OVEN USER GUIDE
EN
MODELS
BO6503X03 - BO6503B03

1, en_US
PRODUTTORE
Merzifon OSB AMASYA, Silverline Endüstri ve Ticaret A.Ş
IMPORTATORE
Via Carlo Porta 4 20813 Bovisio Masciago (MB) - Italy
12.01.2022
OVEN USER GUIDE EN
2

Table of contents
1 PREFACE.................................................................................................... 4
2 IMPORTANT INFORMATION REGARDING SAFETY................................ 5
3 SPECIFICATIONS OF THE OVEN............................................................ 10
4 INSTALLATION OF APPLIANCE............................................................. 12
5 POWER CONNECTION............................................................................ 16
5.1 Energy Efficiency of the Oven........................................................... 19
6 INTRODUCTION OF APPLIANCE............................................................ 21
6.1 Accessories of the Oven.................................................................... 21
7 BEFORE FIRST USE................................................................................ 23
8 SPECIFICATIONS AND OPERATION OF THE APPLIANCE.................. 24
8.1 Specifications of the Oven................................................................. 24
8.2 THE USE OF THE DEVICE.............................................................. 25
8.2.1 Temperature Setting of the Appliance............................................ 25
9 Using Pizza Stone (Option)..................................................................... 26
10 HOW TO USE TELESCOPIC RAIL........................................................... 27
11 CLEANING AND MAINTENANCE OF THE APPLIANCE........................ 29
12 REPLACEMENT OF THE LAMP.............................................................. 35
13 MAIN FUNCTION DESCRIPTION............................................................. 36
14 COOKING CHART.................................................................................... 38
Table of contents
12.01.2022 OVEN USER GUIDE EN 3

1 PREFACE
DEAR COSTUMER
We sincerely thank you for purchasing
our product.
This product has been manufactured
at modern facilities respectful to the
environment without harming nature.
Please read all instructions and warn-
ings in this user manual carefully. This
manual includes important information
for safe installation, use and mainte-
nance of your product and necessary
warnings to get the most out of your
appliance. Keep this manual in a safe
place where it can easily be reached to
use it when required in the future. The
manufacturer shall not be held respon-
sible for damages to persons, environ-
ment or other materials that may occur
due to the translation or printing errors
of this manual, or improper operation
of the appliance.
PREFACE
12.01.2022
OVEN USER GUIDE EN
4

2 IMPORTANT INFORMATION
REGARDING SAFETY
nOperating voltage of your oven is
220 to 240 Volts.
nConnect your oven to a fuse with a
rating of 16A. If the current value
of the fuse in your house is less
than 16A, have a qualified electri-
cian install a 16A fuse.
nAlways use your oven with a
grounded power outlet. Have an
authorized electrician set
grounding equipment. Our com-
pany shall not be held responsible
for damages that might occur as a
result of using the product with an
ungrounded outlet.
nThis section includes the safety
instructions necessary to prevent
the risk of personal injury or mate-
rial damage. Not observing these
instructions may void any warranty
and our company shall not be
responsible for any damage that
may occur.
nIf the electrical connections inside
the appliance are taken out so that
they may be accessible, cut off the
power of the appliance against an
electric shock and contact the
authorized service.
nAvoid contacting the heating ele-
ments inside the oven as it shall
overheat during operation. Be
careful as the oven surface may
get very hot during the grilling
function.
nFlammable objects that are kept
on the cooking compartment may
get ignited. Do not keep the flam-
mable flammable objects on the
cooking compartment.
nUse oven gloves when you are
taking hot food or utensils such as
trays, etc. from the oven or the
grill. Components of the oven the
utensils (tray, etc.) used shall be
very hot during operation.
nThe appliance and its accessories
becomes hot during operation.
Avoid touching heated parts.
nDo not open the door of the appli-
ance if smoke is coming out of it.
Turn off the appliance, unplug it or
switch off the circuit breaker.
nCooking paper may come in con-
tact with heating elements and
catch fire. Do not randomly place
cooking paper during pre-heating
on the accessory. Always place a
container or a cake tin on the
cooking paper. Place the paper
only on the required area. The
cooking paper shall not be on the
accessory.
CAUTION!
This appliance may be used by
children above age of 8 and
persons with limited physical,
perceptual or mental abilities or
persons with a inadequate of
experience and knowledge only
if they are supervised by an
adult or when they comply with
the instructions given on the
operation of the appliance and
understand the risks that may
be encountered.
Children shall not play with the
appliance.
IMPORTANT INFORMATION REGARDING SAFETY
12.01.2022 OVEN USER GUIDE EN 5

nCleaning and maintenance of the
appliance shall not be carried out
by children without supervision.
nThe device may heat up during
operation. Be careful while
touching the heating elements
inside the oven. Keep away from
children.
nDo not use harsh and abrasive
cleaning agents or sharp metal
scrapers to clean the door glass of
the oven as this may cause
breaking of the glass or scratching
of the surface.
nOvens shall be installed away
from flammable environments.
nUse the temperature probe recom-
mended for this oven only
(optional).
nDo not use steam cleaners to
clean the oven.
CAUTION!
Unplug the appliance or cut off
power from the main switch to
prevent electrocution before
replacing the lamp.
nIn case of a damaged power cord,
it shall be replaced with a specific
cord or a cord that is approved by
the manufacturer or the authorized
service.
nTo prevent damages that may be
caused by improper placement of
the thermal circuit breaker, this
device shall not be connected to
external circuit devices such as
timers or always-on or always-off
circuits.
nAccessible parts may be hot.
Small children should be kept
away during use of grill.
nSpilt food stains shall be removed
before cleaning.
WARNINGS BEFORE INSTALLA-
TION AND DURING INSTALLATION
nThe appliance shall always be
installed by an Authorized Service.
nYour appliance features a high
performance air circulation system
for better cooking and cleaning.
Follow the instructions on installa-
tion to ensure this.
nUse your appliance after it is
installed so that it shall operate
safely.
nAppliance shall be placed on the
installation cabinet so that its rear
faces the wall.
nEnsure you remove all packaging
material before starting to operate
the appliance.
nUse your appliance according to
the intended use explained in the
operation manual only.
nThis appliance has been designed
for cooking at home kitchens only.
It is not suitable for industrial or
laboratory operation.
nDo not use or leave the appliance
outdoors.
nDo not use the appliance near
water bodies, on a wet ground or
in the vicinity of a pool.
nThis appliance is not designed to
be operated with an external timer
or with a remote control system.
IMPORTANT INFORMATION REGARDING SAFETY
12.01.2022
OVEN USER GUIDE EN
6

