RUGGEDCOM WIN5158-V-GPS
Installation Guide
Table of Contents
iii
Table of Contents
Preface ............................................................................................................. v
Alerts .................................................................................................................................................. v
Related Documents ............................................................................................................................. vi
Training .............................................................................................................................................. vi
Customer Support ............................................................................................................................... vi
Chapter 1
Introduction ..................................................................................................... 1
1.1Feature Highlights ........................................................................................................................ 2
1.2Description ................................................................................................................................... 2
1.3Required Tools and Materials ......................................................................................................... 3
1.4Decommissioning and Disposal ...................................................................................................... 4
Chapter 2
Installing the Subscriber Unit ............................................................................ 5
2.1General Procedure ........................................................................................................................ 6
2.2Unpacking the Subscriber Unit ....................................................................................................... 7
2.3Site Preparation and Precautions .................................................................................................... 7
2.4Mounting the Subscriber Unit ........................................................................................................ 8
2.4.1Mounting the Subscriber Unit to a Wall or Tower ................................................................. 9
2.4.2Mounting the Subscriber Unit to a Pole ............................................................................. 11
2.5Installing the Antennas ............................................................................................................... 12
2.6Grounding the Subscriber Unit ..................................................................................................... 14
2.7Connecting Power and Data ........................................................................................................ 14
2.8Weatherproofing the Subscriber Unit ............................................................................................ 15
2.8.1Weatherproofing a Cable .................................................................................................. 15
2.8.2Applying Cold Shrink Tubing ............................................................................................. 16
2.8.3Applying Self-Amalgamating Tape ..................................................................................... 16
Chapter 3
Device Management ....................................................................................... 17
3.1Configuring the Subscriber Unit ................................................................................................... 17
Chapter 4
Technical Specifications .................................................................................. 19
4.1Power Supply Requirements ........................................................................................................ 19
Table of Contents
RUGGEDCOM WIN5158-V-GPS
Installation Guide
iv
4.2Power Consumption .................................................................................................................... 19
4.3Radio and Modem Specifications .................................................................................................. 19
4.4Operating Environment ............................................................................................................... 20
4.5Mechanical Specifications ............................................................................................................ 20
4.6Dimension Drawings ................................................................................................................... 21
Chapter 5
Certification .................................................................................................... 23
5.1Approvals ................................................................................................................................... 23
5.1.1CSA ................................................................................................................................. 23
5.1.2European Union (EU) ....................................................................................................... 24
5.1.3TÜV Rheinland ................................................................................................................. 24
5.1.4ISED ................................................................................................................................ 25
5.1.5IEEE ................................................................................................................................ 25
5.1.6RoHS ............................................................................................................................... 25
5.2Environmental Type Tests ............................................................................................................ 25
RUGGEDCOM WIN5158-V-GPS
Installation Guide
Preface
Alerts v
Preface
This guide describes the RUGGEDCOM WIN5158-V-GPS. It describes the major features of the subscriber unit,
installation, commissioning and important technical specifications.
It is intended for use by subscriber unit installers and operators, and assumes readers have a working knowledge
of WiMAX technologies and procedures. While some safety precautions are reviewed here, it is assumed that
installers are trained in safe installation practices. Users unfamiliar with safe installation procedures, WiMAX
technologies, and service procedures should not rely on this manual for comprehensive guidance.
CONTENTS
•“Alerts”
•“Related Documents”
•“Training”
•“Customer Support”
Alerts
The following types of alerts are used when necessary to highlight important information.
DANGER!
DANGER alerts describe imminently hazardous situations that, if not avoided, will result in death or
serious injury.
WARNING!
WARNING alerts describe hazardous situations that, if not avoided, may result in serious injury and/or
equipment damage.
CAUTION!
CAUTION alerts describe hazardous situations that, if not avoided, may result in equipment damage.
IMPORTANT!
IMPORTANT alerts provide important information that should be known before performing a procedure
or step, or using a feature.
NOTE
NOTE alerts provide additional information, such as facts, tips and details.
Preface
RUGGEDCOM WIN5158-V-GPS
Installation Guide
vi Related Documents
Related Documents
Other documents that may be of interest include:
•RUGGEDCOM SU User Guide [https://support.industry.siemens.com/cs/ww/en/view/109737453]
Training
Siemens offers a wide range of educational services ranging from in-house training of standard courses on
networking, Ethernet switches and routers, to on-site customized courses tailored to the customer's needs,
experience and application.
