SimCom SIM7000 Series Installation manual

SIM7000 Series_AT Command
Manual_V1.03
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 22018-05-08
Document Title SIM7000 SeriesAT Command Manual
Version 1.03
Date 2018-05-08
Status Release
Document Control ID SIM7000 Series_AT Command Manual_V1.03
General Notes
SIMCom offers this information as a service to its customers, to support application and
engineering efforts that use the products designed by SIMCom. The information provided is based
upon requirements specifically provided to SIMCom by the customers. SIMCom has not
undertaken any independent search for additional relevant information, including any information
that may be in the customer’s possession. Furthermore, system validation of this product designed
by SIMCom within a larger electronic system remains the responsibility of the customer or the
customer’s system integrator. All specifications supplied herein are subject to change.
Copyright
This document contains proprietary technical information which is the property of Shanghai
SIMCom Wireless Solutions Ltd, copying of this document and giving it to others and the using or
communication of the contents thereof, are forbidden without express authority. Offenders are
liable to the payment of damages. All rights reserved in the event of grant of a patent or the
registration of a utility model or design. All specification supplied herein are subject to change
without notice at any time.
Copyright © Shanghai SIMCom Wireless Solutions Ltd. 2018
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 32018-05-08
Contents
Version History.........................................................................................11
1Introduction.........................................................................................13
1.1 Scope of the document...................................................................................13
1.2 Related documents.........................................................................................13
1.3 Conventions and abbreviations......................................................................13
1.4 AT Command syntax......................................................................................13
1.4.1 Basic syntax ............................................................................................................14
1.4.2 S Parameter syntax..................................................................................................14
1.4.3 Extended Syntax......................................................................................................14
1.4.4 Combining AT commands on the same Command line..........................................14
1.4.5 Entering successive AT commands on separate lines..............................................15
1.5 Supported character sets ................................................................................15
1.6 Flow control...................................................................................................15
1.6.1 Software flow control (XON/XOFF flow control)..................................................15
1.6.2 Hardware flow control (RTS/CTS flow control).....................................................16
1.7 Definitions......................................................................................................16
1.7.1 Parameter Saving Mode..........................................................................................16
1.7.2 Max Response Time................................................................................................16
2AT Commands According to V.25TER .............................................17
2.1 Overview of AT Commands According to V.25TER.....................................17
2.2 Detailed Description of AT CommandsAccording to V.25TER....................18
2.2.1 A/ Re-issues the Last Command Given ...............................................................18
2.2.2 ATD Mobile Originated Call to Dial A Number ..................................................18
2.2.3 ATE Set Command Echo Mode...........................................................................19
2.2.4 ATH Disconnect Existing Connection .................................................................20
2.2.5 ATI Display Product Identification Information ..................................................20
2.2.6 ATL Set Monitor speaker loudness ......................................................................21
2.2.7 ATM Set Monitor Speaker Mode.........................................................................21
2.2.8 +++ Switch from Data Mode or PPP Online Mode to Command Mode..............21
2.2.9 ATO Switch from Command Mode to Data Mode ..............................................22
2.2.10 ATQ Set Result Code Presentation Mode ............................................................22
2.2.11 ATS0 Set Number of Rings beforeAutomaticallyAnswering the Call................23
2.2.12 ATS3 Set Command Line Termination Character................................................23
2.2.13 ATS4 Set Response Formatting Character...........................................................24
2.2.14 ATS5 Set Command Line Editing Character .......................................................25
2.2.15 ATS6 Pause Before Blind Dialling.......................................................................25
2.2.16 ATS7 Set Number of Seconds to Wait for Connection Completion.....................26
2.2.17 ATS8 Set Number of Seconds to Wait for Comma Dial Modifier Encountered in
Dial String of D Command .....................................................................................................26
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 42018-05-08
2.2.18 ATS10 Set Disconnect Delay after Indicating theAbsence of Data Carrier ........27
2.2.19 ATV TA Response Format ..................................................................................27
2.2.20 ATX Set CONNECT Result Code Format and Monitor Call Progress................29
2.2.21 AT&C Set DCD Function Mode..........................................................................29
