Simplicity 4219 Setup guide

Attachment
Illustrated
Parts List
Rev. 07/2005
500 N. Spring Street / PO Box 997
Port Washington, WI 53074-0997 USA
www.simplicitymfg.com
MANUFACTURING, INC.
© Copyright Simplicity Manufacturing, Inc. All Rights Reserved. Printed In USA.2005 TP 400-4219-00-AT-SMA
Mf
g
. No. Descri
p
tion
Attachment
1694499 Catcher, Turbo Clean Sweep Triple
1731896
Part No.:

Cover & Bag Group - Triple
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
4
5
6
4
3
33
4
5
6
2
1
38
9
10
11
12
13
15
14
16
17
18
16
25
29
21
20
22
18
27
28 26
24
31
32
35 4434
7
7
8
30
33
37
19
23
36
16
24
986509

PART NO. DESCRIPTIONREF NO QTY.
Cover & Bag Group - Triple
Footnotes
1 1717025 1 COVER & SCREEN ASSEMBLY, Grass Collector Complete (Incl. Ref. Nos. 2, 3, 4, 5,
6, 7, 8, 9, 10, 11, 12 & 13)
2 1717026 1 COVER, Grass Catcher Black Plastic
3 1960241 9 RIVET, Pop, .25OD .500L Steal,Steal Stem .50HD Black
4 1717067 3 PLATE & TUBE ASSEMBLY, Hinge
5 2825160 25 RIVET, Pop, .188D .527L Steal,Steal Stem .37HD Dia.
6 1910531 16 WASHER, Rivet, .188 (0.20ID x 0.50OD x .05TH) Black
7 1667248 6 CLIP, Canoe .437LG .375DIA
8 1704405 1 DECAL, WARNING Do Not Open Cover
9 1716970 1 CLAMP, Screen 16GA 40.0LG
10 1717041 1 SCREEN, Black Poly, 19.5 x 45.0
11 1717524 1 CLAMP, Seal, .060THK .75WD 48.00LG
12 1716968 1 SEAL, Black Rubber, .075 x 3.00 x 48.0
13 1716972 1 ANGLE, Screen, 14GA 48"LG
14 1719807 1 CHUTE, Grass Collector Upper, 5.76ID 21.7L Scribed
15 1921333 4 CAPSCREW, Hex Head, 5/16-18 x 1 G5 Black
16 1919326 12 WASHER, 5/16 (0.34ID x 0.75OD x .06THK) Black
17 1925003 3 CAPSCREW, Hex Washer Head Taptite, 1/4-20 x 1/2 Black
18 1919438 8 NUT, Hex Lock ESNA Light, 5/16-18NC-3B Black
19 1717039 1 DEFLECTOR, Black Plastic Grass Collector
20 1716973 1 CHANNEL & BRACKET ASSEMBLY, Support
21 1716966 1 PLATE & BRACES ASSEMBLY, 3 Bag Grass Catcher
22 1725969 1 COVER, Inlet, .125THK 8.12 x 8.12 Plexiglass
23 1717038 1 DUCT, Inlet Black Plastic Grass Collector
24 1720875 2 BRACKET, Hinge 3 Bag, 12GA 6.00LG with Point
25 1720945 1 BRACKET, Hinge 3 Bag, 12GA 2.75LG
26 1672344 3 PIN, Round Head Drilled, 3/8 x 2-3/4 Black
27 1928707 16 RIVET, Pop, .188D .277L AL, AL Stem .37HD Black
28 1960074 3 CLIP, Hair Pin, .093DIA Spring Wire 1.625LG Black
29 1921332 4 CAPSCREW, Hex Head, 5/16-18 x 3/4 G5 Black
30 1703764 1 BAG, Grass, 15.4 x 16 x 22.5 White Poly Cloth
31 1931333 2 CARRIAGE BOLT, 5/16-18 x 3/4 G5 Black
32 1703807 1 HANGER, Grass Bag Hoop
33 1917372 2 NUT, Hex 5/16-18 NC-2B Black
34 1917356 2 LOCKWASHER, Spring 3/8 Black
35 1672023 1 CLAMP, Wire Diameter 1/2 (2), .344 Holes (3)
36 1703855 1 HOOP, 1/2 ROD 16.12 x 16.75
37 1675707 1 EDGING, 13.50LG PVC Tube White
38 1717082 1 SEAL, Black Plastic 73"
The above parts group applies to the following Mfg. Nos.:
2005 2 © Copyright Simplicity Manufacturing, Inc. All Rights Reserved.
1694499 - Catcher
TP 400-4219-00-AT-SMA

