Simpli Home WyndenHall Brooklyn+Max 3AXCADM-02 User manual

Redmond / Mansfield / Stanwick
End Table
Model # 3AXCADM-02
TM
TM
1

2
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
simpli-home.com/product-registration
Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
Activate your 1-year warranty
Automatic entry to win a $500 gift certificate
Earn instant rewards and save
ü
ü
ü

3
Review your product and collect rewards!
Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Share photos and get your cash back!
Send us images or share them on social and qualify for instant
rewards. You may even receive store credit on your entire purchase!
simpli-home.com/share-images

4
For Fastest Customer Service:
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order information and issue.
6. Submit form.
7. A customer service associate will contact you.
Other ways to contact us…
Visit Us
Visit our site directly at
www.simpli-home.com
Email Us
[email protected]
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.

Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly
of this product. Keep this manual for future reference.
5

This furniture is designed for indoor use.
Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity
rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and
contracts unequally along different grain directions. As humidity changes, the components
of wooden objects are continually pushing and pulling against each other. This pressure
often results in parts of furniture no longer fitting together closely or becoming distorted
or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by keeping
furniture containing spaces cooler in the winter or most importantly, have a good working
humidifier for your home. A humidistat automatically works to balance the humidity in
your home so it is constant. Dry indoor air can suck enough moisture from its surroundings
to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger but lose moisture more slowly
than other finishes.
To help protect your wood furniture, take these steps:
·Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly
·Don't over-humidify; that can damage wood by causing it to expand and contract
·Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp
·If you can avoid it, don't put furniture near heating vents; if you can’t, keep the
item 3 to 4 inches away from the wall, giving the heat and air space to circulate
·Dust with soft dry cloth
·Do not use liquid or aerosol products
·To avoid marking, do not place rubber on surface (foot pads, etc.)
·For soil build-up, wipe with damp cloth & dry
·Do not use abrasive cleaners
Care & Maintenance
6

TOP
QTY 1
BOTTOM SHELF
QTY 1 BACK PANEL
QTY 1
LEFT SIDE
QTY 1
DRAWER BACK
QTY 1
DRAWER FRONT
QTY 1
LEFT DRAWER SIDE
QTY 1
ALB
CDE
FLG
DRAWER BOTTOM
QTY 1
H
AR
RIGHT SIDE
QTY 1
RIGHT DRAWER SIDE
QTY 1
FR
Front /
Avant
Front /
Avant
Front /
Avant
Part Description
Model # 3AXCADM-02Pre-Assembly Information
7

ALLEN KEY SCREW
M6 X 30mm
QTY 8 ALLEN KEY
QTY 1
123
4
CAM LOCK PIN
CAM LOCK
QTY 14 SETS
HANDLE
M4 X 10mm
QTY 1 SET
Required -
Flathead screwdriver
Phillips screwdriver
Not Included
Model # 3AXCADM-02Pre-Assembly Information
8
Hardware Description

D
C
G
E
H
B
A
L
A
R
F L
F
R
Front /
Avant
Front /
Avant
Front /
Avant
Model # 3AXCADM-02Components - Key Diagram
9

Step 1
Step 2
1. Attach four Cam Lock Pins 3 to back of Drawer Front E .
2. Align Cam Lock Pins with pre-drilled holes and attach Drawer Sides FL , FR .
3. Insert two Cam Locks 3 into pre-drilled holes on each Drawer Side FL , FR .
4. Use flathead screwdriver to secure Cam Locks.
1. Slide Drawer Bottom H firmly into slots on Drawer Sides FL , FR
and Drawer Front E .
E
3
H
E
F
L
F
R
F
L
F
R
10
Model # 3AXCADM-02Assembly

Step 3
1. Use phillips screwdriver to attach Handle 4 to Drawer Front E .
1. Align Drawer Back G with Drawer Bottom H and press firmly into slot.
2. Attach back using two Allen Key Screws 1 through pre-drilled holes on each side.
3. Use Allen Key 2 to tighten Screws. Do not over-tighten.
NOTE: The screwdriver is not
included in the hardware pack.
Step 4
1
2
G
H
4
E
F
L
F R
11
Model # 3AXCADM-02Assembly

Step 5
1. Attach five Cam Lock Pins 3 to each Side AL , AR using guide holes.
2. Align Cam Lock Pins with pre-drilled holes on Bottom Shelf C and Back Panel D .
3. Insert ten Cam Locks 3 into pre-drilled holes on Bottom Shelf C and Back Panel D .
4. Use flathead screwdriver secure Cam Lock.
3
C
D
3
A
L
A
R
Front /
Avant
Front /
Avant
12
Model # 3AXCADM-02Assembly

Step 6
1. Attach Top B to Sides AL , AR using four Allen Key Screws 1
(two screws on each Side).
2. Use Allen Key 2 to tighten. Do not over-tighten.
1. Insert assembled drawer into glides on assembled table.
Step 7
1
2
B
A
L
A R
Front / Avant
Front / Avant
13
Model # 3AXCADM-02Assembly