2.2.22 AT&D Set DTR Function Mode ..........................................................................30
2.2.23 AT&E Set CONNECT Result Code Format About Speed...................................30
2.2.24 AT+GCAP Request Complete TA Capabilities List.............................................31
2.2.25 AT+GMI Request Manufacturer Identification....................................................31
2.2.26 AT+GMM Request TA Model Identification .......................................................31
2.2.27 AT+GMR Request TA Revision Identification of Software Release ...................32
2.2.28 AT+GOI Request Global Object Identification....................................................32
2.2.29 AT+GSN Request TA Serial Number Identification (IMEI)................................33
2.2.30 AT+ICF Set TE-TA Control Character Framing ..................................................34
2.2.31 AT+IFC Set TE-TA Local Data Flow Control.....................................................34
2.2.32 AT+IPR Set TE-TA Fixed Local Rate..................................................................35
3AT Commands According to 3GPP TS 27.007..................................37
3.1 Overview of AT Command According to 3GPP TS 27.007...........................37
3.2 Detailed Descriptions of AT Command According to 3GPP TS 27.007........37
3.2.1 AT+CGMI Request Manufacturer Identification .................................................37
3.2.2 AT+CGMM Request Model Identification ..........................................................38
3.2.3 AT+CGMR Request TA Revision Identification of Software Release.................38
3.2.4 AT+CGSN Request Product Serial Number Identification..................................39
3.2.5 AT+CSCS Select TE Character Set......................................................................39
3.2.6 AT+CIMI Request International Mobile Subscriber Identity...............................40
3.2.7 AT+CLCK Facility Lock......................................................................................41
3.2.8 AT+CMEE Report Mobile Equipment Error .......................................................42
3.2.9 AT+COPS Operator Selection..............................................................................43
3.2.10 AT+CPAS Phone Activity Status..........................................................................45
3.2.11 AT+CPIN Enter PIN ............................................................................................45
3.2.12 AT+CPWD Change Password..............................................................................46
3.2.13 AT+CRC Set Cellular Result Codes for Incoming Call Indication......................48
3.2.14 AT+CREG Network Registration.........................................................................49
3.2.15 AT+CRSM Restricted SIM Access......................................................................50
3.2.16 AT+CSQ Signal Quality Report...........................................................................51
3.2.17 AT+CPOL Preferred Operator List ......................................................................52
3.2.18 AT+COPN Read Operator Names........................................................................53
3.2.19 AT+CFUN Set Phone Functionality.....................................................................54
3.2.20 AT+CCLK Clock .................................................................................................55
3.2.21 AT+CSIM Generic SIM Access...........................................................................55
3.2.22 AT+CBC Battery Charge .....................................................................................56
3.2.23 AT+CUSD Unstructured Supplementary Service Data........................................57
3.2.24 AT+CNUM Subscriber Number...........................................................................58
4AT Commands According to 3GPP TS 27.005..................................59
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 52018-05-08
4.1 Overview of AT Commands According to 3GPP TS 27.005.........................59
4.2 Detailed Descriptions of AT CommandsAccording to 3GPP TS 27.005......59
4.2.1 AT+CMGD Delete SMS Message .......................................................................59
4.2.2 AT+CMGF Select SMS Message Format............................................................60
4.2.3 AT+CMGL List SMS Messages from Preferred Store.........................................61
4.2.4 AT+CMGR Read SMS Message..........................................................................64
4.2.5 AT+CMGS Send SMS Message ..........................................................................67
4.2.6 AT+CMGW Write SMS Message to Memory.....................................................68
4.2.7 AT+CMSS Send SMS Message from Storage .....................................................70
4.2.8 AT+CNMI New SMS Message Indications.........................................................71
4.2.9 AT+CPMS Preferred SMS Message Storage.......................................................73
4.2.10 AT+CRES Restore SMS Settings.........................................................................74
4.2.11 AT+CSAS Save SMS Settings.............................................................................75
4.2.12 AT+CSCA SMS Service Center Address.............................................................76
4.2.13 AT+CSDH Show SMS Text Mode Parameters....................................................77
4.2.14 AT+CSMP Set SMS Text Mode Parameters........................................................77
4.2.15 AT+CSMS Select Message Service .....................................................................78
5AT Commands Special for SIMCom .................................................80
5.1 Overview........................................................................................................80
5.2 Detailed Descriptions of Commands.............................................................81
5.2.1 AT+CPOWD Power off.......................................................................................81
