Simpli Home Brooklyn + max WyndenHall AXCLEV14-SMB User manual

Lev / Rowan / Cadwyn
Low Storage Cabinet
Model # AXCLEV14-SMB
TM
TM
1

It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
simpli-home.com/product-registration
Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
Activate your 1-year warranty
Automatic entry to win a $500 gift certificate
Earn instant rewards and save
ü
ü
ü
2

Review your product and collect rewards!
Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Share photos and get your cash back!
Send us images or share them on social and qualify for instant
rewards. You may even receive store credit on your entire purchase!
simpli-home.com/share-images
3

For Fastest Customer Service:
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order information and issue.
6. Submit form.
7. A customer service associate will contact you.
Other ways to contact us…
Visit Us
Visit our site directly at
www.simpli-home.com
Email Us
[email protected]
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.
4

CAUTION: Injuries and damage can occur from furniture tip over if product is
not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint
provided with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
IMPORTANT : Please read this manual carefully before beginning assembly
of this product. Keep this manual for future reference.
Safety Information
5

This furniture is designed for indoor use.
Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity
rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and
contracts unequally along different grain directions. As humidity changes, the components
of wooden objects are continually pushing and pulling against each other. This pressure
often results in parts of furniture no longer fitting together closely or becoming distorted
or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by keeping
furniture containing spaces cooler in the winter or most importantly, have a good working
humidifier for your home. A humidistat automatically works to balance the humidity in
your home so it is constant. Dry indoor air can suck enough moisture from its surroundings
to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger but lose moisture more slowly
than other finishes.
To help protect your wood furniture, take these steps:
·Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly
·Don't over-humidify; that can damage wood by causing it to expand and contract
·Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp
·If you can avoid it, don't put furniture near heating vents; if you can’t, keep the
item 3 to 4 inches away from the wall, giving the heat and air space to circulate
·Dust with soft dry cloth
·Do not use liquid or aerosol products
·To avoid marking, do not place rubber on surface (foot pads, etc.)
·For soil build-up, wipe with damp cloth & dry
·Do not use abrasive cleaners
Care & Maintenance
6

Part Description
Model # AXCLEV14-SMBPre-Assembly Information
.A.BL .BR
Front /
Avant
TOP
QTY 1
.C.D.E
.FL .FR
.GR
7
.GL
Front /
Avant
BOTTOM SHELF
QTY 1 SHELF QTY 2
DIVIDER
QTY 1
RIGHT SIDE
QTY 1
LEFT SIDE
QTY 1
LEFT DOOR
QTY 1 RIGHT DOOR QTY 1
Warning Label
RIGHT BACK PANEL
QTY 1
Front /
Avant
Front /
Avant
Front /
Avant
LEFT BACK PANEL
QTY 1

Hardware Description
Model # AXCLEV14-SMBPre-Assembly Information
ALLEN KEY SCREW
M6 X 30mm
QTY 12
CAM LOCK PIN
CAM LOCK
QTY 6 SETS
HANDLE
M4 X 15mm
QTY 2 SETS ALLEN KEY
QTY 1
PHILLIPS SCREW
ROUND HEAD
M4 X 15mm
QTY 16
MAGNET AND PLATE
QTY 2 SETS
SHELF SUPPORT
QTY 12
PHILLIPS SCREW
M4 X 15mm
QTY 24
PHILLIPS SCREW
M3 X 15mm
QTY 8
.1.2.3.4
.5.6.7.8
.9.10 .11 .12
8
WOOD DOWEL
Ø8 X 30mm
QTY 10
ADJUSTABLE HINGE
Ø35
QTY 4
a. M4 X 25mm - QTY 2
( 1 is extra )
b. M4 X 15mm - QTY 1
c. M4 X 25mm - QTY 1
FURNITURE TIP OVER
RESTRAINT
QTY 1 SET
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included

Model # AXCLEV14-SMBComponents - Key Diagram
Front /
Avant
Front /
Avant
Front /
Avant
Front/
Avant
Front /
Avant
A
BL
GR GL
C
BR
FR
E
D
E
FL
9

Model # AXCLEV14-SMBAssembly
Step 1
P
X
2
BL
BR
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
C
D
7
2
2
7
7
7
7
7
1. Attach three Cam Lock Pins 2 into
pre-drilled holes on each Side BL , BR .
2. Use Phillips screwdriver to secure Cam Lock Pins. Do not over-tighten.
3. Insert Dowels 7 into guide holes on parts BL , BR , C , D .
4. Use rubber mallet to tap Dowels 7 into bottom of holes securely. 1/2 length of
Dowels should be exposed. 10

Model # AXCLEV14-SMBAssembly
Step 2
11
D
Front /
Avant
Front / Avant
C
D
Front /
Avant
Front /
Avant
C
1
4
1
1. Align Wood Dowels with guide holes and attach Bottom Shelf D to Divider C .
2. Use three Allen Key Screws 1 to attach Bottom Shelf D through guide holes
from Bottom Shelf D to pre-drilled holes of Divider C .
3. Use Allen Key 4 to tighten Screws. Do not over-tighten.

