SIMPA HZB62GL User manual

香港石油氣適用
For Hong Kong LPG
嵌入式煮食爐
Built-in Hob
型號 HZB62GL:
Model
使用說明書
User Instructions

重要安全指示 …………………………………………………………………. 第頁
安裝指示 ……………………………………………………………………….. 第頁
操作指示 ………………………………………………………………………. 第頁
保養 ………………………………………………………………………………. 第頁
故障處理……………………………………………………………………..….. 第頁
規格 ………………………………………………………………………………. 第頁
目錄
注意!
根據香港氣體安全條例，任何氣體裝置工程，包括爐具和接駁喉管的安裝，
必須由註冊氣體裝置技工執行，而該技工已於相關的氣體工程類別註冊及受
聘於註冊氣體工程承辦商。
1
3
5
7
8
9

1
重要安全指示
以下指示對爐具的安全操作十分重要，請詳細閱讀，如有查詢和服務要求，請致電煤氣公司石油氣爐具 24
小時銷售及服務熱線 2232 1111 。
安裝
1. 使用認可印有機電工程署批准標記（例如：機電工程署批准 EMSD APPROVAL GTXXXX） 的氣體接駁
喉管連接爐具，或使用機電工程署接納的其他恰當方法。
2. 當在櫥櫃面安裝嵌入式氣體煮食爐時，檢查面板進風口(如適用)沒有阻塞，以確保煮食爐在使用時操作
正常。
3. 爐具必須安裝在空氣流通之房間內。
4. 不要將易燃物料、噴霧及壓縮容器置於爐具下方的廚櫃內。
使用
1. 當懷疑洩漏氣體時，將窗戶打開，以及關閉煤氣錶閥。切勿操作任何電器或電掣開關。切勿在現場使用
任何電話。在現場以外的地方，致電煤氣公司緊急事故熱線，電話：2880 6999。
2. 請參照說明書內指引正確使用爐具。
3. 爐具只供家用，切勿用於工商業用途。
4. 除了煮食外，切勿使用爐具作其他用途，例如烘乾衣物。
5. 使用爐具前，請開啟窗戶和排氣系統。
6. 不可讓兒童使用爐具。
7. 切勿讓爐具在無人看管下運作。
8. 切勿在爐頭加上錫紙碟，這會引致燃燒問題。
9. 請確保爐頭蓋及爐頭身沒有變形，如有異常，請聯絡煤氣公司安排更換。
10. 使用前，請確保爐頭蓋、爐頭身和爐架擺放正確，沒有傾斜。
11. 請確保爐頭火孔沒有被水或污漬堵塞。
12. 在一個爐架上，切勿放置超過10公斤的重量。
13. 爐架很重的，切勿掉下。
14. 不應按下點火旋鈕超過 10 秒。如爐頭於10 秒後仍未燃點， 等待最少1分鐘後，才再試燃點。
15. 請確保使用時火焰平均。
16. 注意爐面、爐頭及爐架的高溫。
17. 切勿使用直徑過大的平底煮食器皿，避免溫度過高而造成燙傷及影響爐具的使用壽命。 使用細小器皿
時，請將火力調低，避免火焰超出器皿底部。
18. 請確保器皿穩定地放在爐架上，如器皿容易滑動，必須緊握它。
19. 面板是固定的，切勿移動。
爐頭 最大平底煮食器皿直徑（毫米）
左爐頭 280
右爐頭 280

2
20. 燒開水或煮湯時，注入的水量連湯料不可超過器皿容量三分之二，溢出液體會影響燃燒和損壞爐具。
21. 使用小火時，不應急速打開爐具下方的廚櫃門，以免氣流弄熄爐火。
22. 烹調時，請盡量蓋上鍋具。而鍋具的手柄亦應轉向適當位置，避免受熱或碰撞。
23. 請勿在爐具附近使用噴霧產品。
24. 使用後，應將所有旋鈕設於關閉位置。
25. 當爐具熱時，請勿清洗面板。
26. 使用後爐架會很熱，冷卻後方可清潔。
27. 此煮食爐的面板是用強化玻璃製造，較一般玻璃安全，但仍須注意以下事項，避免玻璃面板爆裂：
 經常清潔爐頭以保持火孔暢通，如滾瀉食物及汁液，應在爐具冷卻後儘快清潔爐頭 。
 如爐具出現異常聲響，應先關火。在爐具完全冷卻後，檢查爐頭蓋及放好爐頭蓋，並重新點火。若問題
持續，聯絡煤氣公司進行檢查。
 切勿以硬物撞擊或刮傷面板。
 切勿將重物或器皿放置於玻璃面板上。
保養
1. 定期檢查氣體喉管狀況，確保沒有紐結或裂縫，若發現損壞，請聯絡煤氣公司更換喉管。
2. 讓爐具完全冷卻後，才可進行清潔。
3. 進行清潔時，應穿上保護手套避免割傷。避免接觸爐具的內部零件。
4. 清洗爐頭蓋及爐頭身後，用乾布將爐頭蓋完全抹乾，爐頭火孔不可留有水份，以免影響燃燒。
5. 使用前和使用後，注意爐頭的狀況和清潔。以下不正常狀況會產生燃燒不良，進而引致爐具損壞。請確保
採取相應措施，糾正有關問題。
重要安全指示
不正常情況 處理措施
爐頭蓋和爐頭身變形 聯絡煤氣公司更換零件。
爐頭蓋和爐頭身傾斜 將爐頭蓋和爐頭身重新放好，不可傾斜。
爐頭火孔被水堵塞 用布將爐頭蓋及爐頭身抹乾後，重新放好。
爐頭火孔被污積或溢出物堵塞
用溫和清潔劑和刷子清潔爐頭蓋及爐頭身，用布抹
乾後，重新放好。

