Simpli Home WyndenHall Brooklyn+Max AXWSH001-TB User manual

WARM SHAKER / NORFOLK / LEXINGTON
COFFEE TABLE
MODEL # AXWSH001-TB
1/16
SI
M
P
I
I
HOME
L I F E B Y D E S I G N

2/16
SI
M
P
I
I
HOME
L I F E B Y D E S I G N
Questions, problems, assembly help, missing parts?
No need to return the product, we will gladly help and ship your
replacement parts free of charge
Please call Customer Service at 1-866-518-0120 ext. 262
Monday to Friday between 9 am – 4 pm EST
or go to
www.simpli-home.com/parts request
In order to assist you in a timely manner, please have the following information ready:
Model # _______________________ Part Number or Letter_______________________
Purchased at ___________________Date of Purchase ___________________________
If you wish to return the product, please contact the retailer where the
product was purchased.

IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
SAFETY INFORMATION
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required. Hardware
package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
3/16

4/16
CARE and MAINTENANCE
Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative
humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls,
and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally
along different grain directions. As humidity changes, the components of wooden objects are
continually pushing and pulling against each other. This pressure often results in parts of furniture
no longer fitting together closely or becoming distorted or breaking from their own internal
stresses.
The response to relative humidity changes begins with determining the annual average RH for
your particular space. Then try to keep the RH in the space where your furniture is as close to that
average as possible, generally within about 10% up or down. De-humidify in the summer and
humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern heating
systems, which can drive down interior RH in the winter, almost invariably cause problems for
furniture. To counteract their effect, you can either modify the RH by keeping furniture containing
spaces cooler in the winter or most importantly, have a good working humidifier for your home. A
humidistat automatically works to balance the humidity in your home so it is constant. Dry indoor
air can suck enough moisture from its surroundings to do permanent damage to wood, causing it
to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how rapidly a
wood will lose moisture are pore size and surface hardness. A piece made from a dense and hard
wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished piece
while pieces with veneer finishes are not only stronger, but lose moisture more slowly than other
finishes.
To help protect your wood furniture, take these steps:
• Use a humidifier, preferably one with an automatic control system that can sense the humidity
level and adjust itself accordingly. Don't over-humidify; that can damage wood by causing it to
expand and contract.
• Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp.
• If you can avoid it, don't put furniture near heating vents. If you must, keep the piece 3 to 4
inches away from the wall, giving the heat and air space to circulate.
• Dust with soft dry cloth.
• Do not use liquid or aerosol products.
• To avoid marking, do not place rubber on surface (foot pads, etc.)
• For soil build-up, wipe with damp cloth & dry.
• Do not use abrasive cleaners.
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.

NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
PRE-ASSEMBLY INFORMATION
MODEL # AXWSH001-TB
A
PARTS DESCRIPTION
5/16
TOP
QTY 1
LEFT SIDE
QTY 1
TOP SHELF
QTY 1
BOTTOM SHELF
QTY 1
BACK
QTY 1
CENTRE DRAWER
QTY 1
BL
CDE
F G HL
I J
DRAWER FRONT
QTY 2
DRAWER BACK
QTY 2
DRAWER BOTTOM
QTY 2
LEFT DRAWER SIDE
QTY 2
HR
RIGHT DRAWER SIDE
QTY 2
RIGHT SIDE
QTY 1
BR
Fr
ont /
Avant
Front /
Avant
Front /
Avant
Fr
ont
/
A
v
ant
Fr
ont
/ Av
ant
Front
/
A
vant

PRE-ASSEMBLY INFORMATION
HARDWARE DESCRIPTION
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
6/16
MODEL # AXWSH001-TB
123
4 5
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
ALLEN KEY
QTY 1
WOOD DOWEL
Ø8 X 30 mm
QTY 6
CAM LOCK PIN
CAM LOCK
QTY 18 SETS
ALLEN KEY SCREW
M6 X 30 mm
QTY 26
HANDLE
M4X25 mm
QTY 4 SETS

COMPONENTS – KEY DIAGRAM
7/16
MODEL # AXWSH001-TB
A
E
BL
BR
C
F
D
I
HL
HR
J
G
Front /
Avant
Front /
Avant
Front /
Avant
Front
/
Avant
Front
/ Avant
Front / Avant