5.2.2 AT+CADC Read ADC ........................................................................................81
5.2.3 AT+CFGRI Indicate RI When Using URC .........................................................82
5.2.4 AT+CLTS Get Local Timestamp.........................................................................82
5.2.5 AT+CBAND Get and Set Mobile Operation Band..............................................84
5.2.6 AT+CNBP Set the state of the band preference ...................................................85
5.2.7 AT+CNSMOD Show network system mode...........................................................87
5.2.8 AT+CSCLK Configure Slow Clock.....................................................................88
5.2.9 AT+CCID Show ICCID.......................................................................................88
5.2.10 AT+CDEVICE View Current Flash Device Type...............................................89
5.2.11AT+GSV Display Product Identification Information..........................................89
5.2.12 AT+SGPIO Control the GPIO..............................................................................90
5.2.13 AT+SLEDS Set the Timer Period of Net Light....................................................90
5.2.14 AT+CNETLIGHT Close the Net Light or Open It to Shining .............................91
5.2.15 AT+CSGS Netlight Indication of GPRS Status...................................................92
5.2.16 AT+CGPIO Control the GPIO by PIN Index.......................................................93
5.2.17 AT+CBATCHK Set VBAT Checking Feature ON/OFF.....................................94
5.2.18 AT+CNMP Preferred mode selection..................................................................94
5.2.19 AT+CMNB Preferred selection between CAT-M and NB-IoT...........................95
5.2.20 AT+CPSMS Power Saving Mode Setting............................................................96
5.2.21 AT+CEDRXS Entended-DRX Setting ................................................................97
5.2.22 AT+CPSI Inquiring UE system information........................................................98
5.2.23 AT+CGNAPN Get Network APN in CAT-M Or NB-IOT.................................100
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 62018-05-08
5.2.24 AT+CSDP Service Domain Preference .............................................................100
5.2.25 AT+MCELLLOCK Lock the special CAT-M cell................................................101
5.2.26 AT+NCELLLOCK Lock the special NB-IOT cell...............................................102
5.2.27 AT+NBSC Config NB-IOT Scrambling Feature...............................................102
5.2.28 AT+CAPNMODE Select the Mode of Application Configure APN .................103
5.2.29 AT+CRRCSTATE Query RRC State ................................................................104
5.2.30 AT+CBANDCFG Configure CAT-M Or NB-IOT Band ...................................105
5.2.31 AT+CNACT App Network Active ....................................................................105
5.2.32 AT+CEDUMP Set whether the module reset when the module is crashed........106
5.2.33 AT+CNBS Configure Band Scan Optimization For NB-IOT ...........................107
5.2.34 AT+CNDS Configure Service Domain Preference For NB-IOT.......................108
5.2.35 AT+CENG Switch on or off Engineering Mode................................................109
6AT Commands for GPRS Support ...................................................111
6.1 Overview of AT Commands for GPRS Support ..........................................111
6.2 Detailed Descriptions of AT Commands for GPRS Support .......................111
6.2.1 AT+CGATT Attach or Detach from GPRS Service...........................................111
6.2.2 AT+CGDCONT Define PDP Context................................................................112
6.2.3 AT+CGACT PDP Context Activate or Deactivate.............................................113
6.2.4 AT+CGPADDR Show PDPAddress..................................................................114
6.2.5 AT+CGREG Network Registration Status.........................................................116
6.2.6 AT+CGSMS Select Service for MO SMS Messages.........................................117
7AT Commands for IP Application....................................................119
7.1 Overview......................................................................................................119
7.2 Detailed Descriptions of Commands...........................................................119
7.2.1 AT+SAPBR Bearer Settings for Applications Based on IP................................119
8AT Commands for TCPIP Application Toolkit ...............................121
8.1 Overview......................................................................................................121
8.2 Detailed Descriptions of Commands...........................................................122
8.2.1 AT+CIPMUX Start Up Multi-IP Connection.....................................................122
8.2.2 AT+CIPSTART Start Up TCP or UDP Connection............................................122
8.2.3 AT+CIPSEND Send Data Through TCP or UDP Connection ...........................125
8.2.4 AT+CIPQSEND Select Data Transmitting Mode ..............................................127
8.2.5 AT+CIPACK Query Previous Connection Data Transmitting State ..................127
8.2.6 AT+CIPCLOSE Close TCP or UDP Connection..............................................128
8.2.7 AT+CIPSHUT Deactivate GPRS PDP Context.................................................129
8.2.8 AT+CLPORT Set Local Port..............................................................................129
8.2.9 AT+CSTT Start Task and Set APN, USER NAME, PASSWORD ...................130
8.2.10 AT+CIICR Bring Up Wireless Connection with GPRS.....................................131
8.2.11 AT+CIFSR Get Local IPAddress ......................................................................132
8.2.12 AT+CIFSREX Get Local IPAddress extend......................................................132
8.2.13 AT+CIPSTATUS Query Current Connection Status..........................................133
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 72018-05-08
8.2.14 AT+CDNSCFG Configure Domain Name Server .............................................135
8.2.15 AT+CDNSGIP Query the IPAddress of Given Domain Name .........................135
8.2.16 AT+CIPHEAD Add an IP Head at the Beginning of a Package Received.........136
8.2.17 AT+CIPATS Set Auto Sending Timer ................................................................137
8.2.18 AT+CIPSPRT Set Prompt of ‘>’When Module Sends Data..............................138
8.2.19 AT+CIPSERVER Configure Module as Server .................................................138
8.2.20 AT+CIPCSGP Set GPRS for Connection Mode................................................139
8.2.21 AT+CIPSRIP Show Remote IP Address and Port When Received Data...........140
8.2.22 AT+CIPDPDP Set Whether to Check State of GPRS Network Timing.............141
8.2.23 AT+CIPMODE Select TCPIPApplication Mode ..............................................142
8.2.24 AT+CIPCCFG Configure Transparent Transfer Mode.......................................142
8.2.25 AT+CIPSHOWTP Display Transfer Protocol in IP Head When Received Data143
8.2.26 AT+CIPUDPMODE UDP Extended Mode........................................................144
8.2.27 AT+CIPRXGET Get Data from Network Manually..........................................145
8.2.28 AT+CIPRDTIMER Set Remote Delay Timer ...................................................147
8.2.29 AT+CIPSGTXT Select GPRS PDP context ......................................................148
8.2.30 AT+CIPSENDHEX Set CIPSEND Data Format to Hex...................................149
8.2.31 AT+CIPHEXS Set Output-data Format with suffix...........................................149
8.2.32 AT+CIPTKA Set TCP Keepalive Parameters....................................................150
8.2.33 AT+CIPOPTION Enable or Disable TCP nagle algorithm ...............................151
9AT Commands for HTTP Application .............................................152
9.1 Overview......................................................................................................152
9.2 Detailed Descriptions of Commands...........................................................152
9.2.1 AT+HTTPINIT Initialize HTTP Service............................................................152
9.2.2 AT+HTTPTERM Terminate HTTP Service.......................................................153
9.2.3 AT+HTTPPARA Set HTTP Parameters Value...................................................153
9.2.4 AT+HTTPDATA Input HTTP Data....................................................................155
9.2.5 AT+HTTPACTION HTTP Method Action ........................................................155
9.2.6 AT+HTTPREAD Read the HTTP Server Response ..........................................157
9.2.7 AT+HTTPSTATUS Read HTTP Status..............................................................158
9.2.8 AT+HTTPHEAD Read the HTTP Header Information of Server Response.....159
9.2.9 AT+HTTPTOFS download file to ap file system...............................................159
10 AT Commands for PING Application...........................................162
10.1 Overview ..................................................................................................162
10.2 Detailed Descriptions of Commands........................................................162
10.2.1 AT+CIPPING PING Request.............................................................................162
10.2.2 AT+CIPCTL Set the Mode When Receiving an IP Packet ................................163
10.2.3 AT+CIPFLT Set the Rules of IP Filter ...............................................................164
11 AT Commands for FTP Application .............................................166
11.1 Overview......................................................................................................166
11.2 Detailed Descriptions of Commands...........................................................167
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 82018-05-08
11.2.1 AT+FTPPORT Set FTP Control Port .................................................................167
11.2.2 AT+FTPMODE Set Active or Passive FTP Mode .............................................167
11.2.3 AT+FTPTYPE Set the Type of Data to Be Transferred .....................................168
11.2.4 AT+FTPPUTOPT Set FTP Put Type..................................................................169
11.2.5 AT+FTPCID Set FTP Bearer Profile Identifier..................................................169
11.2.6 AT+FTPREST Set Resume Broken Download..................................................170
11.2.7 AT+FTPSERV Set FTP Server Address.............................................................171
11.2.8 AT+FTPUN Set FTP User Name .......................................................................171
11.2.9 AT+FTPPW Set FTP Password..........................................................................172
11.2.10 AT+FTPGETNAME Set Download File Name.................................................173
11.2.11 AT+FTPGETPATH Set Download File Path .....................................................173
11.2.12 AT+FTPPUTNAME Set Upload File Name......................................................174
11.2.13 AT+FTPPUTPATH Set Upload File Path...........................................................175
11.2.14 AT+FTPGET Download File.............................................................................175
11.2.15 AT+FTPPUT Set Upload File ............................................................................177
11.2.16 AT+FTPDELE Delete Specified File in FTP Server..........................................178
11.2.17 AT+FTPSIZE Get the Size of Specified File in FTP Server..............................178
11.2.18 AT+FTPSTATE Get the FTP State.....................................................................179
11.2.19 AT+FTPEXTPUT Extend Upload File .................................................................180
11.2.20 AT+FTPMKD Make Directory on the Remote Machine...................................181
11.2.21 AT+FTPRMD Remove Directory on the Remote Machine...............................181
