SIGURO SGR-TD-H721W Operating instructions

SGR-TD-H721W
SGR-TD-H911W
Tumble Dryer
Tumble Dryer
Sušička prádla
EN Translation of the operating instructions from the original language.
CZ Návodkpoužitívoriginálnímjazyce.

ENGLISH 4
Safety information 4
Installation 10
Laundry preparation 11
Use of the dryer 13
Table of programmes 22
Maintenance and cleaning 24
Sound machines 27
Troubleshooting 27
Automatic fault warning adn what to do 30
Energy label description and energy saving 31
ČESKY     34
Bezpečnostní informace 34
Instalace 40
Připrava prádla 41
Použití sušičky 43
Tabulka programů 52
Údržba a čištění 54
Zvuk stroje 57
Řešení problémů 57
Automatická upozornění na závadu a co je třeba udělat 60
Popis energetického štítku a úspora energie 61

1
2
8
3
4
5
6
77
9
10
11

EN
EN - 4
Thank you for purchasing a SIGURO appliance. We are grateful for
your trust and are pleased to introduce the device to you on the
following pages and introduce you to all its functions and uses.
We believe in a fair and responsible company and therefore we only work
with suppliers who meet our strict criteria for protecting the interests of em-
ployees, preventing their abuse and provide fair working conditions.
If you need help with extensive maintenance or repair of the product, which
requires intervention in its internal parts, our authorized service is available at
the email address [e-mail], or the operators at the seller's info line. We
have unied these contact points for your convenience in solving any prob-
lems with the products and the above contacts can be used in the event of
any complaints or post-warranty service.
SAFETY INFORMATION
Please read this manual carefully before use and
keep it for future reference.
1. This appliance may be used by children over the age of 8 years and
persons with limited physical, sensory or mental abilities, or persons
without relevant knowledge and experience, provided they are
supervised or have been instructed in the safe use of this appliance and
understand the hazards involved. Children must not play with the device.
Cleaning and maintenance must not be carried out by children without
adult supervision.
2. Children under 3 years of age must not use the appliance unless they are
supervised at all times.
3. This dryer is for indoor and domestic use only. The warranty will be void in
case of commercial use.
4. Use this product only for laundry with a label that indicates it is suitable
for drying.
5. The manufacturer is not liable for damages caused by improper use or
transport.
6. Do not allow oor coverings to obstruct ventilation openings.
7. Installation and repair of the machine must only be carried out by an
authorised service centre. The manufacturer is not liable for damages
caused by unauthorized repairs.
8. WARNING: Never spray or pour water into the dryer to wash it! There is a
risk of electric shock!
9. Leave at least 3 cm of space between the side and rear walls of the
product. This also applies to the top wall if you intend to place the
appliance under the worktop.
10. Installation / dismantling in the case of installation under the line must
be carried out by an authorized service technician.
ENGLISH

EN
EN - 4 EN - 5
ENGLISH
11. Check the product for damage before installation. Never install or
operate a damaged product.
12. Do not allow pets near the dryer.
13. Fabric softeners or similar products must be used in accordance with the
manufacturer's instructions.
14. Remove all items such as lighters and matches from your pockets.
15. The appliance must not be installed behind a lockable door, sliding door
or door with hinges on the opposite side to the tumble dryer if it prevents
the door from opening fully.
16. WARNING: Keep the ventilation openings in the appliance cabinet or
built-in structure clear of obstructions.
17. Before calling the nearest authorized service center for dryer installation,
make sure that the electrical installation and drainage is appropriate
and in accordance with the instructions for use. If they are not suitable,
contact a qualied electrician and plumber to make the necessary
arrangements.
18. Preparation of the dryer location as well as electrical and wastewater
installation is the responsibility of the customer. Check the dryer for
damage before installation. If the dryer is damaged, do not install it.
Damaged products can endanger your health.
19. Install the dryer on a stable and level surface.
20. Use the dryer in a well-ventilated and dust-free environment.
21. Do not reduce the gap between the dryer and the oor with materials
such as carpets, boards and cloths.
22. Do not cover the ventilation grilles located on the base of the dryer.
23. The room in which the dryer is to be located shall not have lockable,
sliding doors or doors with hinges on the opposite side from the tumble
dryer that could block the full opening of the dryer loading door.
24. After installing the dryer, leave it in the same place where the connection
was made. When installing the dryer, make sure that the back of the
dryer does not touch anything (tap, socket, etc.).
25. The operating temperature of the dryer is from +5°C to +35°C. Operating
outside this temperature range will adversely affect the performance of
the dryer and may damage the appliance.
26. Be careful when transporting the product as it is heavy. Always wear
protective gloves.
27. Always install the dryer against the wall.
28. The rear surface of the dryer must be positioned against the wall.
29. If the dryer is placed on a stable surface, use a spirit level to check that it
is fully stable. If not, adjust the feet until the dryer is stable. Repeat this
procedure each time you move the dryer.
30. Do not place the dryer on the power cord.
Electrical safety
1. The appliance must not be powered via an external switching device
such as a timer or connected to a circuit that is regularly switched on and
off.
2. Do not touch the power plug with wet hands. Always pull the plug to

