Silvercrest BLUETOOTH KH 2376 User manual

■ BLUETOOTH CAR RADIO
PL
06/2009
Operating instructions
Instrukcja obsługi
Használati utasítás
KOMPERNASS GMBH ⋅ BURGSTRASSE 21 ⋅ D-44867 BOCHUM
www.kompernass.com
ID-Nr.: KH2376 06/2009-V3
BLUETOOTH CAR RADIO
RADIO SAMOCHODOWE BLUETOOTH
BLUETOOTH AUTÓRÁDIÓ
4A
HU
GB
KH 2376
CV_KH2376_33301_LB4A.indd 1-4CV_KH2376_33301_LB4A.indd 1-4 17.07.2009 11:43:38 Uhr17.07.2009 11:43:38 Uhr

Operating instructions...................................................................5
Instrukcja obsługi.........................................................................43
Használati utasítás......................................................................81
PL
KH 2376
4 5 6 7 8 9 10 11
121314151617181920212223242526
27
28 29
32
33
34
353637383940
28
41
2342 43 44 45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
65
64
63
62
66
68 69
67
70
GB
HU
30 31
,
CV_KH2376_33301_LB4A.indd 5-8CV_KH2376_33301_LB4A.indd 5-8 17.07.2009 11:43:39 Uhr17.07.2009 11:43:39 Uhr

5
Bluetooth Car Radio KH 2376
GB
Index
Introduction . . . . . . . . . . . . . .6
Preface . . . . . . . . . . . . . . . . . . . . . . . 6
Information for these operating
instructions . . . . . . . . . . . . . . . . . . . . 6
Copyright . . . . . . . . . . . . . . . . . . . . . 6
Limited liability . . . . . . . . . . . . . . . . . 7
Warnings . . . . . . . . . . . . . . . . . . . . . 7
Proper use. . . . . . . . . . . . . . . . . . . . . 8
Safety . . . . . . . . . . . . . . . . . . . . . . . . 8
Basic Safety Instructions . . . . . . . . . . 8
Danger from laser radiation . . . . . . . 9
Traffic safety . . . . . . . . . . . . . . . . . .10
Interaction with batteries . . . . . . . .10
Package contents and transport
inspection . . . . . . . . . . . . . . . . . . . .11
Disposal of the packaging . . . . . . .11
Operating elementse
(see foldout sides) . . . . . . . .12
Installation . . . . . . . . . . . . . .14
Connection . . . . . . . . . . . . . . . . . . .14
Installation . . . . . . . . . . . . . . . . . . .16
Uninstalling the device . . . . . . . . . .18
Initial operation . . . . . . . . . .19
Face plate. . . . . . . . . . . . . . . . . . . .19
Remote control . . . . . . . . . . . . . . . .20
Handling and operation . . .20
Switching On and Off . . . . . . . . . .21
Settings. . . . . . . . . . . . . . . . . . . . . .21
Radio reset (RESET) . . . . . . . . . . . .23
Radio functions. . . . . . . . . . . . . . . .23
General CD functions . . . . . . . . . .26
MP3 CDs functions . . . . . . . . . . . .28
USB port. . . . . . . . . . . . . . . . . . . . .29
Card reader (SD/MMC) . . . . . . . .30
Record function. . . . . . . . . . . . . . . .30
Connecting an external audio
device to the car radio . . . . . . . . . .32
Bluetooth operation . . . . . . . . . . . .32
Cleaning . . . . . . . . . . . . . . . .34
Safety instructions. . . . . . . . . . . . . .34
Cleaning. . . . . . . . . . . . . . . . . . . . .34
Troubleshooting . . . . . . . . . .35
Safety instructions. . . . . . . . . . . . . .35
Malfunction causes and remedies .35
Disposal. . . . . . . . . . . . . . . . .38
Disposal of the device . . . . . . . . . .38
Disposing of the batteries. . . . . . . .38
Appendix . . . . . . . . . . . . . . .38
Technical data . . . . . . . . . . . . . . . .38
Declaration of EC conformity . . . .39
Warranty . . . . . . . . . . . . . . . . . . . .40
Importer . . . . . . . . . . . . . . . . . . . . .40
B_KH2376_33301_LB4A indb Abs2 5 17 07 2009 14 13 51 Uhr