3
安裝位置
爐具須安裝在空氣流通之房間內，但切勿置於強風直接吹入的位置。
附近不可放置易燃物料（如紙張、油類）、可燃物料、噴霧及壓縮容
器。爐具與周圍可燃物料應保持 150 毫米以上的距離。爐具上方須
保留最少 650 毫米空間。安裝於爐具上方的抽油煙機，必須與爐架
面保留最少 650 毫米的距離。如抽油煙機要求不同的安裝距離，則
採用較大間距。爐具於煮食時的煙氣應經由抽油煙機排走。
此爐具適合安裝於兩個不同的開孔尺寸。
 開孔尺寸（I）：寬 670 x 深350 毫米
依照圖 1在枱面預留開孔，枱面深度不少於 600 毫米。
 開孔尺寸（II）：寬 703 x 深403 毫米
依照圖 2在枱面預留開孔，枱面深度不少於 600 毫米。安裝時
須加墊片。
安裝爐具
氣體接駁
安裝電池
安裝指示
703 403
600
最少100
670 350
600
最少100
開孔尺寸（I）：
寬670 x 深350 毫米
開孔尺寸（II）：
寬703 x 深403 毫米
圖1
圖2

4
爐架放置
 將爐架對準爐碟平放。
爐架放置錯誤
爐架
安裝指示
爐頭放置
使用前，確定以下配件已置於正確位置:
芯火爐頭蓋傾斜
外環爐頭蓋傾斜
芯火爐頭蓋
爐頭身
定位針
外環爐頭蓋
爐碟
熄火安全感應頭
點火電極
定位槽
爐頭座







5
操作指示
爐具介紹
芯火爐頭蓋
外環爐頭蓋
爐頭身
強化玻璃面板
控制旋鈕
底盤
爐架
爐碟
燃氣接口
前
電池盒

6
操作指示
點燃爐頭
火力調節
關閉爐頭
HZB62GL 旋鈕標示





中火 點火 / 最大 中火 最小 關閉位置

7
保養


一般
清潔爐具

8
故障處理
如爐具出現異常或故障，應先關火。請先確保爐具完全冷卻後，才進行任何故障處理。如採取以下處理方法
後仍然無效，請致電煤氣公司石油氣爐具24小時銷售及服務熱線 2232 1111 安排維修。
故障 原因 處理方法
1. 沒有點燃火花 電池已耗盡。 更換電池。
電池擺放錯誤。 正確裝上電池。
點火電極上有污垢或沾濕。 清理及抹乾點火電極。
2. 沒有爐火 未開啟燃氣錶閥及／或爐具供氣閥。 完全開啟燃氣錶閥及／或爐具供氣閥。
喉管內含有空氣。 重複點火至喉管內空氣完全排出。
錫紙碟阻塞爐頭。 除去錫紙碟。
點火電極上有污垢或沾濕。 清理及抹乾點火電極。
3. 不能保持爐火 熄火安全裝置上有污垢。 清理熄火安全裝置。
未完全按下旋鈕或旋鈕沒有轉至點燃
位置。
按下旋鈕及轉至點火位置。
4. 使用中熄火 熄火安全裝置上有污垢。 熄火安全裝置上有污垢。
爐火過弱被風吹熄，熄火安全裝置啟
動。
旋鈕轉至關閉位置。等待1分鐘，重新
點火。
防高溫保護裝置啟動 。 旋鈕轉至關閉位置。等待1分鐘，重新
點火。
5. 黃火 爐頭蓋及爐頭身有污垢。 使用暖水及清潔劑清洗爐頭蓋及爐頭身
。抹乾後放好，重新點火。
6. 火焰不穩定 爐頭蓋及爐頭身變形。 聯繫煤氣公司更換零件。
爐頭蓋及爐頭身擺放不正確。 待爐具冷卻後，重新放好爐頭蓋及爐頭
身，並重新點火。
7. 鬆開控制旋鈕後，
火花仍然持續點火
設計功能，保持最多10秒火花、方
便點火。
屬正常，不需處理。
8. 使用中現異常聲響 爐頭蓋和爐頭身擺放不正確。 將爐具熄火，待爐具冷卻後，重新放好
爐頭蓋和爐頭身，重新點火。
9. 關火時出現響聲 殘留在爐頭內氣體瞬間燃燒。 屬正常，不需處理。

