Siemens ARCADIS Installation manual

© Siemens AG
The reproduction, transmission or use
of this document or its contents is not
permitted without express written
authority. Offenders will be liable for
damages. All rights, including rights
created by patent grant or registration
of a utility model or design, are
reserved.
Print No.:
Mühlhäuser
ARCADIS
System
Installation and Startup
SP
2004
SPR2-310.814.02.02.02
Replaces: SPR2-310.814.02.01.02
English
Doc. Gen. Date: 04.04
2D Navigation
08080009080800171004768010048590

2 Revision / Disclaimer
ARCADIS SPR2-310.814.02.02.02 Siemens AG
04.04 CS SD 24
Page 2 of 12 Medical Solutions
1Revision / Disclaimer
Document revision level
The document corresponds to the version/revision level effective at the time of system
delivery. Revisions to hardcopy documentation are not automatically distributed.
Please contact your local Siemens office to order current revision levels.
Disclaimer
The installation and service of equipment described herein is to be performed by qualified
personnel who are employed by Siemens or one of its affiliates or who are otherwise
authorized by Siemens or one of its affiliates to provide such services.
Assemblers and other persons who are not employed by or otherwise directly affiliated
with or authorized by Siemens or one of its affiliates are directed to contact one of the
local offices of Siemens or one of its affiliates before attempting installation or service pro-
cedures.

Siemens AG SPR2-310.814.02.02.02 ARCADIS
04.04 CS SD 24
Table of Contents 3
Page 3 of 12
Medical Solutions
1- 0Table of Contents
1 _______ Prerequisites ___________________________________________________ 4
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
General requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Required documents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
System requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Required parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Required license key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 _______ Installation and Settings __________________________________________ 6
Installation of TCP / IP cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Configuration of the network node (step 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Configuration of the network node (step 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Configuration of the network node (step 3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Final steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3 _______ Changes to previous version _____________________________________ 11

4 Prerequisites
ARCADIS SPR2-310.814.02.02.02 Siemens AG
04.04 CS SD 24
Page 4 of 12 Medical Solutions
2-
1Prerequisites
Prerequisites 0
General requirement 0
Required documents 0
System requirement 0
Required parts 0
Required license key 0
Tools 0
- A representative of the manufacturer of the Navigation system should be on site for
startup support.
- ARCADIS System Software VB 10C or higher
- TCP/ IP type crossover cable for a direct connection to the Navigation system (not
included in the shipment)
- TCP/ IP cable for a connection to the Navigation system via the clinical network
(not included in the shipment)
- 2D Navigation license key, part no.: 044 986 01
- Toolkit

Siemens AG SPR2-310.814.02.02.02 ARCADIS
04.04 CS SD 24
Prerequisites 5
Page 5 of 12
Medical Solutions
Safety information 0
WARNING Risk of physical injury or death and property damage!
Non-compliance can lead to death, physical injury or property
damage
¹Observe the following:
¹- the product-specific safety information in these
instructions,
¹- the general safety information in the instructions
TD00-000.860.01... and
¹- the general safety information according to ARTD Part
2.

6 Installation and Settings
ARCADIS SPR2-310.814.02.02.02 Siemens AG
04.04 CS SD 24
Page 6 of 12 Medical Solutions
3-
2Installation and Settings
Installation of TCP / IP cable 0
•Connect the TCP/IP crossover cable to the monitor trolley and the 2D Navigation sys-
tem (see figure below).
NOTE If the ARCADIS system is connected to the Navigation system via
the clinical network, the connection may be affected by heavy net-
work traffic.
Fig. 1: Connection

Siemens AG SPR2-310.814.02.02.02 ARCADIS
04.04 CS SD 24
Installation and Settings 7
Page 7 of 12
Medical Solutions
Configuration of the network node (step 1) 0
•Switch on the system.
•Click <Options>-<Service>-<Local Service>.
•Enter the password and click <ok>.
•Click <Configuration>.
•"Attached to Network" and "Dicom Networking" must be selected.
•Click <Next>.
Fig. 2: Configuration 1

8 Installation and Settings
ARCADIS SPR2-310.814.02.02.02 Siemens AG
04.04 CS SD 24
Page 8 of 12 Medical Solutions
Configuration of the network node (step 2) 0
•Under "DICOM", click <Network Nodes>.
Select "define new" under "Select Host".
•Enter the Host Name of the Navigation system under "Host Properties". Note: "naviga-
tionsys" in the figure below is only an example.
•Ensure that the Navigation system is connected and ready.
•Click "Find" to check whether the host is alive and ensure that the TCP/IP address of
the Navigation system appears in the address field.
•Click <Save>.
•Click ">".
Fig. 3: Configuration 2

Siemens AG SPR2-310.814.02.02.02 ARCADIS
04.04 CS SD 24
Installation and Settings 9
Page 9 of 12
Medical Solutions
Configuration of the network node (step 3) 0
•Select "define new" under "General Node Properties" to edit the logical name
"NAV2D_XXX" (XXX = logical name of Navigation system).
NOTE If the ARCADIS system is also connected to a 3D Navigation sys-
tem, the logical name should be "NAV3D_XXX" (XXX = logical
name of Navigation system).
•Edit the DICOM AE Title of the Navigation system under "Application Entity Proper-
ties". "Note: "NAVISYSTEM" in the figure below is only an example.
•Under Port Number, edit "104" if necessary. If port no. 104 does not work, check if the
Navigation system uses e.g. port 105.
•Click <Add>.
•Click <Verification> to check if the "AE Title" is alive.
•Select <Storage> under "Supported DICOM services".
•Click <Save>.
Fig. 4: Configuration 3

10 Installation and Settings
ARCADIS SPR2-310.814.02.02.02 Siemens AG
04.04 CS SD 24
Page 10 of 12 Medical Solutions
Final steps 0
•Perform a functional check.

Siemens AG SPR2-310.814.02.02.02 ARCADIS
04.04 CS SD 24
Changes to previous version 11
Page 11 of 12
Medical Solutions
4-
3Changes to previous version
None; initial publication
