Siemens SIMATIC RF610T User guide

S
SIMATIC RF600
SIMATIC Ident
RFID systems
S
SIMATIC RF600
System Manual
06/2019
J
31069-D0171-U001-A22-7618
Introduction
1
Safety Information
2
System overview of
S
SIMATIC RF600
3
RF600 system planning
4
Readers
5
Antennas
6
Transponder
7
Integration into networks
8
System diagnostics
9
Accessories
10
Appendix
A

Siemens AG
D
igital Industries
P
ostfach 48 48
9
0026 NÜRNBERG
G
ERMANY
࿕05/2019 Subject to change
Copyright © Siemens AG 2005 - 2019.
A
ll rights reserved
L
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury wwill result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury mmay result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by p
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SIMATIC RF600
System Manual, 06/2019, J31069-D0171-U001-A22-7618 3
TTable of contents
1
1Introduction........................................................................................................................................... 13
1.1 Preface....................................................................................................................................13
1.2 Abbreviations and naming conventions..................................................................................14
2 Safety Information................................................................................................................................. 15
2.1 General safety instructions .....................................................................................................15
2.2 Safety instructions for third-party antennas as well as for modifications to the RF600
system.....................................................................................................................................19
2.3 Safety distance to transmitter antenna...................................................................................20
2.3.1 Safety distance between transmitter antenna and personnel ................................................20
2.3.2 Minimum distance to antenna in accordance with ETSI.........................................................21
2.3.3 Minimum distance to antenna in accordance with FCC .........................................................22
3 System overview of SIMATIC RF600 .................................................................................................... 25
3.1 Application areas of RF600 ....................................................................................................26
3.2 System components ...............................................................................................................27
3.3 Features..................................................................................................................................30
4 RF600 system planning......................................................................................................................... 33
4.1 Overview.................................................................................................................................33
4.2 Possible system configurations ..............................................................................................33
4.2.1 Intralogistics scenario .............................................................................................................33
4.2.2 Scenario for workpiece identification......................................................................................36
4.2.3 Goods tracking scenario.........................................................................................................37
4.2.4 Scenario incoming goods, distribution of goods and outgoing goods ....................................38
4.3 Antenna configurations...........................................................................................................39
4.3.1 Antenna configuration example ..............................................................................................40
4.3.2 Possibilities and application areas for antenna configurations...............................................41
4.3.3 Transponder orientation in space ...........................................................................................45
4.3.4 Specified minimum and maximum spacing of antennas ........................................................46
4.3.5 Reciprocal influence of read points.........................................................................................47
4.3.6 Read and write range..............................................................................................................48
4.3.7 Static/dynamic mode...............................................................................................................49
4.3.8 Operation of several readers within restricted space .............................................................50
4.3.8.1 Using more than one reader...................................................................................................50
4.3.8.2 Optimization of robustness of tag data accesses for readers that are operated
simultaneously ........................................................................................................................50
4.3.8.3 Frequency hopping.................................................................................................................51
4.3.9 Guidelines for selecting RFID UHF antennas.........................................................................51
4.3.9.1 Note safety information...........................................................................................................51
4.3.9.2 Preconditions for selecting RFID UHF antennas....................................................................51
4.3.9.3 General application planning..................................................................................................52

Table of contents
SIMATIC RF600
4System Manual, 06/2019, J31069-D0171-U001-A22-7618
4.3.9.4 Types of antenna ................................................................................................................... 53
4.3.9.5 Antenna cables ...................................................................................................................... 53
4.4 Minimum distances and maximum ranges ............................................................................ 55
4.4.1 Configurations of antenna and transponder .......................................................................... 55
4.4.2 Effects of the materials of the mounting surfaces on the range ............................................ 58
4.4.3 Maximum read/write ranges of transponders ........................................................................ 59
4.4.4 Minimum distances between antennas and transponders .................................................... 65
4.4.5 Influence of electrically conductive walls on the range.......................................................... 65
4.5 Environmental conditions for transponders ........................................................................... 66
4.6 The response of electromagnetic waves in the UHF band.................................................... 66
4.6.1 The effect of reflections and interference .............................................................................. 66
4.6.2 Influence of metals................................................................................................................. 67
4.6.3 Influence of liquids and non-metallic substances .................................................................. 68
4.6.4 Influence of external components.......................................................................................... 68
4.7 Planning and installation of UHF read points......................................................................... 69
4.7.1 Technical basics..................................................................................................................... 69
4.7.2 Implementation of UHF RFID installations............................................................................. 72
4.7.2.1 Preparation phase.................................................................................................................. 72
4.7.2.2 Test phase ............................................................................................................................. 73
4.7.2.3 Setting up read points............................................................................................................ 74
4.7.3 Dealing with field disturbances .............................................................................................. 77
4.7.3.1 Types and approaches to solutions....................................................................................... 77
4.7.3.2 Measures for eliminating field disturbances........................................................................... 78
4.8 Chemical resistance of the readers and transponders.......................................................... 80
4.8.1 Readers.................................................................................................................................. 80
4.8.1.1 Overview of the readers and their housing materials ............................................................ 80
4.8.1.2 Pocan CF2200....................................................................................................................... 81
4.8.2 Transponder........................................................................................................................... 83
4.8.2.1 Overview of the transponders and their housing materials ................................................... 83
4.8.2.2 Acrylonitrile/butadiene/styrene (ABS)....................................................................................83
4.8.2.3 Polyamide 12 (PA12)............................................................................................................. 84
4.8.2.4 Polyamide 6.6 (PA 6.6).......................................................................................................... 86
4.8.2.5 Polyamide 6.6 GF (PA 6.6 GF).............................................................................................. 87
4.8.2.6 Polyethylene terephthalate (PET).......................................................................................... 89
4.8.2.7 Polypropylene (PP)................................................................................................................ 91
4.8.2.8 Polyphenylene sulfide (PPS) ................................................................................................. 95
4.8.2.9 Polyvinyl chloride (PVC) ........................................................................................................ 96
4.9 Regulations applicable to frequency bands........................................................................... 97
4.10 Guidelines for electromagnetic compatibility (EMC).............................................................. 97
4.10.1 Overview ................................................................................................................................ 97
4.10.2 What does EMC mean?......................................................................................................... 98
4.10.3 Basic rules.............................................................................................................................. 99
4.10.4 Propagation of electromagnetic interference....................................................................... 100
4.10.5 Equipotential bonding .......................................................................................................... 102
4.10.6 Cable shielding..................................................................................................................... 103