6
Introduction
Bluetooth Car Radio KH 2376
GB Introduction
Preface
Dear customer,
by purchasing the Bluetooth car radio you have decided on a quality product
from SilverCrest, which, in terms of technology and functionality, meets the most
up-to-date development standards.
Read the information included here so that you can quickly familiarize yourself
with your device and thus make full use of its functions.
We wish you a great deal of enjoyable use.
Information for these operating instructions
These operating instructions are a component of the KH 2376 Bluetooth car radio
(henceforth designated as the device) and supplies you with important informa-
tion for intended use, safety, installation and connection as well as operation of
the device.
The operating instructions must be constantly kept available close to the device.
They are to be read and used by anyone assigned to install, service and repair
faults in the device.
Keep these operating instructions and hand them over with the device to any future
owners.
Copyright
This documentation is copyright protected.
All rights including those of photographic reproduction, duplication and distribution
by means of particular methods (for example data processing, data carriers and
data networks), wholly or partially as well as substantive and technical changes
are reserved.
B_KH2376_33301_LB4A indb Abs1 6 17 07 2009 14 13 51 Uhr

7
Introduction
Bluetooth Car Radio KH 2376
GB
Limited liability
All technical information, data and information for installation, connection and
operation contained in these operating instructions correspond to the latest at time
of printing and, to the best of our knowledge, take into account our previous
experience and know-how.
No claims can be derived from the details, illustrations and descriptions in these
instructions.
The manufacturer assumes no responsibility for damage caused by failure to ob-
serve the instructions, improper use, inappropriate repairs, making unauthorized
changes or for using unapproved replacement parts.
Warnings
In the existing operation instructions the following warnings are used:
WARNING
A warning of this danger level signifies a possible dangerous
situation.
If the dangerous situation is not avoided it can lead to injuries.
The directives in this warning are there to avoid personal injuries.►
IMPORTANT
A warning of this danger level signifies possible property
damage.
If the situation is not avoided it can lead to property damage.
The directives in this warning are there to avoid property damage.►
NOTICE
A notice signifies additional information that assists in the handling of the►
device.
B_KH2376_33301_LB4A indb Abs4 7 17 07 2009 14 13 51 Uhr

8
Introduction
Bluetooth Car Radio KH 2376
GB Proper use
This device is intended only for reception of FM/AM radio stations as well as
for the playback of audio and MP3 CDs, MP3 files from USB data carriers and
SD/MMC memory cards as well as audio signals of external audio devices.
In addition you can couple the device with a Bluetooth mobile phone and with the
microphone unit use the device as a hands free facility.
This device is not intended for any other use or for uses beyond those mentioned.
WARNING
Danger from unintended use!
Danger can come from the device if used for unintended purposes and/or
other types of use.
Use the device exclusively for intended purposes.►
Observe the procedures described in these operating instructions.►
Claims of any kind for damage resulting from unintended use will not be excepted.
The operator alone bears liability.
Safety
In this chapter you receive important safety information regarding handling of the
device.
This device complies with the statutory safety regulations. Incorrect usage can,
however, lead to personal injury and property damage.
Basic Safety Instructions
For safe handling of the device observe the following safety information:
Before use check the device for visible external damage. Do not put into■
operation a device that is damaged or has been dropped.
B_KH2376_33301_LB4A indb Abs3 8 17 07 2009 14 13 52 Uhr

9
Introduction
Bluetooth Car Radio KH 2376
GB
Damaged cables or connections should be replaced by authorized qualified■
persons or by the customer service department.
Persons who, due to their physical, intellectual or motor abilities, are incapable■
of operating the device safely may only use the device under supervision or
direction from a responsible person.
Only permit children to use the device under supervision.■
Repairs should only be carried out by authorized specialist companies or■
by the customer service department. Incorrect repairs can result in significant
dangers for the user. In addition warranty claims become void.
A repair to the device during the warranty period may only be carried out by■
a cutomer service department authorized by the manufacturer otherwise no
additional warranty claims can be considered for subsequent damages.
Defective components may only be replaced with original replacement parts.■
Only by using original replacement parts can you guarantee that the safety
requirements are complied with.
Protect the device from moisture and liquid penetration.■
Danger from laser radiation
WARNING
The device is equipped with a class 1 laser.
Laser radiation is dangerous to the eyesight!
Observe the following safety instructions to avoid exposure of
yourself or others to laser radiation:
NEVER open the device.►
Have the device repaired only by a specialist.►
Do not make any modifications to the device.►
B_KH2376_33301_LB4A indb Abs3 9 17 07 2009 14 13 52 Uhr

