Baxton Studio LC22040702 User manual

TV Stand
ASSEMBLY INSTRUCTION
Date last updated:07-29-2022
1

2
HARDWARE LIST
A
12 PCS
E
16 PCS
I
2 PCS
M
M-1
4 PCS
B
12 PCS
F
24 PCS
J
4 PCS
N
1 PCS
C
28 PCS
G
K
4 PCS
O
D
2 PCS
H
4 PCS
L
4 PCS
3.5x14mm
L-1 L-2
D-1 D-2
2 PCS
10 PCS
M-2

3
PARTS LIST
-1 PC
1-1 PC 2-1 PC3-1 PCS 4
-1 PC5-1 PC6-1 PC
7-2 PCS8
-2 PCS9-2 PCS10 -2 PCS
11 -2 PCS 12
-2 PC13 -1 PC
14

4
ASSEMBLY STEPS
STEP 1.
Fix parts 4 and 14 to part 5 with wooden dowels (C) and screws (E), as shown.
Insert quickfit screws (A) into part 1, as shown.
Fix silicone cushion pads (I) to part 1, as shown.
STEP 2.
CX 4
EX 4
C
C
E
E
E
C
E
5
4
14
E
1
AX 8
I X 2
A
A
A
A
I
I
C
AA
A
A
A
A
A
A
I

5
ASSEMBLY STEPS
STEP 3.
STEP 4.
B X 4
CX 4
1C
C
C
CB
B
B
B
54
B
B
A
CB
C
C
C
C
B
B
1
A
B
B
C
B
6
3
B X 4 CX 4
B
B
Insert cam locks (B) and wooden dowels (C) into parts 4 and 14, as shown.
Fit part 1 to parts 4 and 14, as shown.
Turn cam locks clockwise to tighten.
Insert cam locks (B) and wooden dowels (C) into parts 3 and 6, as shown.
Fit parts 3 and 6 to part 1, as shown.
Turn cam locks clockwise to tighten.
14

6
ASSEMBLY STEPS
STEP 5.
STEP 6.
2
3
4
6
14
EE
EE
712
12
E X 4
E
E
Slide part 2 into grooves between parts 3 and 6, as shown.
Fix parts 12 to part 7 using screws (E), as shown.

7
ASSEMBLY STEPS
STEP 7.
STEP 8.
C X 8
EX 8
C
C
E
E
C
C
C
E
E
E
C
E
C
E
C
E
7
3
4
6
C
E
A X 4
AA
A
A9x2
Bx2
10 B X 4
9
8
B
B
A
8
B
B
14
Insert wooden dowels (C) into parts 3, 4, 14 and 6, as shown.
Attach part 7 to parts 3, 4, 14 and 6 with screws (E), as shown.
Insert quickfit screws (A) into parts 8 and 9, as shwon.
Insert cam locks (B) into parts 10, as shown.
Attach parts 8 and 9 to part 10.
Turn cam locks clockwise to tighten.

O
8
ASSEMBLY STEPS
STEP 9.
STEP 10.
L X4
L-1
L-2
L-2
L-1 L-2
L-1
L-1
L-2
L-2
11
11
10
10
9
8
8
9
L-2
X4
J
L-1
N
x4
C
C
O
C
C
C X 10OX8
C
C
C
C
7
3
6
11
11
O
O
C
J
JX 4
J
J
L-1
J
NX 1
O
O
O
O
O
O
O
O
O
N
Insert nuts (L-2) into parts 11, as shown.
Fix parts 8 and 9 to parts 11 using bolts (L-1) and
allen key (N), as shown.
Attach screw covers (J) to the legs, as shown.
Insert wooden dowels (C) into part 7.
Fix assembled legs to part 7 using screws (O), as shown.

9
ASSEMBLY STEPS
STEP 11.
STEP 12.
GX2
G
G
H
H X4
H
H
H
G
H
7
3
6
D-1
D-2
D-1
D-2
13
13
FF
FF
FF
FF
K
K
K
K
D X2
FX8
K X4
D-1 D-2
FF
X4
D-1
D-2
x2
Fix foot nails (H) to legs 8 and 9, as shown.
Fix foot nails (G) to lesg 12, as shown.
Fix handles (D-2) to doors 13 using screws (D-1), as shown.
Fix hinges (K) to doors 13 using screws (F), as shown.
9
8
9
8
12
12
9

ASSEMBLY STEPS
STEP 13.
STEP 14.
FX8
Fx4 K
Fx4 K
1
3
13
FX8
13 1
16
Fx4
K
Fx4
K
Fx4 K
Fx4
K
10
Fix door 13 to assembled unit using hinges and screws (F), as shown.
Fix door 13 to assembled unit using hinges and screws (F), as shown.

11
ASSEMBLY STEPS
STEP 15.
STEP 16.
M X4
M -1
M
M
M
M
M-2
M-1M-2
M -2
Fix corner brackets (M-2) to part 2 using screws (M-1), as shown.
Your TV Stand is ready for use.