Table of contents
SIMATIC RF600
System Manual, 06/2019, J31069-D0171-U001-A22-7618 5
5
5Readers.............................................................................................................................................. 105
5.1 Overview...............................................................................................................................105
5.2 SIMATIC RF610R.................................................................................................................107
5.2.1 Description............................................................................................................................107
5.2.1.1 Overview...............................................................................................................................107
5.2.1.2 Ordering data........................................................................................................................108
5.2.1.3 Pin assignment of the power supply interface (X80 24VDC)................................................109
5.2.1.4 Pin assignment of the Industrial Ethernet interface (X1 P1).................................................110
5.2.1.5 Ground connection................................................................................................................110
5.2.2 Planning operation................................................................................................................110
5.2.2.1 Internal antenna....................................................................................................................110
5.2.2.2 Interpretation of radiation patterns........................................................................................115
5.2.3 Installation / mounting...........................................................................................................115
5.2.4 Configuration/integration.......................................................................................................116
5.2.5 Technical specifications........................................................................................................117
5.2.6 Dimension drawing ...............................................................................................................120
5.2.7 Certificates and approvals ....................................................................................................121
5.2.7.1 CE mark................................................................................................................................121
5.2.7.2 Country-specific certifications...............................................................................................121
5.2.7.3 FCC information....................................................................................................................122
5.2.7.4 IC-FCB information...............................................................................................................123
5.2.7.5 Other certificates and approvals...........................................................................................123
5.3 SIMATIC RF615R.................................................................................................................124
5.3.1 Description............................................................................................................................124
5.3.1.1 Overview...............................................................................................................................124
5.3.1.2 Ordering data........................................................................................................................125
5.3.1.3 Pin assignment of the DI/DQ interface (X10 DI/DQ) ............................................................126
5.3.1.4 Switching scheme for the DI/DQ interface............................................................................126
5.3.1.5 Pin assignment of the power supply interface (X80 24VDC)................................................128
5.3.1.6 Pin assignment of the Industrial Ethernet interface (X1 P1).................................................129
5.3.1.7 Ground connection................................................................................................................129
5.3.2 Planning operation................................................................................................................130
5.3.2.1 Internal antenna....................................................................................................................130
5.3.2.2 External antenna...................................................................................................................135
5.3.3 Installing/mounting................................................................................................................136
5.3.4 Configuration/integration.......................................................................................................137
5.3.5 Technical specifications........................................................................................................138
5.3.6 Dimension drawing ...............................................................................................................141
5.3.7 Certificates and approvals ....................................................................................................142
5.3.7.1 CE mark................................................................................................................................142
5.3.7.2 Country-specific certifications...............................................................................................142
5.3.7.3 FCC information....................................................................................................................143
5.3.7.4 IC-FCB information...............................................................................................................144
5.3.7.5 Other certificates and approvals...........................................................................................144
5.4 SIMATIC RF650R.................................................................................................................145
5.4.1 Description............................................................................................................................145
5.4.1.1 Overview...............................................................................................................................145
5.4.1.2 Ordering data........................................................................................................................146
5.4.1.3 Pin assignment of the DI/DQ interface (X10 DI/DQ) ............................................................147
5.4.1.4 Switching scheme for the DI/DQ interface............................................................................148