10
Introduction
Bluetooth Car Radio KH 2376
GB Traffic safety
WARNING
Safety in traffic has the highest priority!
Observe the following safety instructions so that you do not put yourself or
others in danger:
Before travel commencement familiarize yourself with the operation of the►
device.
Only operate the device when the traffic situation allows. Stop in a suitable►
place to carry out comprehensive operations.
Only remove or insert the face plate when the vehicle is parked.►
Set to a moderate volume so that acoustic signals from the police, fire►
department and other rescue services can be heard in good time.
Interaction with batteries
WARNING
Danger from improper use!
For safe handling of batteries observe the following safety instructions:
Do not throw the batteries into a fire.►
Do not short circuit the batteries.►
Do not attempt to recharge the batteries.►
Regularly check the condition of the batteries. Leaking battery acid can►
cause permanent damage to the device. Special caution should be shown
when handling damaged or leaking batteries. Danger from acid burns!
Wear protective gloves.
Store batteries in a place inaccessible to children. If swallowed seek►
immediate medical attention.
Remove the batteries from the remote control if you do not intend to use►
the device for extended periods of time.
B_KH2376_33301_LB4A indb Abs3 10 17 07 2009 14 13 52 Uhr

11
Introduction
Bluetooth Car Radio KH 2376
GB
Package contents and transport inspection
WARNING
Risk of suffocation!
Packaging material should not be used as a play thing.►
There is a risk of suffocation!
The device is delivered with the following components as standard:
Car radio (incl. face plate)▯
Installation bracket (Attached)▯
Bezel frame (Attached)▯
Fixture plate (incl. securing material)▯
Remote control▯
1 Battery CR2025, 3 V DC▯
Keys for installation frame (2x)▯
Case for face plate▯
Microphone unit with adhesive strip▯
Operating instructions▯
NOTICE
Check the contents to make sure everything is there and for visible►
damage.
If the contents are not complete or are damaged due to defective►
packaging or through transportation contact the service hotline
(see warranty card).
Disposal of the packaging
The packaging protects the device from transport damage. The packaging
materials are selected from the point of view of their environmental friendliness
and disposal technology and are therefore recyclable.
The recirculation of packaging into the material circuit saves on raw material and
reduces generated waste. Dispose of packaging material that is no longer needed
according to the regionally established regulations.
NOTICE
If possible preserve the device's original packaging during the warranty►
period so that in the case of a warranty claim you can package the device
properly for return.
B_KH2376_33301_LB4A indb Abs3 11 17 07 2009 14 13 52 Uhr

12
Operating Elements
Bluetooth Car Radio KH 2376
GB POWER/DIM:
Switch device on and off/
dim display illumination
2Multi controller:
Turn to set value/volume
3MU:
Switch off sound/button
4TA:
Activate traffic radio/button
5SEL:
Press or hold down to access
adjustment options
6Display
7AF:
Alternative frequency search
/ activate regional programmes
8PTY:
Station search by PTY group
9DISP:
Show display information
10 Unlocking the face plate
11 Card slot for SD/MMC cards
12 USB port
13 AUX IN:
3,5 mm stereo input socket for
the connection of an external
audio device
14 ▸▸I:
Title / Station search forwards
15 I◂◂:
Title / Station search
backwards
16 A/PS:
Automatic station saving
17 Station button 6/next directory
18 Station button 5/previous
directory
19 RDM/4:
Random playback in the CD/
MP3 operation mode,
station button 4
20 INT/3:
Intro function in the CD/MP3
operation mode, station button 3
21 RPT/2:
Repeat function in the CD/
MP3 operation mode,
station button 2
22 PAU/1:
Stop playback in the CD/
MP3 operation mode, station
button 1
23 Sensor for remote control
24 BND/ENT:
Select band range/confirm
selection
25 SCN/REC:
Automatic station search/
Record to a data carrier at
the USB port or the SD/MMC
card slot
26 MD/LD:
Set operating mode/
switch to loudness
27 OPEN:
Reject disc
28 Holder for the face plate
29 RESET:
Resetting the device
30 Theft protection LED
31 Positions LED of the CD
compartment
Operating elementse (see foldout sides)
B_KH2376_33301_LB4A indb Abs3 12 17 07 2009 14 13 52 Uhr

13
Operating Elements
Bluetooth Car Radio KH 2376
GB
32 CD compartment
33 ISO-Block connection B
34 Automotive blade
type fuse 10 A
35 ISO block connection A
36 Bluetooth antenna
37 Socket for microphone unit
38 Securing screw
(incl. M5 nut and washer)
39 LINE OUT:
Audio cinch output L/R for
amplifier
40 Antenna connection for
DIN antenna plug
41 POWER/DIM:
Switch device on and off/
dim display illumination
42 Button
43 I◂◂:
Title / Station search
backwards
44 VOL+:
Volume increase
45 Button
46 ▸▸I:
Title / Station search forwards
47 INT/3:
Intro function in the CD/
MP3 operation mode,
number button 3
48 VOL-:
Volume decrease
49 PTY/7:
Station search by PTY group/
number button 7
50 Number button 6
51 DSP/*:
Sound setting/button *
52 BAND/0:
Select frequency range/
number button 0
53 Battery compartment
54 SEL/#:
Press or hold down to access
adjustment options/button #
55 TA/9:
Activate traffic radio station/
number button 9
56 AF/8:
Alternative Frequency search/
regional programme activation/
number button 8
57 Number button 5
58 RDM/4:
Random playback in the CD/
MP3 operation mode/ number
button 4
59 RPT/2:
Repeat function in the CD/
MP3 operation mode/
number button 2
60 ▸II/1:
Playback start or stop/
number button 1
61 MODE:
Set operation type/
Loudness function
62 Microphone unit plug
63 Microphone
64 TALK button
65 green LED for connection status
66 Case for face plate
67 Bezel frame
68 Installation bracket
69 Key for installation bracket
70 Fixture plate
(incl. securing material)
B_KH2376_33301_LB4A indb Abs3 13 17 07 2009 14 13 52 Uhr

14
Installation
Bluetooth Car Radio KH 2376
GB Installation
WARNING
With the installation of the device damage can occur!
If possible have the device installed by a qualified technician.►
If you want to install the device yourself, for safe and flawless operation►
of the device follow the instructions for connection and installation.
Connection
IMPORTANT
The use of incorrect connections can lead to damage to the
device.
For installation use the device's ISO connections. The vehicle specific ISO►
adapter that you may possibly require can be obtained from a specialist
establishment, from a local dealer or from the store's technical department.
When using other connection types the warranty becomes void!
Configuration of the ISO connections
1357
2468 ISO A
Configuration
1 unconfigured
2unconfigured
3 unconfigured
4 Permanent positive
5 Antenna power
6 unconfigured
7 12 V (Ignition positive)
8 Minus (-)
1357
2468 ISO B
Configuration
1 Rear right +
2Rear right -
3 Front right +
4 Front right -
5 Front left +
6 Front left -
7 Rear left +
8 Rear left -
B_KH2376_33301_LB4A indb Abs3 14 17 07 2009 14 13 53 Uhr

15
Installation
Bluetooth Car Radio KH 2376
GB
To connect the device to two speakers use only the cables for the front speakers.
NOTICE
Make sure that a permanent positive connection is applied to the station►
memory of connection 4 in the ISO block A.
In some automobile models the standard configuration of the connections►
[4] and [7] in ISO block A are interchanged at the factory. If this is the
case the station memory can be lost. To correct this, the connections 7
(Ignition positive) and 4 (Permanent positive) in the ISO Block A must be
swapped.
You can connect an external amplifier to the audio cinch output. For this►
follow the operating instructions for the external amplifier.
Antenna power connection
IMPORTANT
Possible damage to the device!
Never attach the antenna power connection with the antenna's motor►
power cable.
The connection for the antenna power is available for a relay controlled antenna.
The relay then automatically extends the antenna when the device is switched
on. When switched off the antenna retracts. This connection can also be used to
control an external amplifier. For exact connection information please consult the
amplifier's operating instructions.
Connection of an external amplifier
For the connection of an external amplifier use the audio cinch output LINE
OUT 39 . For this follow the operating instructions for the external amplifier.
Connecting the microphone unit
For connection of the microphone unit use the microphone unit socket 37 .
B_KH2376_33301_LB4A indb Abs3 15 17 07 2009 14 13 53 Uhr