nThis appliance is not suitable to be
operated by children, persons with
mental disabilities or by inexper-
ienced persons without a compe-
tent adult who shall take responsi-
bility.
nDo not operate the appliance until
it is repaired by an authorized
service if the door or the gaskets
on the door of the appliance are
damaged.
nDo not hang down the power cord
from the edge of the table or the
countertop.
WARNINGS ON OPERATION
nEnsure you remove all packaging
material before you use your
product.
nThis appliance shall not be used
for a purpose other than cooking.
It is dangerous and inappropriate
to use it for any other purpose
(e.g. to heat the room it is in). Our
company shall not be held respon-
sible for damages that may occur
on people, animals or objects due
to improper, incorrect or imprac-
tical operations of the oven.
nWhen you operate the oven for the
first time, a smell caused by the
insulation materials and heating
elements may occur for once. In
such a case, operate the oven
without putting any food inside it
for 30 minutes at maximum tem-
perature with the upper and lower
heater (and 3D, if applicable) func-
tion turned on.
nPlastic containers that are not
oven-compatible may melt and
damage the oven or may start a
fire at high temperatures.
nNever cook or fry on the bottom of
the oven.
nPay attention that alcoholic bever-
ages used for cooking some
dishes may evaporate at high tem-
peratures and ignite on hot sur-
faces.
nCanning operation or heating may
cause high pressures in enclosed
containers, the containers may
explode as a result of this pres-
sure. Do not can food in closed
containers or do not heat closed
containers.
nDo not cover the bottom of the
oven with aluminium foil.
nUnplug the appliance while
moving, cleaning, or servicing the
oven.
nNever attempt to remove the plug
by pulling it from the cord.
nNever touch the appliance if your
hands or feet are wet or damp.
nDo not allow children or minors to
use the appliance without supervi-
sion.
nIn case of negligence, the oven
door may hurt your hands if it is
removed from its hinge.
nIn case of failure or improper oper-
ation of the oven, turn it off and
unplug the oven.
nWhen the oven is not used,
ensure that all functions are
switched to the “OFF” position.
nAlways wear oven gloves while
removing the tray from the oven.
nAlways keep the oven clean for
your safety and to ensure the
cleanliness of the oven. Oil resi-
dues left inside the oven after
operation may damage the sur-
face of the even in the course of
time.
IMPORTANT INFORMATION REGARDING SAFETY
12.01.2022 OVEN USER GUIDE EN 7

All ma�ntenance and repa�r opera-
t�ons shall be performed by
author�zed serv�ce and or�g�nal
spare parts shall be used only.
When the door of the appl�ance �s
open, do not place any heavy
object on the door or allow ch�l-
dren s�t on �t. Th�s may cause t�p-
p�ng over of the appl�ance or
damage to the door of the appl�-
ance.
Our company shall be held
respons�ble for any damages
caused by hazardous or �mproper
operat�on of the oven.
Damage to your oven may occur �f
you do not follow any warn�ng
g�ven above.
CAUTION!
Do not use the oven handle on
the front door to carry the oven
or to remove �t from �ts pack-
ag�ng.
Th�s product stops cook�ng �n case of
any power cut. Depend�ng on the
model of the product, you can keep
cook�ng or you may need readjust
cook�ng t�me.
To prevent steam condensat�on �n front
of the clock when you open the door
when the cook�ng �s f�n�shed, open the
door of the oven at least w�th�n 3
m�nutes after the end of cook�ng.
DECLARATION OF CONFORMITY
The components of th�s appl�ance that
may contact w�th food comply w�th the
requ�rements of the EEC D�rect�ve no.
89/109.
W�th the mark�ng, we declare that �t
�s respons�b�l�ty to ensure the compl�-
ance of th�s appl�ance to the European
d�rect�ves and meet�ng the legal
requ�rements �n terms of safety, health
and env�ronment.
Ensure that the oven �s good cond�t�on
and not damaged when you take �t out
of �ts package. Do not use the appl�-
ance �n case of any doubt: Contact
author�zed serv�ce.
Put packag�ng mater�als such as nylon
packag�ng, polystyrene foam and na�ls
away from the reach of ch�ldren as
these may pose a danger for ch�ldren.
Keep the or�g�nal package of the
appl�ance.
Use the or�g�nal packag�ng to
transport the appl�ance, follow the
handl�ng s�gns on the package.
If the or�g�nal packag�ng �s
m�ss�ng;
Avo�d �mpacts to the outer surface
of the appl�ance.
IMPORTANT INFORMATION REGARDING SAFETY
12.01.2022
OVEN USER GUIDE EN
8

