Cooper Lighting METALUX 248PG User manual

Catalog #
Project
Comments
Prepared by
Type
Date
SPECIFICATION FEATURES
09/17/2008 4:23:56 PM
Consult your representative for additional options and finishes.
Specifications and Dimensions subject to change without notice.
ADF020742
LAMP CONFIGURATIONS
MOUNTING DATA
DESCRIPTION
The EIM Series is an energy efficient family of industrials that feature
premium performance and durability. The industrial series incorporates
heavy duty, embossed, reflectors that precisely direct and effectively control
light. The EIM reflector is a unique design that was developed to prevent
debris accumulation in special applications. The versatile EIM Series can be
installed using various mounting methods and numerous options and
accessories are available.
The EIM Series can be utilized in simple task and area lighting to the most
demanding specialized industrial applications with environmental
requirements.
A ... Construction
Channel is code gauge prime cold
rolled steel. Die formed with deep
V-grooves for tong hanger. Die
formed channel connector assures
straight rows and continuity of
ground through set screws.
Lampholder mounting brackets are
easily inserted with snap-in action.
B ... Electrical*
Ballast are CBM/ETL Class "P" and
positively secured by mounting
bolts. Metal clad lampholders are
spring loaded for turret safety.
UL/CUL listed. Suitable for damp
locations.
C ... Finish
Multistage iron phosphate
pretreatment ensures maximum
bonding and rust inhibitor.
Lighting grade, baked white
enamel finish.
D ... Reflectors
Painted after fabrication. Die
formed code gauge steel. Deep
draw full width ribs formed with
one press stroke. Side flanges lend
strength with downward turn.
Reflector design prevents lint, dust
and debris buildup. Easily cleaned.
Baked white enamel 13" width.
Four foot sections. Reflectors
secured by positive retaining
screw. Reflector aligners provided.
Standard with 20% uplight (EIM).
Closed top reflector (ECIM).
Optional Industrial fixtures are
available incorporating silver
technology enhancements.
(SilverLining)
EIM
396
396T8
496
496T8
8' INDUSTRIAL
3 OR 4 LAMP
SLIMLINE
Environmental Heavy Duty
Industrial
LAMPS CONTAIN MERCURY. DISPOSE ACCORDING
TO LOCAL, STATE OR FEDERAL LAWS
Safe and convenient means of
disconnecting power
6-3/8"
[162mm]
13"
[330mm]
A B C D
EB Ballast & STD Lamps
396 (221)
396T8 (180)
496 (272)
496T8 (220)
ES Ballast & STD Lamps
496 (316)
STD Ballast & STD Lamps
396 (270)
496 (360)
Luminaire Efficacy Rating
LER = FI-87
Catalog Number: EIM-396T8
Yearly Cost of 1000 lumens,
3000 hrs at .08 KWH = $2.76
*Reference the lamp/ballast data in the
Technical Section for specific lamp/ballast
requirements.
E N E R G Y D ATA
Input Watts:
6-3/8"
[162mm]
13" [330mm]
Y
X
X=4-1/4"
[108mm] Y
Y=3"
[76mm]
6-3/8"
[162mm]
13" [330mm]
Y
X
X=4-1/4"
[108mm] Y
Y=2"
[51mm]
Y
4-1/4"
[108mm]
5/16"
[8mm]
7/8" [22mm] K.O. (5)
11/16" [17mm] x 1 K.O. (2)
7/32" [6mm] x 3/8" [10mm] K.O. (4)
Ground Screw Bump
1-1/16"
[27mm]
89-1/2" [2273mm]
85-1/4" [2165mm]
96" [2438mm]
76" [1930mm]
COOPER LIGHTING - METALUX®

Metalux • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL [phone] • FAX [phone]/2008 4:23:56 PM
Specifications and Dimensions subject to change without notice.