Siemens' Educational Services team thrives on providing our customers with the essential practical skills to make
sure users have the right knowledge and expertise to understand the various technologies associated with critical
communications network infrastructure technologies.
Siemens' unique mix of IT/Telecommunications expertise combined with domain knowledge in the utility,
transportation and industrial markets, allows Siemens to provide training specific to the customer's application.
For more information about training services and course availability, visit https://www.siemens.com/ruggedcom or
contact a Siemens Sales representative.
Customer Support
Customer support is available 24 hours, 7 days a week for all Siemens customers. For technical support or general
information, contact Siemens Customer Support through any of the following methods:
Online
Visit http://www.siemens.com/automation/support-request to submit a Support Request (SR) or check
on the status of an existing SR.
Telephone
Call a local hotline center to submit a Support Request (SR). To locate a local hotline center, visit http://
www.automation.siemens.com/mcms/aspa-db/en/automation-technology/Pages/default.aspx.
Mobile App
Install the Industry Online Support app by Siemens AG on any Android, Apple iOS or Windows mobile
device and be able to:
• Access Siemens' extensive library of support documentation, including FAQs and manuals
• Submit SRs or check on the status of an existing SR
• Contact a local Siemens representative from Sales, Technical Support, Training, etc.
• Ask questions or share knowledge with fellow Siemens customers and the support community
RUGGEDCOM WIN5158-V-GPS
Installation Guide
Chapter 1
Introduction
1
Introduction
The RUGGEDCOM WIN5158-V-GPS subscriber unit is part of the RUGGEDCOM WIN family, a line of mobile WiMAX
broadband wireless access systems based on the IEEE 802.16e mobile WiMAX standard.
The RUGGEDCOM WIN5158-V-GPS is a high-performance, self-learning subscriber. It automatically detects the
base station on the best signal available, allowing for plug-and-play installation and maintenance free operation.
The automatic switching and monitoring features guarantee on-going operation in changing conditions, which
results in low maintenance and considerable operating expense savings.
The subscriber unit is compliant with IEEE 802.16e standards to effectively meet the unique requirements of the
wireless Metropolitan Area Network (MAN) environment and to deliver broadband access services to a wide range
of customers. Specifically designed for point-to-multipoint broadband wireless access applications, the subscriber
unit provides efficient use of the wireless spectrum, supporting a range of user environments.
The subscriber unit also complies with the IEEE 802.16-2005 standard for the deployment of point-to-multipoint
(PMP) and point-to-point (PTP) network architectures.
The subscriber unit is a WiMAX Forum IEEE 802.16e Wave 2 (MIMO) certified subscriber. Each subscriber registers
and establishes a bi-directional data link with the base station.
Primary benefits offered by the RUGGEDCOM WIN5158-V-GPS include:
•Non-Line-of-Sight (NLOS) Propogation
Provides excellent performance in NLOS conditions. Mitigates multi-path and deep fading, providing extended
range and easy installation.
•Automatic Transmit Power Control (ATPC)
ATPC allows for optimal network deployment, tight frequency reuse, and interference avoidance.
•Wide Frequency Band
Provides support for deployments around the world.
CONTENTS
•Section1.1, “Feature Highlights”
•Section1.2, “Description”
•Section1.3, “Required Tools and Materials”
•Section1.4, “Decommissioning and Disposal”
Chapter 1
Introduction
RUGGEDCOM WIN5158-V-GPS
Installation Guide
2 Feature Highlights
Section1.1
Feature Highlights
Long Range
The subscriber unit has multiple built-in receivers to improve range and Non-Line-of-Sight (NLoS) performance.
The system has the ability to leverage sub-channelization technology to balance links with high-power base
stations.
Robust Design
The subscriber unit is designed for mission critical applications in harsh environments with very high Mean Time
Before Failure.
Quality of Service
The subscriber unit gives the user the ability to separate traffic types over the air, and guarantee latency,
minimum bandwidth and jitter according to application needs.
Flexibility
The subscriber unit supports both IP convergence sublayer for wireless Internet service providers or Ethernet
Convergence Sublayer, ideal for mission critical private networks.
Section1.2
Description
The RUGGEDCOM WIN5158-V-GPS features various ports, controls and indicator LEDs on the bottom panel for
connecting, configuring and troubleshooting the subscriber unit.