11.2.22 AT+FTPLIST List Contents of Directory on the Remote Machine ...................182
11.2.23 AT+FTPEXTGET Extend Download File .........................................................183
11.2.24 AT+FTPETPUT Upload File .............................................................................184
11.2.25 AT+FTPETGET Download File ........................................................................185
11.2.26 AT+FTPQUIT Quit Current FTP Session..........................................................186
11.2.27 AT+FTPRENAME Rename the Specified File on the Remote Machine...........187
11.2.28 AT+FTPMDTM Get the Last Modification Timestamp of Specified File on the
Remote Machine...................................................................................................................188
12 AT Command for NTP function....................................................189
12.1 Overview ..................................................................................................189
12.2 Detailed Descriptions of Commands........................................................189
12.2.1 AT+CNTPCID Set GPRS Bearer Profile’s ID ...................................................189
12.2.2 AT+CNTP Sychronize Network Time................................................................189
13 AT Commands for OneNet Application........................................192
13.1 Overview ..................................................................................................192
13.2 Detailed Descriptions of Commands........................................................192
13.2.1 AT+MIPLCREATE Create OneNet configuration.............................................192
13.2.2 AT+MIPLDELETE Delete OneNet configuration.............................................193
13.2.3 AT+MIPLOPEN Connect to OneNet.................................................................193
13.2.4 AT+MIPLADDOBJ Add object.........................................................................194
13.2.5 AT+MIPLDELOBJ Delete Object.....................................................................194
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 92018-05-08
13.2.6 AT+MIPLCLOSE Disconnect to OneNet..........................................................195
13.2.7 AT+MIPLNOTIFY Notify data to OneNet........................................................195
13.2.8 AT+MIPLREADRSP Send response on read command....................................196
13.2.9 AT+MIPLWRITERSP Send response on write command.................................197
13.2.10 AT+MIPLEXECUTERSP Send response on execute command ...................197
13.2.11 AT+MIPLOBSERVERSP Send response on observe command .......................198
13.2.12 AT+MIPLDISCOVERRSP Send response on discover command................198
13.2.13 AT+MIPLPARAMETERRSP Send response on parameter command..........199
13.2.14 AT+MIPLUPDATE Update registeration ......................................................200
13.2.15 AT+MIPLVER Version of OneNet SDK........................................................200
14 AT Commands for Telecom IOT Application ..............................201
14.1 Overview ..................................................................................................201
14.2 Detailed Descriptions of Commands........................................................201
14.2.1 AT+SIMLCREATE Create configuration..........................................................201
14.2.2 AT+SIMLMODE Connection mode..................................................................201
14.2.3 AT+SIMLOPEN Connect to Telecom IOT........................................................202
14.2.4 AT+SIMLSEND Send data to Telecom IOT......................................................202
14.2.5 AT+SIMLCLOSE Disconnect to Telecom IOT .................................................203
15 AT Commands for GNSS Application..........................................204
15.1 Overview ..................................................................................................204
15.2 Detailed Descriptions of Commands........................................................205
15.2.1 AT+CGNSPWR GNSS Power Control..............................................................205
15.2.2 AT+CGNSINF GNSS Navigation Information Parsed From NMEA Sentences205
15.2.3 AT+CGNSURC GNSS Navigation URC Report...............................................208
15.2.4 AT+CGNSPORT GNSS NMEA Out Port Set....................................................209
15.2.5 AT+CGNSCOLD GNSS Cold Start...................................................................209
15.2.6 AT+CGNSWARM GNSS Warm Start ...............................................................210
15.2.7 AT+CGNSHOT GNSS Hot Start .......................................................................210
15.2.8 AT+CGNSMOD GNSS Work Mode Set ...........................................................211
15.2.9 AT+CGNSCFG GNSS NMEA Out Configure ..................................................212
15.2.10 AT+CGNSTST GNSS NMEA Data Out Put To At Port................................213
15.2.11AT+CGNSXTRA GNSS XTRA Function Open................................................214
15.2.12 AT+CGNSCPY GNSS XTRA File Copy.......................................................214
16 AT Commands for File System.....................................................216
16.1 Overview ..................................................................................................216
16.2 Detailed Descriptions of Commands........................................................216
16.2.1 AT+CFSINIT Get Flash Data Buffer.................................................................216
16.2.2 AT+CFSWFILE Write File to the Flash Buffer Allocated by CFSINIT ...........217
16.2.3 AT+CFSRFILE Read File from Flash ...............................................................217
16.2.4 AT+CFSDFILE Delete the File from the Flash.................................................218
16.2.5 AT+CFSGFIS Get File Size...............................................................................219
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 10 2018-05-08
