Emerson Rosemount FS-IR-975 User manual

Reference Manual
00809-0500-4975, Rev DD
May 2022
Rosemount™ FS-IR-975
Flame Simulator

Safety information
WARNING
All individuals who have or will have responsibility for using, maintaining, or servicing this product must read this manual
thoroughly.
WARNING
Physical access
Unauthorized personnel may potentially cause significant damage to and/or misconfiguration of end users’ equipment. This could
be intentional or unintentional and needs to be protected against.
Physical security is an important part of any security program and fundamental to protecting your system. Restrict physical access
by unauthorized personnel to protect end users’ assets. This is true for all systems used within the facility.
NOTICE
The device is not field-repairable due to the meticulous alignment and calibration of the sensors and the respective circuits.
Do not attempt to modify or repair the internal circuits or change their settings, as this will impair the system's performance and
void the Emerson product warranty.
Legal notice
The device described in this document is the property of Emerson.
No part of the hardware, software, or documentation may be reproduced, transmitted, transcribed, stored in a retrieval system,
or translated into any language or computer language, in any form or by any means, without prior written permission from
Emerson.
While great efforts have been made to ensure the accuracy and clarity of this document, Emerson assumes no liability resulting
from any omissions in this document or from misuse of the information obtained herein. The information in this document has
been carefully checked and is believed to be entirely reliable with all of the necessary information included. Emerson reserves the
right to make changes to any products described herein to improve reliability, function, or design and reserves the right to revise
this document and make changes from time to time in content hereof with no obligation to notify any persons of revisions or
changes. Emerson does not assume any liability arising out of the application or any use of any product or circuit described herein;
neither does it convey license under its patent rights or the rights of others.
2

Warranty
1. Limited Warranty . Subject to the limitations contained in Section 2 (Limitation of Remedy and Liability) herein, Seller
warrants that (a) the licensed firmware embodied in the Goods will execute the programming instructions provided by
Seller; (b) that the Goods manufactured by Seller will be free from defects in materials or workmanship under normal use
and care; and (c) Services will be performed by trained personnel using proper equipment and instrumentation for the
particular Service provided. The foregoing warranties will apply until the expiration of the applicable warranty period. The
flame simulator is warranted against defective parts and workmanship for 24 months from the date of purchase, the
battery for 12 months, and the charger for 6 months. Products purchased by Seller from a third party for resale to Buyer
(Resale Products) shall carry only the warranty extended by the original manufacturer. Buyer agrees that Seller has no
liability for Resale Products beyond making a reasonable commercial effort to arrange for procurement and shipping of
the Resale Products. If Buyer discovers any warranty defects and notifies Seller thereof in writing during the applicable
warranty period, Seller shall, at its option, (i) correct any errors that are found by Seller in the firmware or Services; (ii)
repair or replace FOB point of manufacture that portion of the Goods found by Seller to be defective; or (iii) refund the
purchase price of the defective portion of the Goods/Services. All replacements or repairs necessitated by inadequate
maintenance; normal wear and usage; unsuitable power sources or environmental conditions; accident; misuse; improper
installation; modification; repair; use of unauthorized replacement parts; storage or handling; or any other cause not the
fault of Seller, are not covered by this limited warranty and shall be replaced or repaired at Buyer's sole expense and Seller
shall not be obligated to pay any costs or charges incurred by Buyer or any other party except as may be agreed upon in
writing in advance by Seller. All costs of dismantling, re-installation, freight and the time and expenses of Seller's
personnel and representatives for site travel and diagnosis under this limited warranty clause shall be borne by Buyer
unless accepted in writing by Seller. Goods repaired and parts replaced by Seller during the warranty period shall be in
warranty for the remainder of the original warranty period or 90 days, whichever is longer. This limited warranty is the
only warranty made by Seller and can be amended only in a writing signed by an authorized representative of Seller. The
limited warranty herein ceases to be effective if Buyer fails to operate and use the Goods sold hereunder in a safe and
reasonable manner and in accordance with any written instructions from the manufacturers. THE WARRANTIES AND
REMEDIES SET FORTH ABOVE ARE EXCLUSIVE. THERE ARE NO REPRESENTATIONS OR WARRANTIES OF ANY KIND,
EXPRESSED OR IMPLIED, AS TO MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, OR ANY OTHER MATTER WITH
RESPECT TO ANY OF THE GOODS OR SERVICES.
2. Limitation of Remedy and Liability SELLER SHALL NOT BE LIABLE FOR DAMAGES CAUSED BY DELAY IN PERFORMANCE.
THE REMEDIES OF BUYER SET FORTH IN THE AGREEMENT ARE EXCLUSIVE. IN NO EVENT, REGARDLESS OF THE FORM OF
THE CLAIM OR CAUSE OF ACTION (WHETHER BASED IN CONTRACT, INFRINGEMENT, NEGLIGENCE, STRICT LIABILITY,
OTHER TORT, OR OTHERWISE), SHALL SELLER'S LIABILITY TO BUYER AND/OR BUYER'S CUSTOMERS EXCEED THE PRICE TO
BUYER OF THE SPECIFIC GOODS MANUFACTURED OR SERVICES PROVIDED BY SELLER GIVING RISE TO THE CLAIM OR
CAUSE OF ACTION. BUYER AGREES THAT IN NO EVENT SHALL SELLER'S LIABILITY TO BUYER AND/OR BUYER'S CUSTOMERS
EXTEND TO INCLUDE INCIDENTAL, CONSEQUENTIAL, OR PUNITIVE DAMAGES. THE TERM "CONSEQUENTIAL DAMAGES"
SHALL INCLUDE, BUT NOT BE LIMITED TO, LOSS OF ANTICIPATED PROFITS, REVENUE, OR USE AND COSTS INCURRED
INCLUDING WITHOUT LIMITATION FOR CAPITAL, FUEL AND POWER, AND CLAIMS OF BUYER'S CUSTOMERS.
Release history
Revision Date Revision History
A June 2016 First release
B August 2017 Updated certification information.
C March 2018 Updated approval information and charging instructions.
DA February 2020 Updated approval marking.
DB September 2020 Updated battery power specifications, reorganized sections, changed
terminology, and added section on RoHS directive.
DC June 2021 Updated approvals.
DD November 2021 Added UK CA certification and reorganized chapters.
3