nDo not place heavy loads on the
appliance.
nDuring transporting, place your
appliance parallel to the ground
(with the upper side facing up).
Packaging
All packaging materials are recy-
clable. Dispose of remains of
packaging material in recycling
containers to help protection of the
environment.
Disposing of Old Appliances
Appliances that are too old or not
in operable condition shall not be
disposed of directly in the trash.
Old electrical and electronic
devices may contain components
that may be reused and utilized.
Otherwise, the appliances that
include components that operate
the appliance and the ones sent to
the landfill may include materials
that may be harmful to the envi-
ronment.
Therefore, deliver your appliance
to the certain collection centers by
consulting your manufacturer to
ensure that the electrical and elec-
tronic parts are re-used.
Keeping this user manual is rec-
ommended since this provides
information regarding the opera-
tion of the appliance, if the appli-
ance is transferred to another
user. You have to prevent the
potential negative outcomes
against human health and environ-
ment before scrapping and dis-
posing of this appliance. Other-
wise, the appliance will be an
unsuitable waste.
This symbol on the product
aims the appliance to be consid-
ered as domestic waste, and to
warn for delivery to electrical and
electronic waste collection cen-
tres. Appliance disposal must be
conducted in accordance with
local environment regulations. You
can obtain detailed information on
disposing of the appliance, reusing
and recycling it from authorities.
IMPORTANT INFORMATION REGARDING SAFETY
12.01.2022 OVEN USER GUIDE EN 9

3 SPECIFICATIONS OF THE OVEN
These appliances are designed to operate with a single phase supply voltage of
220-240V at 50-60Hz.
F�g. 1
SPECIFICATIONS OF THE OVEN
12.01.2022
OVEN USER GUIDE EN
10

BO6503X03 - BO6503B03
Function 8
Oven Lamp 15 W
Product Dimensions (Width) 595 mm
Product Dimensions (Depth) 547 mm
Product Dimensions (Height) 595 mm
Product Installation Cabinet Dimen-
sions (Width) 560 mm
Product Installation Cabinet Dimen-
sions (Depth) 550 mm
Product Installation Cabinet Dimen-
sions (Height) 600 mm
Capacity 72 lt
Voltage 220-240 V
Maximum Power 2750 W
1
Fig. 2
You may access the nameplate of the
oven indicating technical specifications
of the oven even after installing the
oven in the kitchen. You may see this
nameplate when you open the door
the oven. Use the information provided
in this nameplate to specify the model
of your oven while ordering a spare
part (Fig. 2/1).
SPECIFICATIONS OF THE OVEN
12.01.2022 OVEN USER GUIDE EN 11

4 INSTALLATION OF APPLIANCE
560
600
130
300
130
80
+8
+8
556
595
20
547
595 573
80
550
560
130
300
130
50
80
590
max.594
80
550
Fig. 3
INSTALLATION OF APPLIANCE
12.01.2022
OVEN USER GUIDE EN
12

Corner Installation
Fig. 4
Fig. 5
The illustrations used in the user manual are for representative purposes.
Dimensional information provided in the drawings are given in mm.
INSTALLATION OF APPLIANCE
12.01.2022 OVEN USER GUIDE EN 13

Pay attention to the dimension Fig. 4 during the corner installation to allow
opening of the door of the appliance. Fig. 5 The dimension depends on the thick-
ness of the front face of the furniture placed under the handle.
Fig. 6
nThe fact that the oven becomes lighter when the door and the accessories are
removed facilitates in the placement of the oven inside the cabinet.
nPlace the appliance by centering it inside the built-in appliance cabinet.
nScrew the appliance securely.
nThe clearance between the worktop and the appliance shall not be closed with
additional sills or mouldings.
Installing the screw without drilling a hole suitable for the screw diameter in
the furniture may cause damage to your furniture.
nBe careful not to damage the installation holes by applying too much pressure
on the screws during installation.
nThe appliance may be installed on a high-placed cabinet or under the counter
as desired.
nWe recommended you to provide a minimum clearance of 70 mm from the
rear of the kitchen unit where the oven is installed
nParts that provide insulation and protection shall be installed so that they
cannot be removed by using any tool.
nWhen a built-in stove is installed on the counter on top of the oven, power
cords of the oven and the stove shall be separated for safety purposes and to
ease the removal of the oven from this stove when required.
The appliance shall always be installed by an Authorized Service. Our company
shall not be held responsible for damages that may occur on people, surroundings
or other materials due to incorrect installation of the appliance.
Inspect the appliance after opening the packaging. Do not perform the connection
of the appliance in case of a transport damage.
INSTALLATION OF APPLIANCE
12.01.2022
OVEN USER GUIDE EN
14

