Siemens WM 1065 User manual

Computer Controlled Slimline Frontloader
Operating and Installation Instructions en
S
WM 1065
Family 1085
Silver 1095
WM 1065
Family 1085
Silver 1095

Please read this specification carefully before you use the product.
Any failure and losses caused by ignoring the above mentioned items and cautions
mentioned in the operation and installation instruction are not covered by our warranty
and any liability. Please keep all documents in a safety place for future reference. If
you have any doubt, please contact our local service center of dealer.
If you need an English user manual, please download it from siemens web. Or you
can send the E-mail to service department, or you can call up service hot line for free
supply. Thanks!
http://www.siemens-ha.com.cn
[email protected]
4008899999

1
Table of Contents
Operating
Instructions
Installation
Instructions
Disposal Information . . . . . . . . . . . . . . . . . . . . . .
Environmental Protection/Conservation Issues . .
Safety Precautions and Warnings . . . . . . . . . . . .
Your New Washing Machine . . . . . . . . . . . . . . . .
Programmes and Functions . . . . . . . . . . . . . . . .
Laundry Detergents and Additives . . . . . . . . . . .
First Wash Cycle . . . . . . . . . . . . . . . . . . . . . . . .
Preparing, Sorting and Loading the Laundry . . .
Washing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When the Programme has Ended. . . . . . . . . . .
Special Applications . . . . . . . . . . . . . . . . . . . . .
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting Minor Faults . . . . . . . . . . . . . .
Customer Service . . . . . . . . . . . . . . . . . . . . . . .
Programme Table . . . . . . . . . . . . . . . . . . . . . .
Installation, Connection and Transport . . . . . . .
3
8
10
12
13
18
20
21
23
28
31
32
33
2
4
6

Disposal Information
Your old machine
Dispose of packing materials in a responsible
manner.
Keep packing materials out of the reach of
children. Packing materials are not toys.
Reprocessing and re-using materials saves
raw materials and reduces waste.
All packing materials used are environment
friendly and re-usable.
Cardboard boxes consist of 80% to 100%
recycled paper.
Plastic wrappings are made from polythene(PE),
the tapes are made from polypropylene(PP) and
the CC-free packing is made from foamed
polystyrene (PS).
These materials are pure hydrocarbon compounds
and can be recycled.
Render the machine inoperable when it can no
longer be used. Remove the plug from the socket
and cut off the power cable.
Destroy the catch on the porthole door. Prevent
children at play from being locked in and risking
death by suffocation.
The old machine contains valuable materials which
should be recycled.
Please make your contribution to the environment
by assisting with proper disposal or recycling.
The new machine s
packaging
,
2

Environmental Protection
Conservation Issues
Through the economical use of energy,water and
detergent,your appliance is kind to the environ-
ments as well as your household budget.
You can increase the economy and environm-
ental friendliness of your macnine by washing
maxium loads:
Cottons/coloureds: 5.2kg
Easy-Care: 2.6kg
Delicates/Wool: 2.0kg
Single Wash: 3.5kg
60 C programme achieves
How to save energy:
For small amounts of laundry,the automatic
control system reduces the consumption of both
water and energy.
Where possible,use the 60 C Cottons/coloureds
programme with additional function Intensive
instead of the 90 C Cottons/coloureds+prewash
programme. This a
cleaning result comparable to that of the 90 C
programme using considerably less energy.
How to save water,energy and detergent:
Avoid using the Prewash function when washing
lightly normally soiled laundry.
How to save energy and time:
For lightly soiled laundry,select the short program
appropriate to the type of textile.
How to save detergent:
Add detergent according to the degree of soiling,
amount of laundry and water hardness, and obs-
erve the detergent manufacture s instructions.
3
Hints and tips
,,
,,

Safety Precautions and Warnings
Before using for the
first time:
The washing machine must be installed and
operated in a room with the drain.
Install the machine in accordance with the
instructions(page 33-41). Remove the transit
bolts and keep them in a safe place.
Please keep all documents in a safe place for
future reference.
The manufacturer does not accept liability if
these instructions are not followed.
Please contact an authorized technician to
install the machine and instruct the using method.
Please read the enclosed documents carefully
before using the washing machine for the first
time. They contain important information on the
installation, use and safety of the machine.
This machine complies with all relevant safety
regulations.
When heating, the maximum current of the
washing machine is 10A,so please make sure
that the power supply system(voltage; current
and the cable) is applicable to the load of the
applied appliance.
In order to ensure your safety, you must plug
the cable into a socket which connected to
earth. And please check your socket to make
sure that it is connected with reliable earth
correctly.
If the washing machine is visibly damaged, do
not connect it up. If you are in doubt, contact
your customer service representative or dealer.
This machine use thread connection water inlet
hose, connect it to the water tap together with
the machine according to the require of page 37.
(carry out by an authorized technician)
4