16.2.6 AT+CFSREN Rename a file..............................................................................220
16.2.7 AT+CFSGFRS Get the size of File System.......................................................221
16.2.8 AT+CFSTERM Free the Flash Buffer Allocated by CFSINIT..........................221
16.2.9 AT+CBAINIT Initialize the ap backup file system ...........................................222
16.2.10 AT+CBALIST Set the files which want to backup........................................222
16.2.11 AT+CBAPPS Start to backup ap file system Allocated by CBAINIT and
CBALIST 223
16.2.12 AT+CBART Restore the file into ap file system ...........................................223
17 AT Commands for SIM Application Toolkit................................224
17.1 Overview ..................................................................................................224
17.2 Detailed Descriptions of Commands........................................................224
17.2.1 AT+STIN SAT Indication..................................................................................224
17.2.2 AT+STGI Get SAT information ........................................................................225
17.2.3 AT+STGR SAT respond....................................................................................227
17.2.4 AT+STK STK Switch........................................................................................228
18 AT Commands for TCP/UDP Application Supported SSL..........229
18.1 Overview ..................................................................................................229
18.2 Detailed Descriptions of Commands........................................................229
18.2.1 AT+CACID Set TCP/UDP Identifier.................................................................229
18.2.2 AT+CASSL Set protocol and SSL context identifier .........................................230
18.2.3 AT+CASSLCFG Set SSL certificate and timeout parameters ...........................231
18.2.4 AT+CAOPEN Open a TCP/UDP connection.....................................................232
18.2.5 AT+CASEND Send data via an established connection ....................................234
18.2.6 AT+CARECV Receive data via an established connection ...............................234
18.2.7 AT+CACLOSE Close a TCP/UDP connection..................................................235
18.2.8 AT+CSSLCFG Configure SSL parameters of a context identifier.....................235
19 Supported Unsolicited Result Codes.............................................240
19.1 Summary of CME ERROR Codes...........................................................240
19.2 Summary of CMS ERROR Codes ...........................................................243
19.3 Summary of Unsolicited Result Codes ....................................................247
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 11 2018-05-08
Version History
Version
Date
Chapter
What is new
V1.00 2017-06-22 New version
V1.01 2017-09-08 5.2.22 AT+CPSI Add AT command
5.2.23AT+CGNAPN
Add AT command
5.2.24AT+CSDP Add AT command
5.2.25AT+MCELLLOCK Add AT command
5.2.26AT+NCELLLOCK Add AT command
5.2.27AT+NBSC Add AT command
Charpter 7 Add IP
Charpter 9 Add HTTP
Charpter 10 Add PINGs
Charpter 13 Add GNSS
V1.02 2017-12-18 Delete ATZ,AT&F,AT&V
All
Modify parameter save mode and max
response time
1.7.1 AddAUTO_SAVE_REBOOT
1.7.2 Add Max response time
2.2.2 ATD Delete parameters <;>
3.2.14AT+CREG Change description of parameters
5.2.28AT+CAPNMODE
Add AT command
5.2.29AT+CRRCSTATE Add AT command
5.2.30AT+CBANDCFG Add AT command
8.2.2 AT+CIPSTART C
hange range of parameter <n> from
0…5 to 0…7
8.2.32AT+CIPTKA Add AT command
8.2.33AT+CIPOPTION Add AT command
Charpter 11
Add FTP
Charpter 12 Add NTP
13.3.10AT+CGNSTST Add AT Command
V1.03 2018-05-08 3.2.17 AT+CPOL Modify parameters
3.2.24AT+CNUM Add AT Command
5.2.1 AT+CEDRXS Modify range of < AcT-type>
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 12 2018-05-08
5.2.31AT+CNACT Add AT Command
5.2.32AT+CEDUMP Add AT Command
5.2.33AT+CNBS
Add AT Command
5.2.34AT+CNDS
Add AT Command
5.2.35AT+CENG Add AT Command
9.2.9 AT+HTTPTOFS Add AT Command
Charpter 13 Add OneNet
Charpter 14 Add Telecom IOT
Charpter 15 Add GNSS
Charpter 16 Add File system
Charpter 17 Add SAT
Charpter 18 Add SSL
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 13 2018-05-08
1Introduction
1.1 Scope of the document
This document presents the AT Command Set for SIMCom SIM7000 Series, including
SIM7000A, SIM700C, SIM7000E, SIM7000C-N, SIM7000E-N, SIM7000JC and SIM7000G.
1.2 Related documents
You can visit the SIMCom Website using the following link:
http://www.simcomm2m.com
1.3 Conventions and abbreviations
In this document, the GSM engines are referred to as following term:
ME (Mobile Equipment);
MS (Mobile Station);
TA (Terminal Adapter);
DCE (Data Communication Equipment) or facsimile DCE (FAX modem, FAX board);
In application, controlling device controls the GSM engine by sending AT Command via its
serial interface. The controlling device at the other end of the serial line is referred to as
following term:
TE (Terminal Equipment);
DTE (Data Terminal Equipment) or plainly "the application" which is running on an embedded
system;
1.4 AT Command syntax
The "AT" or "at" or "aT" or "At" prefix must be set at the beginning of each Command line. To
terminate a Command line enter <CR>.
Commands are usually followed by a response that includes.
"<CR><LF><response><CR><LF>"
Throughout this document, only the responses are presented,<CR><LF> are omitted
intentionally.
The AT Command set implemented by SIM7000 Series is a combination of 3GPP TS 27.005,
3GPP TS 27.007 and ITU-T recommendation V.25ter and the AT commands developed by
SIMCom.
Note: Only enter AT Command through serial port after SIM7000 Series is powered on and Unsolicited Result
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 14 2018-05-08
Code "RDY" is received from serial port. If auto-bauding is enabled, the Unsolicited Result Codes "RDY"
and so on are not indicated when you start up the ME, and the "AT" prefix, or "at" prefix must be set at the
beginning of each command line.