Table of contents
SIMATIC RF600
6System Manual, 06/2019, J31069-D0171-U001-A22-7618
5.4.1.5 Pin assignment of the power supply interface (X80 24VDC)............................................... 153
5.4.1.6 Pin assignment of the Industrial Ethernet interface (X1 P1)................................................ 155
5.4.1.7 Grounding connection.......................................................................................................... 155
5.4.2 Planning operation............................................................................................................... 156
5.4.2.1 Antenna/read point configurations....................................................................................... 156
5.4.3 Installation/mounting............................................................................................................ 157
5.4.4 Configuration/integration...................................................................................................... 161
5.4.5 Technical specifications....................................................................................................... 162
5.4.6 Dimension drawing .............................................................................................................. 165
5.4.7 Certificates and approvals ................................................................................................... 166
5.4.7.1 FCC information................................................................................................................... 168
5.4.7.2 IC-FCB information .............................................................................................................. 169
5.5 SIMATIC RF680R................................................................................................................ 170
5.5.1 Description........................................................................................................................... 170
5.5.1.1 Overview.............................................................................................................................. 170
5.5.1.2 Ordering data....................................................................................................................... 171
5.5.1.3 Pin assignment of the DI/DQ interface (X10 DI/DQ)............................................................ 172
5.5.1.4 Switching scheme for the DI/DQ interface........................................................................... 173
5.5.1.5 Pin assignment of the power supply interface (X80 24VDC)............................................... 178
5.5.1.6 Pin assignment of the Industrial Ethernet interface (X1 P1; X1 P2).................................... 180
5.5.1.7 Grounding connection.......................................................................................................... 180
5.5.2 Planning operation............................................................................................................... 181
5.5.2.1 Antenna/read point configurations....................................................................................... 181
5.5.3 Installation/mounting............................................................................................................ 182
5.5.3.1 Mounting/Installation............................................................................................................ 183
5.5.4 Configuration/integration...................................................................................................... 186
5.5.5 Technical specifications....................................................................................................... 187
5.5.6 Dimension drawing .............................................................................................................. 190
5.5.7 Certificates and approvals ................................................................................................... 191
5.5.7.1 FCC information................................................................................................................... 193
5.5.7.2 IC-FCB information .............................................................................................................. 194
5.6 SIMATIC RF685R................................................................................................................ 195
5.6.1 Description........................................................................................................................... 195
5.6.1.1 Overview.............................................................................................................................. 195
5.6.1.2 Ordering data....................................................................................................................... 196
5.6.1.3 Pin assignment of the DI/DQ interface (X10 DI/DQ)............................................................ 197
5.6.1.4 Switching scheme for the DI/DQ interface........................................................................... 198
5.6.1.5 Pin assignment of the power supply interface (X80 24VDC)............................................... 203
5.6.1.6 Pin assignment of the Industrial Ethernet interface (X1 P1; X1 P2).................................... 205
5.6.1.7 Grounding connection.......................................................................................................... 205
5.6.2 Planning operation............................................................................................................... 206
5.6.2.1 Internal antenna................................................................................................................... 206
5.6.2.2 External antenna.................................................................................................................. 215
5.6.3 Installation/mounting............................................................................................................ 216
5.6.4 Configuration/integration...................................................................................................... 220
5.6.5 Technical specifications....................................................................................................... 221
5.6.6 Dimension drawing .............................................................................................................. 224
5.6.7 Certificates and approvals ................................................................................................... 225
5.6.7.1 FCC information................................................................................................................... 227
5.6.7.2 IC-FCB information .............................................................................................................. 228

