Siku TS20 User manual

THERMO-
SWITCH
SOCKET
TS20
Utilization examples:
Temperature regulation
of connected appliance
DESCRIPTION OF
CONTROLS
Fce
P
= selection of functions
= selection of temperatures
= confirmation (ENTER),
information on required
temperature (PO:t),
present time/temperature
(CL:O/tE:P), sum of
operating hours (SU:MA),
and day (dE:n)
= setting of
temperature,time,
functions
/+
electric
heating
plates
direct
heating
bodies
electric
tubular
radiators
build-in temperature
sensor

DISPLAY DESCRIPTION
OPERATING INSTRUCTIONS
Setting of current day and time - “ CLO “ function
1. Functions of TS20
2. Proceed during programming
indication of set time and
temperature program
indication of
operating mode
indication of temperatures
comfort
economy
party
indication of time/
temperature
After connection in 230V-socket is TS20 immediately ready for use. If sign
dO:bI is flashing on the display, the back-up battery is not fully charged
and it is necessary let the TS20 in 230V-socket to charge for minimal 2
days (full charge take about 4 days). After charging it is possible to remove
TS20 from socket without losing the actual time and you can provide the programming outside
the 230V-socket. (Maximal backup time is 100 hours).
If we disconnect TS20 from the network 230V, the TS20 comes to stanby mode and
only actual time will be shown on display (the colon symbol will not be flashing) and the
buttos will be functionless. The activation of the buttons you can make by pressing the
button. When the sign dObI will be permanently shown on display, it is not possible
to make any settings on TS20 without connection into 230VAC
If the TS20 is not in 230V-socket the showed temperature is 2 °C lower than real actual temperature.
After pushing the button you can select following functions by pushing
Fce
Fce
Fce
/+
/+
/+
/+
/+
: thermo-switch socket works according to program as set.
: serves for manual setting of temperature ( the selection by or by
buttons), the temperature should be constant up to next change of mode.
: setting of present day and time.
: setting of parameters (constants).
: programming mode.
: in this mode, TS20 is permanently switched-off .
P
1. AUTO
2. MANU
3. CLO
4. PAr
5. PROG
6. OFF
Note: If you do not push any button in 2 minutes, TS20 returns into set mode. Longer pushing of
buttons speeds up their functions.
Before the programming itself, it is necessary to set present day, time and parameters (constants),
namely in following way.
Press the button, by pressing select CLO (CLOCK)
function and confirm by . Indication of hours blinks on the display,
use buttons to set required data and confirm by button.
Use the same method for minutes and day (d:1represents Monday,
d:2 Tuesday and d:7Sunday). After the completion of setting, press
button to return.

Setting of parameters (constants) - “ PAr “ function
PA:r1 Display option
PA:r2 economic temperature (the 17°C temperature is factory - set)
PA:r3 comfort temperature (the 23°C temperature is factory - set)
PA:r4 party temperature (the 25°C temperature is factory - set)
PA:r5 Hystereze (0,5°C set by default)
PA:r6 Summer mode = switching on of cooling system
PA:r9 Firmwareversion/ factory setting restoration (see page 5)
- Press the button, by pressing select Par (Parameters)
and confirm by .
- PA:r1 shows on the display, confirm by and with using of
buttons select display options in basic mode:
Fce
Fce
/+
/+
/+
/+
/+
/+
/+
P
tinformation on present temperature
Ccurrent time
Press button to confirm.
-PA:r2 shows on the display
- confirm by and with using of buttons set economic
temperature and press button to confirm
-PA:r3 shows on the display
- confirm by and with using of buttons set comfort
temperature and press button to confirm
-PA:r4 shows on the display
- confirm by and with using of buttons set party
temperature and press button to confirm
-PA:r5 shows on the display
- confirm by with using of buttons set the hysterese
from 0,1 to 2 °C and press button to confirm
-PA:r9 shows on the display
- Firmware version for information only
- press button button to return.
-PA:r6 shows on the display, confirm by .
- choose in summer time. By this mode will be your attached cooling
system switched on by required temperature. In this mode the
hysterese will work conversely (for example: PA:r5=0.5 and required
temperature = 23 °C, TS20 switch on by 23,5 °C).
- using of buttons choose required mode, press button to
confirm
HYSTEREZE = (temperature difference between switching on and off of the appliance)