4

Contents
Chapter 1 Introduction.............................................................................................................. 7
1.1 Flame simulator compatibility with flame detector models..........................................................7
1.2 Features and benefits...................................................................................................................7
1.3 Principles of operation................................................................................................................. 7
1.4 Structure..................................................................................................................................... 8
Chapter 2 Operation................................................................................................................ 11
2.1 Unpacking................................................................................................................................. 11
2.2 Operate..................................................................................................................................... 11
2.3 Simulator status.........................................................................................................................12
2.4 Charge the battery.....................................................................................................................12
2.5 Replace the battery....................................................................................................................13
Chapter 3 Troubleshoot........................................................................................................... 15
3.1 LED flashes three times in three consecutive cycles....................................................................15
3.2 LED flashes three times in five consecutive cycles...................................................................... 15
3.3 LED does not turn on..................................................................................................................15
3.4 Flame simulator seems to work properly but does not activate the flame detector.................... 15
Chapter 4 Maintenance............................................................................................................17
Chapter 5 Ordering information...............................................................................................19
Chapter 6 Technical specifications............................................................................................21
6.1 Detection ranges per detector/flame simulator......................................................................... 21
6.2 General specifications................................................................................................................21
6.3 Electrical specifications..............................................................................................................21
6.4 Physical specifications................................................................................................................22
6.5 RoHS directive........................................................................................................................... 22
6.6 Electromagnetic interference (EMI) compatibility......................................................................22
Chapter 7 Product certifications...............................................................................................23
7.1 ATEX and IECEx.......................................................................................................................... 23
7.2 UK CA........................................................................................................................................ 23
7.3 TR CU.........................................................................................................................................23
7.4 InMetro......................................................................................................................................23
7.5 Certification instructions........................................................................................................... 24
Chapter 8 Technical support.....................................................................................................27
Reference Manual Contents
00809-0500-4975 May 2022
Rosemount FS-IR-975 5