EN
EN - 6
disconnect the product from the mains, otherwise electric shock may
occur.
3. Connect the dryer to a grounded socket protected by a fuse. The ground
connection must be connected by a qualied electrician. Our company
cannot be held responsible for damage or loss caused by the use of a
dryer without grounding according to local regulations.
4. The voltage and suitable fuse are indicated on the type plate.(Type plate,
see. Overview)
5. The voltage and frequency values on the type plate must be the same as
the mains voltage and frequency values at home.
6. Unplug the dryer when not in use for an extended period of time and
before installation, maintenance, cleaning and repair, otherwise damage
may occur.
7. The socket must be freely accessible after installation.
8. A damaged power cord/plug can cause re or electric shock. If the cable
or plug is damaged, you must replace it. Replacement must only be
carried out by qualied personnel.
9. To avoid the risk of re or electric shock, do not use extension cords,
multiple sockets or adapters to connect the dryer to the mains.
Child safety
1. This appliance must not be used by persons (including children)
with limited physical, sensory or mental abilities, or persons without
appropriate knowledge and experience, unless they are supervised or
have been instructed in the use of this appliance by a person responsible
for their safety.
2. This appliance may be used by children over the age of 8 years and
persons with limited physical, sensory or mental abilities, or persons
without relevant knowledge and experience, provided they are
supervised or have been instructed in the safe use of this appliance and
understand the hazards involved. Children must not play with the device.
Cleaning and maintenance must not be carried out by children without
adult supervision.
3. Do not leave children unsupervised near the appliance.
4. Children could become trapped in the device, leading to a risk of death.
5. Do not allow children to touch the glass door when the appliance is in
use. The surface becomes extremely hot and can cause skin damage.
6. Keep the packaging material out of the reach of children.
7. Poisoning and irritation may occur if detergents and cleaning agents are
consumed or come into contact with the skin and eyes.
8. Keep cleaning products out of the reach of children. Electrical products
are dangerous for children.
9. Keep children away from the product when it is in use.
10. To prevent children from interrupting the dryer cycle, you can use the
child lock to avoid changes to the program you are running.
11. Do not allow children to sit/climb on or inside the product.