Fce
Fce
Fce
/+
/+
/+
/+
P
P
Programming- “ PROG “ function
EXAMPLE of Programm setting
Short-term change of temperature in AUTO mode:
- Press the button, by pressing buttons select PROG
(PROGRAMMING) function and confirm by .
- By repeated pressing of buttons select one of following
options:
d:1 Monday
d:2 Tuesday
d:3 Wednesday
d:4 Thursday
d:5 Friday
d:6 Saturday
d:7 Sunday
d1:5 Monday to Friday
d6:7 Saturday to Sunday
d:1:7 all week
Tabel for day selection
- Confirm by , button. The sign 1:U1 shows on display for
setting up of the first time interval
- by pressing buttons set the time of first change (min. step
of 10 min.)
- assign comfort, economic or party temperature to the setting time
by repeated pressing of button
- Confirm by , display automatically shows symbol 1:U2 (the
second time interval in the first day).
- Use the same procedure for the setting of further time intervals (max. 6). Leave the
programming regime by pressing button.
- Select AUTO function, TS20 starts to work according to the program set.
Status indication of TS20:
AUTO (or MANU) is shown = output is switched on
AUTO (or MANU) blinks = output is switched off
1, Set on 18°C (PA:r2)
2, Set on 23°C ein (PA:r3)
3, Set Pon 25°C ein (PA:r4)
4, Choose programmig of whole week d1:7(Prog)
5, 17:U1 assig time 6:00 and temperature
6, 17:U2 assig time 9:00 and temperature
7, 17:U3 assig time 13:00 and temperature
8, 17:U4 assig time 16:00 and temperature
9, 17:U5 assig time 19:00 and temperature
10,17:U6 assig time 22:00 and temperature
11, Leave the programming regime by pressing
button and select AUTO mode.
By simple pressing of buttons in AUTO mode, it is possible to make a short-
term change of required temperature. TS20 will maintain this temperature up to next
temperature change as defined in the program.
Mo - Su
[hours]
programm process on LCD

Fce
Fce
Fce
Fce
Fce
/+
/+
+
/+
/+
P
P
P
P
= °C = °C = °C
It serves for keyboard blocking, as a protection against unauthorized handling.By
simultaneous pressing of , and buttons the keyboard is locked (buttons
are inactive) . Message LOC (LOCK) is shortly displayed.The function
can be cancelled, e.g. the keyboard unblocked, by simultaneous
pressing of , and buttons (the buttons are again
functioning from now).
“ OFF “ function:
Child lock:
! RESET - restoring the default settings
Installation:
Error messages:
Press the button, by pressing button select OF:F
function and confirm by button.
In this way, TS20 ispermanently switched off. In this mode, symbol OF:F and data on
current temperature/time are showed alternatively on the display. To cancel this function,
press button and select different mode with using of buttons.
Erasing of programms:
- Press the button, by pressing select function Par and confirm by
button
- By pressing buttons select PA:r9, confirm by
- Simultaneously press and buttons, it will restore the factory settings!
Note: Use only when necessary, all saved changes will be deleted!
1. Connect TS20 in 230V/50 Hz socket and let it charge for approx. 12 hours.
2.Program it according to instructions (register respective data in the table).
3.Connect the heating body you want to regulate.
If following error message is shown on the display, contact immediately the
manufacturer (it is dealing with a failure of temperature sensor).
Table for registration of your programs
The temperature and
time set
123456
Mon
Tue
Wed
Thu
Fri
Sat
Sun
Day progr.

Power 230 V/50 Hz
Number of adjustable temp. 3 different temperatures for each day
Hysteresis 0,1 to 2°C in steps of 0,1°C
Minimal programming time 10 minute
Range of possible temp. 3 to 40°C
Step of temperature setting by 0,5°C
Minimal step of indication 0,1°C
Measurement accuracy ± 1 °C
Back-up battery NiMH 2,4 V/ > 100 hours
Output relay, max. 16 A
THERMO-SWITCH SOCKET TS20
TS20 is a digitally switched socket for automatic regulation of electrical heating sys-
tems (direct heating bodies, towel driers, fires) in family houses, flats,offices. Up to
six time intervals with three temperature levels can be set for each day.
Further advantages:
different temperature program for each day
the possibility to set three temperature levels ( , , P )
setting the HYSTERESIS in the range from 0,1°C to 2°C
simple control and programming
possibility to make a short-term change in program temperature
permanent switching off of the appliance ( OFF )
temperature regulation at steps of 0,5°C
well-arranged display
back-up battery NiMH 2,4 V, for more than 100 operating hours
Specification of TS20
CERTIFICATE OF GUARANTEE
(guarantee period for the product amounts to 2 years)
product No.:
examined by::
date of sale::
stamp of shop:
