Silentaire Scorpion II TT Operating instructions

8614 Veterans Memorial. Houston, Texas, 77088
832/327-7452 800/972-7668 Fax: [phone]
E-mail: [email protected]
SILENTAIRE
TECHNOLOGY
FS-MA-2000 TT
General User and
Maintenance
Instructions

8614 Veterans Memorial. Houston, Texas, 77088
832/327-7452 800/972-7668 Fax: [phone]
E-mail: [email protected]
Thank you and congratulations on the purchase of your SCORPION compressor.
The SCORPION is built to the highest quality standards which produce excellent
efficiency. If you use it properly and maintain it according to this manual, it will
perform to your fullest satisfaction form many years to come. Please read this
manual, carefully and follow the instructions, it will guarantee you a troublefree
operation.
A. Installation
1. After taking your SCORPION compressor out of its packaging,
please check it carefully for any damages due to shipping.
2. Install the compressor on a flat surface in a suitably sized, dry room
with good ventilation, where the temperature is not likely to rise
above 94 Degrees Farenheit (35 Centigrades).
3. Dispose of the packing material in compliance with the regulations
in the country or state where the compressor is installed.
B. Safety
1. Do Not use the OILLESS compressor for purposes other than those
for which it has been designed.
2. Do Not modify or repair the compressor while it is connected to the
electric current.
3. Note: The electric outlet has to be properly installed and grounded!
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR
MOISTURE..
This "bolt of lightning" indicates uninstalled material within your
unit may cause an electrical shock. For the safety of everyone
please do not remove product covering.
The "exclamation point" calls attention to features for which you
should
read the enclosed literature closely to prevent operating and
maintenance problems.

8614 Veterans Memorial. Houston, Texas, 77088
832/327-7452 800/972-7668 Fax: [phone]
E-mail: [email protected]
C. Operating Instructions
1. Connect the equipment for your application to the outgoing ¼” male
fitting at the front of the cylinder head. To keep the connecting
fitting from leaking air you should always applpy Teflon Tape to the
thread of the fitting.
2. When the compressor gets hot from constantly producing
compressed air, it automatically shuts off. After waiting for about
20 minutes to cool down, it will start working again.

8614 Veterans Memorial. Houston, Texas, 77088
832/327-7452 800/972-7668 Fax: [phone]
E-mail: [email protected]
EXPLODED VIEW AND PARTS LIST
FS-MA-2000TT

8614 Veterans Memorial. Houston, Texas, 77088
832/327-7452 800/972-7668 Fax: [phone]
E-mail: [email protected]
101 Motor 148 3-ways Connector
102 Housing, Front 149 Fitting M1/8”-F1/8”
103 Cover, Front 150 Bolt
104 Kit On/Off Switch with Capacitor 151 Nut
105 Piston –Rod 152 Check-Valve
106 Ball Bearing 153 Fitting F1/8” –F1/8”
107 Crankshaft 154 Compression Nut
108 Bolt 155 Spacer
109 Inlet and Exhaust Plate 156 Pressure Switch
110 Bolt 157 Gauge (Tank)
111 Cylinder 158 L-Fitting M/18”-F1/8”
112 Compression Ring 159 Spiral Hose
114 Cylinder Base 160 Space
116 Valve Plate (set) 161 L-Fitting F1/8”-F1/8”
117 O-Ring 162 Fitting M1/8”6mm compression
118 Cylinder Head 163 Ferrel
124 Fitting M1/4”–M1/8: 164 Electric Cable
133 Bolt 165 Cylinder Head with cooling finns
136 Gasket 166 Bolt
139 Housing for Capacitor 167 Nut
140 Base Plate for Housing 168 Washer
141 Capacitor 167 Bolt
142 Bolt 168 Washer
143 Bolt 169 Bolt
144 Filter/Regulator 300 Frame
Mod. FS-MA-2000TT
145 Gauge (Line Pressure) 301 Bolt
146 Fitting M1/8” –M1/8”302 Washer
147 Ballvalve (Inline) 303 Rubber Foot
304 Tank305 Tank Drain
