Siemens WM6HXM71NL User manual

Washing machine
WM6HXM71NL
NL User manual and installation instructions
Register your product on My Siemens and discover
exclusive services and offers.
siemens-home.bsh-group.com/welcome
The future moving in.
Siemens Home Appliances
Translated from Dutch to English - www.onlinedoctranslator.com

NL
Refer to the Digital User's Guide for more
information.
Table of contents
1 Safety................................................ 4
1.1 General instructions .................. 4
6 Before using for the first time ............... 21
6.1 Starting a wash cycle without
laundry................................................ 21
1.2 Destination of the device
rate .................................. 4 7 Display ................................... 22
8 Buttons .................................. 24
9 Programs ................................ 26
10 Accessories................................ 30
1.3 Restriction of users ...... 4
1.4 Safe installation................................. 5
1.5 Safer use ................................... 7
1.6 Safe cleaning and maintenance
hold ........................................... 9
2 Avoiding material damage ...... 11 11 Laundry................................................ 30
11.1 Preparing the laundry.......... 30
3 Environmental protection and saving
ring................................................. 12 12 Detergent and fabric care
ginger.................................. 31
3.1 Disposing of the packaging .... 12
3.2 Saving on energy and
resources ................................... 12 13 The Ministry at its core........... 31
13.1 Switching on the appliance .... 31
13.2 Set program .................. 31
3.3 Energy Saving Mode ........ 13
4 Set-up and connection .................. 13
4.1 Unpacking the device .................. 13
4.2 Package contents.......... 13
13.3 Adjust program
settings ................................ 31
13.4 Filling the drum with detergent
good ................................... 31
4.3 Installation site
requirements ................................... 13 13.5 Inserting the dosing aid for liquid
detergent ............... 32
4.4 Removing transport
locks ................................... 14 13.6 Using the dosing aid for liquid
detergent ............... 32
4.5 Removing transport
reinforcements ................................... 15 13.7 Dosing detergent and care
agent ........... 32
4.6 Connecting the device .................. 16
4.7 Adjusting the device .......... 17 13.8 Starting the program ... 33
13.9 Soaking the laundry ................... 33
13.10 Adding laundry ................................ 33
13.11 Program cancel.................. 33
4.8 Connecting the appliance
electrically................................................. 17
5 Getting to know your device................ 19
5.1 Device ................................... 19
5.2 Detergent drawer.................... 20
5.3 Control panel..................... 20
13.12 Resume program at rinse
hold................................... 33
13.13 Taking out the laundry ............... 33
13.14 Switching off the appliance ........ 33
2

NL
14 Child Lock .................................. 34
14.1 Activating child lock ........... 34
14.2 Deactivating the child lock.......... 34
20 Customer Service............................ 54
20.1 Product number (E no.) and
production number (FD) ........... 55
20.2 AQUA-STOP guarantee ............... 55
21 Consumption values ................... 56
22 Technical data.............. 56
23 Declaration of Conformity........... 57
15 Home Connect ......................... 34
15.1 Device with WLAN home
network (WiFi) with WPS
connect function.................. 35
15.2 Connecting a device to a WLAN home
network (WiFi) without WPS
function........................... 35
15.3 Device with the Ho-
connect me Connect app ... 36
15.4 Activating WiFi on the
device................................................ 36
15.5 Deactivating WiFi on the
device ................................... 36
15.6 Resetting the device's network
settings ................... 37
15.7 Remote start................................ 37
15.8 Remote Diagnosis................... 37
15.9 Protection of personal
data ................................... 37
16 Basic settings .................. 38
17 Cleaning and maintenance .......... 38
17.1 Cleaning the drum ................... 38
17.2 Cleaning the detergent
drawer ................................ 38
17.3 Cleaning the drain pump.............. 39
17.4 Cleaning the inlet opening in the
rubber sleeve...................... 42
18 Troubleshooting ............... 43
18.1 Emergency release................. 53
19 Transporting, Storing and
drain.................................. 53
19.1 Disassembling the device ............... 53
19.2 Transport locks
place .................................. 53
19.3 Restart device
put to use .................................. 53
19.4 Disposal of your old
appliance ..................................... 54
3

NL Safety
1 Safety
Observe the following safety instructions.
1.1 General instructions
s Read this manual carefully.s Keep the operating instructions and
product information for future reference.
for use or for subsequent owners.
s Do not connect the device in case of transport damage.
1.2 Destination of the device
Only use the device:s to wash machine-safe textiles and wool by
hand
wash care label.
s with tap water and commercially available washing machine
detergents and maintenance products.
s for domestic use and in enclosed spaces within the
sly environment.
s to an altitude of 4000 m above sea level.
1.3 Restriction of users
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and/or knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the resulting hazards. understood. Children must
not play with the appliance.
Cleaning and user maintenance shall not be made by children
unless they are supervised.
Make sure that children up to 3 years old and pets cannot reach the
device.
4

Safety NL
1.4 Secure installation
Observe the safety regulations when installing the device.
WARNING ‒ Risk of electric shock!
Improper installations are dangerous.
▶
Only connect and use the device in accordance with the
information on the type plate.
▶
Only connect the device to a mains supply with alternating
current via a properly installed earthing socket.
▶
The protective earth system of the electrical house installation must be
installed in accordance with the electrical engineering regulations. The
installation must have a sufficiently large conductor diameter.
▶
When using an earth leakage circuit breaker, only use a type
marked with .
▶
Never power the device via an external switching device, e.g. a
time switch or remote control.
▶
When the device is installed, the mains plug of the mains
connection cable must be freely accessible or, if free access is not
possible, an all-pole disconnecting device must be installed in the
permanently installed electrical system in accordance with the
installation instructions.
▶
When setting up the device, make sure that the power cord is
not pinched or damaged.
Damaged power cord insulation is dangerous.
▶
Never bring the connecting cable into contact with hot
appliance parts or heat sources.
▶
Never bring the power cable into contact with sharp points or
edges.
▶
Never kink, pinch or alter the power cord.
WARNING ‒ Risk of fire!
Using an extended power cord and unauthorized adapters is
dangerous.
▶
Do not use extension cords or multiple sockets.
5

NL Safety
▶
If the power cord is too short, contact customer service.
▶
Only use adapters approved by the manufacturer.
WARNING ‒ Risk of injury!
The heavy weight of the device can cause injuries when lifted.
▶
Do not lift the device alone.
If this appliance is installed incorrectly in a washer-dryer column,
the installed appliance may fall.
▶
Stack the dryer on top of a washing machine only with the dryer
manufacturer's connection kit. No other method of installation is
allowed.
▶
Do not install the appliance in a washer-dryer column if the dryer
manufacturer does not offer a suitable connection set.
▶
Do not install appliances from different manufacturers and with
different depths and widths in a washer-dryer column.
▶
Do not set up a washer-dryer column on a platform, the
devices can tilt.
WARNING ‒ Risk of suffocation!
Children can pull packing material over their head and become
entangled and suffocate.
▶
Keep packaging material away from children.
▶
Do not let children play with packaging material.
CAUTION ‒ Risk of injury!
The device may vibrate or move during operation.
▶
Set up the device on a clean, flat and solid surface.
▶
Level the appliance using the appliance feet and a spirit level.
There is a tripping hazard with incorrectly laid hoses and mains
connection cables.
▶
Lay the hoses and connection cables in such a way that they cannot
be tripped over.
6

Safety NL
If the appliance is moved by protruding parts, such as the loading
door, the parts can break off.
▶
Do not move the appliance by protruding parts.
CAUTION ‒ Risk of cutting!
Sharp edges on the device can lead to cuts if touched.
▶
Do not touch the device on sharp edges.
▶
Use protective gloves when installing and transporting the
device.
1.5 Safer use
WARNING ‒ Risk of electric shock!
A damaged appliance or power cord is dangerous.
▶
Never use a damaged device.
▶
Never pull on the power cord to disconnect the device from the
power supply. Always pull the plug on the power cord.
▶
If the appliance or the mains cable is damaged, immediately
unplug the mains cable from the socket or switch off the fuse in
the fuse box and close the tap.
▶
Contact customer service. → Page 54
Penetrating moisture can cause an electric shock.
▶
Only use the device in closed rooms.
▶
Never expose the device to excessive heat and humidity.
▶
Do not use a steam cleaner, pressure washer, hoses or nozzles
to clean the appliance.
WARNING ‒ Risk of health hazard!
Children can lock themselves in the appliance and endanger
their lives.
▶
Do not install the appliance behind a door that blocks or
prevents the opening of the appliance door.
7

NL Safety
▶
In the case of discarded appliances, remove the plug of the
mains cable from the socket, then cut the mains cable and
damage the lock of the appliance door so that the appliance door
no longer closes.
WARNING ‒ Risk of suffocation!
Children can inhale or swallow small parts and choke.
▶
Keep small parts away from children.
▶
Do not allow children to play with small parts.
WARNING ‒ Risk of poisoning!
Detergents and care products can lead to poisoning if ingested.
▶
In case of accidental ingestion, seek medical advice.
▶
Keep detergents and care products out of the reach of children.
WARNING ‒ Risk of explosion!
If laundry has been pretreated with cleaning agents containing
solvents, this can lead to an explosion in the appliance.
▶
Rinse pre-treated laundry thoroughly with water before
washing.
CAUTION ‒ Risk of injury!
The cover plate may break when climbing or clambering on the
device.
▶
Do not climb or scramble on the device.
The appliance may tip over when sitting or leaning on the open
door.
▶
Do not sit or lean on the appliance door.
▶
Do not place any objects on the appliance door.
Reaching into the rotating drum can cause injury to hands.
▶
Wait for the drum to come to a complete stop before reaching inside the
drum with your hand.
8

Safety NL
CAUTION ‒ Risk of burns!
The soap gets hot when washing at high temperatures.
▶
Do not touch the hot soapy water.
CAUTION ‒ Risk of chemical burns!
When opening the detergent drawer, detergent and care products
may splash out of the appliance. Contact with eyes or skin may
cause irritation.
▶
In case of contact with detergents or care products, rinse eyes
or skin thoroughly with clean water.
▶
In case of accidental ingestion, seek medical advice.
▶
Keep detergents and care products out of the reach of children.
1.6 Safe cleaning and maintenance
Observe the safety instructions when cleaning and maintaining the
device.
WARNING ‒ Risk of electric shock!
Improper repairs are dangerous.
▶
Only trained specialist personnel may carry out repairs on the
device.
▶
Only original spare parts may be used for repair of the device.
▶
If the power cord of this appliance is damaged, it must be
replaced by the manufacturer, its service agent or a similarly
qualified person in order to avoid a hazard. Penetrating
moisture can cause a shock.
▶
Do not use a steam cleaner, pressure washer, hoses or nozzles
to clean the appliance.
WARNING ‒ Risk of injury!
The use of non-original spare parts and non-original accessories
is dangerous.
▶
Only use original spare parts and original accessories from the
manufacturer.
9

NL Safety
WARNING ‒ Risk of poisoning!
Toxic fumes can be generated when using solvent-based cleaning
agents.
▶
Do not use solvent-based cleaning agents.
10

Avoid material damage NL
▶ Make sure that the internal
diameter of the water tap is at least
17 mm.
▶ Make sure that the thread length
on the connection to the water
tap is at least 10 mm.
Water pressure that is too low or too high can
interfere with the appliance function.
▶ Make sure that the water pressure
on the water supply system is at
least 100 kPa (1 bar) and at most
1000 kPa (10 bar).
▶ If the water pressure exceeds the
specified maximum value, a
pressure reducing valve must be
installed between the drinking
water connection and the hose set
of the device.
▶ Do not connect the appliance to the
mixer tap of a pressureless water
heater or boiler.
Modified or damaged water hoses can
lead to material damage and damage
to the device.
▶ Never kink, pinch, modify or cut
water hoses.
▶ Only use supplied water hoses or
original spare hoses.
▶ Reuse never used water hoses.
Use with contaminated or too hot
water can cause material damage and
damage to the device.
▶ Operate the device only with cold
tap water.
Unsuitable cleaning agents can
damage the surfaces of the device.
▶ Do not use sharp or abrasive
cleaning agents.
▶ Do not use strong alcohol-based
cleaning agents.
▶ Do not use hard scouring or
dishwashing sponges.
2 Material damage
avoid
Follow this instruction to avoid
material damage and damage to the
device.
PAY ATTENTION!
Incorrect dosage of fabric softeners,
detergents, care products and
cleaning agents can affect the
functioning of the appliance.
▶ Follow the manufacturer's dosing
recommendations.
Exceeding the maximum load
quantity affects the operation of the
appliance.
▶ Observe and do not exceed the
maximum load for each
programme.
→ "Programs", Page 26
The device is secured for transport
with transport locks. Transport locks
that have not been removed can lead
to material damage and damage to
the device.
▶ Before commissioning, remove and
store all transport locks completely.
▶ Before each transport, install all
transport locks completely to avoid
transport damage.
Improper connection of the water
inlet hose can lead to material
damage.
▶ Tighten the screw connections on
the water supply hand-tight.
▶ It is best to connect the water inlet
hose directly to the water tap
without additional connecting
elements such as adapter,
extension, valve or the like.
▶ Make sure that the valve housing of
the water inlet hose is installed
without contact with the
environment and that it is not
exposed to external forces.
11

