Simmons SOHO User manual

ADULT ASSEMBLY REQUIRED
If you are missing any parts or have any questions regarding assembly,
do not return this item to the retailers store. Please call our toll-free, customer
service number and have this assembly manual open to the parts list ready to
provide the model name, number and part name or number.
Customer Service
1-877-864-5752
8:30 AM PST - 4:00 PM PST (Monday-Friday)
Website: www.simmonsconvertibles.com
Missing Parts: [e-mail]
Warranty Information: www.simmonsconvertibles.com/warranty
4-4 2017/06
WARNING: This product may contain small components,
please ensure they are kept away from small children.
SOHO
CONVERTIBLE SOFA
2Attach Back Legs (C), Center Support Legs (B), Left Front Leg (D) and
Right Front Leg (E) to Sofa Body (A) using Washer (1) and Bolt (2).
Tighten using provided Allen Key (4).
3Operate your convertible sofa by pushing the backrest forward, this will
release the sofa to the bed position. Lift the backrest up to transition from
bed position to either lounge or sofa position. This sofa has a split back
which will allow you to operate either the left or right side independently.

PARTS
A. SOFA BODY
1X
PLEASE NOTE: Color variation of WOOD ARMS is part of the natural beauty
of this product. To ensure the lasting beauty of your futon,
please use furniture polish on all wood surfaces.
B. CENTER
SUPPORT LEG
2X
C. BACK LEG
2X
D. LEFT FRONT LEG
1X
E. RIGHT FRONT LEG
1X
2-4 3-4
HARDWARE
Please do not completely tighten any screws until the entire assembly is complete.
Once assembly is complete, please be sure to tighten all hardware.
1. WASHER
14X
3. BOLT 1/4X 1/4
8X
4. 5 MM ALLEN KEY
1X
2. BOLT 5/16X 1
14X
5. 4 MM ALLEN KEY
1X
1Flip Sofa Body (A) over.
Pull out Hardware and Parts from the zippered compartment.
FINGER GUARD
• U.S. Patent No. 8,875,321
• Provides Users a Permanent Safety Solution
• Eliminates the Risk & Liability of an Accident
• Heavy Duty, Fully Welded, Protective Metal Plate
