Simplicity 1695163 Setup guide

Attachment
Illustrated
Parts List
Rev. 04/2007
500 N. Spring Street / PO Box 997
Port Washington, WI 53074-0997 USA
www.simplicitymfg.com
MANUFACTURING, INC.
© Copyright Simplicity Manufacturing, Inc. All Rights Reserved. Printed In USA.2007 TP 400-4535-00-AT-SMA
Mf
g
. No. Descri
p
tion
Attachment
1695163 Catcher, Clean Sweep Twin, 38"
1734814
Part No.:

Table Of Content
s
Torque Specification Chart ..................................................................... Inside Back Cover
PRODUCT COMPONENTS PAGES
Twin Catcher Assembly ....................................................................................................................................... 4

Twin Catcher Assembly
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
1695163
The above parts group applies to the following Mfg. Nos.:
4
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1695163 - Catcher
TP 400-4535-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.
Twin Catcher Assembly
Footnotes
COVER ASSEMBLY, with Decal1 1732815SM 1
SCREW, 10 - 24 x 3/42 1960404SM 8
LATCH3 1733416ASM 1
NUT, 10 - 24, ESNA Lock4 1933896SM 8
EDGING, 13-1/8 Long5 1700864SM 2
BAG ASSEMBLY, Twin6 1732350SM 2
CAP7 024862MA 3
TUBE, "U"8 1733440SM 1
TUBE, Center9 054412E701MA 1
SCREW, 5/16 - 24, Curve10 006x93MA 2
LOCKWASHER, 5/1611 1917356SM 2
NUT, 5/16 - 24, Hex12 1920263SM 2
NUT, 1/4 - 20, Keps Lock13 1928372SM 4
SCREW, 1/4 - 20 x 1/214 004x26MA 5
PIN, Cover Hinge15 054407ZMA 1
HINGE, Cover16 054398E701MA 1
PIN, Hair17 1960074SM 1
CHANNEL ASSEMBLY18 1732867SM 1
PIN, Channel Mount19 1732565SM 1
MOUNT ASSEMBLY, Channel20 1732067ASM 1
PIN, Hair, 1/8 x 2-9/1621 1960033SM 1
BOLT, Shoulder, 5/16 - 1822 1728976SM 2
NUT, 5/16 - 18, Speed23 1960717SM 2
WASHER24 1960185SM 1
LATCH, Wire Form25 1704603SM 1
TUBE, Discharge26 1703769SM 1
SCREW, 5/16 - 18 x 3/427 1960122SM 1
WASHER28 1919326SM 1
SEAL, Rubber29 1732799SM 1
PLATE, Seal30 1732735ASM 1
BOLT, Carriage, 5/16 - 18 x 3/431 1931333SM 1
BOOT, 38"32 1732561SM 1
SCREW, 5/16 - 18 x 3/433 1960371SM 3
WASHER, Special34 1704341SM 1
NUT, 5/16 - 18, Centerlock Flange35 1935048SM 5
BRACKET, Boot Mount36 1704355ASM 1
BOLT, Carriage, 5/16 - 18 x 237 1931339SM 3
WINGNUT ASSEMBLY38 1733689SM 1
NUT, Whizlock, 5/16 - 1839 1927557SM 4
SPACER40 1674669SM 2
BAFFLE, 38"41 1703765ASM 1
BLADE, 38" Hi-Lift42 1704977SM 1
BOLT, Carriage, 5/16 - 18 x 1-3/443 1931338SM 5
NUT, 5/16 - 18 ESNA44 1960686SM 6
The above parts group applies to the following Mfg. Nos.:
5
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1695163 - Catcher
TP 400-4535-00-AT-SMA