Contents Reference Manual
May 2022 00809-0500-4975
6 Emerson.com/Rosemount

1 Introduction
To comply with local standards and jurisdictional authorities, perform end-to-end loop
testing of fire protection alarm systems, including detectors, periodically. Many safety
authorities and plant managers of high value/high risk assets and facilities insist on
quarterly end-to-end testing of their entire fire protection systems using an external flame
simulator.
Rosemount Flame Simulators emit electromagnetic radiation in a unique sequential
pattern corresponding to and recognizable as fire by the specific Rosemount 975 Flame
Detector. This allows the detector to be tested under real fire conditions without the
associated risk of an open flame.
Rosemount Flame Simulators are ATEX certified EExd for use in Zone 1, Zone 2, Zone 21,
and Zone 22 hazardous areas and are powered by rechargeable lithium ion batteries.
When fully charged, the Flame Simulator will operate for at least 1,000 tests without
recharging.
The Rosemount Flame Simulator is the only non-hazardous and safe method to test the
flame detector's sensors, internal electronics, alarm activation software, cleanliness of the
viewing window/lens, wiring integrity, actual relay activation, and proper functionality of
any other outputs used (mA, RS-485, or HART®).
1.1 Flame simulator compatibility with flame
detector models
The Rosemount FS-IR-975 Flame Simulator is compatible with the following:
Table 1-1: Flame simulator compatibility
Simulator Part number Compatible with
Multi-spectrum infrared flame simulator FS-IR-975 Rosemount 975MR
1.2 Features and benefits
•Used for maintenance and testing of flame detectors.
•Can activate the flame detector from a distance of 39.4 ft (12 m).
•Includes rechargeable battery.
•Operates at least 1,000 tests before the battery must be recharged.
1.3 Principles of operation
The Rosemount FS-IR-975 emits infrared energy, which is filtered to emit electromagnetic
radiation in a sequential pattern corresponding to the Rosemount 975MR Flame Detector.
Reference Manual Introduction
00809-0500-4975 May 2022
Rosemount FS-IR-975 7

1.4 Structure
This device is built from black coated aluminum housing. It includes:
•Reflector
•Electronic compartment
•Battery compartment
•Hand grip
The electronic compartment includes a PC board with an infrared (IR) or halogen lamp,
which is assembled on the PC board and emits the light through a sapphire window.
The battery compartment includes a battery pack containing four lithium ion batteries of
total 14.8 Vdc and 2.6 Ah.
Figure 1-1: Flame Simulator side view
A. Electronic compartment
B. Battery compartment
C. Battery compartment cover
D. Hand grip
E. Reflector
F. Push button
G. Sight
Introduction Reference Manual
May 2022 00809-0500-4975
8 Emerson.com/Rosemount

Figure 1-2: Flame Simulator rear view
A. Hand grip
B. Reflector
C. Sight
D. Back cover locking screw
Reference Manual Introduction
00809-0500-4975 May 2022
Rosemount FS-IR-975 9

Figure 1-3: Flame Simulator front view
A. Hand grip
B. Push button
C. Sight
D. Laser diode
Related information
Charge the battery
Replace the battery
Introduction Reference Manual
May 2022 00809-0500-4975
10 Emerson.com/Rosemount

2 Operation
2.1 Unpacking
Upon receipt of your device, verify the appropriate purchase order.
NOTICE
Store the device in a suitable container to prevent possible damage during handling.
2.2 Operate
Prerequisites
WARNING
Hazardous areas
Do not open this device for any reason in a hazardous area.
WARNING
Explosion
Do not open when an explosive atmosphere is present.
Only use replaceable battery pack Rosemount 00975-0900-0012.
NOTICE
Disconnect external devices, such as fire alarms and automatic extinguishing systems,
before performing maintenance.
Procedure
1. Verify that you are using the correct simulator that fits the tested detector per Table
1-1.
2. Verify that you are at the correct distance from the detector according to the type
of detector and the detector sensitivity.
See Table 6-1.
3. Aim the flame simulator using the mechanical sight towards the center of the
detector. Push the Activate button and then use the halogen beam for fine
adjustment towards the center of the detector.
Once the trigger is pressed, with an initial two second delay, the equipment will operate
for a maximum of 60 seconds, following which the equipment cannot be operated for a
minimum period of 30 seconds.
Reference Manual Operation
00809-0500-4975 May 2022
Rosemount FS-IR-975 11