EN
EN - 6 EN - 7
Product safety
Due to the risk of re, the following clothes and products must NEVER be dried in the
dryer:
• Do not dry unwashed clothes in the dryer.
• Laundry that has been soiled with substances such as cooking oil, acetone, alcohol,
gasoline, kerosene, stain remover, turpentine, wax and wax remover should be
washed in hot water with extra detergent before tumble drying.
• Wipes and mats that have residues of ammable cleaners or acetone, gas,
kerosene, stain remover, turpentine, candle, wax, wax remover or chemicals.
• Laundry that has residues of hair spray, hair remover and similar substances.
• Laundry on which industrial cleaning chemicals (such as dry cleaning) have been
used.
• Clothes that have any kind of foam, rubber or rubber parts. This includes foam
rubber (latex foam), bathing caps, waterproof textiles, clothing or cushions with
rubber support or items made of rubber foam.
• Items with stufng and damaged items (pillows or jackets). The foam rising from
these items can ignite during drying.
• Operating the dryer in environments that contain coal or our dust may cause an
explosion.
• WARNING: Underwear containing metal reinforcement must not be tumble dried.
The dryer can be damaged if the metal reinforcements become loose or broken
during drying.
R290: Danger of re and damage!
This product contains environmentally safe but am-
mable R290 gas. Protect the product from open
ames and sources of re.
Correct use
1. WARNING: Never stop the appliance until the drying programme has
stopped. If you have to stop the appliance, remove the clothes quickly
and unfold them to cool.
2. WARNING: Make sure that pets do not get into the dryer. Check inside
the dryer before use.
3. WARNING: Overheating of the laundry in the dryer can occur if you stop
the programme or if the power goes out while the dryer is running. This
concentration of heat can cause spontaneous combustion, so always run
the Refresh programme to cool the laundry or quickly remove all laundry
from the dryer and hang it to cool.
4. Use the dryer only for drying in the home and for drying fabrics that are
marked as suitable for drying. All other uses are outside the scope of the
intended use and are prohibited.
5. The warranty will be void in case of commercial use.
6. This appliance is intended for domestic use only and should be placed on
a level and stable surface.
7. Do not sit or lean against the dryer door. The dryer could tip over.
8. To maintain a temperature that does not damage the laundry (e.g. to
prevent the laundry from catching re), the cooling process starts after
heating. The programme will then be terminated. Always remove the

EN
EN - 8
clothes immediately at the end of the programme.
9. WARNING: Never use the dryer without a lint lter or with a damaged
lter.
10. The textile bre lters must be cleaned after each use as described in the
section Cleaning the textile bre lter.
11. After wet cleaning, the textile bre lters must be dried. Wet lters can
cause malfunctions during drying.
12. You must not allow lint accumulation around the dryer drum (does not
apply to appliances that are to be vented to the exterior of the building)
13. IMPORTANT NOTE: Do not reduce the gap between the dryer and the
oor with materials such as carpets, boards and cloths, otherwise the
dryer will not receive sufcient air.
14. Do not place the dryer in rooms where there is a risk of freezing. Freezing
temperatures adversely affect dryer performance. Condensed water that
freezes the pump and hose can cause damage.
Mounting above the washing machine
1. WARNING: The washing machine cannot be placed on the dryer. When
installing the dryer above the washing machine, please observe the
following warnings.
2. WARNING: The dryer can only be placed on washing machines that have
the same or larger capacity.
3. In order to use a dryer that is placed on top of a washing machine, there
must be a xing section between the two products. The xing part must
be attached by an authorised service technician.
4. When the dryer is placed on top of the washing machine, the total
weight of these products can reach almost 150 kilograms (fully loaded).
Place appliances on a solid oor that has sufcient load-bearing capacity!
Installation table for washing machine and dryer
Dryer
(Depth)
Washing machine
37-41 cm 42-45 cm 46-49 cm 50-56 cm 57-63 cm
52.5 cm X
56 cm X X
61 cm XXX
64 cm XXXX
(For more details, see Section 7. Technical specications)
In order to place the dryer on top of the washing machine, it is necessary to use a spe-
cial pull-down kit as a separate attachment. Please contact customer service for more
information. Assembly instructions will be supplied with the download kit

EN
EN - 8 EN - 9
1 Upper tray
2 Control panel
3 Loading door
4 Plinth
5 Plinth opening slot
6 Ventilation grills
7 Adjustable feet
8 Plinth cover
9 Type plate
10 Lint lter
11 Drawer Cover
SGR-TD-H721W SGR-TD-H911W
Height 845 mm 845 mm
Width 596 mm 596 mm
Depth 525 mm 609 mm
Capacity 7 kg 9 kg
Weight 41.9 kg 51.4 kg
Voltage 220–240 V 220–240 V
Power consumption 1000 W 1000 W
* Min. height: Height with adjustable legs is not available. Max. height: Height with
adjustable legs extended to maximum.
** Dry laundry weight before washing.
IMPORTANT NOTE: To improve the quality of the dryer, technical specications may
be changed without notice.
IMPORTANT NOTE: These values were obtained in a laboratory environment accord-
ing to the relevant standards. These values may vary depending on environmental
conditions and the use of the dryer.
WARNING:
1. For safety reasons, regulations require a space of at least 1 m³ per 8 g of refrigerant
for this type of equipment. For 110 g (SGR-TD-H721W) / 150 g (SGR-TD-H911W) of
propane, the minimum allowable room size would be 13.75m3 (SGR-TD-H721W) /
18.75m3 (SGR-TD-H911W).
2. Coolant: Risk of re/risk of poisoning/risk of material damage and damage to the
appliance. The appliance contains a coolant, R290, which is environmentally safe
but ammable. Improper disposal can cause a re or poisoning hazard. Dispose
of the appliance in an appropriate manner, taking care not to damage the
refrigeration circuit piping.
• Type of refrigerant: R290
3

EN
EN - 10
• Amount of gas: 110 g (SGR-TD-H721W) / 150 g (SGR-TD-H911W)
• PDO (Potential Depletion of Ozone): 0
• PGO (Potential Global Warming): 3
3. Danger of explosion and re! Remove all lighters and matches from your pockets.
4. Do not place the dryer next to open ames or sources of re.
INSTALLATION
Connection to waste (with optional drain hose)
For products equipped with a heat pump, water accumulates in the water tank during
the drying cycle. You must drain the accumulated water after each drying cycle. You
can drain the accumulated water directly into the drain via the drain hose that comes
with the appliance instead of regularly pouring out the water collected in the water
tank.
Connecting the drain hose
5. Pull and remove the end of the hose from the back of the dryer. Do not use any
tools to remove the hose.
6. Connect one end of the drain hose supplied with the dryer to the connection point
from which you removed the hose in the previous step.
7. Connect the other end of the drain hose directly to the drain or sink.
Warning:
The hose must be connected in such a way that it cannot come loose. If
the hose becomes disconnected during the water discharge, the house
could ood.
Note:
Connect the drain hose to a maximum height of 80 cm.
Make sure that the drain hose is not bent and is not wedged between the
drain and the appliance.
Adjusting the feet
• To work with less noise and vibration, the dryer must be stable and balanced on
legs. Adjust the feet to ensure the product is balanced.
• Turn the feet left or right until the dryer is horizontal.
Note:
Never remove the adjustable feet.
Electrical wiring
Warning:
There is a risk of electric shock.
• Your dryer is set to 220-240 V and 50 Hz.
Note:
XXXXXXXXXXXXXXXXXXXXXXXXXX

EN
EN - 10 EN - 11
• The dryer's power cord is equipped with a special connector. This connector must
be connected to a grounded outlet protected by a 16 amp fuse as indicated on the
type plate. The fuse for short-circuit protection of the power line where the outlet is
connected must also be 16 amps. If you do not have such an outlet or fuse, contact
a qualied electrician.
• Our company is not responsible for damage caused by use without earthing.
• IMPORTANT NOTE: Operating the equipment at low voltage will shorten the life
and reduce the performance of your machine.
Mounting under the line
• Leave at least 3 cm of space between the side and rear walls of the product. This
also applies to the top wall if you intend to install the appliance under the counter.
• Installation / dismantling in the case of installation under the line must be carried
out by an authorized service technician.
LAUNDRY PREPARATION
Sorting laundry for drying
Always follow the instructions on the garment labels. Only dry clothes with a label
stating that they are suitable for tumble drying.
• Do not use the dryer with quantities and types of laundry that are not listed in the
Dryer Capacity section.
Suitable for tumble
drying
No need to iron Sensitive/Mild drying
Not suitable for tum-
ble drying
Do not dry
Do not chemically
clean At any temperature At high temperatures
At medium temper-
atures At low temperatures Without heating Dry hung

EN
EN - 12
Spread to dry Hang wet to dry Spread in shadow
to dry
Suitable for dry
cleaning
Do not dry thin, multi-ply or thick fabrics together as they dry at different tempera-
tures. For this reason, dry clothes together that have the same texture and fabric type.
This way you achieve even drying. If you think the laundry is still damp, you can select
a time programme for the next drying.
Please dry large items (such as duvets) and small items separately so that you don't
have damp clothes.
IMPORTANT NOTE: Woollen, silk garments, delicate and valuable fabrics, airtight
pieces and tulle curtains are not suitable for machine drying.
Preparing laundry for drying
Danger of explosion and re!
Remove all items such as lighters and matches from your pockets. The
dryer drum and fabrics can be damaged.
• Laundry can be tangled together after washing. Separate items of laundry before
putting them in the dryer.
• Remove all items from the pockets and do the following:
• Tie cloth belts, apron strings and the like together, or use a laundry bag.
• Fasten the zippers, buckles and fasteners, and the buttons on the linen.
• To get the best drying result, sort the laundry according to the fabric type and
drying programme.
• Remove buckles and other metal parts of the garment.
• Fabrics such as T-shirts and knitted garments usually shrink the rst time they
are dried. Use the gentle programme.
• Do not interfere with synthetic
materials. Use sparing.
• When washing laundry you want
to dry, adjust the amount of
fabric softener according to the
manufacturer's specications.
Dryer capacity
Follow the instructions in the "Programme
and consumption table" section. (See Pro-
grams and Consumption Table). Do not
load more laundry than the capacity value
shown in the table.
IMPORTANT NOTE: It is not recommend-
ed to load laundry into the dryer that ex-
ceeds the value shown in the illustration.
If the appliance is overloaded, the drying

EN
EN - 12 EN - 13
performance will be reduced. In addition, damage to the dryer and laundry can occur.
Laundry Dry laundry weight (g)
Bedsheet (double) 725
Pillowcase 240
Bath Towel 700
Hand Towel 225
Shirt 190
Cotton Shirt 200
Jean 650
Fabric - Gabardine Trousers 400
T-shirt 120
USE OF THE DRYER
Control panel
1. Program selection knob
2. Electronic indicator and other
functions

EN
EN - 14
Program selection knob
Use the programme selection knob to select the desired drying programme
Electronic indicator and other functions
Symbols on the screen:
Water tank warning indicator
Lint lter cleaning warning indicator
Heat exchanger cleaning warning indicator
Programme and consumption table
Press the Start/Pause button to start the program. The Start/Pause light indicates that
the programme has started and the drying light comes on.

EN
EN - 14 EN - 15
SGR-TD-H721W
Program Icon Load (kg)
Washing
machine
spin speed
Approximate
amount of
remaining
humidity
Drying time
(minutes)
Cotton Extra Dry 7 1000 60 % 196
Cotton Cupboard Dry 7 1000 60 % 178
Cotton Iron Dry 7 1000 60 % 133
Synthetics Cupboard
Dry 3.5 800 40 % 83
Synthetics Iron Dry 3.5 800 40 % 54
Delicate 2 600 50 % 51
Time drying ----
Baby Care 3 1000 60 % 90
Duvet 4 1000 60 % 133
Sport 4 800 40 % 82
Mix 4 1000 60 % 122
Wool Refresh ---5
Refresh ---10
Express 34' 1 1200 50 % 34
Shirts 20' 0.5 1200 50 % 20
Energy consumption values
Program Load (kg)
Speed
revolutions
in the washing
machine
Approximate
amount of
remaining
moisture
Energy
consumption
values (kWh)
Cotton Cupboard Dry 7 1000 60 % 1.70
Cotton Iron Dry 7 1000 60 % 1.35
Synthetics Cupboard
Dry
3.5 800 40 % 0.75

EN
EN - 16
Power consumption in the “off mode” PO(W) 0.5
Power consumption in the “on mode” PO(W) 1
SGR-TD-H911W
Program Icon Load (kg)
Speed
revolutions
in the wash-
ing machine
Approximate
amount of
remaining
moisture
Drying time
(minutes)
Cotton Extra Dry 9 1000 60 % 210
Cotton Cupboard Dry 9 1000 60 % 205
Cotton Iron Dry 9 1000 60 % 148
Synthetics Cupboard
Dry 4.5 800 40 % 84
Synthetics Iron Dry 4.5 800 40 % 60
Delicate 2 600 50 % 58
Time drying ----
Baby Care 3 1000 60 % 87
Duvet 2.5 800 60 % 109
Extra silent 9 1000 60 % 244
Mix 4 1000 60 % 112
Wool 1.5 600 50 % 160
Refresh ---10
Express 45' 1 1200 50 % 45
Shirts 30' 0.5 1200 50 % 30
Energy consumption values
Program Load (kg)
Speed
revolutions
in the washing
machine
Approximate
amount of
remaining
moisture
Energy
consumption
values (kWh)
Cotton Cupboard Dry 9 1000 60 % 1.57

EN
EN - 16 EN - 17
Cotton Iron Dry 9 1000 60 % 1.15
Synthetics Cupboard
Dry
4.5 800 40 % 0.64
Power consumption in the “off mode” PO(W) 0.5
Power consumption in the “on mode” PO(W) 1
The "Cotton Cupboard Dry" programme used on full and partial loads is
the standard drying programme for which the relevant information is
on the label and information sheet. This programme is the most ener-
gy-efcient programme for drying normal damp cotton laundry.
*Standard energy label programme (EN 61121: 2013)
All values in the table were determined in accordance with EN 61121: 2013. Consump-
tion values may vary from those in the table depending on fabric type, wringing meth-
od, ambient conditions and changes in tension.
Additional features
A table summarising the options that can be selected in the programmes is shown
below.
Option Description
Drying intensity
The drying intensity can be increased by 3 levels. In this
way, the desired level of dryness can be selected. Levels that
can be selected other than the default settings: 1, 2, 3. Once
selected, the corresponding drying level indicator light will
illuminate.
Delicate Delicate fabrics are dried for a longer time at a low tempera-
ture.
Anti-Crease
If you select "Anti-crease" and do not open the dryer door at
the end of the programme, the 1 hour anti-crease phase will
be extended to 2 hours. You will hear an audible alert when
you select the "Anti-squeeze" option. To cancel this option,
press the same button again. If you open the appliance door
or press the Start/Pause button during the crease protection
phase, this phase will be cancelled.
Delayed start
You can delay the start time of the programme by selecting
1 to 23 hours. You can activate the desired snooze time by
pressing the Start/Pause button. After the time has elapsed,
the selected programme will start automatically. During the
snooze period, program-compatible options can be activat-
ed/deactivated. Holding the Snooze Start button will change
the snooze time repeatedly.

EN
EN - 18
Option Description
To cancel the sound
alert
The dryer will sound an audible warning when the pro-
gramme selection knob is turned, when the button is
pressed and at the end of the programme. To cancel the
sound alert, press and hold the "Gentle" button for 3 seconds.
When you press the button, you will hear an audible alert
that this option is cancelled.
Timed drying
If the knob is in the Timed Drying programme position, the
selection can be made by pressing the Timed Drying button
and the programme will start by pressing the Start/Pause
button. Hold down the Timed Drying button to change the
drying time.
Child lock
The appliance is equipped with a child lock to prevent
changes in the program if the buttons are pressed during the
program. To activate the child lock, press and hold the "Gen-
tle" and "Anti-crease" buttons simultaneously for 3 seconds. If
the child lock is activated, all buttons will be deactivated. The
child lock is not automatically deactivated when the program
is nished. To deactivate the child lock when the programme
is nished, set the programme selection knob to "Off". Then
set the program selection knob to the rst position. The child
lock is still active. To deactivate the child lock, press and hold
the "Gentle" and "Anti-crease" buttons simultaneously for 3
seconds. When the child lock is activated/deactivated, the
display will show "CL" for 2 seconds and then switch off and
sound an audible warning. Warning: If the appliance is run-
ning or the child lock is active and you turn the programme
selection knob, you will hear an audible warning and the
display will show "CL" for 2 seconds and then disappear. If
you turn the programme selection knob, an audible warning
sounds. Even if you set the program selection knob to an-
other program, the previous program will continue to run. To
select a new programme, you must deactivate the child lock
and then adjust the programme selection knob.
Starting the program
The Start/Pause light will ash while the program is selected. Press the Start/Pause
button to start the program. The Start/Pause light will illuminate to indicate that the
program has started.
SGR-TD-H721W
Program Description
Cotton Extra Dry
This programme dries thick and multi-layered fabrics, such
as cotton towels, bedsheets, pillowscases, bathrobes, at a
normal temperature to allow you to place them in a closet.
Cotton Cupboard
Dry
This programme dries cotton pyjamas, underwear, table-
cloths, etc. to allow you to place them in a closet.

EN
EN - 18 EN - 19
Program Description
Cotton Iron Dry This programme dries cotton laundry to prepare it for iron-
ing. Laundry removed from the machine will be damp.
Synthetics Cupboard
Dry
This programme dries synthetics, such as shirts, T-shirts,
blouses to allow you to place them in a closet.
Synthetics Iron Dry
This programme dries synthetics such as shirts, T-shirts,
blouses to prepare them for ironing. Laundry removed from
the machine will be damp.
Delicate
This programme dries thin clothes like shirts, blouses, and
silk garments at a low temperature to make them ready to
wear.
Time Drying
To reach the required drying level at a low temperature, you
can use time programmes of 20 min. to 200 min. Regardless
of the drying level, the programme stops at the desired time.
Baby Care This programme dries delicate infant clothes to make them
ready to wear.
Duvet This programme is used to dry duvets.
Sport Sport program is used for synthetic sport laundries like
shorts, t-shirts.
Mix This programme dries cotton-synthetic mixed garments that
do not discolour to make them ready to wear.
Wool Refresh
Wool refresh helps wool textiles to remove excess water after
washing by applying low temperature and gentle move-
ments of drum.
Refresh
Time drying option is selected from 10 minutes to 120
minutes without providing hot air, refresh is done and bad
odors can be eliminated.
Express 34ʼ 1 kg of cotton shirts spun at a high speed in the washing
machine are dried in 34 minutes.
Shirt 20ʼ 2 to 3 shirts are ready for ironing in 20 minutes.

EN
EN - 20
SGR-TD-H911W
Program Description
Cotton Extra Dry
This programme dries thick and multi-layered fabrics, such
as cotton towels, bedsheets, pillowscases, bathrobes, at a
high temperature to allow you to place them in a closet.
Cotton Cupboard
Dry
This programme dries cotton pyjamas, underwear, table-
cloths, etc. to allow you to place them in a closet.
Cotton Iron Dry This programme dries cotton laundry to prepare it for iron-
ing. Laundry removed from the machine will be damp.
Synthetics Cupboard
Dry
This programme dries synthetics, such as shirts, T-shirts,
blouses, at a lower temperature compared to the cottons
programme to allow you to place them in a closet.
Synthetics Iron Dry
This programme dries synthetics such as shirts, T-shirts,
blouses, at a lower temperature compared to the cottons
programme to prepare them for ironing. Laundry removed
from the machine will be damp.
Delicate
This programme dries thin clothes like shirts, blouses, and
silk garments at a low temperature to make them ready to
wear.
Time Drying
To reach the required drying level at a low temperature, you
can use time programmes of 20 min. to 200 min. Regardless
of the drying level, the programme stops at the desired time.
Baby Care This programme dries delicate infant clothes to make them
ready to wear.
Duvet This programme is used to dry duvets.
Extra Silent
Silent programme operates the tumble dryer by decreasing
noise emitted to environment. The feeling of noise decreases
almost 50 % compared to Cotton Cupboard Dry programme.
Mix This programme dries cotton-synthetic mixed garments that
do not discolour to make them ready to wear.
Wool
Use this programme for gentle drying of woolen clothes,
washed as stated in the washing instructions. Take out the
clothes at the end of the drying cycle.
Refresh
Time drying option is selected from 10 minutes to 120
minutes without providing hot air, refresh is done and bad
odors can be eliminated.
Express 45ʼ 1 kg of synthetics shirts spun at a high speed in the washing
machine are dried in 45 minutes.
Shirt 30ʼ 2 to 3 shirts are ready for ironing in 30 minutes.
