Jasco Enbrighten Zigbee Installation instructions

43094 PRODUCT SPECIFICATIONS
Specications
Power: 120VAC, 60Hz Signal Frequency: 2.4Ghz
Maximum load for the Zigbee-controlled outlets:
600W (5A) incandescent/1/2HP motor or 1800W (15A) resistive
Zigbee controlled outlet is fused @ 5A. This fuse is not user
serviceable
Range: Up to 150ft. from controller or closest Zigbee device
Operating Temperature: 32-104° F (0-40° C)
Warranty: 5-year limited product warranty
For indoor use only
www.byjasco.com 1
Design Features
· Remote ON/OFF control
via the Zigbee controller
· Manual ON/OFF control
with the top push button
· Works with Google and Alexa
(requires compatible hub*)
· Can be included in multiple
groups and scenes
· Two Zigbee-controlled
AC outlets
· Both outlets controlled
together (cannot be
controlled independently)
· Space-efcient design
· Does not block the lower
outlet when plugged in to
the upper outlet of a duplex
wall receptacle – assumes
that the duplex receptacle is
mounted with the ground
pin down.
· Plugs and cords route
to the side allowing close
placement of furniture
· Over-the-air updates –
once joined to your Zigbee
network, the smart switch
can automatically receive
updates through your
Zigbee gateway
· Zigbee 3.0 certied for simple
pairing and integrated home
automation
· Visit ezzigbee.com/hubs for hub
compatibility
· Trilingual instruction manual –
English, French, Spanish
Zigbee Features
· Effortless device pairing to
Zigbee certied gateways
· Backward compatible with all
generations of Zigbee devices
· Supports wireless upgrades
to future-proof your home
* Requires Zigbee hub or controller –
functions may vary depending on brand.
Enbrighten Zigbee
Plug-in Dual-Outlet Smart Switch

43094 PRODUCT SPECIFICATIONS
www.byjasco.com 2
Two-Outlet Smart Switch
Wirelessly control both outlets simultaneously
Leaves 2nd outlet free for use
Grounded
wirelessly
controlled outlet
Grounded
wirelessly
controlled outlet
Manual ON/OFF & program button
Device Conguration
Adding your devices to a Zigbee network
Once the hub is ready to add the smart switch, pairing begins
automatically when power is supplied. The switch appears in the
controller’s menu when paired.
To remove and reset the device
Choose to remove the lighting device as instructed by your hub. The
controller indicates the smart switch was removed.
To return to factory defaults
If plugged in, unplug the switch. Press the program button while
plugging in the switch – must release button within four seconds of
plugging in the switch.
Compliances, specications and availability are
subject to change without notice
Distributed by Jasco Products Company LLC
10 E. Memorial Rd., Oklahoma City, OK
©Jasco 2020
V1 3/22/20
