained. The arrows in the illustration show the directional force needed to release
the assembly.
Press the back end of the Wrist
Ring with your index fingers
Press the flange area
of the Wrist Ring with
your thumbs
The Glove Lock QCP attaches easily to the Quick Cuff by connecting the Wrist Ring of the Quick
Cuff inside the Assembly Ring of the Glove Lock QCP. Step by step explanation of this procedure
is to be found in the Glove Lock QCP manual available at; www.sitech.se.
The yellow Wrist Ring above is used only for illustrative purposes and is not available for sale.
The Quick Glove attaches directly into the Stiff Ring of the Quick Cuff system. Step by step
explanation of this procedure is to be found in the Quick Glove manual available at;
www.sitech.se.
These are suggested instructions only
Whatever method chosen, be certain the cuff seal, be it latex or silicone, is properly treated.
Always make a leakage and stress test on your drysuit seals before diving.
2.1 Initiate the assembling process by holding the seal as the left image shows. This is just to
align the rings and to ensure the seal stays in position for the first 2/3 of the travel length.
Hold the front end of the seal in a firm grip when pressing the seal assembly into the Wrist Ring.
Ensure that the inverted part of the seal does not slip from its position while being pressed into the
Wrist Ring. For the last part of the assembly you need to change grip and work as the right image
shows. Stretch the seal using the force direction of the arrow, at the same time you should
press the Stiff Ring into the assembly. Repeat this operation in several steps 360° around the
rings until the seal assembly reaches the bottom of the Wrist Ring.
Important information
• A cuff seal provides the sealing of the system and must be used at all times, even when
the Quick Cuff is used in combination with a SI TECH Dry Glove System.
• A minimun seal thickness of 0,8 mm is recommended. Use of a thinner seal may cause leakage.
• Test the strength and seal integrity before diving.

www.sitech.se
Spare Parts
Item no. Item
60420 Wrist Ring
60200 Stiff ring
61025 Silicone Seal, Standard (wrist circumference 13,2-17 cm / 5,2-6,7”)
61026 Silicone Seal, Small (wrist circumference 10,6-15 cm / 4,2-5,9”)
61150 Latex Seal, X-Small (wrist circumference 12,5-14 cm / 5,0-5,5”)
61130 Latex Seal, Small (wrist circumference 13,5-16 cm / 5,4-6,4”)
61100 Latex Seal, Medium (wrist circumference 15,5-18 cm / 6,2-7,4”)
61090 Latex Seal, Large (wrist circumference 18-21 cm / 7,2-8,4”)
Maintenance and Storage
• Remove the Stiff Ring regularly to rinse the cuff seal and/or glove from salt or debris and
to relieve the Wrist/Rubber Rings and seals from stress settings, especially when storing
for prolonged periods.
• Avoid exposing the Wrist/Rubber Ring to heat or sunlight. Subjecting the assembled
unit to prolonged heat or sunlight with an inserted cuff seal is not recommended.
The material may expand, which could cause leakage.
• Remove the Stiff Ring if the drysuit shall be stored for prolonged periods! This will
decrease stress on the Wrist Ring. Long periods of stress on the Wrist Ring might result
in leakage or other damage to the system.
Our products have
been trusted by divers
for more than 40 years
SI TECH is a Swedish company focusing on manufacturing and
marketing of components for protective suits such as; drysuits,
rescue suits and garments designed for diverse hostile
environments. SI TECH is rooted in the diving industry which
is still the company’s core market. The company was founded
in 1971 by the diving pioneer Stig Insulán.
Core products
Modular Quick Change Solutions, Drysuit Valves, Drysuit seals,
Dry Glove Systems, Gas Inflation Systems and special
compoents for military purposes
Inhouse capabilities
Development and production is made in-house at our facilities in
Brastad, Sweden. Inhouse competencies include: CAD constr-
uction, Injection Molding, CNC Machining, EMD Machining,
Assembly, Sales and Marketing, Logistics and Administration.
Our team of engineers, sales and marketing personell have
close co-operation with the distributors and end-users of our products.

www.sitech.se
SI TECH AB | Quick Cuff manual | Version: 2.1 | August 27, 2013