Model # AXCLEV14-SMBAssembly
Step 3
12
D
BL
BR
Front / Avant
Front / Avant
Front / Avant
Front / Avant
BL
BR
Front / Avant
D
Front / Avant
Front / Avant
2
2
2
1. Align Cam Lock Pins and Wood Dowels with guide holes
and attach Sides BL , BR to Bottom Shelf D .
2. Insert six Cam Locks 2 into guided holes on Bottom Shelf B .
3. Use Phillips screwdriver to secure Cam Locks. Do not over-tighten.
4. Turn assembled pieces right side up.
C
BL
BR
D
Front / Avant
Front / Avant
Front /
Avant

1. Align Wood Dowels with guide holes and attach Top A to Sides BL , BR .
2. Attach Top A to Sides BL , BR using six Allen Key Screws 1
( Three Screws on each Side ).
3. Attach Top A to Divider C using three Allen Key Screws 1 .
4. Use Allen Key 4 to tighten screws. Do not over-tighten.
Model # AXCLEV14-SMBAssembly
Front /
Avant
Front /
Avant
Front/
Avant
CBR
A
4
1
Step 4
13
BL
Front /
Avant

Model # AXCLEV14-SMBAssembly
Step 5 Note:
The back of the cabinet frame
does not have pre-drilled holes to
attach the back panels.
1. Attach parts GL , GR to back frame by using sixteen Phillips Screws Round Head 5 .
2. Use Phillips Screwdriver to tighten screws. Do not over-tighten.
14
5
Warning Label
GL GR
Step 6
11
1. Attach Adjustable Hinges 10 to Doors FL , FR using Phillips Screws 11
into pre-drilled holes on Doors FL , FR.
FL
FR
10

Model # AXCLEV14-SMBAssembly
Step 7
15
1. Attach Adjustable Hinges 10 on Doors FL , FR to Sides BL , BR using Phillips Screws
11 into guide holes on Sides BL , BR .
2. Use Phillips screwdriver to snugly tighten screws.
1. Attach Magnets 8 to Bottom Shelf D
using Phillips Screws 9 into pre-drilled holes on Bottom Shelf D .
2. Attach Magnet Plates 8 using Phillips Screws 9 into pre-drilled holes on
Doors FL , FR .
3. Use Phillips screwdriver to snugly tighten screw.
4. Use Phillips screwdriver to attach Handles 3 to Doors FL , FR through guide hole.
Step 8
10
11
FR
FL
D
3
89
9
8
FR
FL
BR
BL

Model # AXCLEV14-SMBAssembly
Step 9
16
IMPORTANT NOTE:
Tighten the Screw marked II to fasten hinge. The door may need to
be adjusted so that all the spaces between the door and the unit sides are equal.
To adjust, follow instructions:
1. Side adjustment 4 mm
To move the door towards the side panel, loosen screw I and tighten screw II .
To move the door away from the side panel, loosen screw II and tighten screw I .
2. Depth adjustment 4 mm
Loosen screw II ( just one turn ), adjust door to desired position, re-tighten screw .
3. Height adjustment
Loosen screw 11 , adjust door to desired position, re-tighten screw .
II I
11

Model # AXCLEV14-SMBAssembly
Step 10
1. Use four Shelf Supports 6 for each Cabinet Shelf E in desired location.
2. Two Shelf Supports 6 may be used on back top of each Cabinet Shelf E
as a tipping restraint.
17
shelf level 3
shelf level 2
shelf level 1
shelf support
anti - tipping 6
6
E
E
E
E

NOTE: The screwdriver is not
included in the hardware pack.
WARNING
Serious or fatal crushing injuries can occur from furniture tip-over.
If the furniture tip over restraint kit is not in the box, please contact our customer
service department in order to obtain another kit before using the furniture.
Furniture Tip Over Restraint Assembly
Step 11
12
12
18

1. Attach one of the mounting brackets securely to the back edge of
the furniture. Use the shorter screw.
2. Determine where furniture is to be placed and mark location on
the wall for mounting bracket screw hole approximately 2 inches
below the bracket mounted to the furniture.
3. Drill a 3/16 inch hole in the wall. Press the plastic anchor into the
hole and gently tap until the flange on the anchor is against the
wall surface.
4. Position the bracket over the anchor and use the longer screw to
securely attach the bracket to the wall.
5. Place the furniture so the back edge is in line with the bracket on
the wall.
6. Lace an end of the nylon zip-tie strap down through each bracket.
Bring both ends together and slide the smooth side upright
through the square-shaped end and pull through to create the
“locked” position.
7. Check to make sure the strap is securely laced and locked to the
brackets.
·DO NOT put a TV or other heavy objects on top of furniture not
intended for use with a TV
·DO NOT place heavy objects in top drawers or on top shelves
·DO NOT let children climb or hang on drawers, doors or shelves
Px
P
P
x
x
Furniture Anti-Tipping Restraint Instructions
19
