Sigtronics S-ARY Series User manual

igtronics
®
S
Model S-ARY
Headset Instructions
The S-ARY series headsets are adjusted at the factory for immediate use with all
current standard radio systems in general aviation aircraft. Headsets equipped
with two plugs are the standard conguration. The headphone plug is the larger
diameter plug and should be inserted into the headphone jack (.250” standard
stereo or monaural jack). The mic plug is the smaller diameter plug and should
be inserted into the microphone jack (.206” standard microphone jack). The
S-ARY stereo headset has dual volume controls, a stereo headphone plug, and
a stereo-mono switch for operation with either stereo or monaural systems.
The headband is adjustable through a full range of adult sizes, or the locking nuts
may be tightened to allow you to custom t the headset. Place the headset over
your head, adjust the slides up until minimum pressure is felt on the top of your
head. The headset is now properly adjusted. For maximum noise attenuation, the
clamping pressure has been set at the factory. Releasing the clamping pressure
by bending the headband is not advised, because loss of attenuation will result.
Note: If especially small (youth size) or large headbands are needed, they may be
ordered from Sigtronics.
The microphone boom is fully adjustable and will rotate 180 degrees. For best
results use with the microphone on the left side of the head. Make sure you are
speaking into the side of the mic labeled “Talk” or substantial loss of gain will
occur. Microphone placement should be at the corner of the mouth, approxi-
mately 1/4” from the lips. Sigtronics ultra-deep gel ear seals will provide for best
performance. Do not insert any material into the ear cups.
When you rst connect the headset ,make sure the stereo / mono switch is in
the proper position (i.e. in the “MONO” position if plugged in a mono jack or
in the “STEREO” position if plugged into a stereo jack). With the S-ARY power
plug securely fastened to the battery box power jack, push the power switch to
the “ON” position. Turn both volume controls on the headset up to maximum
volume. For the mic side volume control, maximum volume is full clockwise. For
the switch side volume control, maximum volume is full counter-clockwise. Adjust
the listening volume with the audio control of either your radio or intercom as
appropriate. Passengers should also turn their individual headset volumes up fully.
Doing this allows for a full range of adjustment for each passenger, since those
with the most acute hearing can turn their headset volume down, if necessary.
continued on back…
Test the headset in the “ON” and “OFF” modes on the ramp prior to take o. If there is
a problem in the “ON” position then use in the “OFF” position. The S-ARY is completely
fail-safe and will continue to work even if power to the headset is lost. If the power to the
headset is unstable, simply turn o power and use headset in the “OFF” position. The S-ARY
performs best when using high quality Alkaline batteries. The life of these high quality
batteries should last 20 hours minimum. To guard against accidentally leaving the power
on, unplug the power cable from the power module when not in use. DO NOT ATTEMPT
TO POWER THE S-ARY DIRECTLY FROM YOUR AIRCRAFT electrical system without using
our panel mount power system. This system will give clean stable power to the S-ARY.
CLEANING
Headset parts may be cleaned with mild soap on a soft damp cloth. Then dry immediately.
CAUTION: Do NOT immerse any part of the headset in water or any other liquid. Be espe-
cially careful not to allow the microphone to become wet! Exposure to moisture may cause
internal corrosion and failure and will void your manufacturers warranty.
Cleaning will help the headset maintain its “like new ”condition for many years.
WINDSCREEN
The microphone windscreen will reduce annoying wind noise and breath pops picked up
by headset microphones. It also protects the microphone element from dirt and moisture.
The windscreen should be washed regularly to maintain hygiene and avoid clogging. Wash
in warm water and mild soap. Rinse thoroughly and make sure it is completely dry before
putting it back on.
To remove the windscreen, carefully grasp the windscreen lightly along it entire length
and remove from the microphone element being careful not to twist the element itself.
Put the windscreen on the microphone by gently pulling from the open end. Do not pull
it so tightly that it stretches against the end of the microphone.
WARRANTY
Your headset is covered by a limited three-year parts and labor warranty. Please see the
enclosed warranty card for details.
You may refer to the parts list on the reverse side, if you choose to replace parts yourself.
The parts list describes parts for this particular headset only. Parts lists for other models
are available on our Web Site or can be obtained by contacting Sigtronics Corporation.
Sigtronics Corporation
178 East Arrow Highway
San Dimas, CA 91773
Phone: 909 305-9399
E-mail: info@sigtronics.com
Web Site: www.sigtronics.com
5-14-2020
s-ary.pdf



 














 























SIGTRONICS S-ARY HEADSET PARTS IDENTIFICATION BREAKDOWN
ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION
1100049 GROMMET, 5/16 INCH, RUBBER 14 100364 SCREW, 8-32 X 3/8, PHILLIPS HEAD 27 N/A HEAD BAND WITH CUSHION, S-ARY
2100360 KNOB, BLACK, VOLUME 15 100363 SCREW, 8-32 X 1/2, PHILLIPS HEAD 28 100684 FOAM, SOUND AT TENUATING
3100365 POTENTIOMETER, 2K 16 100252 NUT, HEX, 8-32, LOCKING 29 100685 SOUND ATTENUATING, RECEIVER COVER
4100507 NUT, STEREO / MONO SWITCH 17 100604 BRACKET, YOKE SUPPORT WITH TANG, BLACK 30 100686 EAR SEAL, GEL / FOAM FILLED
5100508 WASHER 18 100602 HEADBAND, METAL, BLACK, STANDARD 31 100679 WIRE, 4 CONDUCTOR, 28.5 INCHES
6100509 SWITCH, STEREO / MONO 19 100603 YOKE, EAR CUP MOUNT, METAL, BLACK 32 100221 WIRE, JUMPER, #22, 4 INCHES
7100754 RECEIVER MODULE — SWITCH SIDE 20 100251 E-RING, EAR CUP TO YOKE RETAINER 33 80 0116 CABLE, HEADSET, STEREO
8100755 RECEIVER MODULE — MICROPHONE SIDE 21 100683 EAR CUP, PRINTED AND DRILLED, MIC & NON MIC SIDE 34 100569 STRAIN RELIEF, CABLE
9800044 MICROPHONE & FLEX BOOM ASSEMBLY 22 100373 SLIDE, YOKE BRACKET, LONG, NYLON 35 100579 CLIP, CLOTHING, HEADSET CABLE
10 90 0111 WINDSCREEN, MIC, 8 SERIES 23 100258 CLIP, HEADBAND GUIDE, PLASTIC 36 100672 HEADBAND, METAL, BLACK, YOUTH
11 100597 NUT, HEX, 3/8-24, FLEX BOOM ADAPTER 24 100393 CLIP, ANTI-ROTATION, YOKE, PLASTIC 37 100613 OPTIONAL – HEADBAND, METAL, BLACK, LARGE
12 80 0114 POWER MODULE, BATTERY 25 100362 CLIP, CROSS-OVER, WIRE, PLASTIC
13 10 0179 BATTERY, 9 VOLT 26 800192 PREAMP