ADF020742
PHOTOMETRICS
ORDERING INFORMATION
ACCESSORIES (Order Separately)
SHIPPING INFORMATION
EIM
Candela
Angle Along II 45 oAcross
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
4237 4237 4237
4182 4186 4263
3980 4088 4189
3670 3845 4014
3233 3553 3832
2680 3172 3280
2014 2472 2485
1273 1687 1589
525 515 377
17 63 62
87 139 102
255 334 374
443 130 338
621 323 179
768 560 386
892 655 635
974 861 736
1019 988 981
1031 1031 1031
C o e f ficients of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
0
1
2
3
4
5
6
7
8
9
10
Zonal Lumen Summary
Zone Lumens %Lamp %Fixture
0-30
0-40
0-60
0-90
90-180
0-180
||
EIM-396T8
Energy Saving
Ballast
F96T8/SPX35 Lamps
5950 Lumens
Spacing criterion:
(II) 1.3 x mounting
height, ( ) 1.4 x
mounting height
Efficiency 92.8%
Test Report:
EIM396T8.IES
LER = FI-87
Yearly Cost of 1000
lumens, 3000 hrs at
.08 KWH = $2.76
3425 19.2 20.7
5752 32.2 34.7
10795 60.5 65.2
14235 79.7 86.0
2324 13.0 14.0
16559 92.8 100.0
107 107 107 107 103 103 103 103 96 96 96 89 89 89 83 83 83 80
98 93 89 85 94 90 86 83 83 80 78 77 75 73 72 70 69 66
88 80 74 69 85 78 72 67 72 67 63 67 63 60 63 59 57 54
80 70 62 56 77 68 61 55 63 57 52 59 54 50 55 51 47 45
73 62 54 47 70 60 52 46 56 49 44 52 47 42 49 44 40 38
67 55 46 40 64 53 45 39 50 43 38 46 41 36 43 39 35 32
62 49 41 35 59 48 40 34 45 38 33 42 36 31 39 34 30 28
57 44 36 30 55 43 35 30 40 34 29 38 32 28 36 30 27 25
53 40 32 27 51 39 32 26 37 30 25 35 29 25 33 27 24 22
49 37 29 24 47 36 29 24 34 27 23 32 26 22 30 25 21 19
46 34 26 22 44 33 26 21 31 25 21 29 24 20 28 23 19 17
Tandem
Blank=4'
Length
8T=8' Length
Series
EIM=
Apertured
Reflector
ECIM=Closed
Top
Reflector
SAMPLE NUMBER:EIM-396T8-120V-EB81- U
Number
of Lamps
3or 4Lamps
(Not included)
Voltage (1)
120V=120 Volt
277V=277 Volt
347V=347 Volt
UNV=Universal Voltage 120-277(2)
Lamp Spacing
Blank=Standard Spacing
N=Narrow Spacing for 2
Lamp Only (10% uplight)
Silver (3)
Reflector
SS=
Silver-
Lining
Reflector Wattage (Length)
96=60/75W T12 (72") SL
96T8=59W T8 (96") SL
Options
GL=Single Element Fuse
GM=Double Element Fuse
Emergency=EM InstalledNOTES: (1)Products also available in non-US voltages and frequencies for international
markets. (2)Not available when specifying emergencies, voltage must be specific.
(3)Silver lining not available on fixtures with HO, VHO or PG.
Specifications & dimensions subject to change without notice. Consult your Cooper
Lighting Representative for availability and ordering information.
Ballast Type(1)
EB8=T8 Electronic Instant Start.
Total Harmonic Distortion < 10%
EB8/PLUS=T8 Electronic Instant Start.
High Ballast Factor >1.13. Total
Harmonic Distortion < 20%
ER8=T8 Electronic Program Rapid Start.
Total Harmonic Distortion < 10%
EB2=T12 Electronic Rapid Start.
DLS=Digital Lighting System Dimming
No. of Ballast
1, 2 or 3
No. of
Ballast
1, 2 or 3
No. of Ballast
1, 2 or 3
No. of Ballast
1 or 2
Options
RIF1=Radio Interference
Suppressor
6-3/18 SJT-C&P-515P=Cord
& Plug (120V)
6-3/18 SJT-C&P-
L715P=Cord & Plug (277V)
PI/CPI=Plug-In Option
TILW=Tandem In-Line
Wiring Option (Consult
TILW Option Catalog Page)
POX=Porlux Finish
(See options & accessories)
Packaging
U=Unit Pack
4B=4 Bulk
A1B/Spacer-U=Spacer 1-1/2" to 2-1/2" from ceiling
(Use 2 per fixture)
ATG-4=Tong Hanger (Use 2 per fixture)
SCF=Fixed Stem Set (Specify Length)
SCS=Swivel Stem Set (Specify Length)
SCA=Adjustable 48" Stem Set
AYC-Chain/Set-U=Chain Hanger Set (Use 1 set per fixture)
WG/DI-4FT-U1=Wire Guard
WGG/DI-4FT-U=Wire Gym Guard
DI2=Long Connector
CEP=Closed End Plate
(Note: Reflector will extend 1/4" past the end plate).
(Additional Accessories Available. See Options and Accessories Section).
EIM-396T8136 lbs.
EIM-496T8 36 lbs.
Catalog No. Wt.