Taking care of your
machine:
Your washing machine is designed for domestic
use only, i.e. for washing machine-washable
textiles in a detergent solution.
Never use flammable; explosible and/or poison-
ous solvents, such as gasoline; alcohol etc. As
the washing lotion. Please only use the lotions
suitable for using in washing machine available
in the market.
Operate the machine with cold tap water only.
When washing:
5
Never let children play with the washing machine.
Never wash the carpet in the washing machine.
Keep pets away from the washing machine.
Exercise caution when pumping out hot deterg-
ent solution.
Do not fill water during washing cycle manually.
When the program
has ended:
When the programme has ended:
The Spin/End indicator light flashes.
Open the loading door after cutting the power
of machine.
,,
,,
After the program has ended, please cut the
supply of power and water immediately.
Do not lean against the door.
Do not climb onto the washing machine.
Do not expose the machine in the place with
causticity or explosibility gas.(e.g. dust, steam
and gas, etc.)
Do not install the washing machine in a bath-
room or a room very wet.
When transporting
the machine:
Insert the transit bolts by technician.
Drain any water left in the machine.
Take care when moving the machine.
Do not lift the machine by any of the protruding
parts,and the loading door.
Please close the loading door correctly, if it is
difficult to close it, please check if the laundry
is distributed evenly in the drum.

6
Your New Washing Machine
Adding detergent/cleaning
product
Dispenser I:
Detergent for pre-wash or starch.
Dispenser II:
Detergent for main wash,
soaking agent, water softener,
blench or stain remover.
Dispenser :
Additives, e.g. fabric softener or
former. (Fill at least to lower edge
of insert 1. )
Open the loading door and close it Drain washing solution
if necessary.

Control Panel
7
“开始／暂停”
Programme selector
For switching the machine on and off and
for selecting the programme.
Can be rotated in either direction.
The programme selector does not rotate
while the programme is running the
programme sequence is electronically
controlled.
Start/Pause button
For starting/pausing the wash cycle (programme
must have been selected).
,,
,,
Indicatolr lights
Indicate the status of the washing machine:
“准备／洗涤”
Ready/Wash Indicate light flashes, if the
programme is selected; is on, the programme
is running.
“漂洗”
Rinse indicator light is on, the rinsing cycle
is running.
“脱水／结束”
Spin/End indicator light is on, the spinning
cycle is running; flashes, if the selected pro-
gramme is ended.
Press buttons for additional functions
(Where required to supplement the programme)
强力去污
额外漂洗
Intensive Stains：Increase the
programme duration.
Extra Rinse：Additional rinse cycle.
Additional options can be combined before the
programme is started.
The indicator lights of the buttons come on, if
the additional options are active.
Switch off additional option: press button again.

8
Programmes and functions
Programme selector
Basic programme
Select the desired programme (refer also to
separate Programme Table ).
90 C Cottons/coloureds+prewash
An energy-intensive program for heat-resistant
fabrics made from cotton or linen.
For the protection of the drainage pipe, the hot
washing solution is mixed with approx.5 liters
of cold water before being drained.
Cold, 30-Quick wash, 40, 60 C
Cottons/coloureds
For hard-wearing fabrics.
Cold, 40, 60 C Easy-care
For easy-care fabrics made from cotton,
synthetics or blended fabrics.
Cold, 30 C Delicates
For delicate, washable textiles, e.g. Silk, satin,
synthetic materials or blended fabrics(e.g.
curtains).
Delicates cycle at 30 C for machine washable
silk. We do not recommend washing these
textiles with other rougher textiles.
Cold, 30 C , Wool
For hand or machine-washable fabrics made
from wool or wool blend.
Programme options
,,
,,
Single wash
Single wash cycle without subsequent drain and
spin cycle.
Rinse
Rinse cycle with subsequent spin cycle for rinsing
hand-washed items or for starching.
Reduced spin speed.
Spin
Spin cycle for spinning hand-washed items after
selection of required speed. Washing water or
rinsing water is drained before the spin cycle.
+

WM 1065
600 600 600600 600 600
800 600800 800 800 800
Family 1085
9
600
800
*
*
800 600800 800 800 800
Silver 1095
800
Additional function
buttons
Spin speed
Intensive stains
For very dirty clothes, the washing duration will
be prolonged 20 to 60 minutes after pressing
this button, and this is decided by the program
that you selected.
Extra Rinse
An additional rinsing cycle performed; the washing
duration will be prolonged 10 minutes.
Observe the maximum load for each type of fabric;
Remove the laundry immediately after the spin
cycle.(depend on different models)
For your clothes, there are different spin speeds
in different washing programme of SIEMENS
washing machines. (see Maximum spin speed )
ograPr mme
im n
Max um spi
speed(rpm)
model
Cottons Easy-care Delicates Wool Rinse SpinSingle
wash
Single wash cycle without subsequent spin cycle, if the spin cycle is desired after
this wash cycle, please select the addtional function Extra Rinse.

10
Laundry Detergents and
Additives
Amount of
detergent
!Risk of explosion
not use solvent-based cleaning agents in
fully automatic washing machines. Explosion
hazard.
Do
Keep detergents and additives out of the reach
of children.
You can use any standard powder or liquid de-
tergent which is suitable for automatic washing
machines.
Do not use any detergent boosters containing
solvents or dirt and stain-removing spraying
near the machine, as these could damage the
machine.
Do not use non-automatic detergent as these
produce too much foam.
The best washing results will only be achieved
if you add the correct amount of detergent.
Observe the instructions for use shown on the
detergent packing.
When using liquid detergents, you can use any
measuring aids provided with the detergent,
such as dosage balls of bags.
Please put the liquid detergents into correct
chamber.
The amount of detergent depends on:
- water hardness
- degree of soiling
- laundry load
- amount of detergent to be added according to
its manufacturer.

11
Dispensing the correct amount of detergent
relieves the strain on the environment and ensures
optimum washing results.
Frequent use of insufficient detergent will eventually
become noticeable as follows:
- washing appears grey or not properly clean
- grey-brown stains(grease marks) form on the
washing
- scale builds up on the heating elements
Too much detergent results in:
- unnecessarily high environmental pollution
- due to the generation of too much foam, the
washing is hardly agitated which leads to
poor washing results.
The amount of detergent indicated on its packaging
refers to a full machine load.
For small loads or less soiling, reduce the amount
of detergent.
Filling laundry
detergent and/or
additive dispensers
Chamber I:
Detergent for prewash, starch or pre-soaking
agent.
Chamber II:
Detergent for main wash, water softener, bleach
and stain removal product.
Chamber :
Additives, e.g. fabric softener of former.
- Do not fill beyond the MAX mark, otherwise
will be flushed into the machine together with
the detergent at the start of the program.
- If the liquid additive is thick, mix with a little
water before dispensing(prevents clogging of
the overflow).
Pull out the detergent dispenser up to the end
stop.
Add the detergent and/or additive.
Close the detergent dispenser.
,,
,,

The Spin/End indicator light flashes if the
selected programme is ended. Turn the
programme selector to Off .
12
First Wash Cycle
The installation of the washing machine is
finished.(see page 33-41)
All machines are all tested in the factory. So, it
maybe left a bit little of water in the drum.
Please carry out the first wash cycle without
laundry to remove any water.
Pour half a measuring cup of detergent into
chamber II.
Do not use a special detergent for delicates or
wollens as these will create too much foam.
Input about 1 liter of water in chamber II.
Pull the detergent drawer out as far as it will go.
Turn the tape ON.
Do not load any laundry.
Ready/Wash indicator light flashes.
Turn the programme selector to 90 C Cottons/
coloureds+prewash.
,,,,
,,
Press the Start/Pause button.
Ready/Wash and Start/Pause indicator lights
are on. The programme starts.
,,,,
,,
,,,,
,,
,,,,
,,
,,,,
,,
,,,,
,,

