Siemens D1085-A User manual

Additional Technical Manual
A26361-D1085-Z180-2-7619 Page 1
Introduction
This technical manual applies for the mainboard D1085. This system board is available in different
configuration levels. Depending on the hardware configuration of your device, it may be that you
cannot find several options in your version of the system board, even though they are described.
Further information e. g. the complete Technical Manual for the D1085 and the Reference Manual
for the BIOS Setup are provided on the "Drivers & Utility" CD. For detailed information please
look at chapter 3.
1 Features
Function Version Version
D1085-A D1085-E
Processor Intel PentiumII,
233 - 333 MHz
Intel Celeron
Intel PentiumII,
233 - 333 MHz
Intel Celeron
Chipset Intel 440LX Intel 440EX
AGP connector X X
Wake on LAN (WOL) connector X -
USB X X
IrDA connector X -
Chipcard reader X -
Keyboard on X -
BIOS Fax - -
Quiet Boot X X
DMI X X
Systemmonitoring X -
DIMM 3 2
Memory ECC Support X -
FAX On - -
PCI Slots* 4 4
ISA Slots* 3 3
* = 1 PCI/ISA slot is shared
2 Mechanics
!Computer mainboards and components contain very delicate IC chips. To protect
them against damage caused from electric static, you have to follow some
precautions:
• Unplug your computer when you work inside.
• Hold components by the edge, don’t touch their leads.
• Use a grounded wrist strap.
Place the mainboard and the components on a grounded antistatic pad whenever
you work outside the computer.
Once you have installed the system board, you should remove the battery
protection (i.e. the thin plastic plate between battery and contact spring).

Additional Technical Manual
Page 2 A26361-D1085-Z180-2-7619
2.1 Layout
ATX 12’’ x 7,3’’ (305 mm x 185,4 mm)
Some of the following connectors are optional and may therefore not be included on your
mainboard.
ISA 1
ISA 3
ISA 2
PCI 2
PCI 1
PCI 3 PCI 4
3 2 1
2
3
45 6
1
1 = Serial port 2
2 = Serial port 1
3 = PS/2 mouse port
4 = PS/2 keyboard port
5 = Parallel port
6 = USB ports

Additional Technical Manual
A26361-D1085-Z180-2-7619 Page 3
ISA 1
ISA 3
ISA 2
PCI 2
PCI 1
PCI 3
PCI 4
3 2 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1 = System fan
2 = Chipcard reader
3 = Power supply
4 = Infrared receiver (IrDA)
5 = Cover detection
6 = Power supply monitor
7 = IDE drives 3 and 4 (secondary)
8 = IDE drives 1 and 2 (primary)
9 = Floppy disk drive
10 = Processor fan
11 = Control panel
12 = Intrusion plug
13 = Power On
14 = Wake-up on LAN
The connectors marked do not have to be present on the system board.

Additional Technical Manual
Page 4 A26361-D1085-Z180-2-7619
2.2 Assembling Slot 1
iBefore inserting the CPU, you have to assembly the including stabilisators. Please be
carefully to avoid a damage of the mainboard.
2.3 Connectors, DIP-Switch, Jumpers
!Some of the following connectors are optional!
2.3.1 Power supply ATX connector
Pin Signal Pin Signal
11 + 3.3V 1 + 3.3V
12 - 12V 2 + 3.3V
13 GND 3 GND
14 PS on (low
asserted) 4 + 5V
15 GND 5 GND
16 GND 6 + 5V
17 GND 7 GND
18 - 5V 8 Powergood (high
asserted)
19 + 5V 9 + 5V SB
20 + 5V 10 + 12V
2.3.2 Power control connector
Pin Signal
1 Monitor on
2 SV FAN off request (low asserted)
3 SV FAN full on (low asserted)
4 SV FAN pulse
5 SMB CLK
6 SMB DATA
7 VCC EEPROM
8 GND
Pin 1Pin 11
Pin 1

Additional Technical Manual
A26361-D1085-Z180-2-7619 Page 5
2.3.3 Power on switch connector
Pin Signal
1 GND
2 Power on pulse (low asserted)
2.3.4 Wake on LAN (WOL) connector (stuffing option)
Pin Signal
1 + 5 V SB
2 GND
3 Wake pulse (high asserted)
2.3.5 CPU-FAN connector
Pin Signal
1 GND
2 FAN power supply
3 FAN sense
2.3.6 Internal serial port 1 for chip card reader
Pin Signal Pin Signal
1 DCD 2 (low asserted) 2 DSR 2 (low asserted)
3 SIN 2 (high asserted) 4 RTS 2 (low asserted)
5 SOUT 2 (high asserted) 6 CTS 2 (low asserted)
7 DTR 2 (low asserted) 8 PC_ON_Strobe
9 GND 10 VCC SB
11 12 VCC
13 RESETDRV
(high asserted) 14 GND
15 GND 16 Key
Pin 1
Pin 1
Pin 1 Pin 2
Pin 1