Take off and remove all packaging materials and adhesive tapes from the cooking
compartment and the door before operating the appliance.
Carefully read the installation pages for the installation of the accessories.
The installation dimensions to be used for all installation types of the appliance are
provided in Fig. 3, Fig. 4, Fig. 5.
Do not install the appliance behind a decoration or a furniture cover. This would
pose a risk due to overheating.
Cutting operations on the furniture shall be performed before the installation of the
appliance. Remove any burrs. They may have an adverse effect on the functioning
of electrical units.
Use protective gloves to prevent injuries.
You shall provide the shaded areas shown in the drawings for ventilation and
cooling inside the cabinet or cupboard to ensure correct operation of the appliance
(Fig. 3).
The connection outlet of the appliance shall be inside the shaded area shown or it
shall be out the installation area (Fig. 3).
Surfaces on the furnitures where the appliance is built-in shall withstand tempera-
tures up to 120 ºC.
A support that may handle the weight of the oven shall be put under it while
placing the oven.
For safety reasons, direct contact of the appliance with electrical parts shall be
prevented when the installation is complete.
Parts that provide insulation and protection shall be installed so that they cannot
be removed by using any tool.
We recommended you to install the appliance in a wall cabinet to ensure a more
efficient air circulation.
Rear compartment of the cabinet in the kitchen unit shall be removed to ensure a
more efficient air circulation.
We recommended you to provide a minimum clearance of 70 mm from the rear of
the kitchen unit where the appliance is installed.
We do not recommend installation of the appliance near a refrigerator or deep
freezer. Otherwise, the performance of such appliances shall be affected
adversely due to the dissipated heat.
To make your oven ready for operation, have the location it shall be placed in built
with the electrical installation. Then, call the Authorized Service.
INSTALLATION OF APPLIANCE
12.01.2022 OVEN USER GUIDE EN 15

5 POWER CONNECTION
nThe appliance shall be connected to the main electrical installation as per the
current rules and legislation and by an authorized service only.
nEnsure that the power received from the mains meet the power specified in
the nameplate placed on the bottom front of the appliance.
nIf the current value of the switch in your house is less than 16A, have a quali-
fied electrician install an 16A fuse switch.
nThe appliance shall always be grounded. Have an authorized electrician set
grounding equipment.
nPower cable of your oven is fitted with a grounded plug. This plug must be
used with a grounded line.
nPlace the appliance so that the outlet or double pole switch used for power
connection may be reached easily.
nDo not place the power cord in contact with hot surfaces and do not pinch it to
the product cover.
nThe temperature of the power cord shall not reach a temperature that is 50 ˚C
above the ambient temperature.
nPlease contact the nearest Authorized Service when the power cord gets
damaged. Have the authorized service replace the cord with a new one with
the same dimensions and plastic insulation and that may withstand the elec-
trical current required by the appliance.
nIf the appliance shall be connected directly to the mains, a double pole switch
suitable for carrying the desired load as per the current legislation and with a
clearance of 3mm between its contact points shall be installed between the
appliance and the mains. Grounding wire shall not be cut off by the double
pole switch.
nWe do not recommend usage of adapters, multi sockets or extension cords. If
it is absolutely required, you may use adaptors or extension cords by com-
plying with the applicable safety legislation. However, you shall never exceed
the maximum current capacity and the maximum power specified for the
adaptor.
nTest the heating elements for 3 minutes when the connection is complete.
Electrical safety of the appliance is guaranteed when it is correctly con-
nected to a suitable source with proper grounding as per the applicable
rules only. Our company shall not be held responsible for damages that
may occur on people, animals or objects due to improper grounding of the
appliance.
POWER CONNECTION
12.01.2022
OVEN USER GUIDE EN
16

sarı-yeşl / yellow-green
mav / blue
kahvereng / brown
3 ad. M4x6 Vda
3 pcs. M4x6 Screw
Fig. 7
POWER CONNECTION
12.01.2022 OVEN USER GUIDE EN 17

