Simplified MFG DAC1 User manual

DAC1
Dolby 5.1, DTS5.1 to Stereo
Downmixing Audio Converter
VER 2.0

1
Thank you for purchasing this device
The Simplified MFG DAC1 is designed to provide years of
reliable service. At Simplified MFG, we want the experience
with this device to be the best possible and are committed to
helping achieve that experience.
Surge protection device recommended
This product contains sensitive electrical components that may
be damaged by electrical spikes, surges, electric shock, lighting
strikes, etc. Use of surge protection systems is highly
recommended to protect and extend the life of your equipment.
Set top boxes (STB) that are connected to the outside world can
introduce surges through the HDMI. Simplified MFG’s HDSURGE
is recommended for use with these STB devices (cable and
satellite)

2
Table of Contents
1. Introduction ..................................................................... 3
2. Features .......................................................................... 3
3. Package Contents ............................................................. 4
4. Specifications ................................................................... 4
5. Operation Controls and Functions....................................... 6
6. Application Example.......................................................... 7
7. Function Explanation………………………………………………………8
8. Warranty……………………………….………………..…………….………..9
9. Contact……………………….…………………..……….…….…………….10

3
1. Introduction
The DAC1 is an 18Gbps HDMI2.0b audio extractor that can
downmix all Dolby 5.1 and DTS 5.1 formats to stereo or 5.1
formats via the optical SPDIF and/or the 3.5mm mini jack.
2. Features
•HDMI 2.0b (18Gbps), HDCP2.2/HDCP1.4 compliant.
•Supports video resolution up to 4K2K@50/60Hz
(4:4:4)
•Extracts audio with downmixing feature in all Dolby™
and DTS™ formats including DTS-X and Atmos
•Three position switch allows for passing bitstream
and breaking out stereo, using the display for the
audio EDID and breaking out multi-channel and, and
convert all to stereo
•HDR10+/ DolbyVision™ Pass-through
•Supports CEC pass-through

4
3. Package contents
1x DAC1 audio extractor/converter
1x 5VDC 1A power supply
1x Manual
4. Specifications
Technical
HDMI Compliance
HDMI 2.0b
HDCP Compliance
HDCP 2.2 and HDCP 1.4
Video Bandwidth
18Gbps
Video Resolutions
720P50/60Hz,1080P50/60Hz,
4K2K24Hz, 4K2K30Hz, 4K2K@50/60Hz
(4:4:4)
Color Depth
8, 10, or 12bit (depends on source
setting)
Color Space
RGB, YCbCr 4:4:4, YCbCr 4:2:2
HDMI Audio Formats
LPCM, Dolby Digital/Plus/EX, Dolby
True HD, Atmos, DTS, DTS-EX, DTS-
96/24, DTS High Res, DTS-HD Master
Audio, DSD & DTS-X
L/R Audio Formats
PCM 2.0
Optical Audio
LPCM [2.0/2.1]CH, Dolby 5.1, Dolby

5
Formats
True HD, Dolby DD+, DTS 5.1, DTS-ES
6, DTS-HDMA 5.1, DTS HD-HRA 5.1
ESD Protection
Human-body Model：
±8kV (Air-
gap discharge), ±4kV
(Contact discharge)
Connections
Input ports
1×HDMI Type A [19-pin female]
Output ports
1×HDMI Type A [19-pin female]
2×RCA Connectors [L & R]
1×Optical out [S/PDIF]
Mechanical
Housing
Metal Enclosure
Color
Black
Dimensions
73.5mm (2.9”) [W] × 60.7mm (2.4”)
[D] × 17mm (.67”) [H]
Weight
130g / 4.6 oz.
Power Supply
Input: AC100~240V 50/60Hz, Output:
DC5V/1A
(US/EU standards, CE/FCC/UL
certified)
Power Consumption
1W (max)
Operating
Temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage
Temperature
-20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity
20~90% RH (non-condensing)

6
5.Operation Controls and Functions
5.1 Input Side
❶❷❸❹❺
Number
Name
Function description
1
5.5mm
5VDC In
The 5VDC 1A power supply is connected
here
2
LED Power
Indicator
This green LED will illuminate when the
5VDC 1A power supply is powering the
the DAC1
3
Three
position
function
switch
TV: Audio EDID is copied from HDMI
connection (usually 5.1)
Bitstream:Audio EDID is on AVR copy
mode (use with Atmos/DTS-X)
2CH: All Audio is set to stereo
4
HDMI
Input
The HDMI source you wish to extract
audio from connects here
5
Link LED
The Link Indicator shows that there is a
HDMI signal connected

7
5.2 Rear Panel
❶❷❸
Number
Name
Function description
1
HDMI
OUTPUT
Connect to HDMI display device such as
TV or monitor
2
OPTICAL
OUT
Optical audio output
3
L/R OUT
RCA analog audio output
6. Application Example

8
7. Function Explanation
When the audio selection switch is in the “TV” position
the audio EDID copies how the display is set (5.1 or
stereo, usually). The RCA’s will output stereo and the
optical will output multichannel and stereo (within its
capabilities listed in the specs). When it is set to
“Bitstream” the audio EDID is set to the abilities of the
AVR and the optical output will be limited to only
formats supported by the optical output. The HDMI
of course will support all HD audio formats. When
the switch is set to “2CH” all outputs are now in stereo
mode. The RCA outputs are live with stereo in all
settings as the DAC1 will convert the other formats to
stereo.

9