4
3
1
8
6
5
7
2
RSSI
W.LINK PWR
Figure1:RUGGEDCOM WIN5158-V-GPS
1.ETH Port 2.PWR Port 3.ANT 1 Port 4.ANT 2 Port 5.RSSI LEDs 6.W.LINK LED 7.PWR LED 8.Chassis Ground
RUGGEDCOM WIN5158-V-GPS
Installation Guide
Chapter 1
Introduction
Required Tools and Materials 3
12VDC Port A 4-pin, female, D-Coded M12 port for power. For more information about connecting data
and power, refer to Section2.7, “Connecting Power and Data”.
ANT 1 and ANT 2 Ports Ports for connecting primary and secondary external antennas. For information about
connecting the antennas, refer to Section2.5, “Installing the Antennas”.
RSSI LEDs Indicates the received signal strength.
LED RSSI Level
< -90
-85 to -90
-80 to -85
-75 to -80
-70 to -75
-65 to -70
-20 to -60
> -20
W.LINK LED Indicates when the subscriber unit is connected with a base station.
State Description
Green (Solid) Subscriber unit is connected to the base
station and receiving services.
Green (Blinking) Link between the subscriber unit and the
base station is down.
PWR LED Indicates when power is supplied to the subscriber unit.
State Description
Green Power is on.
Off Power is off.
ETH Port A 4-pin, female, D-Coded M12 port for data.
Chassis Ground Connection Protects the subscriber unit from power surges and accumulated static electricity. For
information about grounding the subscriber unit, refer to Section2.6, “Grounding the
Subscriber Unit”.
Section1.3
Required Tools and Materials
The following tools and materials are required to install the RUGGEDCOM WIN5158-V-GPS:
Tools
• Wrench or socket set
• Phillips screwdriver
• Drill with an 8 mm (5/16 in) drill bit
• Wall anchors (if necessary)
Greases
• Marine grease (for marine applications only)
Tapes
• POE cold shrink (maximum 49.2 mm or 1.9 in inner
diameter before shrinking) or self-amalgamating tape
Chapter 1
Introduction
RUGGEDCOM WIN5158-V-GPS
Installation Guide
4 Decommissioning and Disposal
Sprays
• Cleaner and de-greaser
• SCC3 conformal coating
• Corrosion protection
• UV-resistant vinyl tape
• Electrical insulation putty
Mounting Hardware (Wall/Tower Only)
• Four 1/4" × 1/2" HEX chipboard screws
• Four 1/4" flat washers
• Four 1/4" spring washers
Section1.4
Decommissioning and Disposal
Proper decomissioning and disposal of this device is important to prevent malicious users from obtaining
proprietary information and to protect the environment.
Decommissioning
This device may include sensitive, proprietary data. Before taking the device out of service, either permanently or
for maintenance by a third-party, make sure it has been fully decommissioned.
For more information, refer to the associated User Guide.
Recycling and Disposal
For environmentally friendly recycling and disposal of this device and related accessories, contact a facility
certified to dispose of waste electrical and electronic equipment. Recycling and disposal must be done in
accordance with local regulations.
RUGGEDCOM WIN5158-V-GPS
Installation Guide
Chapter 2
Installing the Subscriber Unit
5
Installing the Subscriber Unit
This chapter describes how to install the subscriber unit, including mounting the subscriber unit, connecting
power, connecting the antenna, and connecting the subscriber unit to the network.
DANGER!
Electrocution hazard – risk of serious personal injury and/or damage to equipment. Before performing
any maintenance tasks, make sure all power to the subscriber unit has been disconnected and wait
approximately two minutes for any remaining energy to dissipate.
DANGER!
Electrocution hazard – risk of death or serious injury. When the subscriber unit is installed in an
outdoor location, all indoor components (e.g. Ethernet and power supply) should be connected
through a lightning protector.
Lightning protection protects people and equipment located indoors from lightning that may strike
the subscriber unit or its outdoor cables. Therefore, install the lightning protector indoors, as close
as possible to the point where the cables enter the building. The lightning protector can also be
installed outdoors as long as the cables that lead indoors are well protected from lightning between
the protector and the building entrance.
WARNING!