2.3 Simulator status
For the first five seconds, the laser defines the simulator status.
Normal status
When switching to normal status, the equipment will operate for a maximum period of 60
seconds, following which the equipment cannot be operated for a minimum period of 30
seconds.
Fault status
When the battery is lower than 12.3 Vdc the lamp won't be activated.
2.4 Charge the battery
This device uses lithium ion batteries as a rechargeable power source. When the batteries
are fully charged, under normal conditions (room temperature), the device operates at
least 1,000 times without restarting. When the voltage from the batteries is lower than
the required operational level, the device will not operate.
To charge the battery:
Procedure
1. Place the device on a table in a safe area not exceeding 104 °F (40 °C).
2. Release the locking screw.
See Figure 1-2
3. Unscrew the battery compartment cover counter-clockwise.
See Figure 1-1.
4. Unscrew the locking disc clockwise using a 1.5 mm hex key.
See Figure 2-1.
5. Pull out the battery from the flame simulator.
WARNING
The battery must be charged only after being removed from the flame simulator.
6. Connect the battery to the charger. Verify that the charger is the one supplied with
the flame simulator.
7. Let the battery charge for a maximum of two to three hours.
8. Disconnect the charger.
9. Insert the battery into the flame simulator.
The LED will flash twice to indicate that the battery is fully charged.
10. Screw in the locking disc using a 1.5 mm hex key.
See Figure 1-1.
11. Screw in the battery compartment cover.
Operation Reference Manual
May 2022 00809-0500-4975
12 Emerson.com/Rosemount

See Figure 1-1.
12. Lock the back cover with the locking screw.
See Figure 1-2.
2.5 Replace the battery
Figure 2-1: Flame simulator battery replacement
A. Simulator
B. Battery pack
C. Locking disc
D. Back cover
Procedure
1. To remove the battery, follow Step 1 through Step 5 in Charge the battery.
2. Insert the new battery pack into the simulator housing.
Use only Rosemount battery pack, PN 00975-9000-0012.
3. Follow Step 9 through Step 12 in Charge the battery.
Reference Manual Operation
00809-0500-4975 May 2022
Rosemount FS-IR-975 13

Operation Reference Manual
May 2022 00809-0500-4975
14 Emerson.com/Rosemount

3 Troubleshoot
3.1 LED flashes three times in three consecutive
cycles
Recommended action
Recharge the battery.
3.2 LED flashes three times in five consecutive
cycles
Recommended actions
1. Disconnect and reconnect the battery.
2. Operate the flame simulator again.
3.3 LED does not turn on
Recommended actions
1. Recharge the battery.
2. Replace the battery.
3.4 Flame simulator seems to work properly but
does not activate the flame detector
Recommended actions
1. Verify that you are aiming the flame simulator beam at the center of the flame
detector.
2. Verify that you are at the correct distance.
3. Verify that the flame detector is at the correct sensitivity.
4. Verify that the flame detector is operating.
5. Verify that the flame detector is clean.
Reference Manual Troubleshoot
00809-0500-4975 May 2022
Rosemount FS-IR-975 15

Troubleshoot Reference Manual
May 2022 00809-0500-4975
16 Emerson.com/Rosemount

4 Maintenance
WARNING
Explosion
Do not open when an explosive atmosphere is present.
Only use replaceable battery pack Rosemount 00975-0900-0012.
•Ensure the flame simulator is charged before operation.
•Ensure the reflector and the window are clean.
•Before replacing the battery, ensure that you have a Rosemount battery pack,
PN 00975-9000-0012.
•When the simulator is not in use, remove the battery pack and recharge every six
months.
•The typical lithium ion battery lifetime is two to three years under normal conditions.
Reference Manual Maintenance
00809-0500-4975 May 2022
Rosemount FS-IR-975 17

Maintenance Reference Manual
May 2022 00809-0500-4975
18 Emerson.com/Rosemount

5 Ordering information
The kit is supplied in a carry case that includes:
•Flame simulator
•Charger
•Tool kit
•Reference manual
Reference Manual Ordering information
00809-0500-4975 May 2022
Rosemount FS-IR-975 19

Ordering information Reference Manual
May 2022 00809-0500-4975
20 Emerson.com/Rosemount