NL Environmental protection and saving
▶ Clean the device only with water
and a soft, damp cloth.
▶ Remove all detergent residues, spray
mist residues or residues immediately
upon contact with the appliance.
Dose detergent according to the
degree of soiling of the laundry.
a For a light to normal degree
of contamination, a small amount
of detergent is sufficient. Follow the
detergent manufacturer's dosing
recommendations.
3 Environmental protection and
savings Reduce washing temperature for
lightly and normally soiled laundry.
a At low temperatures, it consumes
device less energy. For light to
normal soiling, lower
temperatures than those stated on
the care label are also sufficient.
3.1 Disposing of the
packaging
The packaging materials are
environmentally friendly and can be
reused.
▶ Dispose of the individual components
separately according to type.
Set the maximum speed if the
laundry is subsequently to be dried
in the tumble dryer.
3.2 Energy- and resource-
efficient
a Dryer laundry shortens the pro-
gramme time during drying and
reduces energy consumption. With
a higher spin speed, the residual
moisture in the laundry decreases
and the spinning sound volume
increases.
If you follow these directions, your
device will use less power and water.
Use programs with low temperatures
and longer washing times and use
the maximum load capacity.
Wash laundry without prewash.
a Washing with prewash extends
program duration and increases
energy and water consumption.
a The energy consumption and water
consumption are the most efficient. The device has automatic load
matching.
Use economical program setting.
a The automatic load matching
ming optimally adapts the water
consumption and the program
duration to the type of textile and the
load capacity.
a When you set the program
For a programme, the display
shows the expected consumption.
12

Set up and connect NL
3.3 Energy Saving Mode 4.2 Package contents
If you do not operate the device for a
long time, it automatically switches
to energy-saving mode.
The energy saving mode is exited
when you operate the device again.
If you do not operate the device
further, it will switch off.
After unpacking, check all parts for
transport damage and the
completeness of the delivery.
PAY ATTENTION!
Use with incomplete or defective
accessories may impair the operation
of the device or cause material
damage and damage to the device.
▶ Do not use the device with
incomplete or defective accessories.
▶ Replace the accessories before
using the device.
→ "Accessories", Page 30
Remark: The device does not turn off
automatically when WiFi is activated.
4 Set up and connect Remark: The device has been checked
at the factory for correct operation.
Water stains may remain in the
device. The stains disappear after the
first wash.
4.1 Unpacking the device
PAY ATTENTION!
Objects that remain in the drum and
that are not intended for use with the
device can lead to material and device
damage.
▶ Before use, remove all these items
and the supplied accessories from
the drum.
The delivery consists of:s
Washing machine
s Accompanying documentss
Transport protections
→ "Remove transport locks
run", Page 14
s cover caps
s Elbow for attaching
the water drain hose
1. Completely remove packaging
material and protection from the
device.
→ "Disposal of the packaging",
Page 12 .
4.3 Installation site
requirements
2. Check the device for visible
damage. WARNING
Risk of electric shock!
The device contains live parts.
Touching live parts is dangerous.
▶ Do not use the appliance without
a cover.
3. Open the appliance door.
→ "The Ministry in essence",
Page 31
4. Remove the accessories from the
drum.
5. Close the appliance door.
13