Table of contents
SIMATIC RF600
System Manual, 06/2019, J31069-D0171-U001-A22-7618 7
5.7 SIMATIC RF650M.................................................................................................................229
5.7.1 Description............................................................................................................................229
5.7.2 Field of application and features...........................................................................................229
6
6Antennas ............................................................................................................................................ 231
6.1 Overview...............................................................................................................................231
6.2 SIMATIC RF615A.................................................................................................................233
6.2.1 Characteristics ......................................................................................................................233
6.2.2 Ordering data........................................................................................................................234
6.2.3 Mounting ...............................................................................................................................234
6.2.4 Connecting the antenna........................................................................................................235
6.2.5 Antenna parameter assignment............................................................................................236
6.2.6 Antenna patterns...................................................................................................................238
6.2.6.1 Alignment of transponders to the antenna............................................................................238
6.2.6.2 Antenna pattern ETSI ...........................................................................................................241
6.2.6.3 Antenna pattern FCC............................................................................................................244
6.2.6.4 Interpretation of directional radiation patterns ......................................................................247
6.2.7 Technical data.......................................................................................................................248
6.2.8 Dimension drawing ...............................................................................................................250
6.2.9 Certificates & approvals........................................................................................................251
6.3 SIMATIC RF620A.................................................................................................................252
6.3.1 Characteristics ......................................................................................................................252
6.3.2 Ordering data........................................................................................................................253
6.3.3 Installation.............................................................................................................................253
6.3.4 Connecting the antenna........................................................................................................254
6.3.4.1 Bending radii and bending cycles of the cable.....................................................................254
6.3.5 Antenna parameter assignment............................................................................................255
6.3.6 Antenna patterns...................................................................................................................257
6.3.6.1 Alignment of transponders to the antenna............................................................................257
6.3.6.2 Antenna pattern ETSI ...........................................................................................................260
6.3.6.3 Antenna pattern FCC............................................................................................................263
6.3.6.4 Interpretation of directional radiation patterns ......................................................................266
6.3.7 Technical data.......................................................................................................................267
6.3.8 Dimension drawing ...............................................................................................................269
6.3.9 Approvals & certificates ........................................................................................................270
6.4 SIMATIC RF640A.................................................................................................................271
6.4.1 Characteristics ......................................................................................................................271
6.4.2 Ordering data........................................................................................................................272
6.4.3 Installation.............................................................................................................................272
6.4.4 Connecting the antenna........................................................................................................273
6.4.4.1 Bending radii and bending cycles of the cable.....................................................................274
6.4.5 Antenna parameter assignment............................................................................................274
6.4.5.1 Setting RF640A parameters for RF650R..............................................................................274
6.4.5.2 Setting RF640A parameters for RF680R/RF685R...............................................................276
6.4.6 Antenna patterns...................................................................................................................278
6.4.6.1 Antenna radiation patterns in the ETSI frequency band.......................................................278
6.4.6.2 Antenna radiation patterns in the FCC frequency band .......................................................283
6.4.6.3 Interpretation of directional radiation patterns ......................................................................288
6.4.7 Technical data.......................................................................................................................289
6.4.8 Dimension drawing ...............................................................................................................291
6.4.9 Approvals & certificates ........................................................................................................292

Table of contents
SIMATIC RF600
8System Manual, 06/2019, J31069-D0171-U001-A22-7618
6.5 SIMATIC RF642A ................................................................................................................ 293
6.5.1 Characteristics ..................................................................................................................... 293
6.5.2 Ordering data....................................................................................................................... 294
6.5.3 Installation............................................................................................................................ 294
6.5.4 Connecting the antenna....................................................................................................... 295
6.5.4.1 Bending radii and bending cycles of the cable .................................................................... 296
6.5.5 Antenna parameter assignment........................................................................................... 297
6.5.5.1 Alignment of transponders to the antenna........................................................................... 297
6.5.5.2 RF642A parameter assignment........................................................................................... 300
6.5.6 Antenna patterns.................................................................................................................. 302
6.5.6.1 Antenna radiation patterns in the ETSI frequency band...................................................... 302
6.5.6.2 Antenna radiation patterns in the FCC frequency band....................................................... 304
6.5.6.3 Interpretation of directional radiation patterns ..................................................................... 306
6.5.7 Technical data...................................................................................................................... 307
6.5.8 Dimension drawing .............................................................................................................. 309
6.5.9 Approvals & certificates ....................................................................................................... 310
6.6 SIMATIC RF650A ................................................................................................................ 311
6.6.1 Characteristics ..................................................................................................................... 311
6.6.2 Ordering data....................................................................................................................... 312
6.6.3 Installation............................................................................................................................ 312
6.6.4 Connecting the antenna....................................................................................................... 313
6.6.4.1 Bending radii and bending cycles of the cable .................................................................... 314
6.6.5 Antenna parameter assignment........................................................................................... 314
6.6.6 Antenna patterns.................................................................................................................. 316
6.6.6.1 Antenna patterns in the ETSI frequency band..................................................................... 317
6.6.6.2 Antenna patterns in the FCC frequency band ..................................................................... 319
6.6.6.3 Interpretation of directional radiation patterns ..................................................................... 321
6.6.7 Technical data...................................................................................................................... 322
6.6.8 Dimension drawing .............................................................................................................. 324
6.6.9 Approvals & certificates ....................................................................................................... 325
6.7 SIMATIC RF660A ................................................................................................................ 326
6.7.1 Characteristics ..................................................................................................................... 326
6.7.2 Ordering data....................................................................................................................... 327
6.7.3 Installation............................................................................................................................ 327
6.7.4 Connecting the antenna....................................................................................................... 328
6.7.4.1 Bending radii and bending cycles of the cable .................................................................... 328
6.7.5 Antenna parameter assignment........................................................................................... 329
6.7.6 Antenna patterns.................................................................................................................. 331
6.7.7 Technical data...................................................................................................................... 334
6.7.8 Dimension drawing .............................................................................................................. 336
6.7.9 Approvals & certificates ....................................................................................................... 337
6.8 SIMATIC RF680A ................................................................................................................ 338
6.8.1 Characteristics ..................................................................................................................... 338
6.8.2 Ordering data....................................................................................................................... 340
6.8.3 Installation............................................................................................................................ 340
6.8.4 Connecting the antenna....................................................................................................... 341
6.8.4.1 Bending radii and bending cycles of the cable .................................................................... 342
6.8.5 Antenna parameter assignment........................................................................................... 343
6.8.6 Antenna patterns.................................................................................................................. 345
6.8.6.1 Antenna patterns in the ETSI frequency band..................................................................... 346
6.8.6.2 Antenna patterns in the FCC frequency band ..................................................................... 350