Front Weight Carrier Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
1
5
62
63
63
66
62
64
66
986507
The above parts group applies to the following Mfg. Nos.:
2005 3 © Copyright Simplicity Manufacturing, Inc. All Rights Reserved.
1694499 - Catcher
TP 400-4219-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.
Front Weight Carrier Group
Footnotes
1 5049082 1 HOLDER ASSEMBL, Weight
2 1921333 4 CAPSCREW, Hex Head, 5/16-18 x 1 G5 Black
3 1919326 4 WASHER, 5/16 (0.34ID x 0.75OD x .06THK) Black
4 1927557 4 NUT, Hex Flange Whiz Lock, 5/16-18 Large Black
5 5049143 1 ROD, Retaining, 1/2 x 13-3/4LG
6 2176012 2 RETAINER, Pin, Spring
The above parts group applies to the following Mfg. Nos.:
2005 4 © Copyright Simplicity Manufacturing, Inc. All Rights Reserved.
1694499 - Catcher
TP 400-4219-00-AT-SMA

Mount Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
50"
44"
Torque to•
55-70 ft. lbs.
35
49
48
7
8
6
4
5
Existing Hardware•
(Bolt, Washer, Lockwasher, & Nut)
40
41
42
43
22
38 44
1
1
2
3
9
18
18
15
16
17
8
14
13
Existing Pulley
& Spacer
24
25
26
27
32
31
30
36
37
38
22
39
19
8
34
45
11
21
2
22
20
23
33
29
12
10
47
46
17
28
Existing Hardware•
Existing
Hardware•
18
986508
The above parts group applies to the following Mfg. Nos.:
2005 5 © Copyright Simplicity Manufacturing, Inc. All Rights Reserved.
1694499 - Catcher
TP 400-4219-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.
Mount Group
Footnotes
1 1921333 4 CAPSCREW, Hex Head, 5/16-18 x 1 G5 Black
2 1919326 3 WASHER, 5/16 (0.34ID x 0.75OD x .06THK) Black
3 1718304 1 SUPPORT, Belt Cover 10GA 1.0WD 3.0LG
4 1933896 4 NUT, Hex Lock, 10-24 with Nylon Insert NC3B Black
5 1718295 1 ROD, .375DIA 22.0LG
6 1960404 4 SCREW, Truss Head Phillips, #10-24 x 3/4 Black
7 1722546 1 PIVOT & BRACKETS ASSEMBLY, 38, 44 & 50"
8 1931277 6 NUT, Hex Flange Whiz Lock, 5/16-18 Small Black
9 1919438 1 NUT, Hex Lock ESNA Light, 5/16-18NC-3B Black
10 5049171 1 COVER, Belt 44" 12GA
11 1717291 2 DECAL, WARNING Sheild & Mower Deflector
12 5049170 1 COVER, Belt 50" 12GA
13 1916950 1 NUT, Hex 3/8-16 NC-2B Black
14 1916965 1 LOCKWASHER, Spring 3/8
15 1704768 1 BRACKET, Z .164TH 5.88WD 3.21LG
16 1724373 1 BRACKET, L 12GA 1.24WD 2.24LG 2.28LG
17 1924940 1 WASHER, 3/8 (0.41ID x 0.87OD x .08THK) Black
18 1923701 1 CAPSCREW, Hex Head, 3/8-16 x 2 G5 Black
19 1714817 1 PULLEY, Idler, 2.75OD 0.380ID 0.50W
20 2172845 1 STOP, Belt, .188WIRE 1.750,2.250 Black
21 1921221 1 CAPSCREW, Hex Head, 5/16-18 x 1-1/2 G5 Black
22 1917356 1 LOCKWASHER, Spring 5/16 Black
23 1710703 1 SPACER, 0.328ID x 0.499OD x 0.625LG Powdered Metal
24 1713523 1 NUT, Sleeve, 9/16-18 x 3/4INT x 1.34LG Black
25 1603592 1 WASHER, Bellville, 0.88ID x 1.75OD x .08TH Black
26 1709941 1 PULLEY, 04.30OD 1.000ID 0.579 Groove 9GA
27 1713623 1 HUB, .79ID x 1.5OD x .73LG Metafusion
28 5049145 1 PLATE, Spring Support 10GA
29 5049088 1 SPACER, 0.812ID x 1.75OD x 0.50LG
30 1960318 1 CAPSCREW, Hex Head, 5/16-18 x 2-1/2 G5 Flat Black
31 1919381 1 WASHER, 5/16 (0.34ID x 1.00OD x .13THK) Black
32 1705064 1 SPRING, Latch, .125WIRE 4.3LG Black
33 2108717 1 SPACER, 0.390ID x 0.625OD x .265LG
34 1922755 1 WASHER, 3/8 (0.41ID x 1.00OD x .13THK) Black
35 1705142 1 V-BELT, 3L, 44" Mower Deck
36 1923362 1 NUTHex Centerlock, 5/16-18 Black
37 1679163 1 NUT & CUP ASSEMBLY, Wing, 5/16-18 E-Coat
38 1917372 2 NUT,Hex, 5/16-18 NC-2B Black
39 1704982 1 PLATE, Anchor
40 1960223 1 CARRIAGE BOLT, 5/16-18 x 1-1/4 G5 Black
41 1659867 1 BRACKET ASSEMBLY, Cutoff, 44"
42 1666294 1 SPACER, 0.385ID x 0.668OD x 0.455LG Powdered Metal Black
43 1705308 1 BRACKET, L 12GA 1.00WD 1.98LG 0.62LG
44 1923325 2 CAPSCREW, Hex Head, 5/16-18 x 7/8 G5 Black
The above parts group applies to the following Mfg. Nos.:
2005 6 © Copyright Simplicity Manufacturing, Inc. All Rights Reserved.
1694499 - Catcher
TP 400-4219-00-AT-SMA

