Introduction
A26361-D992-Z121-2-7419 English - 1
Introduction
This description applies for the system board D992 with PCI bus (Peripheral Component
Interconnect).
System board D992 is available in two variants: as a monoprocessor system (D992-
Mono) and as a dual-processor system (D992-Dual). This manual applies for both
variants. Explicit reference is made to any differences.
You may find further information in the description "BIOS Setup".
Further information to drivers is provided in the readme files on hard disk or on the
supplied drivers diskettes or on the "Drivers & Utility" or "ServerStart" CD.
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
!Pa
yp
articular attention to texts marked with this s
y
mbol. Failure to observe
this warnin
g
endan
g
ers
y
our life, destro
y
sthes
y
stem, or ma
y
lead to loss of
data.
i
This symbol is followed by supplementary information, remarks and tips.
Ê Texts which follow this symbol describe activities that must be performed in the
order shown.
ËThis symbol means that you must enter a blank space at this point.
Ú
ÚÚ
ÚThis symbol means that you must press the Enter key.
Texts in this typeface are screen outputs from the PC.
Texts in this bold typeface are the entries you make via the keyboard.
Texts in italics indicate commands or menu item.
"Quotation marks" indicate names of chapters and terms that are being emphasized.

Important notes
2 - English A26361-D992-Z121-2-7419
Important notes
Store this technical manual close to the device. If you pass on the device to third parties,
you should also pass on this manual.
!Be sure to read this
p
a
g
e carefull
y
and note the information before
y
ou o
p
en
the s
y
stem.
Please note the information
p
rovided in the cha
p
ter "Safet
y
"intheO
p
eratin
g
Manual of the s
y
stem.
Incorrect re
p
lacement of the lithium batter
y
ma
y
lead to a risk of ex
p
losion. I
t
is therefore essential to observe the instructions in the cha
p
ter „Re
p
lacin
g
the
lithium batter
y
“.
The lithium batter
y
must be re
p
laced with an identical batter
y
or a batter
y
t
yp
e recommended b
y
the manufacturer (CR2032).
Do not throw lithium batteries into the trashcan. It must be dis
p
osed of in
accordance with local re
g
ulations concernin
g
s
p
ecial waste.
Connecting cable for peripherals must be adequately insulated to avoid interference.
!Modules can become ver
y
hot durin
g
o
p
eration. Make sure
y
ou do not touch
modules when addin
g
com
p
onents to the s
y
stem board. There is a dan
g
er of
burns!
i
The warrant
y
ex
p
ires if the device is dama
g
ed durin
g
the installation or
re
p
lacement of s
y
stem ex
p
ansions. Information on which s
y
stem ex
p
ansions
y
ou can use is available from
y
our sales office or the customer service.
Boards with electrostatic sensitive devices (ESD) may be identified by labels.
When you handle boards fitted with ESDs, you must observe the following points under
all circumstances:
• You must always discharge yourself (e.g. by touching a grounded object) before
working.
• Theequipmentandtoolsyouusemustbefreeofstaticcharges.
• Pull out the power plug before inserting or pulling out boards containing ESDs.
• Always hold boards with ESDs by their edges.
• Never touch pins or conductors on boards fitted with ESDs.

Features
A26361-D992-Z121-2-7419 English - 3
Features
• Mono processor system (D992 mono) or
Dual processor system (D992 dual: second processor optional)
• Processor: Pentium II, 233 (only D992 mono), 266, 300 and 333 MHz with 66 MHz
bus frequency, with integrated 16 Kbyte first-level cache and 512 Kbyte second-
level cache
• Only D992 dual: Upgrade with second Pentium II processor in slot 2
• Voltage regulators which sets themselves automatically to the required voltage range
(1.5 V to 3.5 V)
• Intel 82440FX chipset with ISA bridge
• 72-bit data bus (64-bit data and 8-bit ECC)
• 64 Mbyte to 512 Mbyte main memory for buffered DIM modules, ECC protected (4
banks), 1 Gbyte main memory with 333-MHz processor and extended cacheability
• 4MbitFlashBIOS
• 6 PCI slots, 2 ISA slots (1 slot shared)
• Screen controller connected to PCI bus, graphics processor Cirrus Logic CL-
GD5446, 1 Mbyte DRAM video memory, 2 Mbyte optional
• Ultra-Wide SCSI controller AIC 7880P
• SNI-ASIC for Server Management
• IDE hard disk controller connected to PCI bus for two IDE drives
• Real-time clock/calendar with integrated battery backup
• Floppy disk controller (up to 2.88 Mbytes format)
• Connector for loudspeaker, two fans, remote-On/Off, wide SCSI drive, floppy disk
drive, IDE disk drive, control panel and service, temperature sensor
• Monitor port
• Parallel interface (ECP- and EPP-compatible)
• Two serial ports (compatible 16550, 16-Byte-FIFO)
• PS/2 mouse port, PS/2 keyboard port
• CAN bus interface for control of external drive cabinets
(CAN = Controller Area Network)
• Security functions in BIOS
• Server management support