Table of contents
SIMATIC RF600
System Manual, 06/2019, J31069-D0171-U001-A22-7618 9
6.8.6.3 Interpretation of directional radiation patterns ......................................................................354
6.8.7 Technical data.......................................................................................................................355
6.8.8 Dimension drawing ...............................................................................................................357
6.8.9 Approvals & certificates ........................................................................................................358
7
7Transponder ....................................................................................................................................... 359
7.1 Overview...............................................................................................................................359
7.1.1 Mode of operation of transponders.......................................................................................359
7.1.2 Transponder classes and generations..................................................................................360
7.1.3 Electronic Product Code (EPC)............................................................................................360
7.1.4 SIMATIC memory configuration of the RF600 transponders and labels..............................362
7.1.5 Storage and transportation roll goods...................................................................................363
7.2 SIMATIC RF630L Smartlabel ...............................................................................................364
7.2.1 Features................................................................................................................................364
7.2.2 Ordering data........................................................................................................................365
7.2.3 Technical data.......................................................................................................................366
7.2.4 Dimension drawings..............................................................................................................374
7.2.5 Certificates and approvals ....................................................................................................377
7.3 SIMATIC RF642L Smartlabel ...............................................................................................378
7.3.1 Features................................................................................................................................378
7.3.2 Ordering data........................................................................................................................378
7.3.3 Technical specifications........................................................................................................379
7.3.4 Dimension drawing ...............................................................................................................381
7.4 SIMATIC RF690L Smartlabel ...............................................................................................382
7.4.1 Characteristics ......................................................................................................................382
7.4.2 Ordering data........................................................................................................................382
7.4.3 Memory organization ............................................................................................................383
7.4.4 Technical specifications........................................................................................................383
7.4.5 Dimension drawing ...............................................................................................................385
7.4.6 Certificates and approvals ....................................................................................................386
7.5 SIMATIC RF610T .................................................................................................................387
7.5.1 Features................................................................................................................................387
7.5.2 Ordering data........................................................................................................................387
7.5.3 Technical specifications........................................................................................................388
7.5.4 Dimension drawing ...............................................................................................................390
7.5.5 Certificates and approvals ....................................................................................................390
7.6 SIMATIC RF610T ATEX.......................................................................................................391
7.6.1 Features................................................................................................................................391
7.6.2 Ordering data........................................................................................................................392
7.6.3 Use of the transponder in hazardous areas..........................................................................392
7.6.3.1 Use of the transponder in hazardous areas for gases..........................................................394
7.6.3.2 Use of the transponder in hazardous areas for dusts...........................................................395
7.6.4 Technical specifications........................................................................................................396
7.6.5 Dimension drawing ...............................................................................................................398
7.6.6 Certificates and approvals ....................................................................................................398
7.7 SIMATIC RF620T .................................................................................................................399
7.7.1 Characteristics ......................................................................................................................399
7.7.2 Ordering data........................................................................................................................400
7.7.3 Planning the use...................................................................................................................400

Table of contents
SIMATIC RF600
10 System Manual, 06/2019, J31069-D0171-U001-A22-7618
7.7.3.1 Range when mounted on flat metallic carrier plates............................................................ 400
7.7.3.2 Range when mounted on non-metallic carrier materials ..................................................... 401
7.7.4 Technical specifications....................................................................................................... 402
7.7.5 Dimension drawing .............................................................................................................. 404
7.7.6 Certificates and approvals ................................................................................................... 405
7.8 SIMATIC RF625T................................................................................................................. 406
7.8.1 Characteristics ..................................................................................................................... 406
7.8.2 Ordering data....................................................................................................................... 407
7.8.3 Planning the use .................................................................................................................. 407
7.8.3.1 Optimum antenna/transponder positioning with planar mounting of the transponder on
metal .................................................................................................................................... 407
7.8.3.2 Range when mounted on flat metallic carrier plates............................................................ 408
7.8.3.3 Range when mounted on non-metallic carrier materials ..................................................... 409
7.8.3.4 Mounting in metal................................................................................................................. 409
7.8.4 Technical specifications....................................................................................................... 410
7.8.5 Dimension drawing .............................................................................................................. 412
7.8.6 Certificates and approvals ................................................................................................... 412
7.9 SIMATIC RF630T................................................................................................................. 413
7.9.1 Characteristics ..................................................................................................................... 413
7.9.2 Ordering data....................................................................................................................... 414
7.9.3 Planning application............................................................................................................. 414
7.9.3.1 Optimum antenna/transponder positioning.......................................................................... 414
7.9.3.2 Range when mounted on flat metallic carrier plates............................................................ 416
7.9.4 Technical specifications....................................................................................................... 417
7.9.5 Dimension drawing .............................................................................................................. 419
7.9.6 Certificates and approvals ................................................................................................... 420
7.10 SIMATIC RF640T................................................................................................................. 421
7.10.1 Characteristics ..................................................................................................................... 421
7.10.2 Ordering data....................................................................................................................... 422
7.10.3 Planning the use .................................................................................................................. 422
7.10.3.1 Optimum antenna/transponder positioning with plane mounting of the transponder on
metal .................................................................................................................................... 422
7.10.3.2 Range when mounted on flat metallic carrier plates............................................................ 423
7.10.3.3 Range when mounted on non-metallic carrier materials ..................................................... 424
7.10.3.4 Use of the transponder in hazardous areas......................................................................... 424
7.10.3.5 Use of the transponder in hazardous areas for gases......................................................... 425
7.10.3.6 Use of the transponder in hazardous areas for dusts.......................................................... 427
7.10.4 Technical specifications....................................................................................................... 430
7.10.5 Dimension drawing .............................................................................................................. 433
7.10.6 Certificates and approvals ................................................................................................... 434
7.11 SIMATIC RF645T................................................................................................................. 435
7.11.1 Characteristics ..................................................................................................................... 435
7.11.2 Ordering data....................................................................................................................... 435
7.11.3 Technical specifications....................................................................................................... 436
7.11.4 Dimension drawing .............................................................................................................. 438
7.11.5 Certificates and approvals ................................................................................................... 440
7.12 SIMATIC RF680T................................................................................................................. 441
7.12.1 Characteristics ..................................................................................................................... 441
7.12.2 Ordering data....................................................................................................................... 442

