Siemens SCALANCE W788-1PRO User manual

SCALANCE W788-xPRO/RR / W74x-
1PRO/RR
___________________
___________________
___________________
___________________
___________________
___________________
___________________
SIMATIC NET
Industrial Wireless LAN
SCALANCE W788-xPRO/RR /
W74x-1PRO/RR
Operating Instructions
07/2014
A5E02280448
-08
Information on the Internet
1
Introduction
2
Description
3
Mounting
4
Connecting up
5
Technical specifications
6
Certification
7

Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E02280448-08
Ⓟ
07/2014 Subject to change
Copyright © Siemens AG 2011 - 2014.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are requi
red to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SCALANCE W788-xPRO/RR / W74x-1PRO/RR
Operating Instructions, 07/2014, A5E02280448-08 3
Contents
1 Information on the Internet ...................................................................................................................... 5
2 Introduction ............................................................................................................................................. 7
2.1 Information on the Operating Instructions ...................................................................................... 7
2.2 Type designations .......................................................................................................................... 8
3 Description ............................................................................................................................................ 11
3.1 Components of the product .......................................................................................................... 11
3.2 LED displays ................................................................................................................................ 12
3.3 Reset button ................................................................................................................................. 15
4 Mounting ............................................................................................................................................... 17
4.1 Notes on operating the device in a hazardous area .................................................................... 17
4.2 Securing the housing ................................................................................................................... 18
5 Connecting up ....................................................................................................................................... 21
5.1 Connectors for external antennas and power supply .................................................................. 21
5.2 Replacing the C-PLUG ................................................................................................................ 24
5.3 Assembling an IE hybrid cable 2 x 2 + 4 x 0.34 with an IE IP 67 hybrid connector .................... 25
5.4 Fitting the IE FC TP standard cable 4 x 2 GP to an IE IP 67 hybrid connector ........................... 30
5.5 Pinning of the M12 male connector ............................................................................................. 35
5.6 Lightning protection, power supply, and grounding ..................................................................... 36
5.7 Suitable antenna cables and antennas for SCALANCE W-700 .................................................. 40
5.8 Cabling for power supply and Ethernet ........................................................................................ 42
6 Technical specifications ........................................................................................................................ 43
6.1 Technical specifications for the SCALANCE W788-xPRO/RR and W74x-1PRO/RR ................. 43
6.2 Dimension drawing SCALANCE W788 ....................................................................................... 48
6.3 Technical specifications ANT795-4MR ........................................................................................ 50
6.4 Dimension drawing ANT795-4MR ............................................................................................... 51
6.5 Permitted antennas ...................................................................................................................... 52
7 Certification ........................................................................................................................................... 53
7.1 Approvals for the SCALANCE W788-xPRO/RR and 74x-1PRO/RR ........................................... 53
7.2 National approvals ....................................................................................................................... 62

Contents
SCALANCE W788-xPRO/RR / W74x-1PRO/RR
4 Operating Instructions, 07/2014, A5E02280448-08