ASSEMBLY
STEP 1
8/16
MODEL # AXWSH001-TB
1. Slide Drawer Bottom J firmly into slots on Drawer Sides HL , HR and
Drawer Front G .
STEP 2
1. Attach 4 Cam Lock Pins 2 to back of Drawer Front G .
2. Align Cam Lock Pins with pre-drilled holes and attach Drawer Sides HL , HR .
3. Insert 2 Cam Locks 2 into pre-drilled holes on each Drawer Side HL , HR .
4. Use flathead screwdriver to secure Cam Locks.
G
2
HR
HL
G
HR
HL
J

ASSEMBLY
STEP 3
MODEL # AXWSH001-TB
STEP 4
1. Use Phillips Screwdriver to attach Handle 4 to Drawer Front G .
1. Align Drawer Back I with Drawer Bottom J and press firmly into slot .
2. Attach back using 2 Allen Key Screws 1 through pre-drilled holes on each side.
3. Use Allen key 3 to tighten. Do not over tighten.
NOTE: The screwdriver is not
included in the hardware pack.
G
J
HR
HL
I
1
3
4
G
Repeat Step 1-4 for the second drawer.
9/16

ASSEMBLY
STEP 5
10/16
MODEL # AXWSH001-TB
NOTE:
Holes are on the right side.
C
BL
13
1. Attach Top Shelf C to Left Side BL using Allen Key Screws 1 through pre-drilled holes.
Front / Avant
Front
/
Avant

ASSEMBLY
STEP 6
11/16
MODEL # AXWSH001-TB
1. Attach 2 Cam Lock Pins 2 to Left Side BL using guide holes.
2. Align and insert Cam lock Pins on Left Side BL into pre-drilled holes on Back E .
3. Using a flathead screwdriver tighten Cam Locks into Pins.
4. Use Phillips screwdriver to attach Handle 4 to Back E .
BL
CE
4
2
Front
/ Avant
Front
/
Avant

ASSEMBLY
STEP 7
12/16
MODEL # AXWSH001-TB
1. To attach Right Side BR to Top Shelf C and Back E , repeat steps 5 - 6.
BR
E
C
2
1
3
Front
/ Avant
Front
/
Avant
Front /
Avant

ASSEMBLY
STEP 8
13/16
MODEL # AXWSH001-TB
1. Attach Centre Drawer F to Top Shelf C
using Allen Key Screws 1 through pre-drilled holes.
F
C
1
3
Front
/ Avant
Front
/
Avant
Front / Avant
Front
/ Avant

ASSEMBLY
STEP 9
14/16
MODEL # AXWSH001-TB
1. Insert 2 Dowels 5 into pre-drilled holes on the Centre Drawer F .
2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach Bottom Shelf D to Sides BL , BR and Centre Drawer F
using Allen Key Screws 1 through pre-drilled holes.
D
BR
BL
F
3
1
5
Front
/ Avant
Front /
Avant
Front
/
Avant
Front
/
Avant
Front /
Avant
Front
/
Avant

ASSEMBLY
STEP 10
15/16
MODEL # AXWSH001-TB
1. Insert Dowels 5 into each corner of Side BL , BR .
2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach 6 Cam Lock Pins 2 to bottom of Top A .
4. Align and insert Cam Lock Pins on Top A into pre-drilled holes on Sides BL , BR .
5. Using a flathead screwdriver tighten Cam Locks into Pins.
STEP 11
A
BR
BL
5
2
1. Insert assembled drawer into glides on assembled table.
2. Drawers can be inserted into either side of table opening.

WARRANTY
16/16
Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max
product. These products have been made to demanding, high-quality
standards and are guaranteed for domestic use against manufacturing
faults for a period of 12 months from the date of purchase. This warranty
does not affect your statutory rights.
In case of any malfunction of your product (failure, missing parts, etc.)
please contact us at our toll free service line at 1-866-518-0120 ext. 262
from 9 am to 4 pm, Monday to Friday, Eastern Standard Time or by email at
cust[email protected].
We reserve the right to repair or replace the defective product, at its
discretion.
This product is guaranteed for 12 months if used for normal purposes.
Any warranty is invalid if the product has been overloaded or subject to
neglect, improper use or an attempted repair by other than an authorized
agent. Heavy-duty or daily professional/commercial usage are not
guaranteed.
Due to continuous product improvement, we reserve the right to change
the product specifications without prior notice.
