sidhil 3012/LO User manual

Introduction
Thank you for purchasing a Sidhil Easi - Riser over bed table.
Key Features include :-
R ising on underside load Prevents the risk of trapped legs by automatically moving upwards .
BioCote Anti Bacterial coating
Wheeled base E as y movement for helpers and user s.
Specifications
301 2 /LO
Easi - Riser Overbed table
Standard Base
301 3/ LO
Easi - Riser Overbed table
Wheelchair Base
Table top maximum Load 30Kg (66lb) Table top maximum Load 30Kg (66lb)
Minimum table h eight 740mm (29.1 ) Minimum table height 740mm (29.1 )
Maximum table height 1090mm (42.9 ) Maximum table height 1090mm (42.9 )
Overall table area 910 x 380 mm
(35.8 x 14.9 )
Overall table area 910 x 380 mm
(35.8 x 14.9 )
Base width (intern al) Not Applicable B ase width (internal) 660mm (25.9 )
Net weight 22 Kg ( 48.5 lb) Net weight 22Kg (48.5lb)
Assembly & preparing for use
Your table is delivered fully assembled and ready to use .
Using your table : Do s & Don ts
DO ensure you read t hese instructions and fully understand them before using your table.
DO ensure the table is cleaned on a regular basis
DO ensure the table is inspected on a regular basis (minimum once a year recommended ).
D O NOT exceed the safe working load
The table is designed to carry a maximum load of 30Kg that is evenly distributed across the table top.
It is advantages to place heavier items towards the supporting column end.
User Guide
Easi- Riser Table 3012 /LO 301 3 /LO

Adjusting the table
Raising
Gently push up on the table underside and table top wil l rise up. It will automatically lock in the desired position .
Lowering
Support the weight of the table, s queeze upwards the front leaver and lower the table to the desired position ,
release the lever.
Care and maintenance
Biocote
The painted parts o f your table come with an antibacterial additive incorporated into the powd er coated
metalwork. Biocote inhibits the growth of bacteria on the surface of the table frame. It is effective
against a wide range of both gram positive and negative bacteria as well as fungi. Examples of bacteria
that Biocote is resistant to include:
Bacillus Subtilis Staphylococcus Aureus (MRSA)
Escerichia Coli 0157 Streptococcus Faecalis
Salmonella Enteritides Listeria Monocytogenes
Biocote is an aid to keeping your table infection free but it does not substitute the need for the table to
be cleaned at regular intervals.
Cleaning
All surfaces to be wiped down with a disposable cleaning cloth, moistened with a mild detergent and diluted in
hot water (60°C). Extra care should be taken around areas where excess dirt or dust may gather. Rinse down
with clean water and dry off with a paper towel.
Always ensure that the table is dry before re - using.
It is not recommended to use any bleach or surface cleaner that may scour the painted surface.
Warranty
Sidhil Limited standar d terms and conditions apply to all purchases; a copy is available from the address below.
Your statutory rights are not affected.
Sidhil Limited , Sid hil Business Park , Holmfield , Halifax , West Yorkshire HX2 9TN
Tel: [phone] Fax: [phone] Email: [email protected]
Sales Tel: [phone] Sales Fax: [phone]
A Member of the Siddall & Hilton Ltd Group of Companies