Twin Catcher Assembly
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
1695163
The above parts group applies to the following Mfg. Nos.:
6
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1695163 - Catcher
TP 400-4535-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.
Twin Catcher Assembly
Footnotes
BRACE STIFFENER48 1733432ASM 1
CAPSCREW, 5/16 - 18 x 3/449 1930591SM 1
DECAL, Cover Warning52 1732819SM 1
RIVET, Pop, 3/1653 1673320SM 18
WASHER, Rivet, 3/1654 1910531SM 12
SCREEN, Twin Cover55 1732488SM 1
FASTENERS, Push, 1/4 x 1/256 1732490SM 6
SCREEN SUPPORT, Twin57 1734384SM 1
INSTRUCTION MANUAL58 1733419 1
The above parts group applies to the following Mfg. Nos.:
7
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1695163 - Catcher
TP 400-4535-00-AT-SMA

Torque Specification Chart
FOR STANDARD MACHINE HARDWARE (Tolerance ± 20%)
Hardware
Grade
SAE Grade 2 SAE Grade 5 SAE Grade 8
Size Of in/lbs in/lbs in/lbs
Hardware ft/lbs Nm. ft/lbs Nm. ft/lbs Nm.
8-32 19 2.1 30 3.4 41 4.6
8-36
20 2.3 31 3.5 43 4.9
10-24
27 3.1 43 4.9 60 6.8
10-32
31 3.5 49 5.5 68 7.7
1/4-20
66 7.6 810.9 12 16.3
1/4-28
76 8.6 10 13.6 14 19.0
5/16-18 11 15.0 17 23.1 25 34.0
5/16-24 12 16.3 19 25.8 27 34.0
3/8-16 20 27.2 30 40.8 45 61.2
3/8-24 23 31.3 35 47.6 50 68.0
7/16-14 30 40.8 50 68.0 70 95.2
7/16-20 35 47.6 55 74.8 80 108.8
1/2-13 50 68.0 75 102.0 110 149.6
1/2-20 55 74.8 90 122.4 120 163.2
9/16-12 65 88.4 110 149.6 150 204.0
9/16-18 75 102.0 120 163.2 170 231.2
5/8-11 90 122.4 150 204.0 220 299.2
5/8-18 100 136 180 244.8 240 326.4
3/4-10 160 217.6 260 353.6 386 525.0
3/4-16 180 244.8 300 408.0 420 571.2
7/8-9 140 190.4 400 544.0 600 816.0
7/8-14 155 210.8 440 598.4 660 897.6
1-8 220 299.2 580 788.8 900 1,244.0
1-12 240 326.4 640 870.4 1,000 1,360.0
Hex Head Capscrew
Hex Nut
Lockwasher
Washer
Carriage Bolt
NOTES
1. These torque values are to be used for all hardware
excluding: locknuts, self-tapping screws, thread forming
screws, sheet metal screws and socket head setscrews.
2. Recommended seating torque values for locknuts:
a. for prevailing torque locknuts - use 65% of grade 5
torques.
b. for flange whizlock nuts and screws - use 135% of
grade 5 torques.
3. Unless otherwise noted on assembly drawings, all torque
values must meet this specification.
Hardware Identification & Torque Specifications
Common Hardware Types
Screw, 1/2 x 2
Body
Diameter
Body
Length
Inside
Diameter
Nut, 1/2”
No
Marks
3/8” Bolt or Nut
Wrench—9/16”
3/8
5/16” Bolt or Nut
Wrench—1/2”
5/16
1/4” Bolt or Nut
Wrench—7/16”
1/4
1/2” Bolt or Nut
Wrench—3/4”
1/2
DIA.
7/16
DIA.
7/16” Bolt or Nut
Wrench (Bolt)—5/8”
Wrench (Nut)—11/16”
Wrench & Fastener Size Guide
Standard Hardware Sizing
When a washer or nut is identified as 1/2”, this is the
Nominal size , meaning the inside diameter is 1/2 inch; if a
second number is present it represent the
threads per inch
When bolt or capscrew is identified as 1/2 - 16 x 2”, this
means the
Nominal size , or body diameter is 1/2 inch; the
second number represents the
threads per inch (16 in this
example, and the final number is the
body length of the
bolt or screw (in this example 2 inches long).
The guides and ruler furnished below are designed to
help you select the appropriate hardware and tools.
0
1/4 3/4
1/2
1
1/4 3/4
1/2
2
1/4 3/4
1/2
3
1/4 3/4
1/2
4