SCALANCE W788-xPRO/RR / W74x-1PRO/RR
Operating Instructions, 07/2014, A5E02280448-08 5
Information on the Internet
1
Bitte beachten Sie die Warnhinweise und zusätzlichen Informationen in der
Betriebsanleitung (kompakt) in Ihrer Sprache im Internet:
http://support.automation.siemens.com/ww/view/at/10806097
http://support.automation.siemens.com/ww/view/ch/10806097
http://support.automation.siemens.com/ww/view/de/10806097
http://support.automation.siemens.com/ww/view/li/10806097
http://support.automation.siemens.com/ww/view/lu/10806097
Please observe the warnings and additional information in the user manual (compact) in your
language in the Internet:
http://support.automation.siemens.com/ww/view/au/10806097
http://support.automation.siemens.com/ww/view/ca/10806097
http://support.automation.siemens.com/ww/view/gb/10806097
http://support.automation.siemens.com/ww/view/ie/10806097
http://support.automation.siemens.com/ww/view/us/10806097
http://support.automation.siemens.com/ww/view/za/10806097
Veuillez observer les avertissements et informations supplémentaires du manuel d’utilisation
(compact) dans votre langue dans l’internet:
http://support.automation.siemens.com/ww/view/be/10806097
http://support.automation.siemens.com/ww/view/ch/10806097
http://support.automation.siemens.com/ww/view/fr/10806097
http://support.automation.siemens.com/ww/view/lu/10806097
Osservare le avvertenze di sicurezza e le informazioni aggiuntive nel manuale d'istruzioni
(compatto) nella propria lingua in Internet:
http://support.automation.siemens.com/ww/view/it/10806097
Por favor, observe las indicaciones de advertencia y las informaciones adicionales en las
instrucciones de servicio (compactas) en su idioma disponibles en Internet:
http://support.automation.siemens.com/ww/view/cl/10806097
http://support.automation.siemens.com/ww/view/es/10806097
Berte prosím v úvahu výstražné pokyny a dodatečné informace v provozním návodu
(kompakt) na internetu ve vaší řeči:
http://support.automation.siemens.com/ww/view/cz/10806097
De bedes iagttage advarselsanvisningerne og de yderligere informationer i
betjeningsvejledningen (kompakt) for Deres sprog på internettet:
http://support.automation.siemens.com/ww/view/dk/10806097
Huomioi internetissä oman kielisessäsi käyttöohjeessa (kompakti) olevat varoitusohjeet ja
lisäinformaatiot:
http://support.automation.siemens.com/ww/view/fi/10806097
Προσέξτε παρακαλώ τις προειδοποιητικές υποδείξεις και τις πρόσθετες πληροφορίες στις
οδηγίες λειτουργίας (συνεπτηγμένες) στη γλώσσα σας στο διαδίκτυο.
http://support.automation.siemens.com/ww/view/gr/10806097
请遵守互联网上用您的语言编写的用户手册（简易版）中的警告信息和附加说明：
http://support.automation.siemens.com/ww/view/cn/10806097

Information on the Internet
SCALANCE W788-xPRO/RR / W74x-1PRO/RR
6 Operating Instructions, 07/2014, A5E02280448-08
http://support.automation.siemens.com/ww/view/hk/10806097
http://support.automation.siemens.com/ww/view/sg/10806097
Kérjük, vegye figyelembe az Interneten található magyar nyelvű használati utasításban
(kompakt) olvasható figyelmeztető utasításokat és a kiegészítő információkat!
http://support.automation.siemens.com/ww/view/hu/10806097
Vinsamlegast athugið varúðarábendingar og viðbótarupplýsingar í notendahandbókinni (stytt
útgáfa) á Netinu:
http://support.automation.siemens.com/ww/view/is/10806097
以下のインターネットアドレスでお客様の言語による取扱説明書（コンパクト版）をご覧
http://support.automation.siemens.com/ww/view/jp/10806097
いただけます。同取扱説明書内に記載された警告事項および補足情報にご注意ください。
인터넷 http://support.automation.siemens.com/ww/view/kr/10806097에서 귀하의
사용 언어로 된 사용자 설명서(컴팩트)의 경고 및 추가 정보를 확인하십시오.
يجب التنبه إلى
ارشاداث التحذير و المعلومات الإضافية المذكورة في دليل التشغيل الملخص
بلغتكم و الموجود على شبكة الانترنت التحذير و المعلومات الإضافية المذكورة في
دليل التشغيل الملخص بلغتكم و الموجود على شبكة الانترنت
http://support.automation.siemens.com/ww/view/kw/10806097
Neem de waarschuwingen en de bijkomende informatie in acht, te vinden in de handleiding
(compact) in uw taal in het internet:
http://support.automation.siemens.com/ww/view/be/10806097
http://support.automation.siemens.com/ww/view/nl/10806097
Vennligst se advarsler og ytterligere opplysninger i driftsveiledningen (kompakt) på ditt språk
i Internett:
http://support.automation.siemens.com/ww/view/no/10806097
Por favor observe as advertências e as informações adicionais no manual de instruções
(compacto) na sua língua na internet:
http://support.automation.siemens.com/ww/view/po/10806097
Var vänlig observera varningarna och tilläggsinformationerna i bruksanvisningen (kompakt)
på ditt språk på Internet:
http://support.automation.siemens.com/ww/view/se/10806097
Lütfen internette sizin dilinizde sunulan işletme kılavuzundaki (yoğunlaştırılmış) uyarı
bilgilerine ve ek bilgilere dikkat ediniz:
http://support.automation.siemens.com/ww/view/tr/10806097