Safety hazard – risk of serious personal injury and/or damage to equipment. Installing the
RUGGEDCOM WIN5158-V-GPS can pose a serious safety hazard. Be sure to take precautions to avoid
the following:
• Exposure to high voltage lines during installation
• Falling when working at heights or with ladders
• Injuries from dropping tools
• Contact with AC wiring (power system connection)
IMPORTANT!
Only certified personnel should be permitted to install equipment.
IMPORTANT!
This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall
render all warranties null and void.
Changes or modifications not expressly approved by Siemens Canada Ltd could invalidate
specifications, test results, and agency approvals, and void the user's authority to operate the
equipment.
Chapter 2
Installing the Subscriber Unit
RUGGEDCOM WIN5158-V-GPS
Installation Guide
6 General Procedure
IMPORTANT!
This product should be installed in a restricted access location where access can only be gained by
authorized personnel who have been informed of the restrictions and any precautions that must be
taken. Access must only be possible through the use of a tool, lock and key, or other means of security,
and controlled by the authority responsible for the location.
IMPORTANT!
Install equipment in accordance with the electrical code relevant to the country of installation, such as:
• the National Electrical Code (NEC), ANSI/NFPA 70
• the Canadian Electrical Code (CEC), Part 1, CSA C22.1
• the National Electrical Safety Code IEEE C2 (when applicable)
Unless marked or otherwise identified, the Standard for the Protection of Electronic Computer/Data
Processing Equipment, ANSI/NFPA 75, also applies.
IMPORTANT!
Outdoor exposed communication lines longer than 40 m (140 ft) must be considered as TNV-1 circuits.
The installer must make sure the power supply and network ports are designed for full compliance with
the standards for TNV-1 telecommunication networks.
CONTENTS
•Section2.1, “General Procedure”
•Section2.2, “Unpacking the Subscriber Unit”
•Section2.3, “Site Preparation and Precautions”
•Section2.4, “Mounting the Subscriber Unit”
•Section2.5, “Installing the Antennas”
•Section2.6, “Grounding the Subscriber Unit”
•Section2.7, “Connecting Power and Data”
•Section2.8, “Weatherproofing the Subscriber Unit”
Section2.1
General Procedure
The general procedure for installing the subscriber unit is as follows:
1. Review the relevant certification information for any regulatory requirements. For more information, refer to
Section5.1, “Approvals”.
2. Unpack and inspect the subscriber unit components. For more information, refer to Section2.2, “Unpacking
the Subscriber Unit”.
3. Mount the subscriber unit to a pole, wall or tower. For more information, refer to Section2.4, “Mounting the
Subscriber Unit”.
4. Install and connect the antenna(s). For more information, refer to Section2.5, “Installing the Antennas”.
5. Make sure the subscriber unit is grounded. For more information, refer to Section2.6, “Grounding the
Subscriber Unit”.
RUGGEDCOM WIN5158-V-GPS
Installation Guide
Chapter 2
Installing the Subscriber Unit
Unpacking the Subscriber Unit 7
6. Connect the subscriber unit to a power source and the network. For more information, refer to Section2.7,
“Connecting Power and Data”.
7. Seal all cable connections. For more information, refer to Section2.8, “Weatherproofing the Subscriber Unit”.
8. Configure the subscriber unit. For more information, refer to Section3.1, “Configuring the Subscriber Unit”.
Section2.2
Unpacking the Subscriber Unit
The following items are included in the RUGGEDCOM WIN5158-V-GPS package:
Item Quantity
RUGGEDCOM WIN5158-V-GPS Subscriber Unit 1
Radio Frequency (RF) antenna cables, 5 m (16.4 ft) long 2
Pole/wall/tower mounting kit 1
When unpacking the subscriber unit, do the following:
1. Inspect the package for damage before opening it.
2. Visually inspect each item in the package for any physical damage.
3. Verify all items are included.
If any item is missing or damaged, contact Siemens for assistance.
Section2.3
Site Preparation and Precautions
Before installing the subscriber unit and or antenna(s), it is important to plan the the complete installation and
make sure the appropriate safe guards are in place.
Site Selection
Consider the following recommendations when selecting an appropriate site for the subscriber unit and
antenna(s):
• Mount the antenna(s) at the highest point possible. Reception will increase according to the height of the
antenna(s).
• Mount the antenna(s) in a place with as few obstructions as possible between the antenna(s) and the planned
service area.
• To avoid interference, mount the antenna(s) and subscriber unit as far as possible from other antenna(s) and
subscriber units.