Mount Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
50"
44"
Torque to•
55-70 ft. lbs.
35
49
48
7
8
6
4
5
Existing Hardware•
(Bolt, Washer, Lockwasher, & Nut)
40
41
42
43
22
38 44
1
1
2
3
9
18
18
15
16
17
8
14
13
Existing Pulley
& Spacer
24
25
26
27
32
31
30
36
37
38
22
39
19
8
34
45
11
21
2
22
20
23
33
29
12
10
47
46
17
28
Existing Hardware•
Existing
Hardware•
18
986508
The above parts group applies to the following Mfg. Nos.:
2005 7 © Copyright Simplicity Manufacturing, Inc. All Rights Reserved.
1694499 - Catcher
TP 400-4219-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.
Mount Group
Footnotes
45 1931333 1 CARRIAGE BOLT, 5/16-18 x 3/4 G5 Black
46 5049159 1 SPRING, Compression, 0.720OD x 2.25 LG .085 Wire
47 5049144 1 SPACER, 0.390ID x 0.75OD x 1.13 LG YELLOW
48 1704983 1 BRACKET & PLATE ASSEMBLY, Clamp
49 1707956 1 V-BELT, 3L, 50" Mower Deck
The above parts group applies to the following Mfg. Nos.:
2005 8 © Copyright Simplicity Manufacturing, Inc. All Rights Reserved.
1694499 - Catcher
TP 400-4219-00-AT-SMA

Tubes & Support Group - Triple
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
11
12
13
1
5
2
4
6
3
10
5
2
3
6667
6668
6669
66615
66614
16
986506
The above parts group applies to the following Mfg. Nos.:
2005 9 © Copyright Simplicity Manufacturing, Inc. All Rights Reserved.
1694499 - Catcher
TP 400-4219-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.
Tubes & Support Group - Triple
Footnotes
1 5049152 1 CHUTE, Grass Collector Lower, Black Poly
2 1960404 5 SCREW, Truss Head Phillips, #10, 24 x 3/4 Black
3 1960096 5 WASHER, 3/16 (0.19ID x 0.75OD x .06THK) Black
4 1705063 1 CLIP, Spring, 1.40 x 1.48 Open 3.50LG 0.88WD
5 1933896 5 NUT, Hex Lock, 10-24 with Nylon Insert NC3B Black
6 5049151 1 CHUTE, Grass Collector Middle, Black Poly
7 1931335 4 CARRIAGE BOLT, 5/16-18 x 1 G5 Black
8 1917356 4 LOCKWASHER, Spring, 5/16 Black
9 1917372 4 NUT, Hex 5/16-18 NC-2B Black
10 1723437 1 SUPPORT ASSEMBLY, Triple Collector
11 1960033 1 CLIP, Hair Pin, .125DIA Spring Wire 2.562LG Black
12 1726968 1 PLATE & PINS ASSEMBLY, Hitch Triple Collector Black
13 1717085 1 ROD, Hitch, .625DIA 16.5LG
14 1921176 4 CAPSCREW, Hex Head, 1/2-13 x 1-1/4 G5 Black
15 1960668 4 NUT, Hex Flange Whiz Lock, 1/2-13 Black
16 * 1 DECAL, ID Plate
* Not a serviceable part.
The above parts group applies to the following Mfg. Nos.:
2005 10 © Copyright Simplicity Manufacturing, Inc. All Rights Reserved.
1694499 - Catcher
TP 400-4219-00-AT-SMA