SCALANCE W788-xPRO/RR / W74x-1PRO/RR
Operating Instructions, 07/2014, A5E02280448-08 7
Introduction
2
2.1
Information on the Operating Instructions
Validity of the Operating Instructions
These operating instructions cover the following products:
●SCALANCE W788-1PRO
●SCALANCE W788-2PRO
●SCALANCE W788-1RR
●SCALANCE W788-2RR
●SCALANCE W744-1PRO
●SCALANCE W746-1PRO
●SCALANCE W747-1RR
These operating instructions apply to the following software version:
●SCALANCE W788-xPRO/RR or W74x-1PRO/RR with firmware as of version 4.4
Purpose of the Operating Instructions
Based on the Operating Instructions, you will be able to install and connect up the
SCALANCE W788-xPRO/RR or W74x-1PRO/RR correctly. The configuration and the
integration of the device in a WLAN are not described in these instructions.
Documentation on the accompanying CD
You will find detailed information on configuration in the configuration manual
SCALANCE W-700 on the accompanying CD in the file:
PH_SCALANCE-W-700_76.pdf
Note
Make sure that you read the explanations and instructions in the README.txt file

Introduction
2.2 Type designations
SCALANCE W788-xPRO/RR / W74x-1PRO/RR
8 Operating Instructions, 07/2014, A5E02280448-08
2.2
Type designations
Abbreviations used
The information in the manuals for the SCALANCE W-700 product family often applies to
more than one product variant. In such situations, the designations of the products are
shortened to avoid having to list all the type designations. The following table shows how the
abbreviations relate to the product variants.
Product group
The designation . . . stands
for . . .
Product name
Ethernet client modules (IP30, cabinet
installation)
W74x-1 W744-1
W746-1
W747-1
Ethernet client modules (IP65, installed
outside a cabinet)
W74x-1PRO/RR W744-1PRO
W746-1PRO
W747-1RR
All Ethernet client modules SCALANCE
W
W74x W744-1
W746-1
W747-1
W744-1PRO
W746-1PRO
W747-1RR
Access points (IP30, cabinet installation) W784-1xx W784-1
W784-1RR
Access points (IP65, installed outside a
cabinet, extreme climatic requirements)
W786-xPRO/RR W786-1PRO
W786-2PRO
W786-3PRO
W786-2RR
Access points (IP65, installed outside a
cabinet)
W788-xPRO/RR W788-1PRO
W788-2PRO
W788-1RR
W788-2RR
Access points with the "RR" range of
functions
W78x-xRR W784-1RR
W786-2RR
W788-1RR
W788-2RR

Introduction
2.2 Type designations
SCALANCE W788-xPRO/RR / W74x-1PRO/RR
Operating Instructions, 07/2014, A5E02280448-08 9
Product group
The designation . . . stands
for . . .
Product name
All SCALANCE W access points W78x W788-1PRO
W788-2PRO
W788-1RR
W788-2RR
W786-1PRO
W786-2PRO
W786-3PRO
W786-2RR
W784-1
W784-1RR
All SCALANCE W devices W -700 W788-1PRO
W788-2PRO
W788-1RR
W788-2RR
W744-1PRO
W746-1PRO
W747-1RR
W786-1PRO
W786-2PRO
W786-3PRO
W786-2RR
W784-1
W784-1RR
W744-1
W746-1
W747-1

Introduction
2.2 Type designations
SCALANCE W788-xPRO/RR / W74x-1PRO/RR
10 Operating Instructions, 07/2014, A5E02280448-08

SCALANCE W788-xPRO/RR / W74x-1PRO/RR
Operating Instructions, 07/2014, A5E02280448-08 11
Description
3
3.1
Components of the product
The following parts belong to the consignment of the SCALANCE W788-xPRO/RR or W74x-
1PRO/RR:
●SCALANCE W788-xPRO/RR or W74x-1PRO/RR
●2 OMNI antennas ANT795-4MR
●1 IE IP 67 hybrid plug-in connector
●1 protective cap for the M12 socket
●2 (or 4 with SCALANCE W788-2PRO or SCALANCE W788-2RR) sealing plugs for the R-
SMA sockets
●1 SIMATIC NET Industrial Wireless LAN CD
Please check that the consignment you have received is complete. If it is not complete,
please contact your supplier or your local Siemens office.