• Keep the cable from the subscriber unit to the antenna(s) as short as possible and mount the antenna(s) as
close as possible to the subscriber unit. Using a cable longer than 2 m (6.6 ft) will result in greater loss and more
interference, as the cable will act as an antenna itself.
• Do not point the antenna(s) directly at populated areas.
• Locate the antenna(s) at least 3.6 m (11.8 ft) from people and public areas.
Chapter 2
Installing the Subscriber Unit
RUGGEDCOM WIN5158-V-GPS
Installation Guide
8 Mounting the Subscriber Unit
• Make sure the antenna(s) and subscriber unit are easily accessible for maintenance purposes.
• Mount the GPS antenna in a position where the whole sky is visible to the antenna. If the subscriber unit is
mounted on a wall and the GPS antenna is mounted on top of the subscriber unit, only half of the sky will be
visible to the antenna. This may not be enough for proper operation.
• Conduct a site survey to best position the subscriber unit and antenna(s) in relation to other subscriber units,
antennas and base stations in the area. The site survey should also take into consideration the overall safety of
the selected site
Site Survey
Most wireless networks include many subscriber/base stations installedin various locations in an overlapping
radio-cell pattern. It is important to position each subscriber unit in an optimal location considering the
assignment of its radio channels. Therefore, a site survey becomes an essential first step before physically
deploying the subscriber unit.
The site survey should include details important to the planning of the subscriber unit deployment in each specific
site, including potential mounting points for the subscriber unit and antennas, as well as the routing options for
data, power and antenna cables.
For safety, always consult with the local power utility as well. It is important to select a site that not only offers
maximum coverage, but is also safe for installers to work in.
Safety Precautions
When installing the subscriber unit or an antenna, make sure to adhere to the following safety precautions:
• Always install the subscriber unit with the help of a partner.
• Always use the most appropriate mounting method for the site and the equipment being installed. For
assistance, contact a Siemens representative.
• Always assume an overhead line can cause serious injury or death. Note that electric power lines and phone
lines look alike.
• Always wear the appropriate Personal Protective Equipment (PPE) for the task, including but not limited to
rubber boots, rubber gloves, hard hat, harness and lanyard, etc.
• Always use a ladder made of a non-conductive material, such as wood or fiberglass. Do not use a metal ladder.
• Always work under favorable conditions. Do not work on wet or windy days.
• If the subscriber unit or antenna begins to drop, step away immediately and allow it to fall. The subscriber unit,
cables, metal guy wires and pole (in the case of pole mount installations) are all excellent conductors. Any
contact between these components and an electrical power line will complete an electrical path through the
subscriber unit/antenna and the installer.
• If any part of the subscriber unit or an antenna comes in contact with an electrical power line, contact the local
power utility. Do not attempt to touch or remove the component.
Section2.4
Mounting the Subscriber Unit
The RUGGEDCOM WIN5158-V-GPS is designed for maximum mounting and display flexibility. It can be secured to
a bracket and then mounted to a pole, wall or tower.
RUGGEDCOM WIN5158-V-GPS
Installation Guide
Chapter 2
Installing the Subscriber Unit
Mounting the Subscriber Unit to a Wall or Tower 9
NOTE
For detailed dimensions of the subscriber unit, refer to Section4.6, “Dimension Drawings”.
When choosing the mounting location for the unit, consider the available mounting structures and antenna
clearance.
Site Survey
Most wireless networks include many subscriber/base stations installedin various locations in an overlapping
radio-cell pattern. It is important to position each subscriber unit in an optimal location considering the
assignment of its radio channels. Therefore, a site survey becomes an essential first step before physically
deploying the subscriber unit.
The site survey should include details important to the planning of the subscriber unit deployment in each specific
site, including potential mounting points for the subscriber unit and antennas, as well as the routing options for
data, power and antenna cables.
Recommended Site Requirements
It is highly recommended the subscriber unit be mounted with as few obstructions as possible between itself and
the base station. The subscriber unit should be pointed in the direction of the designated server base station.
When choosing the ideal location, it is also important to take into consideration the overall area topology.
CONTENTS
•Section2.4.1, “Mounting the Subscriber Unit to a Wall or Tower”
•Section2.4.2, “Mounting the Subscriber Unit to a Pole”
Section2.4.1
Mounting the Subscriber Unit to a Wall or Tower
Mount the subscriber unit to any wall or tower capable of supporting its weight. An outer wall on a roof or other
high location to avoid interference from other buildings or trees is preferred.
