CABINETCO Lazy Susan User manual

Assmbly Instruction
Lazy Susan
This assembly instruction is for reference only. Page 1
Required Tools:
Power Drill Rubber Hammer
Step-by-Step Instruction:
Code Description Qty.
A Bottom Panel 1
B Lazy Susan Hardware 1
C Bottom Tunetable, and squre wood board 1 + 1
D Middle Panel with Tunetalbe Attached 1
E Rear Side Panel (L/R) 2
F Front Side Panel (L/R) 2
G Front Frame Long Sticker 1
H Front Frame 2
I Back Panel 1
J Toe Kick 2
K Milldle Turntable Sticker 2
L Front Door 2
M Hinges Door to Door 2
N Hinges Door to Frame 2
O Door Magnet 2 (1set)
P Back Panel Support 1
Step 1 Step 2
Lay A flat, finished side facing
upward, find the middle point
by using pensil to draw out 2
crossing lines.
Open B (as picture) and lay it
on A , secure B on A with
screws.
**Create a larger hole for
securing screws purpose for
Step 2**
Lay C flat facing downward,
attach square board on the
middle of C
Attach A on C, using the
larger hole created from
Step 1 to secure the screws
on the C. Using the same
method to secure 4 screws
For Product lines:
Modern Gray/Frenso Gray Shaker/Anaheim
Gray/Beech Espresso

Assmbly Instruction
Lazy Susan
This assembly instruction is for reference only. Page 2
Step 3 Step 4
Lay E flat; grooves facing
upward and insert F,
security with Metal Clips
Repeat this step with the
other E and F panels
Insert bototom tune talbe A
& C into to both E and F
Securtiy using the Metal
Clips
Step 5 Step 6
Attach I onto E and secure
with screws into pre-drilled
holes from the back panel
Attach J onto F secure
Metal Clips
Attach two K onto both
middle of F, make sure it is
even and balanced, secrue
with screws
Lay D onto K and secure
with screws
Step 7 Step 8
Attach both H onto F,
secure with Metal Clips
onto F
*One front frame (H) has
door hinges gap, it can be
installed on left or right, it
depends on the door
openning direction*
Attach G on the H and
secure with screws, also
screw G between E and F

Assmbly Instruction
Lazy Susan
This assembly instruction is for reference only. Page 3
Step 9 Step 10
Attach P onto E, secure
with Metal Clips, and
secure with Metal Clips
onto I
Use door to door hinges
(M) to connect two doors
Step 11 Step 12
Attach hinges (N) on the
faceframe, install door (L)
onto hinge
Attach door Magnet (O) on
the door frame (H) upper
position
Attach door magnet (O)
metal part on the door (L)