Table of contents
SIMATIC RF600
System Manual, 06/2019, J31069-D0171-U001-A22-7618 11
7.12.3 Planning the use ...................................................................................................................442
7.12.3.1 Optimum antenna/transponder positioning with plane mounting of the transponder on
metal .....................................................................................................................................442
7.12.3.2 Range when mounted on flat metallic carrier plates.............................................................443
7.12.3.3 Range when mounted on non-metallic carrier materials......................................................443
7.12.3.4 Use of the transponder in the hazardous area .....................................................................444
7.12.3.5 Use of the transponder in the hazardous area for gases .....................................................444
7.12.3.6 Use of the transponder in the hazardous area for dusts ......................................................448
7.12.4 Technical specifications........................................................................................................451
7.12.5 Dimension drawing ...............................................................................................................453
7.12.6 Certificates and approvals ....................................................................................................454
7.13 SIMATIC RF682T .................................................................................................................455
7.13.1 Characteristics......................................................................................................................455
7.13.2 Ordering data........................................................................................................................456
7.13.3 Planning operation................................................................................................................456
7.13.3.1 Optimum antenna/transponder positioning with plane mounting of the transponder on
metal .....................................................................................................................................456
7.13.3.2 Note on installation ...............................................................................................................457
7.13.3.3 Range when mounted on flat metallic carrier plates.............................................................457
7.13.4 Technical specifications........................................................................................................458
7.13.5 Dimension drawing ...............................................................................................................460
7.13.6 Certificates and approvals ....................................................................................................461
8
8Integration into networks..................................................................................................................... 463
8.1 Overview of parameterization of RF600 reader....................................................................463
8.2 Integration in IT networks via the user application ...............................................................464
8.3 Integration in control networks..............................................................................................464
9 System diagnostics............................................................................................................................. 467
9.1 Diagnostics via the LED displays of the reader....................................................................467
9.1.1 How the LED status display works .......................................................................................471
9.1.2 Diagnostics via LED operating display .................................................................................472
9.2 XML/PLC error messages ....................................................................................................473
10 Accessories ........................................................................................................................................ 481
10.1 Wide-range power supply unit for SIMATIC RF systems.....................................................481
10.1.1 Features................................................................................................................................481
10.1.2 Scope of supply ....................................................................................................................481
10.1.3 Ordering data........................................................................................................................482
10.1.4 Safety Information.................................................................................................................483
10.1.5 Mounting & connecting .........................................................................................................485
10.1.6 Pin assignment of DC outputs and mains connection..........................................................488
10.1.7 Technical specifications........................................................................................................488
10.1.8 Dimension drawing ...............................................................................................................491
10.1.9 Certificates and approvals ....................................................................................................492
10.2 Power splitter for RF600 systems.........................................................................................494
10.2.1 Characteristics......................................................................................................................494
10.2.2 Ordering data........................................................................................................................494
10.2.3 Example of a configuration ...................................................................................................495
10.2.4 Technical specifications........................................................................................................495

Table of contents
SIMATIC RF600
12 System Manual, 06/2019, J31069-D0171-U001-A22-7618
10.2.5 Dimension drawing .............................................................................................................. 496
10.3 Reader and antenna holders ............................................................................................... 497
10.3.1 Overview.............................................................................................................................. 497
10.3.2 Ordering data....................................................................................................................... 497
10.3.3 Mounting with the SIMATIC antenna holder........................................................................ 497
10.3.4 Dimension drawing .............................................................................................................. 499
A
AAppendix .............................................................................................................................................503
A.1 Certificates & approvals....................................................................................................... 503
A.2 Service & support................................................................................................................. 506