To mount the subscriber unit to a wall or tower, do the following:
1. Attach the subscriber unit to the mounting bracket.
Chapter 2
Installing the Subscriber Unit
RUGGEDCOM WIN5158-V-GPS
Installation Guide
10 Mounting the Subscriber Unit to a Wall or Tower
2
1
3
5
46
8
10 2
96
5
7
Figure2:Mounting the Subscriber Unit to a Wall or Tower
1.Subscriber Unit 2.Mounting Kit 3.Wall Holder/Pole Mount 4.M8 × 25 mm Hex Screw 5.M8 Spring Washer 6.M8 Flat
Washer 7.M8 Nut 8.M5 Flat Washer 9.NS 1/4" × 1/2" HEX Chipboard Screw 10.Wall Anchor
2. Liberally apply an anti-corrosion spray to all galvanized steel components, including mounting brackets,
washers and screws.
3. Select a mounting location on the wall.
4. Place the mounting bracket on the wall and mark four mounting holes.
5. Drill four holes and insert a wall anchor into each hole.
6. Secure the mounting bracket to the wall with four 1/4" × 1/2" HEX screws, four spring washers, and four flat
washers.
7. Connect the arm bracket to the mounting bracket using a screw, spring washer, flat washer and nut. Make
sure the nut is hand tight
8. Connect the subscriber unit to the arm bracket using a screw, spring washer, flat washer and nut. Make sure
the nut is hand tight.
9. Make sure the subscriber unit is properly grounded according to local standards. For more information, refer
to Section2.6, “Grounding the Subscriber Unit”.
10. Tighten the screws connecting the arm bracket to the subscriber unit and mounting bracket. Make sure the
screws are torqued to 24 N·m (17.7 ft. lb.).
RUGGEDCOM WIN5158-V-GPS
Installation Guide
Chapter 2
Installing the Subscriber Unit
Mounting the Subscriber Unit to a Pole 11
Section2.4.2
Mounting the Subscriber Unit to a Pole
The subscriber unit can be attached to any pipe or pole with a diameter of 44.5 to 254 mm (1.75 to 10 in).
To mount the subscriber unit to a pole, do the following:
1. Attach the subscriber unit to the mounting bracket.
4
9
2
3
6
6
8
3
5 6 7
1
7
Figure3:Mounting the Subscriber Unit to a Large Pole
1.Subscriber Unit 2.Pole 3.Clamping Bracket 4.Mounting Bracket 5.M8-25 Hex Screw 6.M8 Spring Washer 7.M8 Flat
Washer 8.M8 Nut 9.M8-70 Hex Screw
Chapter 2
Installing the Subscriber Unit
RUGGEDCOM WIN5158-V-GPS
Installation Guide
12 Installing the Antennas
2
3
9
6
7
6
8
7
6
5
3
4
1
Figure4:Mounting the Subscriber Unit to a Small Pole
1.Subscriber Unit 2.Pole 3.Clamping Bracket 4.Mounting Bracket 5.M8-25 Hex Screw 6.M8 Spring Washer 7.M8 Flat
Washer 8.M8 Nut 9.M8-70 Hex Screw
2. Liberally apply an anti-corrosion spray to all galvanized steel components, including mounting brackets, nuts,
washers and screws.
3. Select a mounting location on the pole.
4. Position the mounting bracket against the pole.
NOTE
When mounting the subscriber unit, note the orientation of the clamping bracket in Figure 3 or
Figure 4.
5. Secure the clamping bracket to the mounting bracket using screws, spring washers and nuts. Make sure the
screws are hand tightened.
6. Make sure the subscriber unit is properly grounded according to local standards. For more information, refer
to Section2.6, “Grounding the Subscriber Unit”.
7. Tighten the screws connecting the clamping bracket to the mounting bracket. Make sure the screws are
torqued to 14 N·m (10 lbf-ft).
Section2.5
Installing the Antennas
The RUGGEDCOM WIN5158-V-GPS supports N-Connect female antennas.
To install an antenna, do the following:
RUGGEDCOM WIN5158-V-GPS
Installation Guide
Chapter 2
Installing the Subscriber Unit
Installing the Antennas 13
WARNING!