9
規格
型號 HZB62GL
氣體種類 香港石油氣
供氣壓力(千帕) 2.9
氣體入口接駁 3/8 吋 膠喉咀
面板物料 強化玻璃
整體尺寸 (毫米)
(高x闊x深)
至廚檯面 67 x 760 x 450
至爐面 82 x 760 x 450
至爐架 140 x 760 x 450
額定熱負荷 (千瓦)
總額 9
左爐頭 4.5
右爐頭 4.5
重量(千克) 16
點火裝置 快易點火系統
熄火安全裝置 熱電偶
防高溫保護裝置 熱敏電阻
電源供應 1.5 伏特 D型鹼性電池 x 2

10

Important Safety Instructions P.
Installation Instructions P.
Operating Instructions P.
Maintenance P.
Trouble Shooting P.
Specifications P.
Attention!
According to the Gas Safety Ordinance of Hong Kong, any gas
installation works including the installation of appliances and
connection tubing, must be undertaken by registered gas
installers who are registered for that appropriate classes and be
employed by registered gas contractors.
1
3
5
7
8
9
Content

1
The following instructions are very important to safe operation of gas appliance. Please read through them
carefully. Please contact Towngas Company LPG Appliances 24-Hour Sales Enquiry and Service Hotline on
2232 1111 for enquiry and services.
Installation
1. Use approved gas tubing bearing EMSD approval marking (such as: 機電工程署批准 EMSD APPROVAL
GTXXXX) for connection to appliance or other appropriate methods accepted by EMSD.
2. When installing gas appliance on top of kitchen cabinet, check that the air-intake opening at top plate (if
applicable) is not blocked in order to ensure proper operation of the gas appliance.
3. Install the gas appliance in a well-ventilated room.
4. Do not store any flammable materials, sprays or pressurized containers inside the stove cabinet below
appliance.
Operation
1. In case of suspected gas leak, open windows and shut off gas meter valve. Do not operate any electric
appliances or switches. Do not use any phones on site. Contact Towngas Emergency Hotline on 2880
6999 with a phone outside the premises.
2. Please use the appliance properly according to the operating instructions.
3. This appliance is designed for domestic use only. Do not use it for commercial purposes.
4. Do not use appliance for any purposes other than cooking, e.g. drying clothes.
5. Open windows and turn on ventilation system before operating the appliance.
6. Do not allow kids to use appliance.
7. Do not leave operating appliance unattended.
8. Do not add aluminum discs to burners. This will incur combustion problem.
9. Ensure that burner cap and burner body are not deformed. Contact Towngas Company to replace the
parts if deformation is found.
10. Before use, ensure the burner cap, burner body and pan supports are in correct position and are not
tilted.
11. Ensure that flame holes of burners are free from water and dirt.
12. Do not put weight exceeding 10kg on each pan support.
13. Pan support is heavy. Do not drop it.
14. Do not press the rotary knob for more than 10 seconds. If the burner is not ignited after 10 seconds, wait
at least 1 minute before making further attempt.
15. Make sure that flame condition is uniform during operation.
16. Heed high temperature of top plate, burners and pan supports.
17. Do not use flat bottom utensil with too large diameter to avoid the risk of scald by high temperature and
reduce the service life of the appliance. When using small utensil, reduce flame power that flame does
not escape from utensil bottom.
18. Ensure stability of utensil resting on pan support. Hold utensil firmly if it slips easily.
19. Top plate is fixed. Do not remove it.
Important Safety Instructions
Burner Maximum Diameter of Flat Bottom Utensil
(mm)
Left Burner 280
Right Burner 280