SIMATIC RF600
System Manual, 06/2019, J31069-D0171-U001-A22-7618 13
IIntroduction
11
1
1.1 Preface
Purpose of this document
This system manual contains the information needed to plan and configure the RF600
system.
It is intended both for programming and testing/debugging personnel who commission the
system themselves and connect it with other units (automation systems, further
programming devices), as well as for service and maintenance personnel who install
expansions or carry out fault/error analyses.
Scope of this documentation
This documentation is valid for all supplied versions of the SIMATIC RF600 system and
describes the state of delivery as of 06/2019. If you are using older firmware versions, please
refer to the 08/2011 edition of the documentation.
Registered trademarks
SIMATIC®, SIMATIC RF®, MOBY®, RF MANAGER® and SIMATIC Sensors® are registered
trademarks of Siemens AG.
Recycling and disposal
The products are low in harmful substances, can be recycled and meet the requirements of
the Directive 2012/19/EU for disposal of waste electrical and electronic equipment (WEEE).
Do not dispose of the products at public disposal sites.
For environmentally compliant recycling and disposal of your electronic waste, please
contact a company certified for the disposal of electronic waste or your Siemens
representative.
Note the different country-specific regulations.

Introduction
1.2 Abbreviations and naming conventions
SIMATIC RF600
14 System Manual, 06/2019, J31069-D0171-U001-A22-7618
H
History
Currently released versions of the SIMATIC RF600 system manual:
Edition
Comment
11/2005
First edition
... ...
10/2015
Approval for the readers RF650R, RF680R, and RF685R
12/2015
New antennas RF650A and RF680A
10/2016
Revision of the transponder sections
02/2018 Expansion of the documentation by the following:
xRF615A antenna
xRF645T, RF682T transponders
11/2018 Expansion of the documentation by the following:
xReader SIMATIC RF615R
06/2019 Expansion of the documentation by the following:
xReader SIMATIC RF610R
xTransponder RF630L
Declaration of conformity
The EC declaration of conformity and the corresponding documentation are made available
to authorities in accordance with EC directives. Your sales representative can provide these
on request.
Observance of installation guidelines
The installation guidelines and safety instructions given in this documentation must be
followed during commissioning and operation.
1.2 Abbreviations and naming conventions
Abbreviations and naming conventions
The following terms/abbreviations are used synonymously in this document:
Reader
Write/read device (SLG)
Transponder, tag
Data carrier, mobile data storage, (MDS)
Communications module (CM)
Interface module (ASM)

SIMATIC RF600
System Manual, 06/2019, J31069-D0171-U001-A22-7618 15
SSafety Information
22
2
2.1 General safety instructions
Note
H
Heed the safety notices
P
lease observe the safety instructions on the back cover of this documentation.
SIMATIC RFID products comply with the salient safety specifications to VDE/DIN, IEC, EN,
UL and CSA. If you have questions about the admissibility of the installation in the
designated environment, please contact your service representative.
WARNING
Safety extra low voltage
The equipment is designed for operation with Safety Extra-Low Voltage (SELV) by a
Limited Power Source (LPS). (This does not apply to 100 V ... 240 V devices.)
This means that only safety-extra low voltage (SELV) with a limited power source (LPS)
complying with IEC 60950-1 / EN 60950-1 / VDE 0805-1 may be connected to the power
supply terminals or the power supply unit for the equipment power supply must comply with
NEC Class 2, according to the National Electrical Code (r) (ANSI / NFPA 70).
There is an add
i
itional requirement if devices are operated with a redundant power supply:
If the equipment is connected to a redundant power supply (two separate power supplies),
both must meet these requirements.
WARNING
Opening the device
D not open the device when energized.
NOTICE
Alterations not permitted
Alterations to the devices are not permitted.
Failure to observe this requirement shall constitute a revocation of the radio equipment
approval, CE approval and manufacturer's warranty.

Safety Information
2.1 General safety instructions
SIMATIC RF600
16 System Manual, 06/2019, J31069-D0171-U001-A22-7618
O
Operating temperature
CAUTION
Increased temperatures on the lower casing
Note that the lower casing of the readers is made of metal. This means that temperatures
can occur on the lower casing that are higher than the maximum permitted operating
temperature.
CAUTION
Do not expose the readers to direct sunlight
Note that the readers must not be exposed to direct sunlight. Direct sunlight can lead to the
maximum permitted operating temperature being exceeded.
Overvoltage protection
NOTICE
Protection of the external 24
V
VDC voltage supply
If the module is supplied via extensive 24 V supply lines or networks, interference by strong
electromagnetic pulses on the supply lines is possible, e.g. from lightning or the switching
of large loads.
The connector for the 24 VDC external power supply is not protected against strong
electromagnetic pulses. Make sure that any cables liable to lightning strikes are fitted with
suitable overvoltage protection.
Repairs
WARNING
Repairs only by authorized qualif
i
ied personnel
Repairs may only be carried out by authorized qualified personnel. Unauthorized opening
of
and improper repairs to the device may result in substantial damage to equipment or risk of
personal injury to the user.

