Walker Edison AF44MOL2DR User manual

P.1
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Please visit our website for the most current instructions, assembly tips, report damage,
or request parts. www.walkeredison.com
Revised 02/01/2020 (L)
®
Walker Edison
TM
Item # : AF44MOL2DR
Assembly Instructions

P.2
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
General Assembly Guidelines
I. Ensure that all parts and hardware are available before beginning assembly.
II. Follow each step carefully to ensure the proper assembly of this product.
21
III. Two people are recommended for ease in the assembly of this product.
IV. The three main types of hardware used to assemble this product are : wood
dowels , screws and bolts.
V. The provided glue is to secure wood dowels in place . When first inserting dowels ,
locate the appropriate hole for the dowel , place a small amount of glue in the hole
and insert the dowel . Wipe away excess glue immediately.
In future assembly steps when dowels are necessary to attach assembly parts
together , place a small amount of glue on the end of the dowel before attaching
parts together . Wipe away excess glue immediately.
VI. A Phillips head screwdriver is required for the assembly of this product .
VII. Power tools should not be used to assemble this product .

P.3
Parts List
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
1
x 2
36
5
5
4
7
8
9
10
2
11
11 11
11
12
13
14
15
16
17

P.4
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Hardware List
The hardware quantities listed above are required for proper assembly.
Some extra hardware may also have been included.
Ø8x30mm Wooden dowelA 38 pcs
Ø6x35mm Cam boltB 31 pcs
Ø15x9mm Cam lock
C
8 pcs
Sticker
D
31 pcsE
F
G
H
J
K
L
M
Ø15x11mm Cam lock 23 pcs
Ø4x32mm Screw 8 pcs
Ø3.5x15mm Screw 2 pcs
Glue tube 1 pc
Screw 21 pcsØ6x50mm
Ø6x12mm Bolt 20 pcs
M4 Hex Key 1 pc
Philips head screwdriver required for assembly
(not included)
Plastic stopper 2 pcs

P.5
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 1
x 2
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
1
13
Secure cam bolt (B) into parts (1, 13) with Philips head screwdriver as per diagram.

P.6
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 2
B
B
B B
B
B
A
A
A
AA
A
A
A
A
A
AA
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
34
5
5
6
7
8
9
Insert wooden dowel (A) into parts (3,4,5,6,7,8,9) ,then secure cam bolt (B) into parts (3,6) with
Philips head screwdriver as per diagram.

Step 3
P.7
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
B
B
A
A
A
A
J
J
K
K
10
10
Insert wooden dowel (A) into part (10),then secure cam bolt (B) into part (10).Using screw (K) attach
Plastic stopper (J) to part (10) with philips head screwdriver as per diagram.

Step 4
P.8
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
H
7
8
10
F
F
F
F
Finished edge
Using screw (F) attach part (10) into parts (7,8) with hex key (H) as per diagram.

P.9
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 5 21 3
C
C
C
C
3
8
3
10
Using cam lock(C) secure part (3) to parts(8,10) with Philips head screwdriver as per diagram.

P.10
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 6 21 3
C
C
C
C
6
8
6
10
Using cam lock(C) secure part (6) to parts(8,10) with Philips head screwdriver as per diagram.

P.11
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 7 21 3
C
C
C
C
C
C
C
1
3
4
6
78
Using cam lock(C) secure parts (3,4,6,7,8) to part (1) with Philips head screwdriver as per diagram.

P.12
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 8 21 3
C
C
1
5
5
9
10
put part (5) as per diagram ,then using cam lock(C) secure part (9) to part(10) with Philips head
screwdriver as per diagram.

P.13
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 9
F
F
F
F
F
F
F
F
F
FFFF
F
F
F
F
H
3
455
6
9
2
Using screw (F) attach part (2) into parts (3,4,5,6,9) with hex key (H) as per diagram.

P.14
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 10
G
G
G
G
H
2
11
11
11
11
12
Using bolt (G) attach parts (11,12) to part (2) with hex key (H) as per diagram.

P.15
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 11
x 2
L
L
L
L
14
15
16
Using screw (L) attach parts (14,16) to part (15) with Philips head screwdriver as per diagram.

P.16
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 12
x 2
14 15
16
17
Put part (17) as per diagram.

P.17
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 13 21 3
x 2
D
D
D
D
13
14
16
Using cam lock(D) attach parts (13) to part (14,16)with Philips head screwdriver as per diagram.

P.18
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 14
x 2
E
E
E
E
Place sticker (E) cover the holes as per diagram .

P.19
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 15
Insert the assembled drawers into the unit frame.

P.20
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 16
Position the assembled unit at the desired location ,if necessary adjust the floor leveler at the
bottom of the support leg to level the unit .