NL Set up and connect
WARNING
Risk of injury!
When used on a plinth, the device can
tip over.
▶ The device feet for commissioning
on a plinth must be absolutely
with the fixings
→ Page 30 from the manufacturer
settle.
installation site
kitchen
To demand
The device al-
borrow under a
continuous work
place sheet,
that fixed with the
adjacent
cabinet is connected
Pine tree. Required
niche width:
60 cm.
PAY ATTENTION!
Freezing residual water in the device
can damage the device.
▶ Do not place and use the device in
frost-sensitive places or outdoors.
If the device is tilted more than 40°,
residual water can run out of the
device and cause material damage.
▶ Carefully tilt the device.
▶ Transport the device upright.
on a wall no snakes
between wall and
device clamping
man.
4.4 Removing transport locks
The device is secured for transport
with transport locks at the rear of the
device.
installation site
Plinth
To demand
The device with
locking lips
→ Page 30
confirm.
Remark: Keep the screws of the
transport locks and the sleeves for
later transport
→ Page 53 .
1. Pull the hoses out of the holders.
Floor with wooden
beams
Place the device
guess at a wa-
resistant
wooden plate (thick-
too minimal
30mm) which
screwed to the
floor.
14

Set up and connect NL
2. Loosen and remove all bolts of the
4 transport locks with a SW13
open-end wrench
.
5. Install the 4 cover caps.
6. Push the 4 cover caps down.
3. Pull the mains connection cable out of the
holder.
4.5 Removing transport
reinforcements
4. Remove the 4 sleeves.
1. Loosen and remove the screws of
the vertical transport
reinforcements with a T20
screwdriver.
15

NL Set up and connect
2. Remove the transport
reinforcements. 4.6 Connecting device
Connect water supply hose
WARNING
Risk of electric shock!
The device contains live parts.
Touching live parts is dangerous.
▶ Do not immerse the electric
Aquastop valve in water.
1. Connect the water inlet hose to the
tap (26.4 mm = 3/4").
3. Loosen and remove the screws of
the horizontal transport
reinforcement with a T20
screwdriver.
2. Open the tap carefully and check
that the connections are tight.
4. Remove the transport
reinforcement.
Water drainage connection types
The information will help you connect this
appliance to the water outlet.
PAY ATTENTION!
When draining, the water drain hose is
under pressure and can come loose
from the installed connection position.
▶ Secure the water drain hose against
unintentional disconnection.
Remark: Observe the pumping
heights.
The maximum pumping height is
100 cm.
16

Set up and connect NL
The connection position
tie with a
hose clamp
(24-40 mm) bore
gene.
2. To adjust the appliance, turn the
appliance feet. Check the horizontal
adjustment of the appliance with a
spirit level.
washbasin the water drainage
feeding hose with
a bend
fixate and
gene.
plastic stand
pipe with rubber
run muff or a
floor drain
the water drainage
feeding hose with
a bend
fixate and
gene.
All appliance feet must be firmly
planted on the floor.
3. Tighten the lock nuts against the
housing with an open-end wrench
SW17 hand-tight.
4.7 Adjusting the device
To reduce noises and vibrations and to
prevent the device from walking, place
the device horizontally.
1. Loosen the lock nuts with a SW17
open-end wrench. Hold the appliance foot while
doing so and do not adjust the
height.
4.8 Connecting the appliance
electrically
1. Insert the mains plug of the
mains cable of the device into a
socket in the vicinity of the
device.
The connection data of the device
can be found in the technical data
→ Page 56 .
17

NL Set up and connect
2. Check the mains plug for tightness.
18

Getting to know your device NL
5 Getting to know your device
5.1 Device
Here you will find an overview of the components of your device.
3 4 5 6 7
288
19
Depending on the device type, details in the image may differ, e.g. color and
shape.
1Service valve and pump
→ Page 39
7
8
Mains connection cable → Page 17
Transport protections
→ Page 14
2
3
4
Door
Detergent drawer → Page 20
9Water supply hose
→ Page 16
Control panel
→ Page 20
5
6
Water drain hose
→ Page 16
Transport reinforcements
→ Page 15
19

NL Getting to know your device
5.2 Detergent drawer 1Dosing aid for liquid
detergent
→ "Dosing aid for liquid
place detergent",
Page 32
4
3
2Detergent dispenser II:
s Detergent for the main
used to be,
s softener
s Bleach
s Stain salt
3Compartment :
s fabric softener
s Liquid starch
s Impregnating agent
1 2
4Detergent dispenser I:
s Detergent for the pre-
used to be
s Hygiene detergent
5.3 Control panel
You can set all functions of your device and obtain information about the
operating status via the control panel.
2 4
1 1
3
3
1
2
Programs 3
4
Buttons → Page 24
Display → Page 22
Program selector
→ Page 31
20