Description
3.2 LED displays
SCALANCE W788-xPRO/RR / W74x-1PRO/RR
12 Operating Instructions, 07/2014, A5E02280448-08
3.2
LED displays
Information on the operating status and data transfer of the SCALANCE W-788-xPRO/RR or W74x-
1PRO/RR
There are several LEDs on the front of the SCALANCE W788-xPRO/RR or W74x-1PRO/RR
that provide information its operating status:
Note
If the LED for the WLAN interface is not green when the device starts up, although it is
activated, the interface is not ready for operation (interface not initialized).
The main reason for this is usually that during commissioning of a SCALANCE
W788-
xPRO/
RR or W74x-1PRO/RR products, a waiting time of up to 15 minutes can occur when
the ambient temperature is below zero. The device is ready for operation at the specified
ambient temperature as soon as the LED for the WLAN interface is lit green.
Figure 3-1 LEDs of the SCALANCE W788-xPRO/RR or W74x-1PRO/RR

Description
3.2 LED displays
SCALANCE W788-xPRO/RR / W74x-1PRO/RR
Operating Instructions, 07/2014, A5E02280448-08 13
LED
Color
Meaning
P1
Yellow
Data transfer over the Ethernet interface (traffic).
Green
There is a connection over the Ethernet port. (Link)
Flashing yellow
PRESET-PLUG detected.
Yellow/green
PRESET function completed successfully.
Flashing green
"Flashing" enabled over PST.
L2 Green Power supply over the hybrid connector X1 (PoE or
energy contacts).
R1
Yellow
Data transfer over the first WLAN interface.
Green W788-xPRO/RR in access point mode:
The WLAN interface is initialized and ready for operation.
W788-xPRO/RR in client mode or W74x-1PRO/RR:
There is a connection over the first WLAN interface.
Flashing green W788-xPRO/RR in access point mode:
The channels are being scanned.
W788-xPRO/RR in client mode or W74x-1PRO/RR:
The client is searching for a connection to an access point or ad hoc
network.
Green flashing
quickly
W788-xPRO/RR in access point mode:
With 802.11h, the channel is scanned for one minute for primary users
before the channel can be used for data traffic.
W788-xPRO/RR in client mode or W74x-1PRO/RR:
The client waits for the adopt MAC address due to the setting <Auto find
'Adopt MAC'> and is connected to no access point.
Green 3 x fast ,1
x long flashing
W788-xPRO/RR in client mode or W74x-1PRO/RR:
The client waits for the adopt MAC address due to the setting <Auto find
'Adopt MAC'> and is connected to an access point.
Flashing yellow
PRESET-PLUG detected.
Yellow/green
PRESET function completed successfully.

Description
3.2 LED displays
SCALANCE W788-xPRO/RR / W74x-1PRO/RR
14 Operating Instructions, 07/2014, A5E02280448-08
LED
Color
Meaning
R2 Yellow W788-xPRO/RR in access point mode:
Data transfer over the second WLAN port.
W788-xPRO/RR in client mode or W74x-1PRO/RR:
The LED is always off because the 2nd interface is not available in client
mode.
Green W788-xPRO/RR in access point mode:
The WLAN interface is initialized and ready for operation.
W788-xPRO/RR in client mode or W74x-1PRO/RR:
The LED is always off because the 2nd interface is not available in client
mode.
Flashing green W788-xPRO/RR in access point mode:
The channels are being scanned.
W788-xPRO/RR in client mode or W74x-1PRO/RR:
The LED is always off because the 2nd interface is not available in client
mode.
Green flashing
quickly
W788-xPRO/RR in access point mode:
With 802.11h, the channel is scanned for one minute for primary users
before the channel can be used for data traffic.
W788-xPRO/RR in client mode or W74x-1PRO/RR:
The LED is always off because the 2nd interface is not available in client
mode.
Flashing yellow
PRESET-PLUG detected.
Yellow/green
PRESET function completed successfully.
L1
Green
Power supply over the M12 connector (X2).
F Red An error has occurred during operation of the SCALANCE W788-
xPRO/RR or W74x-1PRO/RR.
Flashing red,
R1 or R2
flashing green at
the same time
A primary user was found on all enabled channels.
Note
Primary user (radar) on all enabled channels
If the device detects a primary user on all enabled channels (for example radio waves of a
radar station), the LEDs F
and
R1
flash. No data traffic is then possible for the next 30
minutes. After this time, the device runs the scan again and checks whether a primary user
still exists. If no primary user is detected, data traffic is possible again.
The wait time of 30 minutes is
necessary due to legal requirements and cannot be shortened
even by resetting the device.