All these AT commands can be split into three categories syntactically: "basic", "S parameter",
and "extended". These are as follows:
1.4.1 Basic syntax
These AT commands have the format of "AT<x><n>", or "AT&<x><n>", where "<x>"is the
Command, and "<n>"is/are the argument(s) for that Command. An example of this is "ATE<n>",
which tells the DCE whether received characters should be echoed back to the DTE according to
the value of "<n>". "<n>" is optional and a default will be used if missing.
1.4.2 S Parameter syntax
These AT commands have the format of "ATS<n>=<m>", where "<n>" is the index of the S
register to set, and "<m>"is the value to assign to it. "<m>" is optional; if it is missing, then a
default value is assigned.
1.4.3 Extended Syntax
These commands can operate in several modes, as in the following table:
Table 1: Types ofAT commands and responses
Test Command AT+<x>=?
The mobile equipment returns the list of parameters
and value ranges set with the corresponding Write
Command or by internal processes.
Read Command AT+<x>? This command
returns the currently set value of the
parameter or parameters.
Write Command AT+<x>=<…> This command sets the user-
definable parameter
values.
Execution Command AT+<x> The execution command reads non-variable
parameters affected by internal processes in the GSM
engine.
1.4.4 Combining AT commands on the same Command line
You can enter several AT commands on the same line. In this case, you do not need to type the
"AT" or "at" prefix before every command. Instead, you only need type "AT" or "at" the
beginning of the command line. Please note to use a semicolon as the command delimiter after
an extended command; in basic syntax or S parameter syntax, the semicolon need not enter, for
example: ATE1Q0S0=1S3=13V1X4;+IFC=0,0;+IPR=115200.
The Command line buffer can accept a maximum of 559 characters (counted from the first
command without "AT" or "at" prefix) or 39 AT commands. If the characters entered exceeded
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 15 2018-05-08
this number then none of the Command will executed and TA will return "ERROR".
1.4.5 Entering successiveAT commands on separate lines
When you need to enter a series of AT commands on separate lines, please Note that you need to
wait the final response (for example OK, CME error, CMS error) of last AT Command you
entered before you enter the nextAT Command.
1.5 Supported character sets
The SIM7000 Series AT Command interface defaults to the IRA character set. The SIM7000
Series supports the following character sets:
GSM format
UCS2
IRA
The character set can be set and interrogated using the "AT+CSCS" Command (3GPP TS
27.007). The character set is defined in GSM specification 3GPP TS 27.005.
The character set affects transmission and reception of SMS and SMS Cell Broadcast messages,
the entry and display of phone book entries text field and SIMApplication Toolkit alpha strings.
1.6 Flow control
Flow control is very important for correct communication between the GSM engine and DTE.
For in the case such as a data or fax call, the sending device is transferring data faster than the
receiving side is ready to accept. When the receiving buffer reaches its capacity, the receiving
device should be capable to cause the sending device to pause until it catches up.
There are basically two approaches to achieve data flow control: software flow control and
hardware flow control. SIM7000 Series support both two kinds of flow control.
In Multiplex mode, it is recommended to use the hardware flow control.
1.6.1 Software flow control (XON/XOFF flow control)
Software flow control sends different characters to stop (XOFF, decimal 19) and resume (XON,
decimal 17) data flow. It is quite useful in some applications that only use three wires on the
serial interface.
The default flow control approach of SIM7000 Series is hardware flow control (RTS/CTS flow
control), to enable software flow control in the DTE interface and within GSM engine, type the
following AT Command:
AT+IFC=1,1
Ensure that any communications software package (e.g. Hyper terminal) uses software flow
control.
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 16 2018-05-08
NOTE:
Software Flow control should not be used for data calls where binary data will be transmitted or
received (e.g. TCP/IP) as the DTE interface may interpret binary data as flow control characters.
1.6.2 Hardware flow control (RTS/CTS flow control)
Hardware flow control achieves the data flow control by controlling the RTS/CTS line. When the
data transfer should be suspended, the CTS line is set inactive until the transfer from the
receiving buffer has completed. When the receiving buffer is ok to receive more data, CTS goes
active once again.
To achieve hardware flow control, ensure that the RTS/CTS lines are present on your application
platform.
1.7 Definitions
1.7.1 Parameter Saving Mode
For the purposes of the present document, the following syntactical definitions apply:
NO_SAVE: The parameter of the current AT command will be lost if module is rebooted or
current AT command doesn't have parameter.
AUTO_SAVE: The parameter of the current AT command will be kept in NVRAM
automatically and take in effect immediately, and it won't be lost if module is rebooted.
AUTO_SAVE_REBOOT: The parameter of the current AT command will be kept in
NVRAM automatically and take in effect after reboot, and it won't be lost if module is
rebooted.
-:"-" means this AT command doesn’t care the parameter saving mode.