M
THERMOPROTECTOR
M
THERMOPROTECTOR
GRILL
L
N
12 3
1C
P1
P1
P2
P3
P4
P5
P6
P7
P8
1
2
3
4
5
6
7
8
MKNK
TIMER
orange (1x1.50 mm2)
red (1x1.50 mm2)
grey (1x1.50 mm2)
green (1x1.50 mm2)
brown (1x1.50 mm2)
blue (1x1.50 mm2)
black (1x1.00 mm2)
yellow
(1x1.50
mm2)
blue (1x1.50 mm2)
yellow
(1x1.50 mm2)
yellow-green (1x1.50 mm2)
yellow-green (1x1.50 mm2)
BOTTOM
RES.
THERMOSTAT
ROTARY
SWITCH
COOLING FAN
SUPPLY
TURBO FAN
TOP RES.
TURBO RES.
brown (1x1.00 mm2)
blue (1x1.50 mm2)
wh!te (1x1.00 mm2)
blue (1x1.50 mm2)
brown (1x1.50 mm2)
brown (1x1.50 mm2)
red (1x1.50 mm2)
blue (1x1.50 mm2)
red (1x1.50 mm2)
red (1x0.50 mm2)
wh!te (1x0.50 mm2)
blue (1x1.50 mm2)
yellow-green
(1x1.50 mm2)
OVEN
LAMP
WARNING
LAMP
yellow-green (1x1.50 mm2)
yellow-green (1x1.50 mm2)
yellow-green (1x1.50 mm2)
LIMIT
THER
MOSTAT
yellow (1x1.50 mm2)
blue
(1x1.50
mm2)
blue (1x1.50 mm2)
yellow
(1x1.50
mm2)
yellow-green
(1x1.50 mm2)
red (1x1.50 mm2)
NC
155°C
blue (1x1.50 mm2)
Fig. 8
THINGS TO DO FOR THE FIRST OPERATION OF THE APPLIANCE
nSet the temperature to maximum level.
nSet the function button to lower and upper grill position (or 3D position, if
applicable).
nOperate the oven in empty condition for 30 minutes in this way.
POWER CONNECTION
12.01.2022
OVEN USER GUIDE EN
18

nOpen the windows to ventilate your room.
nAt this time, a smell and smoke caused by the insulation materials and
heating elements may occur for once. In such a case, wait until the smell and
smoke wears off before putting any food inside the oven.
nClean the inside of the oven using a soft cloth slightly dampened with soapy
water.
Fig. 9
Always grab the handle from its center to open the oven door.
CAUTION!
Wash the components such as tray or grill with alkaline (non-abrasive)
cleaning agents before operating the oven for the first time.
5.1 Energy Efficiency of
the Oven
nOvens with high efficiency of
power and with heat insulation
shall be preferred.
nOpening the oven door frequently
during cooking allows the cold air
enter inside the oven each time,
thus it causes loss of energy.
Therefore, do not open the oven
door more than required.
nTry to cook multiple dishes simul-
taneously in the oven. Take the
meal cooked with a lower temper-
ature out first, and use less energy
without changing the oven temper-
ature.
nExcess heat remaining after
cooking a meal shall be used for
the next meal, too. This shall save
power.
nUse the pre-heating function of the
oven for a short time (10 minutes
at maximum).
POWER CONNECTION
Energy Efficiency of the Oven
12.01.2022 OVEN USER GUIDE EN 19

nFrozen food shall be thawed
before cooking in the oven.
nThe oven would continue cooking
with the current temperature using
less energy when it is turned off a
few minutes before the cooking
time.
POWER CONNECTION
Energy Efficiency of the Oven
12.01.2022
OVEN USER GUIDE EN
20