Description
3.3 Reset button
SCALANCE W788-xPRO/RR / W74x-1PRO/RR
Operating Instructions, 07/2014, A5E02280448-08 15
3.3
Reset button
Functions of the reset button
The reset button is on the rear of the device below the sealing screw directly beside the C-
PLUG and has several functions:
●Restart of the device
To restart the device, press the Reset button.
●Loading new firmware
If the normal procedure with the Load & Save menu of Web Based Management does not
work, the reset button can be used to load new firmware. This situation can occur if there
was a power outage during the normal firmware update.
●Restoring the default parameters (factory defaults)
●Adopting the configuration data from the PRESET PLUG.

SCALANCE W788-xPRO/RR / W74x-1PRO/RR
Operating Instructions, 07/2014, A5E02280448-08 17
Mounting
4
4.1
Notes on operating the device in a hazardous area
WARNING
EXPLOSION HAZARD
When used in hazardous environments corresponding to Class I, Division 2 or Class I,
Zone 2, the device must be installed in a cabinet or a suitable enclosure.
WARNING
Requirements for the cabinet/enclosure
To comply with EU Directive 94/9 (ATEX95), this enclosure must meet the requirements of
at least IP54 in compliance with EN 60529.

Mounting
4.2 Securing the housing
SCALANCE W788-xPRO/RR / W74x-1PRO/RR
18 Operating Instructions, 07/2014, A5E02280448-08
4.2
Securing the housing
Grounding terminal
WARNING
To operate the SCALANCE W788 safely, the housing must make contact with a chassis
ground cable. Do not use the SCALANCE W788 without a ground cable connected.
The ground cable can be connected to one of the securing screws. To allow this, several of
the screw contact surfaces in the housing do not have a powder coating. You will find these
contact surfaces on the right-hand side of the housing (when looking at the front of the
housing).
Wall mounting or standard rail
Note
Installation location
There are no restrictions regarding the installation location for the device.
Antennas, in particular directional antennas, must be mounted in keeping with their
characteristics (refer to the technical specifications of the antenna
--> Radiation pattern
d
iagrams).
There are two ways of securing the housing:
●Wall mounting
Use the holes in the housing to screw the device to the wall or on a horizontal surface.
●Standard rail mounting
Mount the SCALANCE W788-xPRO/RR or W74x-1PRO/RR on a 90 mm long, vertically
mounted section of standard rail (S7-300). In this case, the standard rail serves as an
adapter between the wall and SCALANCE W788-xPRO/RR or W74x-1PRO/RR. If you
want to mount the SCALANCE W788-xPRO/RR or W74x-1PRO/RR along with a PS791-
1PRO, you will require a 150 mm long standard rail.
Make sure that there is suitable strain relief for the connecting cable.

Mounting
4.2 Securing the housing
SCALANCE W788-xPRO/RR / W74x-1PRO/RR
Operating Instructions, 07/2014, A5E02280448-08 19
Drilling template
The location of the holes for wall mounting of the SCALANCE W788-xPRO/RR / W74x-
1PRO/RR is shown in the following diagram:
NOTICE
Premature aging of the device and cables due to UV radiation
For applications outdoors, the use of the hardware SCALANCE W786 is advisable due to
its greater suitability.
Protect the SCALANCE W788-xPRO/RR or W74x-1PRO/RR from direct sunlight by
providing suitable shade. This avoids unwanted heating of the device and prevents
premature aging of the device and cabling. When operating the SCALANCE W outdoors, it
must be mounted so that it is protected from UV.
UV radiation can discolor the front panel of the SCALANCE W788-xPRO/RR or W74x-
1PRO/RR. Discoloring of the front panel does not impair the mechanical stability of the
device. The device must also not be subjected to long periods of rain (provide cover to
protect from rain). The cover should be made of a synthetic material since metal impairs the
radiation of radio waves.
Note
The minimum distance to fluorescent lamps should be 0.5 m. When installed in a cabinet, we
recommend that you do not install relays on the same or on directly neighboring mounting
rails.

Mounting
4.2 Securing the housing
SCALANCE W788-xPRO/RR / W74x-1PRO/RR
20 Operating Instructions, 07/2014, A5E02280448-08