13
Preparing, Sorting and Loading
the Laundry
Preparing the
laundry
Make sure that wire-cup bras in a pillow case
which can be securely closed with a zip or
buttons. If the wire works itself out of the cup it
may fall through the holes of the drum and
cause extensive damage.
Make sure that the wire-cup bras are machine
washable.
Some items are best turned inside out. These
included knitwear, trousers, T-shirts and swe-
atshirts.
Particularly delicate items, such as tights or lace
curtains, or smaller items, such as tiny socks or
handkerchiefs, should only be washed in a net
bag or pillow case.
Remove curtain runners, or secure them in a
net bag.
Close zips and button up cushion covers, duvet
covers, etc.
Brush sand, coins, etc. out of pocket and cuffs.
Remove any loose items or metal objects, such
as safety pins, paper clips, etc. from the laundry.
!

According to colour and
degree of dirt
Sorting the laundry
Degree of dirt
White items may become grey. Always wash
white and coloured items separately.
Items of clothing can become discoloured.
Never wash new multi-coloured items together
with other items.
Caution
Normal dirt
- Light summer clothing and sportswear that
No recognizable dirt or staining. Laundry may
have some body odour.
Slight dirt
has only been worn for a few hours.
- T-shirts, shirts and blouses that have been
used for one day.
- Bed linen and guest towels that have been
used for one day.
Visible dirt and/or some light staining recognizable.
- T-shirts, shirts and blouses that are very sweaty
or have been worn several times.
- Underwear that has been worn for one day.
- Tea towels, hand towels and bed linen that have
been used for up to one week.
- Net curtains (without nicotine staining) that have
not been washed for up to 1/2 year.
14

Intensive dirt
Dirt and/or staining reconizable.
- Kitchen hand towels that have been used for
up to one week.
- Fabric napkins.
- Children's outer clothing or football shirts and
shorts with grass and soil stains.
- working clothes such as overalls or baker's
and butcher's coats.
Typical stains
- Skin fat, cooking oils/fat, sauces, mineral oil,
wax(containing fat/oil)
- Tea, coffee, red wine, fruit, vegetables(blea-
chable).
- Blood, egg, milk, starch(containing protein/
carbohydrate).
- Soot, soil, sand(pigments), red sand on tennis
clothes.
Removing stains
Wherever possible, remove/pretreat stains
whilst they are still fresh.
First, dab soapy water onto the stain. Do not
rub.
Subsequently wash the items of clothing using
the appropriate program.
Several washing cycles may sometimes be
required in order to remove stubborn/dried in
stains.
15

Sorting laundry
according to their
care label
specifications
Loading the
laundry
Only wash laundry that is labelled with the
following care symbols:
95
60
60
90
40
40
30
30
40 40 30 30
40 40 30 30
= do not wash
Risk of explosion
Caution
!
Items of clothing that have been pretreated
with solvent-based cleaning agents, e.g. stain
remover and dry cleaning spirit, represent an
explosion hazard once loaded into the washi-
ng machine.
Therefore, these items must be rinsed thoroughly
by hand.
Loose debris in the washing machine drum can
damage the laundry. Before loading the laundry,
check that there is no debris in the drum.
90 C Cottons + lines
(hand and machine-washable)
60 C, 40 C, 30 C Cottons + lines
Laundry that is labelled with the following care
symbol must not be washed in the washing
machine.
60 C, 40 C, 30 C Easy-care
40 C, 30 C Delicates
40 C, 30 C Wollens
16

Close the loading door.
Take care not to trap any items of clothing
between the loading door and rubber seal.
When washing a small amount of laundry, the
washing machine automatically reduces the
amount of the water and energy used.
Do not exceed the maximum load: Overloading
will cause poor wash results and encourage
creasing.
Unfold the sorted items of clothing and place
them loosely into the drum. Mix up large and
small items. Items of varying size will distribute
better during the spin cycle.
Open the loading door.
17
klack

( Picture example: WM 1065, 40 C Easy-Care)
18
Washing
1. Turn on the tap.
2. Turn the program selector to the desired
program (refer to ).
The Ready ight
me
me Programme table
/Wash indicator l flashes.
,,
,,
,,
,,
3. Where required,press the option button(s) for
additional function(s).
4. Press the Start/Pause button.
The Ready/Wash indicator light stops flashing
and comes on, the programme starts. The
Spin/End indicator light flashes when the
selected programme is ended.
,,
,,
,,
,,
,,
,,