16
Installation
Bluetooth Car Radio KH 2376
GB
Connection schematic
1 34
ISO
A
ISO B
Installation
The device can be installed into any standard ISO mounting duct. In the event that
your vehicle does not have an ISO mounting duct contact your local specialist
establishment, local dealer or the technical department of the store.
NOTICE
Before installation remove, without fail, the two transport securing screws►
on the top of the housing (marked with a red sticker)!
Connect the cable before finally installing the device. Make sure that it is►
plugged in properly and that the system functions correctly.
Installation instructions
Install the device in the duct provided for it or select the installation location so■
that all buttons can be comfortably reached and the driver is not impeded.
Only connect the device to a properly installed 12 V automotive battery.■
Only connect the device in the vehicle via an ISO plug.■
Install the device in such a way as to avoid the development of heat accumu-■
lation and so that the device is sufficiently ventilated.
Antenna Bluetooth antenna
External amplifier
Microphone unit
B_KH2376_33301_LB4A indb Abs3 16 17 07 2009 14 13 53 Uhr

17
Installation
Bluetooth Car Radio KH 2376
GB
To avoid function disturbances the installation angle should be less than 30°.■
Do not install the device in a location where it will be subjected to high■
temperatures(i.e. direct sunlight or heating vents), heavy contamination and
strong vibrations.
In the event that changes to the vehicle are necessary contact your vehicle■
dealer/qualified radio installation facility.
Installing the device into the ISO duct
Pull the installation bracket68 and the bezel frame 67 from the device's
housing.
Place the installation bracket into the ISO mounting duct.
Bend the tabs on the installation bracket with a screw driver so that the bracket
is fixed firmly into the mounting duct (see diagram).
Check to make sure that the bracket is securely fixed.
Connect the ISO socket block of the device with the two ISO plugs on your
vehicle.
Connect the antenna cable from the vehicle antenna to the antenna socket
on the device.
Feed the microphone unit cable into the mounting duct and connect it to the
microphone unit socket. Lay the cable in such a way that the microphone
unit can be secured later in the vehicle interior see chapter "Using the micro-
phone" on page 32.
Contingently connect the audio cinch cable of an external amplifier to the
LINE OUT socket 39 on the device.
B_KH2376_33301_LB4A indb Abs3 17 17 07 2009 14 13 53 Uhr

18
Installation
Bluetooth Car Radio KH 2376
GB
If necessary secure your device against theft with additional measures.
Attach the securing screw with the anchoring plate 70 and the securing material
to the engine firewall of the vehicle.
Carefully push the device into the mounting duct until it locks into place.
After all connections have been made activate theRESET button with a ball
point pen or other pointed object.
Attach the face plate as described under "Installing the face plate".
IMPORTANT
Possible damage to the cable!
Observe the position of the cable when sliding the device into the duct so►
as to avoid damaging it.
Finally put on the bezel frame.
Uninstalling the device
To remove the installed device proceed as follows:
Remove the bezel frame67 .
Insert the right and left keys69 into their respective slots on the sides of the
device. (The tabs are now bent back.)
Pull the device out.
B_KH2376_33301_LB4A indb Abs3 18 17 07 2009 14 13 53 Uhr

19
Initial operation
Bluetooth Car Radio KH 2376
GB
Initial operation
Face plate
To protect against theft you can remove the face plate from your device. Do not
store the removed face plate in your vehicle.
NOTICE
When the face plate is not inserted into the frame the theft protection►
LED 30 on the device blinks.
To safeguard the face plate always keep it stored in its case.►
Installing the face plate
Place the face plate with the left side in the
frame first.
Then firmly press the right side until it locks into
place.
Check to make sure that the face plate is firmly and
correctely installed in the frame. If the face plate is
incorrectly installed it can result in malfunctions when
operating the device.
Removing the face plate
Press the10 button to unlock the face plate.
Tilt the face plate completely forward.
Slide the face plate to the left and then pull first
the right and then the left side away.
B_KH2376_33301_LB4A indb Abs3 19 17 07 2009 14 13 53 Uhr