Features
4 - English A26361-D992-Z121-2-7419
Ports and connectors: D992 dual
12345
6
7
8
9101112131415
16
17
18
19
20
1= Powersu
pp
l
y
5V and ±12V
2 = Volta
g
e converter for
p
rocessor 1
3= Tem
p
erature sensor for
p
rocessor
2
4 = Volta
g
e converter for
p
rocessor 2
5= Control
p
anel 1
6= Louds
p
eaker
7= Fan2
8= Fan1
9= Servermana
g
ement su
pp
or
t
10 = IDE drives
11 = Tem
p
erature sensor for
p
rocessor
1
12 = SCSI indicator
13 = Ultra wide SCSI drives
14 = Diskette drives
15 = Modem On
16 = CAN bus controller 1
17 = CAN bus controller 2
18 = Ke
y
board and mouse
19 = Serial
p
ort 1 and 2
20 = Parallel
p
ort and monitor
p
or
t

Features
A26361-D992-Z121-2-7419 English - 5
Ports and connectors: D992 mono
 !"
#
$
%
&' !
"
#
$
&
%
1= Powersu
pp
l
y
5V and ±12V
2= Tem
p
erature sensor for
p
rocessor
3 = Volta
g
e converter for
p
rocessor
4= Control
p
anel 1
5= Louds
p
eaker
6= Fan2
7= Fan1
8= Servermana
g
ement su
pp
or
t
9= IDEdrives
10 = SCSI indicator
11 = Ultra wide SCSI drives
12 = Diskette drives
13 = Modem On
14 = CAN bus controller 1
15 = CAN bus controller 2
16 = Ke
y
board and mouse
17 = Serial
p
ort 1 and 2
18 = Parallel
p
ort and monitor
p
or
t

Features
6 - English A26361-D992-Z121-2-7419
Possible screen resolution
Depending on the operating system used the screen resolutions in the following table
refer to the screen controller on the system board for 1 Mbyte video memory.
If you are using an external screen controller, you will find details of supported screen
resolutions in the Operating Manual or Technical Manual supplied with the controller.
Screen resolution Refresh rate (Hz) Horizontal-
rate (kHz) ** Max. number of colors
640x350 70 31,5 16
640x480 60 31,5 16777216
640x480 75 37,5 16777216
640x480 85 43,4 16777216
640x480 100 50,6 16777216
720x400 70 31,5 16
720x400 84 38 16
800x600 60 38 65536
800x600 72 48 65536
800x600 75 47 65536
800x600 85 53,7 65536
800x600 100 63 65536
1024x768 60 48,4 256
1024x768 75 60 256
1024x768 85 68,7 256 *
1024x768 87 interlaced 36 256
1024x768 100 81 256 *
1280x1024 87 interlaced 49 16
* no 16 color mode
** The horizontal rate values may have a tolerance range of ± 0.3 kHz.

Features
A26361-D992-Z121-2-7419 English - 7
Interrupt table
assi
g
ned IRQ
S
y
stem cloc
k
IRQ0
Ke
y
board IRQ1
not available IRQ2
Serial
p
ort COM 2 IRQ3
Serial interface COM1 IRQ4
free IRQ5
Flo
ppy
disk drive controller IRQ6
Parallel interface LPT1 IRQ7
Real-time clock (RTC) IRQ8
free IRQ9
free IRQ10
free IRQ11
Mouse controller IRQ12
Numeric
p
rocessor IRQ13
IDE controller/free IRQ14
free IRQ15
"assigned IRQ" = interrupts assigned as shipped
i
Note that an interru
p
t cannot be used b
y
two ISA boards or onboard
controllers at the same time.
The screen controller of the s
y
stem board does not re
q
uire interru
pt
IRQ9. If
y
ou are usin
g
a different screen controller, it ma
y
need interru
pt
IRQ9.

Settings on the system board
8 - English A26361-D992-Z121-2-7419
Settings on the system board
OPEN/OFF
ON
1
23 4
5
6
7
8
Switch 1 = S
y
stem BIOS recover
y
Switch 2 = must be set to off
Switch 3 = Write-
p
rotection for s
y
ste
m
BIOS
Switch 4 = write
p
rotection for flo
ppy
dis
k
drive
Switch 5,6,7,8=clocks
p
eed
i
The switch settin
g
sa
pp
l
y
both to the dual-
p
rocessor s
y
stem and to the
mono
p
rocessor s
y
stem.