Safety Information
2.1 General safety instructions
SIMATIC RF600
System Manual, 06/2019, J31069-D0171-U001-A22-7618 17
L
Lightning protection
CAUTION
Installation only in protected areas
Antennas and readers can be installed in the protected part of a building. When
implementing your lightning protection concept, make sure you adhere to the VDE 0182 or
IEC 62305 standards.
When installing outdoors, we recommend that you protect the readers/antennas from the
weather with a box.
The antenna RF650A must not be installed in the (protected) outdoor area.
཰Antenna or reader
ཱProtected area (indoors); grounding is not necessary here.
ིProtected area (outdoors); grounding is not necessary here.
Figure 2-1 Mounting the reader in protected areas

Safety Information
2.1 General safety instructions
SIMATIC RF600
18 System Manual, 06/2019, J31069-D0171-U001-A22-7618
S
System expansion
Only install system expansion devices designed for this device. If you install other upgrades,
you may damage the system or violate the safety requirements and regulations for radio
frequency interference suppression. Contact your technical customer service or where you
purchased your device to find out which system expansions are suitable for installation.
Note
W
War
ranty conditions
I
f you cause system defects by improperly installing or exchanging system expansion
d
evices, the warranty becomes void.
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be
connected to an enterprise network or the internet if and to the extent such a connection is
necessary and only when appropriate security measures (e.g. firewalls and/or network
segmentation) are in place.
For additional information on industrial security measures that may be implemented, please
visit
Link: (http://www.siemens.com/industrialsecurity)
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customers’ exposure
to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under
Link: (http://www.siemens.com/industrialsecurity)

Safety Information
2.2 Safety instructions for third-party antennas as well as for modifications to the RF600 system
SIMATIC RF600
System Manual, 06/2019, J31069-D0171-U001-A22-7618 19
2
2.2 Safety instructions for third-party antennas as well as for
modifications to the RF600 system
Always observe the following general safety instructions before selecting a component from
a different vendor:
The manufacturer accepts no responsibility for functional suitability or legal implications for
the installation of third-party components.
Not
e
e
Alterations not permitted
A
lterations to the devices are not permitted. If this is not adhered to, the radio approvals, th
e
r
elevant country approvals (e.g. CE or FCC) and the manufacturer's guarantee are
in
validated.
Modifications to the SIMATIC RF600 system
NOTICE
Damage to the system
If you install unsuitable or unapproved extensions, you may damage the system or violate
the safety requirements and regulations for radio frequency interference suppression.
Contact your technical customer service or where you purchased your device to find out
which system expansions are suitable for installation.
NOTICE
Loss of warranty
If you cause defects on the SIMATIC RF600 system by improperly installing or exchanging
system expansions, the warranty becomes void.
Note
L
Loss of validity for type tests and certificates
S
IMATIC RFID products comply with the salient safety specifications to VDE/DIN, IEC, EN
,
U
L and CSA. When using RFID components that do not belong to the RF600 range of
p
roducts, all type tests as well as all certificates relevant to the RF600, such as CE, FCC,
U
L, CSA are invalidated.

Safety Information
2.3 Safety distance to transmitter antenna
SIMATIC RF600
20 System Manual, 06/2019, J31069-D0171-U001-A22-7618
NNote
U
User responsibility for modified product
A
s a user of the modified product, you accept responsibility for use of the complete RFID
p
roduct comprising both SIMATIC RF600 components and third-party RFID components.
T
his particularly applies to modification or replacement of:
xAntennas
xAntenna cables
xreaders
xPower supply units with connection cables
2
2.3 Safety distance to transmitter antenna
2.3.1 Safety distance between transmitter antenna and personnel
For antenna configurations where it is possible to be briefly or constantly within the
transmission range of the antennas, as in loading ramps, for example, minimum distances
must be maintained.
Limits
The ICRP (International Commission of Radiological Protection) has worked out limit values
for human exposure to HF fields that are also recommended by the ICNIRP (International
Commission of Non Ionizing Radiological Protection). In German legislation on emissions
(since 1997), the following limit values apply. These can vary according to frequency:
Frequency f [MHz]
Electrical field strength E [V/m]
Magnetic field strength H [A/m]
10 - 400
27,5
0,073
400 - 2.000
1.375 x f
1/2
0.0037 x f
1/2
2.000 - 300.000
61
0,16
The limit values for the 900 MHz reader antenna alternating field are thus:
Electrical field strength: E = 41.25 V/m
Magnetic field strength: H = 0.111 A/m
HF power density: E x H = 4.57 W/m2