Torque Specification Chart
FOR STANDARD MACHINE HARDWARE (Tolerance ± 20%)
Hardware
Grade
SAE Grade 2 SAE Grade 5 SAE Grade 8
Size Of in/lbs in/lbs in/lbs
Hardware ft/lbs Nm. ft/lbs Nm. ft/lbs Nm.
8-32 19 2.1 30 3.4 41 4.6
8-36
20 2.3 31 3.5 43 4.9
10-24
27 3.1 43 4.9 60 6.8
10-32
31 3.5 49 5.5 68 7.7
1/4-20
66 7.6 810.9 12 16.3
1/4-28
76 8.6 10 13.6 14 19.0
5/16-18 11 15.0 17 23.1 25 34.0
5/16-24 12 16.3 19 25.8 27 34.0
3/8-16 20 27.2 30 40.8 45 61.2
3/8-24 23 31.3 35 47.6 50 68.0
7/16-14 30 40.8 50 68.0 70 95.2
7/16-20 35 47.6 55 74.8 80 108.8
1/2-13 50 68.0 75 102.0 110 149.6
1/2-20 55 74.8 90 122.4 120 163.2
9/16-12 65 88.4 110 149.6 150 204.0
9/16-18 75 102.0 120 163.2 170 231.2
5/8-11 90 122.4 150 204.0 220 299.2
5/8-18 100 136 180 244.8 240 326.4
3/4-10 160 217.6 260 353.6 386 525.0
3/4-16 180 244.8 300 408.0 420 571.2
7/8-9 140 190.4 400 544.0 600 816.0
7/8-14 155 210.8 440 598.4 660 897.6
1-8 220 299.2 580 788.8 900 1,244.0
1-12 240 326.4 640 870.4 1,000 1,360.0
Hex Head Capscrew
Hex Nut
Lockwasher
Washer
Carriage Bolt
NOTES
1. These torque values are to be used for all hardware
excluding: locknuts, self-tapping screws, thread forming
screws, sheet metal screws and socket head setscrews.
2. Recommended seating torque values for locknuts:
a. for prevailing torque locknuts - use 65% of grade 5
torques.
b. for flange whizlock nuts and screws - use 135% of
grade 5 torques.
3. Unless otherwise noted on assembly drawings, all torque
values must meet this specification.
Hardware Identification & Torque Specifications
Common Hardware Types
Screw, 1/2 x 2
Body
Diameter
Body
Length
Inside
Diameter
Nut, 1/2”
No
Marks
3/8” Bolt or Nut
Wrench—9/16”
3/8
5/16” Bolt or Nut
Wrench—1/2”
5/16
1/4” Bolt or Nut
Wrench—7/16”
1/4
1/2” Bolt or Nut
Wrench—3/4”
1/2
DIA.
7/16
DIA.
7/16” Bolt or Nut
Wrench (Bolt)—5/8”
Wrench (Nut)—11/16”
Wrench & Fastener Size Guide
Standard Hardware Sizing
When a washer or nut is identified as 1/2”, this is the
Nominal size , meaning the inside diameter is 1/2 inch; if a
second number is present it represent the
threads per inch
When bolt or capscrew is identified as 1/2 - 16 x 2”, this
means the
Nominal size , or body diameter is 1/2 inch; the
second number represents the
threads per inch (16 in this
example, and the final number is the
body length of the
bolt or screw (in this example 2 inches long).
The guides and ruler furnished below are designed to
help you select the appropriate hardware and tools.
0
1/4 3/4
1/2
1
1/4 3/4
1/2
2
1/4 3/4
1/2
3
1/4 3/4
1/2
4