1.7.2 Max Response Time
Max response time is estimated maximum time to get response, the unit is seconds.
"-" means this AT command doesn’t care the response time.
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 17 2018-05-08
2AT Commands According to V.25TER
These AT Commands are designed according to the ITU-T (International Telecommunication
Union, Telecommunication sector) V.25ter document.
2.1 Overview of AT Commands According to V.25TER
Command
Description
A/
Re-issues the last command given
ATD Mobile originated call to dial a number
ATE Set command echo mode
ATH Disconnect existing connection
ATI Display product identification information
ATL
Set monitor speaker loudness
ATM Set monitor speaker mode
+++
Switch from data mode or ppp online mode to command mode
ATO Switch from command mode to data mode
ATQ Set result code presentation mode
ATS0 Set number of rings before automatically answering the call
ATS3 Set command line termination character
ATS4
Set response formatting character
ATS5
Set command line editing character
ATS6 Pause before blind dialling
ATS7 Set number of seconds to wait for connection completion
ATS8 Set number of seconds to wait for comma dial modifie
r encountered in
dial string of D command
ATS10
Set disconnect delay after indicating the absence of data carrier
ATV TA response format
ATX Set connect result code format and monitor call progress
ATZ Reset default configuration
AT&C Set DCD function mode
AT&D
Set DTR function mode
AT&F
Factory defined configuration
AT&V Display current configuration
AT&E Set CONNECT Result Code FormatAbout Speed
AT+GCAP Request complete TA capabilities list
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 18 2018-05-08
AT+GMI
Request manufacturer identification
AT+GMM Request TA model identification
AT+GMR
Request TA revision identification of software release
AT+GOI Request global object identification
AT+GSN Request TA serial number identification (IMEI)
AT+ICF Set TE-TA control character framing
AT+IFC Set TE-TA local data flow control
AT+IPR
Set TE-TA fixed local rate
2.2 Detailed Description ofAT Commands According to V.25TER
2.2.1 A/ Re-issues the Last Command Given
A/ Re-issues the Last Command Given
Execution
Command
A/
Response
Re-issues the previous Command
Reference
V.25ter
Note
2.2.2 ATD Mobile Originated Call to Dial A Number
ATD Mobile Originated Call to Dial A Number
Execution
Command
ATD<n>[<mgsm
]
Response
This command can be used to set up outgoing data calls
. It also serves to
control supplementary services.
Note: This command may be aborted generally by receiving an ATH
Command or a character during execution. The aborting is not possible
during some states of connection establishment such as handshaking.
If error is related to ME functionality
+CME ERROR: <err>
If no dial tone and (parameter setting ATX2 or ATX4)
NO DIALTONE
If busy and (parameter setting ATX3 or ATX4)
BUSY
If a connection cannot be established
NO CARRIER
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 19 2018-05-08
If the remote station does not answer
NO ANSWER
If connection successful and non-voice call.
CONNECT<text> TA switches to data mode.
Note: <text> output only if ATX<value>
parameter setting with the
<value> >0
When TA returns to command mode after call release
OK
Parameters
<n> String of dialing digits and optionally V.25ter modifiers dialing
digits: 0-9, * , #, +, A, B, C
Following V.25ter modifiers are ignored:
,(comma), T, P, !, W, @
Emergency call:
<n> Standardized emergency number 112 (no SIM needed)
<mgsm> String of GSM modifiers:
IActives CLIR (Disables presentation of own number to
called party)
iDeactivates CLIR
(Enable presentation of own number
to called party)
GActivates Closed User Group invocation for this call
only
g Deactivates Closed User Group invocation for this call
only
Parameter Saving
Mode
NO_SAVE
Max Response
Time
Timeout set with ATS7 (data call)
Reference
V.25ter
Note
2.2.3 ATE Set Command Echo Mode
ATE Set Command Echo Mode
Execution
Command
ATE<value>
Response
This setting determines whethe
r or not the TA echoes characters received
from TE during Command state.
OK
Parameters
SIMCOM COMFIDENTIAL FILE

Smart Machine Smart Decision
SIM7000 Series_AT Command Manual_V1.03 20 2018-05-08
<value> 0Echo mode off
1Echo mode on
Parameter Saving
Mode
Max Response
Time
-
Reference
V.25ter
Note
2.2.4 ATH Disconnect Existing Connection
ATH Disconnect Existing Connection
Execution
Command
ATH
Response
Disconnect existing call by local TE from Command line and terminate call
OK
Note: OK is issued after circuit 109(DCD) is turned off, if it was previously
on.
Parameter Saving
Mode
NO_SAVE
Max
Response
Time
20s
Reference
V.25ter
Note
2.2.5 ATI Display Product Identification Information
ATI Display Product Identification Information
Execution
Command
ATI
Response
TA issues product information text
Example:
SIM7000 R1351
OK
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
SIMCOM COMFIDENTIAL FILE
