Simpli Home WyndenHall Brooklyn+Max AXCART17-HB User manual

ARTISAN / HOLDEN / STRATFORD
TALL TV MEDIA STAND
MODEL # AXCART17-HB
1/22
SI
M
P
I
I
HOME
L I F E B Y D E S I G N
®

2/22
Questions, problems, assembly help, missing parts?
No need to return the product, we will gladly help and ship your
replacement parts free of charge
Please call Customer Service at 1-866-518-0120 ext. 262
Monday to Friday between 9 am – 4 pm EST
or go to
www.simpli-home.com/parts request
In order to assist you in a timely manner, please have the following information ready:
Model # _______________________ Part Number or Letter_______________________
Purchased at ___________________Date of Purchase ___________________________
If you wish to return the product, please contact the retailer where the
product was purchased.
SI
M
P
I
I
HOME
L I F E B Y D E S I G N
®

3/22
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
SAFETY INFORMATION
CAUTION: Injuries and damage can occur from furniture tip over if product is not
properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided
with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required. Hardware
package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.

4/22
CARE and MAINTENANCE
Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative
humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls,
and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally
along different grain directions. As humidity changes, the components of wooden objects are
continually pushing and pulling against each other. This pressure often results in parts of furniture
no longer fitting together closely or becoming distorted or breaking from their own internal
stresses.
The response to relative humidity changes begins with determining the annual average RH for
your particular space. Then try to keep the RH in the space where your furniture is as close to that
average as possible, generally within about 10% up or down. De-humidify in the summer and
humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern heating
systems, which can drive down interior RH in the winter, almost invariably cause problems for
furniture. To counteract their effect, you can either modify the RH by keeping furniture containing
spaces cooler in the winter or most importantly, have a good working humidifier for your home. A
humidistat automatically works to balance the humidity in your home so it is constant. Dry indoor
air can suck enough moisture from its surroundings to do permanent damage to wood, causing it
to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how rapidly a
wood will lose moisture are pore size and surface hardness. A piece made from a dense and hard
wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished piece
while pieces with veneer finishes are not only stronger, but lose moisture more slowly than other
finishes.
To help protect your wood furniture, take these steps:
• Use a humidifier, preferably one with an automatic control system that can sense the humidity
level and adjust itself accordingly. Don't over-humidify; that can damage wood by causing it to
expand and contract.
• Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp.
• If you can avoid it, don't put furniture near heating vents. If you must, keep the piece 3 to 4
inches away from the wall, giving the heat and air space to circulate.
• Dust with soft dry cloth.
• Do not use liquid or aerosol products.
• To avoid marking, do not place rubber on surface (foot pads, etc.)
• For soil build-up, wipe with damp cloth & dry.
• Do not use abrasive cleaners.
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.

NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
PRE-ASSEMBLY INFORMATION
MODEL # AXCART17-HB
PARTS DESCRIPTION
5/22
A
TOP
QTY 1
BL
LEFT SIDE
QTY 1
BR
RIGHT SIDE
QTY 1
C
CENTRE SHELF
QTY 1
D
BOTTOM SHELF
QTY 1
EL
LEFT DIVIDER
QTY 1
ER
RIGHT DIVIDER
QTY 1
F
DOOR (L&R Same)
QTY 2
G
SHELF PART
QTY 4
Front
/
Avant
Front
/
Avant
Front
/
Avant
Front
/ Avant
Front / Avant
Front / Avant

NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
PRE-ASSEMBLY INFORMATION
MODEL # AXCART17-HB
PARTS DESCRIPTION
6/22
H
SHELF PART
QTY 1
I
BACK PANEL
QTY 1
J
BACK PANEL
QTY 1
KL
LEFT BACK PANEL
QTY 1
L
DRAWER FRONT
QTY 2
ML
LEFT DRAWER SIDE
QTY 2
O
N
DRAWER BACK
QTY 2
DRAWER BOTTOM
QTY 2
MR
RIGHT DRAWER SIDE
QTY 2
KR
RIGHT BACK PANEL
QTY 1
Warning Label
P
BOTTOM SUPPORT LEG
QTY 1

1
PRE-ASSEMBLY INFORMATION
HARDWARE DESCRIPTION
23
4 5
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
6
7
10
8 9
ALLEN KEY SCREW
M6 X 30 mm
QTY 26
PHILLIPS SCREW
M3 X 12 mm
QTY 12
HANDLE
M4 X 30 mm
QTY 4 SETS
CAM LOCK PIN
CAM LOCK
QTY 20 SETS
PHILLIPS SCREW
M3 X 15 mm
QTY 8
MAGNET AND PLATE
QTY 2 SETS
ALLEN KEY
QTY 1
PHILLIPS SCREW ROUND HEAD
M4 X 15 mm
QTY 25
SHELF SUPPORT
QTY 30
Required -
Flathead screwdriver
Phillips screwdriver
Not Included
7/22
MODEL # AXCART17-HB
11
a. M4 X 25 - QTY 2
( )1 is extra
b. M4 X 15 - QTY 1
c. M4 X 25 - QTY 1
FURNITURE TIP OVER RESTRAINT
QTY 1 SET
PHILLIPS SCREW
M4 X 30 mm
QTY 4

COMPONENTS – KEY DIAGRAM
8/22
MODEL # AXCART17-HB
EL
ER
A
BL
KR
I
KL
J
H
C
G
G
ML
MR
N
OL
BR
F
F
Front / Avant
Front / Avant
Front /
Avant
Front
/
Avant
Front
/
Avant
Front
/ Avant
G
G
D
P

ASSEMBLY
STEP 1
STEP 2
1. Slide Drawer Bottom O firmly into slots on Drawer Sides ML , MR and
Drawer Front L .
MODEL # AXCART17-HB
B
9/22
ML
MR
L
L
ML
MR
O
2
1. Attach 4 Cam Lock Pins 2 to back of Left Drawer Front L .
2. Align Cam Lock Pins with guide holes and attach Drawer Sides ML , MR .
3. Insert 2 Cam Locks 2 into guide holes on each Drawer Side ML , MR .
4. Use flathead screwdriver to secure Cam Locks.