Settings on the system board
A26361-D992-Z121-2-7419 English - 9
Recovering System BIOS - switch 1
Switch 1 enables recovery of the old system BIOS after an attempt to update has failed.
To restore the old BIOS you need a Flash BIOS Diskette (call customer service). The
existing BIOS settings are meaningless for restoring the system BIOS (e.g. the Security
menu in the Flash Write field).
OFF The System BIOS is started with the system BIOS from the system board
(default setting).
ON The system is started from the Flash BIOS Diskette in drive A. A recovery
of the system BIOS is executed.
i
If switch 1 is set to ON, switch 3 must be set to OFF (OPEN).
Write protection for System BIOS - switch 3
Switch 3 enables and disables system BIOS updating. Before an update of the system
BIOS can be carried out, write protection for the system BIOS must also be disabled in
the BIOS Setup (in the Security menu,theFlash Write field must be set to Enabled). If you wish
to update your system BIOS, please consult our customer service.
OFF System BIOS can be overwritten (default setting).
ON System BIOS is write protected.
Write protection for floppy disk drive - switch 4
Switch 4 is used to define whether floppy disks can be written or deleted in the floppy
disk drive. To write and delete floppy disks, the write protection in BIOS setup must be
disabled (in menu Security,thefieldDiskette Write must be set to Enabled).
OFF Read, write and delete floppy disks is possible (default setting).
ON The floppy disk drive is write-protected.
Clockspeed-switch5,6,7and8
!The switch ma
y
onl
y
be set as s
p
ecified in the table below for the
p
articular
p
rocessors used.
p
rocessor switch 5 switch 6 switch 7 switch 8
233 MHz on off off on
266 MHz on on on off
300MHz on off on off
333 MHz on on off off

Extensions: D992 dual
10 - English A26361-D992-Z121-2-7419
Extensions: D992 dual
1 234 5 678
9
10
11
12
13
14
1 = Main memor
y
bank 3
2 = Main memor
y
bank 2
3 = Main memor
y
bank 1
4 = Main memor
y
bank 0
5 = Volta
g
e converter for
p
rocessor 1
6= First
p
rocessor
7 = Second
p
rocessor (o
p
tional)
8 = Volta
g
e converter for
p
rocessor 2
9 = Lithium batter
y
10 = Flash BIOS
11 = ISA slots - from below: 1 and 2
12 = PCI slots (from below: 2, 3, 4, 5, 6, 7)
13 = Video memor
y
1Mb
y
te (o
p
tional)
14 = Video memor
y
1Mb
y
te
i
PCI slots 2, 3 and 4 are connected to the
p
rimar
y
PCIbus.PCIslots5,6
and 7 are connected to the secondar
y
PCI bus.
PCI slot 7 is onl
y
for short boards.

Extensions: D992 mono
A26361-D992-Z121-2-7419 English - 11
Extensions: D992 mono
 !" #$
&
'


!

%
1 = Main memor
y
bank 3
2 = Main memor
y
bank 2
3 = Main memor
y
bank 1
4 = Main memor
y
bank 0
5 = Processor
6 = Volta
g
e converter for
p
rocessor
7 = Terminatin
g
board
8 = Lithium batter
y
9= FlashBIOS
10 = ISA slots - from below: 1 and 2
11 = PCI slots (from below: 2, 3, 4, 5, 6, 7)
12 = Video memor
y
1Mb
y
te (o
p
tional)
13 = Video memor
y
1Mb
y
te
i
PCI slots 2, 3 and 4 are connected to the
p
rimar
y
PCIbus.PCIslots5,6and7
are connected to the secondar
y
PCI bus.
PCI slot 7 is onl
y
for short boards.

Extensions: D992 mono
12 - English A26361-D992-Z121-2-7419
Upgrading main memory
The system board incorporates four locations for installing memory modules in DIMM
format (bank 0 to bank 3). The board supports a maximum of 512 Mbytes. On 333-MHz
processors with extended cache ability only, the maximum memory capacity is 1 Gbyte.
You may use EDO DRAM memory modules of 64, 128 or 256 Mbytes.
Equipping must be performed starting with bank 0 in sequence.
EDO-DRAM = Enhanced Data Output Dynamic Random Access Memory
!You ma
y
onl
y
use buffered 3.3V memor
y
modules. Unbuffered memor
y
modules are not
p
ermitted.
EDO-DRAM memor
y
modules must have an access time of 60 ns or less.
Installing memory modules
Ê Flip the holders on each side of the relevant location outwards.
Ê Insert the memory module into the location.
Ê At the same time flip the lateral holders upwards until the memory module snaps in
place.
Removing a memory module
Ê Flip the holders to the right and left of the location outwards.
Ê Pull the memory module out of its location.
Replacing the Pentium II
System board D992 dual
The system board can be upgraded with a second Pentium II processor in slot 2. You can
replace the Pentium II processor in slot 1.
If the system board contains only one processor in slot 1, a terminating board must be
inserted in slot 2 and there is no voltage converter for processor 2 inserted.
!The second Pentium II
p
rocessor must have the same clock rate as the first. A
suitable multi
p
rocessor o
p
eratin
g
s
y
stem must be used if dual o
p
eration is
re
q
uired. On the
p
rocessor modules
y
ou ma
y
use onl
yp
rocessors of the same
t
yp
e.
System board D992 mono
The system board can only be operated with a Pentium II processor in slot 2. There is a
terminating board in slot 1. Voltage converter slot 1 is empty.