Additional Technical Manual
Page 6 A26361-D1085-Z180-2-7619
2.2.7 Internal infrared (IrDA) connector
Pin Signal
1 VCCHELP
2 Key
3 IRDA_RX
4 GND
5 IRDA_TX
2.2.8 Internal speaker connector
Pin Signal
1 VCC
2 GND
3 Key
4 Speaker output
2.3.9 System management SM-BUS
Pin Signal
1 VCC
2 SM Clock
3SM Data
4 GND
Pin 1
Pin 1
Pin 1

Additional Technical Manual
A26361-D1085-Z180-2-7619 Page 7
2.3.10Front panel connector 1
Pin Signal Pin Signal
1 Boot Lock
(high asserted) 2 Speaker
3 Stand By LED
(high asserted) 4 Key
5 Key 6 GND
7 Power On LED
(high asserted) 8 VCC
9 Speaker 10 Key Pin
11 Power On &
Stand By LED
(low asserted)
12 Key
13 Message LED
(high asserted) 14 Key
15 Message LED
(low asserted) 16 Key Pin
17 Key 18 Key
19 VCC 20 Key
21 HD LED
(low asserted) 22 Key
23 Sleep Button
(low asserted) 24 Not connected
25 Power Button
(low asserted) 26 SCSI LED (low asserted)
27 Sleep Button
(low asserted) 28 SCSI LED (low asserted)
29 Reset Button
(low asserted) 30 Not connected
Pin 1 Pin 2

Additional Technical Manual
Page 8 A26361-D1085-Z180-2-7619
2.3.11PCI-IDE Connector
Pin Signal Pin Signal
1 Reset Drive 2 GND
3 Data 7 4 Data 8
5 Data 6 6 Data 9
7 Data 5 8 Data 10
9 Data 4 10 Data 11
11 Data 3 12 Data 12
13 Data 2 14 Data 13
15 Data 1 16 Data 14
17 Data 0 18 Data 15
19 GND 20 Key
21 DRQ 22 GND
23 I/O Write 24 GND
25 I/O Read 26 GND
27 IORDY 28 N.C.
29 DACK 30 GND
31 IRQ 32 N.C.
33 ADR 1 34 N.C.
35 ADR 0 36 ADR 2
37 Chip Select 1 38 Chip Select 3
39 IDE-LED 40 GND
2.3.12AUX Audio IN Connector (e. g. MPEG, TV-Cards)
Pin Signal
1 GND
2 MPEG Audio In LEFT
3 GND
4 MPEG Audio In RIGHT
Pin 1
Pin 1

Additional Technical Manual
A26361-D1085-Z180-2-7619 Page 9
2.3.13Infrared Connector
Pin Signal
1 VCC
2 key
3 IRDA_RX
4 GND
5 IRDA_TX
2.3.14Front Panel Connector 1
Pin Signal
1 Boot Lock
2 + Standby LED
3 Key
4 + Power LED
5 Key
6 - Standby/ Power LED
7 Keylock
8 GND
9 Key
10 + HD LED
11 HD LED
12 HD LED
Pin 1
Pin 1

Additional Technical Manual
Page 10 A26361-D1085-Z180-2-7619
2.3.15Configuration SWITCH-Block (DIP-Switch)
For Frequency selection, Reserved, Password clear, Recovery and Floppy write.
Function SW1
SKP SW2 RCV SW3 FWP SW4 RES SW5 CF1 SW6 CF2 SW7 CF3 SW8 CF4
Password Skip On x x x x x x x
Off Off x x x x x x x
Recovery BIOS x On x x x x x x
Off x Off x x x x x x
Floppy Write Protect x x On x x x x x
Off x x Off x x x x x
Reserved x x x On x x x x
Reserved x x x Off x x x x
Recovering System BIOS - switch 2
Switch 2 enables recovery of the old system BIOS after an attempt to update has failed. To restore
the old system BIOS you need a Flash BIOS Diskette (call customer service).
on The System BIOS executes from floppy drive A: and restores the System BIOS on
the system board.
off The System BIOS is started from the system board (default setting).
Write protection for floppy disks - switch 3
Switch 3 is used to define whether floppy disks can be written or deleted in the floppy disk drive. To
write and delete floppy disks, the write -protection in BIOS setup must be disabled (in menu Security,
the field Diskette Write must be set to Enabled).
on The floppy disk drive is write-protected.
off Read, write and delete floppy disks is possible (default setting).