ASSEMBLY
STEP 3
STEP 4
1. Align Drawer Back N with Drawer Bottom O and press firmly into slot.
2. Attach back using 2 Allen Key Screws 1 through guide holes on each side.
3. Use Allen Key 3 to tighten screws. Do not over tighten.
1. Use Phillips screwdriver to attach Handle 7 to Drawer Front L .
Repeat Step 1-4 for the second drawer .
MODEL # AXCART17-HB
B
10/22
N
O
L
1
3
7

ASSEMBLY
STEP 5
1. Attach 3 Cam Lock Pins 2 to each Divider EL , ER .
2. Align Cam Lock Pins with guide holes and attach Center Shelf C .
3. Insert 6 Cam Locks 2 into guide holes on Center Shelf C .
4. Use flathead screwdriver to secure Cam Locks.
11/22
MODEL # AXCART17-HB
Front
/ Avant
Front
/
Avant
C
EL
ER
2

ASSEMBLY
STEP 6
1. Attach Dividers EL , ER to Bottom Shelf D using 6 Allen Key Screws 1 through
guide holes.
12/22
MODEL # AXCART17-HB
D
EL
ER
1
3
Front /
Avant
Front / Avant
Front
/
Avant

ASSEMBLY
STEP 7
1. Attach 6 Cam Lock Pins 2 to 2 Sides BL , BR using pre-drilled holes.
2. Align Cam Lock Pins with guide holes on Bottom Shelf D and attach
Bottom Shelf D .
3. Insert 6 Cam Lock 2 into guide holes on Bottom Shelf D .
4. Use a flathead screwdriver to tighten Cam Locks into Pins.
13/22
MODEL # AXCART17-HB
Front
/ Avant
Front
/
Avant
Front
/ Avant
Front
/ Avant
Front
/ Avant
D
BR
BL
Right
Left
22

ASSEMBLY
STEP 8
1. Attach Bottom Support Leg P to Bottom Shelf D using 4 Phillips Screws 10 .
2. Use Phillips screwdriver to tighten screws. Do not over-tighten.
14/22
MODEL # AXCART17-HB
Front / Avant
Front
/
Avant
Front
/
Avant
Front
/
Avant
Front
/ Avant
BL
EL
ER
BR
P
P
10
D

ASSEMBLY
STEP 9
1. Attach Top A to 2 Sides BL , BR and 2 Dividers EL , ER using Allen Key Screws 1
through guide holes.
2. Use Allen Key 3 to tighten screws. Do not over-tighten.
15/22
MODEL # AXCART17-HB
Front / Avant
Front /
Avant
Front
/
Avant
Front /
Avant
Front
/ Avant
Front
/
Avant
BL
EL
ER
BR
A
1
3
1
3

ASSEMBLY
STEP 10
16/22
MODEL # AXCART17-HB
KL
KR
I
J
Front / Avant
Front /
Avant
Front /
Avant
Front
/ Avant
Front
/
Avant
Front
/ Avant
Front
/ Avant
Front / Avant
Warning Label
KR
KL
I
J
1. Use Phillips screws Round Head 6 to attach Back Panels I , J , KL , KR through
guild holes.
2. Use Phillips screwdriver to tighten screws.
6
Note:
The back of the tv frame does not have
pre-drilled holes to aach the back panels.

ASSEMBLY
STEP 11
1. Attach hinges on Doors F to Sides BL , BR using Phillips Screws 4 into pre-drill holes:
- Using Phillips screwdriver to attach Screws 4 at middle hole of hinges for both top &
bottom hinges.
- Adjust the door to ensure they are aligned straight & square with bottom shelf & side.
- Using Phillips screwdriver to tighten the rest of screws 4 into pre-drill holes ( top & bottom
holes on hinges).
2. Attach Magnet Plates 8 to bottom corners of Doors F using Phillips Screws 5 into
pre-drill holes on Doors F .
3. Attach Magnets 8 using Phillips Screws 5 into pre-drill holes on Bottom Shelf D .
4. Use Phillips screwdriver to attach Handles 7 to Doors F .
17/22
MODEL # AXCART17-HB
8
5
5
8
7
BL
BR
F
F
D
First Step Last Step ( after adjust the door )
4
4
4

ASSEMBLY
STEP 12
A
1. Use 4 Shelf Supports 9 for each Shelf H or G in desired location .
2. 2 Shelf Supports 9 may be used on back top of each Shelf H or G as a
tipping restraint.
18/22
MODEL # AXCART17-HB
shelf level 1
shelf level 2
shelf level 3
shelf support
anti - tipping
9
9
GHG

ASSEMBLY
STEP 13
1. Insert assembled drawers into glides on assembled Tall TV Media Stand.
19/22
MODEL # AXCART17-HB

20/22
STEP 14
B
11
11
NOTE: The screwdriver is not
included in the hardware pack.
WARNING
Serious or fatal crushing injuries can occur from furniture tip-over.
If the furniture tip over restraint kit is not in the box, please contact our customer
service department in order to obtain another kit before using the furniture.
FURNITURE TIP OVER RESTRAINT ASSEMBLY