2
20. Do not fill water including soup ingredients over two-thirds of utensil volume when boiling water or
soup. Spilled liquid of boiling will affect combustion and damage the appliance.
21. When the appliance is operating at low flame, do not open underneath cabinet door rapidly; otherwise,
flame may be extinguished by air draught.
22. Always use pots with covers and make sure that the handles of the pots are correctly positioned to avoid
heating and collision of handles.
23. Do not use sprays near the appliance.
24. All knobs should be turned to off position after use.
25. Do not clean the top plate when the appliance is hot.
26. Pan support gets hot after usage. Clean after cooling down.
27. The top panel of appliance is made of tempered glass which is safer than normal glass for this
application. However, the following safety precautions should be noted in order to prevent the glass top
panel from breaking:
 Clean the burner frequently to maintain a clear gas passage of flame holes. Clean and tidy up the
burner after spillage of food and liquid once the appliance cools down.
 If abnormal noise is observed, turn off flame. Check placement of burner caps and place them
correctly after appliance cools down. Contact Towngas Company if problem persists.
 Do not scratch or impact the glass top plate with hard objects.
 Do not place heavy objects or place cooking utensils on the glass top plate.
Maintenance
1. Check condition of gas hose regularly. Ensure that it is free from kink or crack. Contact Towngas
Company to replace it if damage is found.
2. Allow the appliance to cool down completely before cleaning.
3. Wear glove to protect the hands from cut injury when cleaning the appliance. Do not touch any internal
parts of the appliance.
4. Dry burner cap and burner body completely with dry cloth after washing. Flame holes of burner must be
free from water lest combustion is affected.
5. Before and after use, notice the condition and cleanliness of burner. The following abnormal conditions
will incur abnormal combustion and thus damage of the appliance. Ensure undertaking measures to
rectify the problem accordingly.
Important Safety Instructions
Abnormal Condition Handling Measure
Burner cap and burner body are deformed Contact Towngas Company to replace the parts.
Burner cap and burner body are tilted Replace burner cap and burner body properly.
Burner flame holes are blocked by water Dry burner cap and burner body with cloth and
Burner flame holes are blocked by dirt Clean burner cap and burner body with mild
detergent and brush. Ensure that they are wiped

3
Installation Position
Install the appliance in a well-ventilated room, but do not install at the
position of strong wind. Keep it away from any flammable objects
(such as paper, oil), combustible, sprays or pressurized containers. The
appliance should be installed with a distance of more than 150mm
away from surrounding combustible materials. Allow 650mm or more
clearance above appliance. Install a range-hood at a distance of not
less than 650mm from the surface of pan support of appliance. If the
range-hood requires a different installation distance, adopt the larger
value. The combustion products of appliance shall be evacuated by
means of range-hood.
The appliance can be installed in two cut-out dimensions.
 Cut-out dimension (I): W670 x D350 mm
Reserve cut hole on bench-top according to Fig.1. Depth of bench-
top should be 600mm or more.
 Cut-out dimension (II): W703 x D403 mm
Reserve cut hole on bench-top according to Fig.2. Depth of bench-
top should be 600mm or more. Spacers must be installed.
Connect the gas appliance to the gas supply according to the prescribed standards in force and ensure that
the appliance matches with the type of gas supply.
Installation Instructions
703 403
600
Min.100
670 350
600
Min.100
Cut-out dimension（I）：
W670 xD350mm
Fig.1
Fig.2


Cut-out dimension（II）：
W703 xD403mm

4
Make sure that the following parts are fitted properly before use.
 Place the pan support in line with cover disc.
Installation Instructions
Placement of Burner
Locating slot of outer ring burner cap should be matched
with the locating of burner body.
Do not use appliance with burner cap and burner body positioned
improperly.


 It may cause flame getting into the appliance and damage it.
Do not use appliance with pan support positioned improperly. Due
to improper fixing of pan support, cooking utensil may become
unstable and cause hazard.
Ignition Electrode
Cover Disc
Flame Failure
Burner Body
Simmer Burner Cap
Outer Ring Burner Cap
Locating Pin
Locating
Slot
Burner Base
Tilted outer ring burner cap
Tilted simmer burner cap
Pan support
Improper placement of pan support




5
Operating Instructions
Tempered Glass Top Plate
Appliance Descriptions
Pan Support
Outer Ring Burner Cap
Burner Body
Cover Disc
Simmer Burner Cap
Base Tray
Control Knob
Gas Inlet
Front
Battery Box

6
Operating Instructions
Ignition of Burner
Fully press and turn the rotary knob in anti-clockwise direction to ignition position. Electric sparks from
ignition electrode ignite the burner. After releasing the rotary knob, make sure the flame persists.
Flame Control
After ignition, turn the rotary knob to adjust flame power according to cooking needs. Please adjust slowly.
Minimum flame power is located at the end of anti-clockwise direction.




Turning Off Burner
Turn the rotary knob to the off position.

Indications of HZB62GL Rotary Knob
Medium Ignition / Maximum Medium Minimum Off position