Additional Technical Manual
A26361-D1085-Z180-2-7619 Page 11
Clock speed - switch 5, 6, 7 and 8
!The switches may only be set as specified in the table below for the particular Pentium II
used.
This system board you may use with processors with a host bus frequency of 66 MHz
only.
Don't use processors with a host bus frequency of 100 MHz.
Pentium II with 66 MHz host bus frequency
Processor switch 5 switch 6 switch 7 switch 8
233 MHz off off on on
266 MHz on on off on
300 MHz off on off on
333 MHz on off off on
2.3.16PCI-SLOT Configuration and Placement
PCI-Slot IDSEL Device number
PCI-Slot 1 ADR 23 12 h
PCI-Slot 2 ADR 24 13 h
PCI-Slot 3 ADR 25 14 h
PCI-Slot 4 ADR 26 15 h
2.4 Power Requirements (Power Supply)
Source Voltage Max. Variation Max. Current
SV + 5.0 V +/- 5 % 15A
SV - 5 V +/- 5 % 100mA
SV + 12 V +/- 10 % 300mA
SV - 12 V +/- 10 % 100mA
SV + 3,3 V +/- 5 % 4 A
SV + 5.0 V (aux) +/- 5 % 500mA
− ATX-capable

Additional Technical Manual
Page 12 A26361-D1085-Z180-2-7619
3 Installing drivers and utilities; documentation

Insert the "Drivers & Utilities" CD.

When the DeskStart window appears, select Explore the CD via HTML.

Select the language in which you want to operate the user interface.

Select Scenic Pro and then select e. g. Windows 95.
Here you will find the required drivers, utilities and the additional documentation.

For the following components, install the software offered to you in the HTML interface:
− Harddisk-Controller: PIIX4-Support
− Updates: USB-Support

You will find the description for the Mainboard D1085 under “Documentation” > Technical
Manual (You may have to install the Acrobat Reader - Software on the CD-ROM (path:
utls/acrobat) before reading!)
For more details please read the according readme.txt files
4 Upgrades
4.1 Main Memory
Further information is given in the main technical manual.
For correct functionality of this mainboard we recommend the usage of the following DIMM-
Modules.
For upgrades of the following list, please ask your local dealer.
16MB DIMM SDRAM, 2Mx64
Producer Part.-No
Samsung KMM366S203BTN-G0 und -G2
32MB DIMM SDRAM, 4Mx64
Producer Part.-No
NEC MC-454AD644F-A67
Samsung KMM366S403BTN-G0 und -G2
HYUNDAI HYM7V64400TFG-10

Additional Technical Manual
A26361-D1085-Z180-2-7619 Page 13
32MB DIMM SDRAM, 4Mx72
Producer Part.-No
Goldstar GMM2734233BLTG-10K
Hyundai HYM7V72A400TFG-10
Samsung KMM374S4030BTN-G2
64MB DIMM SDRAM, 8Mx64
Producer Part.-No
NEC MC-458CB644F-A10
Samsung KMM366S823BTL-G0
64MB DIMM SDRAM, 8Mx72
Producer Part.-No
NEC MC458CA724F-A10
Samsung KMM374S823BTL-G0
128MB DIMM SDRAM, 16Mx64
Producer Part.-No
NEC MC-4516CD644F-A10
128MB DIMM SDRAM, 16Mx72
Producer Part.-No
NEC MC-4516CC724F-A10

Additional Technical Manual
A26361-D1085-Z180-2-7619
Contents
Introduction.......................................................................................................................................1
1 Features.........................................................................................................................................1
2 Mechanics......................................................................................................................................1
2.1 Layout.........................................................................................................................................2
2.2 Assembling Slot 1........................................................................................................................4
2.3 Connectors, DIP-Switch, Jumpers...............................................................................................4
2.3.1 Power supply ATX connector............................................................................................4
2.3.2 Power control connector...................................................................................................4
2.3.3 Power on switch connector...............................................................................................5
2.3.4 Wake on LAN (WOL) connector (stuffing option)..............................................................5
2.3.5 CPU-FAN connector.........................................................................................................5
2.3.6 Internal serial port 1 for chip card reader..........................................................................5
2.2.7 Internal infrared (IrDA) connector......................................................................................6
2.2.8 Internal speaker connector...............................................................................................6
2.3.9 System management SM-BUS.........................................................................................6
2.3.10 Front panel connector 1..................................................................................................7
2.3.11 PCI-IDE Connector.........................................................................................................8
2.3.12 AUX Audio IN Connector (e. g. MPEG, TV-Cards).........................................................8
2.3.13 Infrared Connector..........................................................................................................9
2.3.14 Front Panel Connector 1.................................................................................................9
2.3.15 Configuration SWITCH-Block (DIP-Switch)...................................................................10
2.3.16 PCI-SLOT Configuration and Placement......................................................................11
2.4 Power Requirements (Power Supply)........................................................................................11
3 Installing drivers and utilities; documentation................................................................................12
4 Upgrades......................................................................................................................................12
4.1 Main Memory.............................................................................................................................12

Additional Technical Manual
A26361-D1085-Z180-2-7619
A26361-D1085-Z180-2-7619
System board D1085
Additional Technical Manual
October 1998 edition
Copyright Siemens AG September 1998.
