Signtex CAE Series Quick start guide

Before connecting to power supply, TURN OFF ELECTRICAL
POWER AT CIRCUIT BREAKER OR FUSE
Disconnect AC power before servicing.
Refer to wiring diagram for proper connections.
All servicing should be performed by qualified personnel.
Consult your local building code for approved wiring and installation.
Do not use outdoors.
Suitable for indoor damp locations (when specified).
Do not let power cords touch hot surfaces.
Do not mount near gas or electric heaters.
Mount and secure exit sign at a location and height to avoid
ready access and tampering by unauthorized persons.
(Exception: Floor proximity installations)
The use of accessory equipment is not recommended by
the manufacturer and may cause an unsafe condition.
Do not use this equipment for other than intended use.
INSTALLATION INSTRUCTIONS AND OWNER'S MANUAL
IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
SPECIFIED EMERGENCY LIGHTINGSPECIFIED EMERGENCY LIGHTING
Signtex Inc
LIGHTING
REV 01.12.02
Crystal Edge- lit LED
Sign System
Series CAE
Accessible Exit
Designed to meet requirements of State of Connecticut,
State Fire Safety Code Para 1011.1.1 and 1011.1.2

WALL MOUNT
WALL
POWER MODULE
J- BOX
4"x4"x2 1/8"
1900
EXTENSION
4"x4"x1 1/2"
CANOPY
-2-
ALL INSTALLATIONS REQUIRE STANDARD TYPE
4" x 4" SQ x 2 1/8" DEEP J- BOX.
SET J-BOX EDGE AT ¼" BELOW FINISHED PANEL SURFACE
1. Connect Power Module AC wiring to main power lines in J-Box, using wire nuts or
connectors supplied.
Attach building ground wire to back box with screw provided.
2. Route wire nuts to side of J-box, insert Power Module into box and secure with 2 #8-32 box
screws. NOTE: Power module orientation is universal, position as required to clear nipple and
wire nuts in J-box.
3. For battery backup models, connect 2-pin polarized battery plug.
4. Run LED lamp plug from power module through canopy center and secure canopy to j-box
with 2 #8-32 screws supplied.
5. Raise sign to canopy, connect LED lamp plug, insert excess wiring and plug into j-box cavity.
Position lamp housing into canopy, center assembly, then secure with 2 #6-32 set screws.
BATTERY MODELS: BLACK: 120 277 VAC WHITE: Common
AC MODELS: Non- Polarized Line in.
WALL OR CEILING MOUNT
AC POWER
INPUT
120/277 VAC
POWER MODULE
MOUNT SCREWS
#8-32 (2 REQD)
SET SCREWS
#6-32
(2 REQD)
Crystal Edge- lit LED
Sign System
Series CAE
Accessible Exit
Designed to meet requirements of State of Connecticut,
State Fire Safety Code Para 1011.1.1 and 1011.1.2
REV 01.12.02

CEILING
J- BOX
4"x4"x2 1/8"
1900
AC POWER INPUT
120/277 VAC
POWER
MODULE
CANOPY MOUNT
#8-32 SCREWS
(2 REQD)
CANOPY
SET SCREWS
#6-32
(2 REQD)
CEILING MOUNT
-3-
POWER MODULE
MOUNT SCREWS
#8-32 (2 REQD)
EXTENSION
4"x4"x1 1/2"
Crystal Edge- lit LED
Sign System
Series CAE
Accessible Exit
Designed to meet requirements of State of Connecticut,
State Fire Safety Code Para 1011.1.1 and 1011.1.2
REV 01.12.02

Wiring Diagrams & Instructions
Crystal Edge- lit LED
Sign System
Series CAE
Accessible Exit
REV 01.12.02
-4-
POWER MODULE
RED BROWN
OUTPUT 2.4-5 VDC
EMERGENCY SIGNS AC FIXTURES
BATTERY
FIXTURE HOUSING
BLK
RED
RED
VIOLET
VIOLET
BROWN
BROWN
YELLOW
GREEN
PINK
ORANGE
BLACK
OUTPUT 2.4-5 VDC
RED
LAMP CIRCUIT BOARD
LAMP CIRCUIT BOARD
FIXTURE
GROUND
NEUTRAL
120-277 VAC
WHITE
BLACK
BLACK
WHITE
GREEN GROUND
NEUTRAL
120-277 VAC
BLACK
BLACK
BLACK
WHITE
GREEN
POLARIZED
CONNECTOR
TEST PANEL
DIAGNOSTICS INDICATOR
CHARGE LIGHT
TEST SWITCH
8-PIN POLARIZED
2-PIN POLARIZED
CONNECTOR
CONNECTOR
Wiring
1. This equipment to be connected to an unswitched circuit
only.
2. For exits with Master- Remote or Self- Diagnostics, refer
to supplementary data sheet for wiring diagrams and
additional instructions.
3. CAUTION: Damage to battery will occur if battery connec-
tor is connected to charger board for prolonged period of
time without continuous AC power provided.
Inspection and Maintenance
Important Note: Emergency lighting systems should be
tested as often as local codes require, or at least monthly, to
acertain that all components are operational. Allow battery to
charge 8 hours before initial testing, and 24 hours to fully
charge battery.
1. Normal Operation: When unit is functioning properly, with AC
power supplied, the "Ready" light and exit lamp will be on.
2. To Test: Press manual test switch. Status light will turn off
and exit lamp will remain on in DC mode.
Note: Turn off AC power and disconnect battery before
servicing unit.
Battery Replacement
Remove fixture from J-Box. Locate battery wiring and
disconnect 2- pin polarized battery plug. Pry battery
out of cavity to release hook and loop fastener. Replace
battery, reconnect battery plug and replace fixture.
Power Module Replacement
Remove fixture from J-Box. Remove two #8-32 screws
to J-Box and remove Power Module Assembly from J-Box.
Disconnect wire nuts or push nut connectors to AC line
inputs. To replace with new Power Module, reverse this
sequence.
4" SQ x 2 1/8" DEEP J-BOX
WITH 1 " EXTENSION RING
220 VFWAvenue,Grasonville,MD21638
TEL:[phone] Fax:[phone]
[email protected] www.signtexinc.com
Signtex Inc
LIGHTING
REV 07.07.2