20
Handling and operation
Bluetooth Car Radio KH 2376
GB Remote control
Inserting the battery
Remove the supplied battery from the packing.
To insert the battery and/or change the battery proceed
as follows:
Pull the battery compartment out of the remote control
by pressing the lateral locking device and at the same
time pull the battery compartment out.
Remove the depleted battery and insert a new battery
of the type CR2025 (Button cell) into the battery com-
partment. Be sure to insert the battery with the correct
polarity.
Slide the battery compartment back into the remote
control.
Using the remote control
Point the remote control to the Infrared sensor23 on the front panel of the
device.
NOTICE
You can use the remote control up to a distance of 8 m from the device.►
Handling and operation
In this chapter you receive important information for the handling and operation
of the device.
NOTICE
Most of the functions can be operated by the buttons on the device as well►
as by the buttons on the remote control. In these instructions operation via
the buttons on the device is described. Any reference to the pushbuttons on
the remote control will be specifically highlighted.
If no setting is made and/or no button pushed within approx. 5 seconds the►
device returns to its previous operating mode. Changed settings are saved.
B_KH2376_33301_LB4A indb Abs3 20 17 07 2009 14 13 53 Uhr

21
Handling and operation
Bluetooth Car Radio KH 2376
GB
Switching On and Off
Press briefly thePOWER/DIM button to switch the device on. In the display
the notice WELCOME appears.
Briefly touch thePOWER/DIM button to dim the display illumination.
To switch off hold down thePOWER/DIM button longer.
Settings
WARNING
Hearing damage as a result of too high a volume!
If the volume is set too high it can lead to permanent hearing damage.
Set the volume to moderate levels only.►
Volume
Turn the multi controller to set the volume.
Bass/Treble/Balance/Fader
Press theSEL button. The current volume level is shown. Each further press of
the SEL button accesses the next setting point.
The following settings are possible:
VOL - Volume (from 0 to 45),
BAS - Bass (from -7 to +7),
TRE - Treble (from -7 to +7)
BAL - Balance (sound distribution between the right and left speakers)
(from 8L to 8R)
FAD - Fader (sound distribution between the rear and front speakers)
(from 8R to 8F)
Turn the multi controller to change the settings of the displayed menu items.
further settings with the SEL button
Hold down theSEL button for approx. 2 seconds and then press the SEL
button repeatedly until the desired function is shown in the display.
INVOL - switch on volume
Turn the multi controller to set the volume level, with which the device is to be
set when turned on.
B_KH2376_33301_LB4A indb Abs3 21 17 07 2009 14 13 54 Uhr

22
Handling and operation
Bluetooth Car Radio KH 2376
GB
ADJ - Time of day
NOTICE
The device is equipped with an RDS controlled clock. The clock sets itself►
automatically when the EON function is switched on and also continues to
run when the radio is switched off. If you do not receive any RDS signal you
can also set the time of day manually.
Turn the multi controller to the right to set the hours and to the left to set the
minutes.
TAVOL - Volume for traffic radio
Turn the multi controller to set the volume level, with which traffic reports are
to be played back.
EON - Information from other stations
When the EON function is switched on the radio switches to traffic radio or PTY
groups if the TA or PTY function has been activated.
Turn the multi controller in order to switch the EON function on (EON ON)
or off (EON OFF).
REC - Recording format
Turn the multi controller to set the record format for recording on SD/MMC
and/or USB data carriers, MP3 (MP3 data) or WMA (Windows Media
Audio).
DSP - Equalizer (Digital Sound Processing)
Turn the multi controller to select one of the settingsDSP CLASSIC, DSP
ROCK, DSP POP, DSP FLAT or DSP NONE. In the setting DSP NONE
no DSP is switched on. The DSP equalizer setting is shown at the bottom of
the display.
You can also set the equalizer by pressing the DSP button on the remote control.
With this setting DSP is switched off when the radio frequency is shown again.
Loudness
Hold down theMD/LD button to switch the loudness function on or off.
B_KH2376_33301_LB4A indb Abs3 22 17 07 2009 14 13 54 Uhr