Radiation hazard – risk of Radio Frequency (RF) exposure. This subscriber unit is compliant with the
requirements set forth in FCC CFR 47, section 1.1307, addressing Radio Frequency (RF) exposure from
radio frequency base stations, as defined in FCC OET Bulletin 65 [http://transition.fcc.gov/Bureaus/
Engineering_Technology/Documents/bulletins/oet65/oet65.pdf]. The emitted radiation should be as
little as possible. To achieve minimum RF exposure, install the subscriber unit when it is configured
not to transmit and set it to operational mode remotely, rather than having a technician enable
transmission on-site. For maintenance of the subscriber unit or other operations which require RF
exposure, the exposure should be minimized in time and according to the regulations set forth by the
country of installation or the Federal Communications Commission (FCC).
WARNING!
The subscriber unit must be placed at a distance of at least 20 cm (8 in) from all persons during normal
operation. The antennas used for this product must not be located or operating in conjunction with any
other antenna or transmitter, except in accordance with FCC multi-transmitter evaluation procedures.
IMPORTANT!
During antenna installation, observe the following:
• Always install the antenna at least 40 cm (16 in) from people and public areas.
• Antenna must be in a fixed position.
• Make sure the front of the antenna is always facing the base station. In some conditions, such as
when the line of sight to the subscriber unit is impeded, better reception may be achieved using a
reflected signal. In this case, direct the antenna towards the reflecting object, rather than towards
the base station.
• In some cases, the antenna may need to be tilted to make sure the level at which the subscriber unit
receives transmissions from the base station (and vice versa) is not too high. When only the last RSSI
LED is on, this indicates saturation and the received signal level is too high. This must be avoided,
preferably by tilting the antenna upwards. As a general rule, if the subscriber unit is located at a
distance of less than 300 m (984 ft) from the base station, it is recommended to tilt the antenna
upwards by approximately 10 to 15°.
• After the antenna is installed, do not change the antenna position.
1. Mount the antenna to a pole or wall in an area that provides good signal coverage and is away from any
signal noise emanating from other communications equipment.
2. Position the antenna towards the general direction of the designated base station.
WARNING!
Fire hazard – risk of serious personal injury and/or damage to equipment. To reduce the risk of fire,
use only 26 AWG or larger telecommunication line cord between indoor and outdoor devices.
3. Using shielded coaxial cables, connect the antenna to the lightning protector. Make sure the cables are
routed away from any noise sources, such as Switch-Mode Power Supplies (SMPS).
Chapter 2
Installing the Subscriber Unit
RUGGEDCOM WIN5158-V-GPS
Installation Guide
14 Grounding the Subscriber Unit
1
1
4
3
3
5
2
6
Figure5:Antenna and Lightning Protector Assembly
1.Drain Wire 2.RUGGEDCOM WIN5158-V-GPS 3.Shielded Coaxial Cable 4.Lightning Protector 5.Ground Wire 6.Antenna
4. Make sure the PWR LED on the subscriber unit is on.
5. Adjust the position of the antenna until the maximum RSSI link quality reading is achieved. A single RSSI LED
indicates the subscriber unit is at minimum synchronized with the base station. For information about the
RSSI LED indicators, refer to Section1.2, “Description”.
If the subscriber unit is not synchronized with the base station, make sure the subscriber unit is properly
configured. For more information, refer to the RUGGEDCOM WIN User Guide for the subscriber unit.
If the expected link quality still cannot be achieved, try to improve the reception quality by placing the
antenna at a higher point or in an alternate location.
6. Make sure the antenna is properly grounded according to local standards.
Section2.6
Grounding the Subscriber Unit
When connecting the ground cable to the subscriber unit, make sure to use a 10 AWG grounding cable and torque
the screw to 15 N·m (11 ft. lb.).
DANGER!
Electrocution hazard – risk of death or serious injury. The system must be properly grounded to protect
against power surges and accumulated static electricity. It is the installer’s responsibility to install this
base station in accordance with the local electrical codes.
Section2.7
Connecting Power and Data
The RUGGEDCOM WIN5158-V-GPS requires a 9 to 36 VDC Class 2 power supply.
IMPORTANT!
When connecting a DC battery power supply, make sure to use a 36 VDC, 3 A, double-pole circuit
breaker as the main disconnecting device.
Table of contents
Other Siemens GPS manuals
